Remotely

1
Remotely Controlled Weapon Stations
2
FEWAS - Remote Controlled Weapon Stations Family
FEWAS 300
30mm
FEWAS 80
3
FEWAS - main advantages

• New world for the mechanized forces
  observation, accuracy, ranges of interest,
  networking
• Lightweight
• Enhanced gunner protection( working under armor)
• Modular, versatile, easy installation
• Interfaces with every C² system and BMS
• Occupy very small space in the vehicle
• Eye contact between gunner and vehicle crew
• Good ergonomics
• Weapon systems cover ranges from 0 to 4500m
• High accuracy for al types of weapons against
  various of targets

4
FEWAS 120 RCWS
M240 MG (7.62mm)
MK19 AGL (40mm)
M2 MG (0.5)
5
FEWAS 120 RCWS - A state-of-the-art Remote
Controlled Weapon Station for crew protection and
target engagement. The FEWAS 120 RCWS is suitable
for any light combat platform such as
wheeled/tracked vehicles and fast attack
craft/patrol boats. The FEWAS 120 RCWS is
suitable for integration onto a variety of
existing or new fighting vehicles. It provides
enhanced accuracy, under-armor operation and
flexibility of location at any hatch.
6
FEWAS 120 - Main Features

• Complete remote operation
• Day/night operation
• Closed hatch and head-out operation capability
• Electric drives and firing
• Manual emergency mode of operation
• Safety firing inhibit system
• Built-in test
• Variety of weapons
• Low silhouette
• Stabilization (optional)

7
FEWAS 120 With 0.5 Heavy MG
8
FEWAS 120 With 40mm Mk-19
9
FEWAS 120 with M2 HMG
10
FEWAS 120 With 7.62 GPMGOver Deck
11
FEWAS 120 With 12.7 HMG - Over Deck
12
FEWAS 120 With 12.7 HMG - Below Deck
13
FEWAS 120 With 7.62 GPMG
ABOVE DECK
BELOW DECK
14
FEWAS 120 Mounted on Static PostsBorder
Installation
15
FEWAS 120- Main Advantages

• Lightweight
• Improved gunner protection
• No toxic gas hazard
• Good ergonomics and habitability
• External ejection of spent cartridges and links
• Low weapon depression angles
• Firing while the vehicle is under cover
• Eye contact between the gunner and the vehicle
  crew
• Easy installation
• Remote control enables operational and technical
  flexibility
• Manual backup operation

16
FEWAS 120 - Technical Data

• Armament (interchangeable by the crew)
• 7.62mm GPMG
• or 12.7mm HMG
• or 40mm AGL
• and others
• Crew
• One (option dual control posts)

17
FEWAS 120- Technical Data

• Ammunition
• 7.62 mm GPMG 230 rounds ready for use
• NATO Std. ammunition box
• (option 460 rounds ammunition box, 690
  rounds)
• 12.7 mm HMG 100 rounds ready for use
• (option up to 200, up to 400)
• 40 mm AGL 32 rounds ready for use
• (option up to 48)

18
FEWAS 120- Technical Data

• Control
• Traverse
• Electrically controlled nx360 deg.
• High speed 1.0 rad/sec
• Low speed 0.5 mrad/sec
• Elevation
• Electrically controlled,
• Elevation range -20 deg. to 60 deg.
• High speed 1.0 rad/sec
• Low speed 0.5 mrad/sec
• Manual backup operation

19
FEWAS 120- Technical Data

• Optics
• Day sight Charged Coupled Device (CCD) camera
• Night sight Thermal uncooled microbolometer
  camera
• (option LLLTV Camera)
• Other sensor are available on customer request
• Display LCD monitor
• Weight
• Over deck assembly 105-160 kg (w/o weapon and
  ammunition)
• In hull assembly 20 kg

20
FEWAS 120- Technical Data

• Height Above Deck
• 540/620 mm.
• Power supply
• 24 VDC
• Options
• Stabilization
• Fire control (LRF etc.)
• Remote charging
• Slave mode
• Long range observation
• Ammo counter
• Integration of Spike missile

21
RCWS Main Characteristics (cont.)

• STABILIZATION
• The RCWS is stabilized in traverse and
• elevation.
• Stabilization error for typical cross-country
  travel Elevation lt 1.0 mrad (1 sigma),
  Traverse lt 0.7 mrad (1 sigma).

22
Day Sight Main Characteristics

• Color CCD
• Zoom 1/10, focal length 8 96 mm
• FOVs 3 (H) X 2.2 (V) to 33 X 25
• Typical PerformanceDetection range of 2.3 X 2.3
  m target _at_ FOV 30 is 5.0 KmRecognition range of
  2.3 X 2.3 m target _at_ FOV 30 is 2.5 Km
• The sight shall endure gun fire shock
• The sight shall endure armored personnel carrier
  transportation shock and Vibration

23
Night Sight Main Characteristics

• Uncooled/Cooled FLIR
• Wave length 8-12 microns
• Focal length of lens 150 mm, F 1
• Single FOV 5.6 (H) X 4.2 (V) (option for dual
  FOVs)
• Typical PerformanceDetection range of 2.3 X 2.3
  m target is 3.0 KmRecognition range of 2.3 X
  2.3 m target is 1.2 Km
• No. of pixels 320 x 240

24
RCWS Main Characteristics (Cont.)

• AUTO TRACKER
• Developed especially for weapon station
  (reliability and maintainability).
• Tracking of highly maneuvering platforms.
• Specifically fitted for cross country terrain
  conditions.
• Operational integrity under blurry and poor
  lighting
• conditions.
• Capabilities for re-locking on the target
  (future target trajectory) in case of temporary
  target loss.
• Does not loose target acquisition during firing.

25
RCWS Main Characteristics (Cont.)

• HIT PROBABILITY WITH M2 HMG (ACCURACY)
• For target size of 0.5X1.1 meters at a range
  of 500 m,
• the probability of hitting with at least 1
  round in 3
• bursts of 3 rounds is greater than 75.
• Static pointing accuracy lt 0.25 mrad
• Dynamic pointing accuracy lt 3 mrad
• KANT ANGLES COMPENSATIONFor 12.7 and 7.62
  full compensation (the maximal weapon range)For
  AGL 40 mm at 30 the maximal range 1300 m.

26
FEWAS 120 Main Characteristics (cont.)

• WEIGHT
• Over Deck 160 Kg (Excluding Weapon And Ammo.)
• Under Deck 20 Kg
• HIGHT ABOVE DECK 615 mm (without chute)
• POWER SUPPLY 28 VDC per MIL-STD-1275
• DISPLAY 11-12.1 LCD Monitor
• COMPATIBILITY WITH PIRANHA IIIC, M113 ,Eagle
  III/4 and
• others

27
RCWS - Options

• Laser Range Finder
• Ballistic Protection
• Smoke Grenade Launcher
• Embedded Trainer
• Foldable mechanism for Stryker installation ,
  C-130 orA-400 transportable
• Cooled thermal imaging sight or other required
  sight
• Integration of Multi-Purpose Guided Missile
• Slaving to an external target designation
• Stabilization of video image
• Duplicating the control post for the commander
  (all or part)
• Laser Warning System

28
FEWAS 120 With 12.7 HMG - Polish Configuration -
HMMWV
29
FEWAS 120 7.62 or 12.7 - Panther - UK
30
FEWAS 120 12.7 - VAB - French Army
31
FEWAS 120 12.7 Installed on the EAGLE III
Live Fire Test Exhibition in Romania
32
FEWAS 120 12.7 Installed on the EAGLE IV
IDEB Exhibition in Slovakia May 2006
33
FEWAS 120 12.7 Installed on the EAGLE IV
MSPO Exhibition in Poland August 2006
34
FEWAS 120 12.7 Installed on the ALIGATOR
IDEB Exhibition in Slovakia May 2006
35
FEWAS 120 12.7 Installed on the PANDUR
Live Fire Test in Austria
36
FEWAS 120 12.7 PATRIA AMV
Live Fire Test in Poland
37
FEWAS 120 Installed on Flyer
38
PC Controlled Embedded Trainer
