Programming I/O for Embedded System

1
Programming I/O for Embedded System
2
Overview

• Basis A DE2 Computer Architecture
• Parallel I/O
• 7-Segment Display Basic
• Manipulating 7-Segment Display on DE2
• Interrupt and Interruption handling
• DE2 Internal Timer Basic
• Manipulating Internal Timer

3
Basis A DE2 Computer Architecture

• A SOPC system on DE2 Board
• Created by Quartus II
• With a full featured I/O and memory devices
  integrated

4
System components

• NIOS II Processor with on-chip memory
• SDRAM
• Flash Memory
• Internal Timer
• Parallel output ports to 8 green leds and 16 red
  leds
• Parallel output ports to 8 on-board 7-segment
  leds
• On-board LCD output
• Parallel input ports to 16 switches
• Parallel input ports to 4 push-buttons
• JTAG-UART connection to host machine

5
Basis A DE2 Computer Architecture

• CPU 32 bits word width, 50 MHz
• On-Chip SRAM 32 bits, 4KB
• On-board SDRAM 16bits, 8MB
• On-board Flash Memory 16 bits, 4MB
• Internal Timer period 1ms
• 3 Parallel I/O ports to LEDs and Switches 8 bits
• 8 Parallel I/O ports to 7-segment LED 8 bits
• On-board LCD Optrex 16207
• JTG UART Serial Communication 64 bits FIFO buffer

6
Interrupt request (IRQ)

• Input device generated interrupts
• push buttons IRQ 2
• JTAG_UART IRQ 0
• Internal Timer IRQ 1
• Interrupts provide an asynchronous way for
  data transmission between I/O devices and CPU

7
Address Map

• Check sopc configuration for detailed Address map

8
Using HAL for embedded software development

• HAL Hardware Abstraction Layer
• A programming interface for embedded system
  development, provide user a hardware-irrevelant
  programming platform
• Parallel I/O Communication
• Device Driver
• Interrupt and DMA control
• Video/Audio signal processing
• Ethernet/Internet access

9
Using HAL

• HAL require a bunch of header files be included
  in user C source file, different HAL module
  require different header files
• system.h includes the basic configuration of
  SOPC, Processor parameters, address and data
  bus width, I/O Address Map, should be included if
  HAL is used.

10
Parallel I/O

• Parallel I/O is directly connected to processor
  pins, NIOS parallel I/O is addressed in 8-bit,
  and made up by 5 basic port registers
• Data Register
• Direction Register
• Interruptmask Register
• Edge Capture Register
• Outset Register
• Outclear Register

11
Parallel I/O Port
12
Access to Parallel I/O port in NIOS

• HAL integrated a group of macros and functions
  for I/O port access
• Header file requested
• include system.h
• include "altera_avalon_pio_regs.h

13
Access to Parallel I/O port in NIOS

• IORD_ALTERA_AVALON_PIO_DATA(base)
• IOWR_ALTERA_AVALON_PIO_DATA(base,data)
• // Read and write to I/O Port
• IORD_ALTERA_AVALON_PIO_DIRECTION(base)
• IOWR_ALTERA_AVALON_PIO_DIRECTION(base,data)
• // Set/Get port direction
• IORD_ALTERA_AVALON_PIO_IRQ_MASK(base)
• IOWR_ALTERA_AVALON_PIO_IRQ_MASK(base, data)
• // Set/Get interrupt mask

14
Difference between direct assignment and using
HAL Macro

• We have already seen such code before
• define PIO_ADDR 0x00000010
• .
• ((char )PIO_ADDR)(char) 0xff
• Equivalent code using HAL Macro will be
• define PIO_ADDR 0x00000010
• IOWR_ALTERA_AVALON_PIO_DATA(PIO_ADDR,0xff)
• Difference? HAL provides a safety way for data
  transmission, user doesnt need to be involved
  into complicated type cast and data alignment.

15
Constants definition in system.h

• The constants in SOPC system s.t. I/O port and
  register file address, are defined in system.h.
• For example, user have a 8-bit PIO port named
  switch_0_7 build in SOPC
• The corresponding definition will be added to
  system.h
• define SWITCH_0_7_BASE 0x1803020

16
7-segment Display

• Can display hex numbers (0-9,A-F)
• Widely used in digital clock, temperature
  controller,etc

17
7-segment Display
18
How board segment display works

• Segment display on DE2 board is implemented as
  common-cathode

0x01803080
bit 7 6 5 4 3 2 1 0
X 0 1 1 0 0 0 0
19
Connecting segment display to processor

• the 7 pins of segment display can be connected to
  parallel I/O port and use parallel I/O operation
  to control the display on LED.

20
C Code Example of Segment Display

• include system.h
• include "altera_avalon_pio_regs.h
• // define SEG_LED_0_ADDR 0x01803080
• // Or use the definition in system.h, which is
  SEG_LED_0_BASE
• main()
• IOWR_ALTERA_AVALON_PIO_DATA(SEG_LED_0_B
  ASE,0x30)
• //turn segment e and f off

21
Push button

• Push button is similar to switch, the difference
  is it need to be hold pressed down to keep the
  value on the parallel I/O port.
• The way to read push button input is the same to
  switch

22
Interrupt handling and using internal timer

• Two way for processor to accept external input
• Waiting for input
• Processor will be halting and listening to the
  input port until data is transmitted
• while(data is not updated)
• read data from address of some I/O
  port

23
Interrupt handling and using internal timer

• Interrupt
• Data arrival will start an interrupt request to
  processor, when a interrupt is generated,
  processor will stop its current work and turn to
  interrupt service function (data receive), and
  resume work after interrupt is handled.
• interrupt_func()
• transmit data from I/O port to processor
• Main()
• setup interrupt handling function

24
Interrupt Request

• interrupt request" (or IRQ) is used to refer to
  either the act of interrupting the bus lines used
  to signal an interrupt, or the interrupt input
  lines on a Programmable Interrupt Controller
• Generated when an I/O event occurs, handled by
  interrupt controller
• Interrupts from different sources are
  differentiated by IRQ line number

25
IRQ setting in DE2 Computer
Device IRQ
JTAG_UART 0
Internal Timer 1
Push Button 2
26
Interrupt handler function

• NIOS Processer keeps a special address in memory
  ad the entry point for interrupt handler function
• Exception Vector stores the address of interrupt
  handler function, when an IRQ is received by
  processor, it will save the instruction context
  and jump to interrupt handler function.

27
How to use interrupt handler

• Enable corresponding IRQ line to processor in
  SOPC builder
• Set I/O devices to enable external interrupt
  generation
• Enable the interruptmask register of
  Parallel I/O
• The ITO bit in internal timer control
  register
• Write interrupt handler function
• Register interrupt handler function

28
Code sample for interrupt handler setup

• Include files
• include "system.h"
• include "alt_types.h"
• include "sys/alt_irq.h"
• include "sys/alt_sys_init.h"

29
Pseudo-Code sample for interrupt handler setup

• void interrupt_handler()
• main()
• enable system irq
• register handler of irqX as
  interrupt_handler

30
Internal Timer

• NIOS Internal Timer
• Works as a stop watch, period register and
  control signals are set by user by programming,
  once started, counter will count down from the
  value in period register to 0 and generate an
  interrupt when time is over.

31
Top-level timer diagram
32
Timer configuration
33
Timer configuration
Configured in SOPC Builder
34
Register File for Internal Timer
35
Register File for Internal Timer
36
Register File for Internal Timer
37
How to use internal timer in programming

• Internal timer will loopingly count down from
  value in period register to 0, when counter
  reaches 0, an interrupt on IRQ 1 will generated,
  user need to write IRS function for IRQ 1 to
  capture timer events
• In DE2 Computer, the period of timer is 1 ms,
  means the interrupt will occur 1000 per second

38
How to use internal timer in programming

• include "system.h"
• include "alt_types.h"
• include "altera_avalon_timer_regs.h"
• include "altera_avalon_timer.h"
• include "sys/alt_irq.h"
• include "sys/alt_sys_init.h"

39
Macros for timer register file access

• IORD_ALTERA_AVALON_TIMER_STATUS(base)
• IOWR_ALTERA_AVALON_TIMER_STATUS(base, data)
• // Read/write to 16 bits status register
• IORD_ALTERA_AVALON_TIMER_CONTROL(base)
• IOWR_ALTERA_AVALON_TIMER_CONTROL(base, data)
• // Read/write to 16 bits control register
• IORD_ALTERA_AVALON_TIMER_PERIODL(base)
• IOWR_ALTERA_AVALON_TIMER_PERIODL(base, data)
• // Read/write to lower 16 bits of period register
• IORD_ALTERA_AVALON_TIMER_PERIODH(base)
• IOWR_ALTERA_AVALON_TIMER_PERIODH(base, data)
• // Read/write to higher 16 bits of period register

40
How to use internal timer in programming

• Write user IRS function
• static void Timer_Interrupts(void
  context,alt_u32 id)
• if(Timer_counter gt 1000) / 1S /
• Timer_counter 0 //global
  variable to store reached counter event
• ltUSER CODE HEREgt
• else
• Timer_counter
• IOWR_ALTERA_AVALON_TIMER_STATUS(TIMER_BASE
  , 0x00)//clear status register

41
How to use internal timer in programming

• Register IRS
• alt_irq_register(TIMER_IRQ,NULL,Timer_Interrupts)

• //Register IRS
• IOWR_ALTERA_AVALON_TIMER_CONTROL(TIMER_BASE,
  0x07)
• //Start timer

42
How to capture Timer event in user program

• Keep a global variable for storing information
  from timer events, in main function, check the
  global variable to update timer events
• static int timer_event
• interrupt_handler()
• . //set timer_event
• main()
• register IRS function
• while(timer_event updated)
• user actions

43
Summary

• DE2 Computer
• A basic hardware configuration in Quartus for
  embedded system software design
• Parallel I/O
• Basic, register file structure and
  programming
• 7-Segment LED
• Driven by parallel I/O, programming and
  display
• Interrupt handling
• Basic concepts, and how to use in
  programming
• Internal Timer
• Basic, register file structure and
  programming
