Protein Structure Prediction

1
Protein Structure Prediction

• Xiaole Shirley Liu
• And
• Jun Liu
• STAT115

2
Protein Structure Prediction Ram
Samudrala University of Washington
3
Outline

• Motivations and introduction
• Protein 2nd structure prediction
• Protein 3D structure prediction
• CASP
• Homology modeling
• Fold recognition
• ab initio prediction
• Manual vs automation
• Structural genomics

4
Protein Structure

• Sequence determines structure, structure
  determines function
• Most proteins can fold by itself very quickly
• Folded structure lowest energy state

5
Protein Structure

• Main forces for considerations
• Steric complementarity
• Secondary structure preferences (satisfy H bonds)
• Hydrophobic/polar patterning
• Electrostatics

6
Rationale for understanding protein structure and
function
Protein sequence -large numbers of sequences,
including whole genomes
?
Protein function - rational drug design and
treatment of disease - protein and genetic
engineering - build networks to model cellular
pathways - study organismal function and evolution
7
Protein Databases

• SwissProt protein knowledgebase
• PDB Protein Data Bank, 3D structure

8
View Protein Structure

• Free interactive viewers
• Download 3D coordinate file from PDB
• Quick and dirty
• VRML
• Rasmol
• Chime
• More powerful
• Swiss-PdbViewer

9
Compare Protein Structures

• Structure is more conserved than sequence
• Why compare?
• Detect evolutionary relationships
• Identify recurring structural motifs
• Predicting function based on structure
• Assess predicted structures
• Protein structure comparison and classification
• Manual SCOP
• Automated DALI

10
Compare protein structures

• Need ways to determine if two protein structures
  are related and to compare predicted
• models to experimental structures
• Commonly used measure is the root mean square
  deviation (RMSD) of the Cartesian
• atoms between two structures after optimal
  superposition (McLachlan, 1979)
•
• Usually use Ca atoms
•

• Other measures include contact maps and torsion
  angle RMSDs

11
SCOP

• Compare protein
• structure, identify
• recurring structural
• motifs, predict function
• A. Murzin et al, 1995
• Manual classification
• A few folds are highly
• populated
• 5 folds contain 20 of all homologous
  superfamilies
• Some folds are multifunctional

12
Determine Protein Structure

• X-ray crystallography (gold standard)
• Grow crystals, rate limiting, relies on the
  repeating structure of a crystalline lattice
• Collect a diffraction pattern
• Map to real space electron density, build and
  refine structural model
• Painstaking and time consuming

13
Protein Structure Prediction

• Since AA sequence determines structure, can we
  predict protein structure from its AA sequence?
• predicting the three angles, unlimited DoF!
• Physical properties that determine fold
• Rigidity of the protein backbone
• Interactions among amino acids, including
• Electrostatic interactions
• van der Waals forces
• Volume constraints
• Hydrogen, disulfide bonds
• Interactions of amino acids with water

14
Protein folding landscape Large
multi-dimensional space of changing conformations
free energy
folding reaction
15
Protein primary structure
16
2nd Structure Prediction

• ? helix, ? sheet, turn/loop

17
2nd Structure Prediction

• Chou-Fasman 1974
• Base on 15 proteins (2473 AAs) of known
  conformation, determine P?, P? from
• ? 0.5-1.5
• Empirical rules for 2nd struct nucleation
• 4 H? or h? out of 6 AA, extends to both dir, P? gt
  1.03, P? gt P?, no ? breakers
• 3 H? or h? out of 5 AA, extends to both dir, P? gt
  1.05, P? gt P?, no ? breakers
• Have 50-60 accuracy

18
P? and P?
19
2nd Structure Prediction

• Garnier, Osguthorpe, Robson, 1978
• Assumption each AA influenced by flanking
  positions
• GOR scoring tables (problem limited dataset)
• Add scores, assign 2nd with highest score

20
2nd Structure Prediction

• D. Eisenberg, 1986
• Plot hydrophobicity as function of sequence
  position, look for periodic repeats
• Period 3-4 AA, ? (3.6 aa / turn)
• Period 2 AA, ? sheet
• Best overall JPRED by Geoffrey Barton, use many
  different approaches, get consensus
• Overall accuracy 72.9

21
3D Protein Structure Prediction

• CASP contest Critical Assessment of Structure
  Prediction
• Biannual meeting since 1994 at Asilomar, CA
• Experimentalists before CASP, submit sequence of
  to-be-solved structure to central repository
• Predictors download sequence and minimal
  information, make predictions in three categories
• Assessors automatic programs and experts to
  evaluate predictions quality

22
CASP Category I

• Homology Modeling (sequences with high homology
  to sequences of known structure)
• Given a sequence with homology gt 25-30 with
  known structure in PDB, use known structure as
  starting point to create a model of the 3D
  structure of the sequence
• Takes advantage of knowledge of a closely related
  protein. Use sequence alignment techniques to
  establish correspondences between known
  template and unknown.

23
CASP Category II

• Fold recognition (sequences with no sequence
  identity (lt 30) to sequences of known structure

• Given the sequence, and a set of folds observed
  in PDB, see if any of the sequences could adopt
  one of the known folds
• Takes advantage of knowledge of existing
  structures, and principles by which they are
  stabilized (favorable interactions)

24
CASP Category III

• Ab initio prediction (no known homology with any
  sequence of known structure)
• Given only the sequence, predict the 3D structure
  from first principles, based on energetic or
  statistical principles
• Secondary structure prediction and multiple
  alignment techniques used to predict features of
  these molecules. Then, some method necessary for
  assembling 3D structure.

25
Structure Prediction Evaluation

• Hydrophobic core similar?
• 2nd struct identified?
• Energy minimized? H-bond contacts?
• Compare with solved crystal structure gold
  standard

26
Comparative modelling of protein structure
refine
27
Homology Modeling Results

• When sequence homology is gt 70, high resolution
  models are possible (lt 3 Å RMSD)
• MODELLER (Sali et al)
• Find homologous proteins with known structure and
  align
• Collect distance distributions between atoms in
  known protein structures
• Use these distributions to compute positions for
  equivalent atoms in alignment
• Refine using energetics

28
Homology Modeling Results

• Many places can go wrong
• Bad template - it doesnt have the same structure
  as the target after all
• Bad alignment (a very common problem)
• Good alignment to good template still gives wrong
  local structure
• Bad loop construction
• Bad side chain positioning

29
Homology Modeling Results

• Use of sensitive multiple alignment (e.g.
  PSI-BLAST) techniques helped get best alignments
• Sophisticated energy minimization techniques do
  not dramatically improve upon initial guess

30
Fold Recognition Results

• Also called protein threading
• Given new sequence and library of known folds,
  find best alignment of sequence to each fold,
  returned the most favorable one

31
Fold Recognition with Dynamic Programming

• Environmental class for each AA based on known
  folds (buried status, polarity, 2nd struct)

32
Protein Folding with Dynamic Programming

• D. Eisenburg 1994
• Align sequence to each fold (a string of
  environmental classes)
• Advantages fast and works pretty well
• Disadvantages do not consider AA contacts

33
Fold Recognition Results

• Each predictor can submit N top hits
• Every predictor does well on something
• Common folds (more examples) are easier to
  recognize
• Fold recognition was the surprise performer at
  CASP1. Incremental progress at CASP2, CASP3,
  CASP4

34
Fold Recognition Results

• Alignment (seq to fold) is a big problem

35
ab initio

• Predict interresidue contacts and then compute
  structure (mild success)
• Simplified energy term reduced search space
  (phi/psi or lattice) (moderate success)
• Creative ways to memorize sequence ?? structure
  correlations in short segments from the PDB, and
  use these to model new structures ROSETTA

36
Ab initio prediction of protein structure
sample conformational space such that native-like
conformations are found
hard to design functions that are not fooled by
non-native conformations (decoys)
astronomically large number of conformations 5
states/100 residues 5100 1070
37
Sampling conformational space continuous
approaches

• Most work in the field
• Molecular dynamics
• Continuous energy minimization (follow a valley)
• Monte Carlo simulation
• Genetic Algorithms

• Like real polypeptide folding process
• Cannot be sure if native-like conformations are
  sampled

38
Molecular dynamics

• Force -dU/dx (slope of potential U)
  acceleration, force m a(t)
• All atoms are moving so forces between atoms are
  complicated functions of time
• Analytical solution for x(t) and v(t) is
  impossible numerical solution is trivial
• Atoms move for very short times of 10-15 seconds
  or 0.001 picoseconds (ps)
• x(tDt) x(t) v(t)Dt 4a(t) a(t-Dt)
  Dt2/6
• v(tDt) v(t) 2a(tDt)5a(t)-a(t-Dt) Dt/6
• Ukinetic ½ S mivi(t)2 ½ n KBT
• Total energy (Upotential Ukinetic) must not
  change with time

acceleration
old velocity
old position
new position
new velocity
n is number of coordinates (not atoms)
39
Energy minimization

• For a given protein, the energy depends on
  thousands of x,y,z Cartesian atomic coordinates
  reaching a deep minimum is not trivial
• Furthermore, we want to minimize the free energy,
  not just the potential energy.

40
Monte Carlo Simulation

• Propose moves in torsion or Cartesian
  conformation space
• Evaluate energy after every move, compute ?E
• Accept the new conformation based on
• If run infinite time, the simulated conformation
  follows the Boltzmann distribution
• Many variations, including simulated annealing
  and other heuristic approaches.

41
Scoring/energy functions

• Need a way to select native-like conformations
  from non-native ones
• Physics-based functions electrostatics, van der
  Waals, solvation, bond/angle terms.
• Knowledge-based scoring functions
• Derive information about atomic properties from a
  database of experimentally determined
  conformations
• Common parameters include pairwise atomic
  distances and amino acid burial/exposure.

42
Rosetta

• D. Baker, U. Wash
• Break sequence into short segments (7-9 AA)
• Sample 3D from library of known segment
  structures, parallel computation
• Use simulated annealing (metropolis-type
  algorithm) for global optimization
• Propose a change, if better energy, take
  otherwise take at smaller probability
• Create 1000 structures, cluster and choose one
  representative from each cluster to submit

43
Manual Improvements and Automation

• Very often manual examination could improve
  prediction
• Catch errors
• Need domain knowledge
• A. Murzins success at CASP2
• CAFASP Critical Assessment of Fully Automated
  Structure Prediction
• Murzin Cant play!!
• MetaServers combine different methods to get
  consensus

44
CAFASP Evaluation
45
Structural Genomics

• With more and more solved structures and novel
  folds, computational protein structure prediction
  is going to improve
• Structural genomics
• Worldwide initiative to high throughput determine
  many protein structures
• Especially, solve structures that have no homology

46
Summary

• Protein structures 1st, 2nd, 3rd, 4th
• Different DB SwissProt, PDB and SCOP
• Determine structure X-ray crystallography
• Protein structure prediction
• 2nd structure prediction
• Homology modeling
• Fold recognition
• Ab initio
• Evaluation energy, RMSD, etc
• CASP and CAFASP contest
• Manual improvement and combination of
  computational approaches work better
• Structural Genomics, still very difficult problem

47
Acknowledgement

• Amy Keating
• Michael Yaffe
• Mark Craven
• Russ Altman
