Advanced topics on Mapreduce with Hadoop

1
Advanced topics on Mapreduce with Hadoop

• Jiaheng Lu
• Department of Computer Science
• Renmin University of China
• www.jiahenglu.net

2
Outline

• Brief Review
• Chaining MapReduce Jobs
• Join in MapReduce
• Bloom Filter

3
Brief Review

• A parallel programming framework
• Divide and merge

Input data
Mappers
Shuffle
Reducers
Output data
split0
Map task
Reduce task
output0
split1
Map task
Reduce task
output1
split2
Map task
4
Chaining MapReduce jobs

• Chaining in a sequence
• Chaining with complex dependency
• Chaining preprocessing and postprocessing steps

5
Chaining in a sequence

• Simple and straightforward
• MAP REDUCE MAP REDUCE MAP
• Output of last is the input to the next
• Similar to pipes

6

• Configuration conf getConf()
• JobConf job new JobConf(conf)
• job.setJobName("ChainJob")
• job.setInputFormat(TextInputFormat.class)
• job.setOutputFormat(TextOutputFormat.class)
• FileInputFormat.setInputPaths(job, in)
• FileOutputFormat.setOutputPath(job, out)
• JobConf map1Conf new JobConf(false)
• ChainMapper.addMapper(job, Map1.class,
  LongWritable.class, Text.class, Text.class,
  Text.class, true, map1Conf)

7
Chaining with complex dependency

• Jobs are not chained in a linear fashion
• Use addDependingJob() method to add dependency
  information

x.addDependingJob(y)
8
Chaining preprocessing and postprocessing steps

• Example remove stop word in IR
• Approaches
• Separate inefficient
• Chaining those steps into a single job
• Use ChainMapper.addMapper() and
  ChainReducer.setReducer

Map Reduce Map
9
Join in MapReduce

• Reduce-side join
• Broadcast join
• Map-side filtering and Reduce-side join
• A given key
• A range from dataset(broadcast)
• a Bloom filter

10
Reduce-side join

• Map
• output ltkey, valuegt
• keygtgtjoin key, valuegtgttagged with data source
• Reduce
• do a full cross-product of values
• output the combination results

11
Example
table x
key
value
key
valuelist
a b
1 ab
1 cd
4 ef
output
x ab
x cd
y b
1
x ab
x cd
shuffle()
map()
1
1
a b c
1 ab b
1 cd b
4 ef c
4
x ef
reduce()
join key
table y
key
value
2
y d
tag
a c
1 b
2 d
4 c
1
y b
x ef
y c
map()
4
2
y d
4
y c
12
Broadcast join (replicated join)

• Broadcast the smaller table
• Do join in Map()
• Using distributed cache
• DistributedCache.addCacheFile()

13
Map-side filtering and Reduce-side join

• Join key student IDs from info
• generate IDs file from info
• broadcast
• join
• What if the IDs file cant be stored in memory?
• a Bloom Filter

14
A Bloom Filter

• Introduction
• Implementation of bloom filter
• Use in MapReduce join

15
Introduction to Bloom Filter

• space-efficient data structure, constant size,
  test elements, add(), contains()
• no false negatives and a small probability of
  false positives

16
Implementation of bloom filter

• Apply a bit array
• Add elements
• generate k indexes
• set the k bits to 1
• Test elements
• generate k indexes
• all k bits are 1 gtgt true, not all are 1 gtgt false

17
Example
false positives

v
add x(0,2,6)
add y(0,3,9)
contain m(1,3,9)
contain n(0,2,9)
initial state
0
0
0
0
0
0
0
0
0
0
0
1
2
3
4
5
6
7
8
9
1
0
1
0
0
0
1
0
0
0
0
1
2
3
4
5
6
7
8
9
1
0
1
1
0
0
1
0
0
1
0
1
2
3
4
5
6
7
8
9
1
0
1
1
0
0
1
0
0
1
0
1
2
3
4
5
6
7
8
9
1
0
1
1
0
0
1
0
0
1
0
1
2
3
4
5
6
7
8
9
?
?
?
?
?
18
Use in MapReduce join

• A separate subjob to create a Bloom Filter
• Broadcast the Bloom Filter and use in Map() of
  join job
• drop the useless record, and do join in reduce

19
References

• Chunk Lam, Hadoop in action
• Jairam Chandar, Join Algorithms using Map/Reduce

20
