Class and Method Modifiers

1
Class and Method Modifiers

• Roderick Rodriguez, Dianne Musciano, Sukumar
  Simhadri,
• George Blank

2
Modifiers

• Modifiers are Java keywords that extend or place
  limits on defined classes, fields, methods, and
  sub-classes.
• Imagine that we are creating a game and want to
  simulate a pair of dice. We might define a die
  class, shown graphically on the next slide.

3
Class Example Die

• A class has a name and can contain data
  declarations and/or method declarations

Die
Class Name
- faceValue integer roll() integer
Data declarations
Method declarations
4
Definitions for Die

• class a specification of all the data, and
  behavior for a single die.
• object a die class that has been instantiated
  in a running program
• field a data attribute or variable like
  faceValue used by the class
• method a specification of behavior like roll()
  used by the class

5
Object Class

• Object
• Abstracts away (data, algorithm) details
• Encapsulates data
• Instances exist at run time
• Class
• Blueprint for objects (of same type)
• Exists at compile time

6
How die works

• The values of the data define the state of an
  object created from the class
• The functionality of the methods define the
  behaviors of the object
• For our Die class, we might declare an integer
  that represents the current value showing on the
  face
• One of the methods would allow us to roll the
  die by setting its face value to a random number
  between one and six

7
Super and Sub Classes

• The extends clause specifies the super class
  of this class. The implements clause specifies
  the interfaces being implemented by this class.
  Member declarations can be declarations of
  fields, methods, and nested classes. The field,
  method, and nested class declarations can be
  intermixed. The order of declarations is
  immaterial to the compiler. Thus, they should be
  ordered in a way that is most logical and
  comprehensible.

8
Modifiers

• Modifiers in Java can define accessibility and
  can be applied to both classes and class members
  (sub-classes, fields and methods).
• Some of the modifier keywords are shared by both
  classes and methods.
• When using access modifiers only one can be used
  at a time.

9
Scope, Visibility, Accessibility

• Scope refers to the boundaries of programs and
  components of programs.
• Visibility refers to portions of the scope that
  can be known to a component of a program.
• Accessibility refers to portions of the scope
  that a component can interact with.

10
Scope

• Scope
• Part of program where a variable may be
  referenced
• Determined by location of variable declaration
• Boundary usually demarcated by
• Example
• public MyMethod1()
• int myVar myVar accessible in
• ... method between

11
Scope Example
Scope

• package edu.umd.cs
• public class MyClass1
• public void MyMethod1()
• ...
• public void MyMethod2()
• ...
• public class MyClass2

Method
Class
Package
Method
Class
12
Accessibility/Visibility Modifiers

• Modifiers can control visibility/accessibility.
• These modifiers are used to implement the
  object-oriented principles of abstraction and
  encapsulation.
• Visibility and Accessibility are normally used
  interchangeably, since visible components are
  normally accessible and accessible components are
  normally visible.

13
Other Modifiers

• In addition to scope, modifiers can refer to
  related concepts, such as limiting access to a
  thread in a multithreaded environment
  (synchronized) or indicating that a method or
  field belongs to the whole class instead of a
  single instance (static).

14
Modifier Examples

• public class MyApplet extends java.applet.Applet

• private boolean killJabberwork
• static final double weeks 9.5
• protected static final int MEANINGOFLIFE 42
• public static void main(String arguments

15
Class Modifiers

• Class modifiers include the following
• ltnonegt  - When no modifier is present, by default
  the class is accessible by all the classes within
  the same package.
• public - A public class is accessible by any
  class.
• abstract - An abstract class contains abstract
  methods.
• final - A final class may not be extended, that
  is, have subclasses.

16
Class Modifiers

• Syntax for class modifiers
• ClassModifier class ClassName
• Example
• public class Employee

17
Class Modifiers

• Important points for class modifiers
• A single Java file can only contain one class
  that is declared public.
• An abstract class cannot be instantiated.
• A static nested class does not have an implicit
  reference to the enclosing class.

18
Method Modifiers

• Method Modifiers include the following
• ltnonegt - When no modifier is present, by default
  the method is accessible by all the classes
  within the same package.
• public - A public method is accessible by any
  class.
• protected -A protected method is accessible by
  the class itself, all its subclasses.
• private - A private method is accessible only by
  the class itself.

19
Method Modifiers

• static - accesses only static fields.
• final - may not be overridden in subclasses.
• abstract - defers implementation to its
  subclasses.
• synchronized - atomic in a multithreaded
  environment
• native - compiled to machine code by Assembler, C
  or C.

20
Method Modifiers

• Syntax for method modifiers
• MethodModifers ReturnType MethodName
  (ParameterList)
• Example
• private void GetEmployee(int ID)

21
Method Modifiers

• Important points for method modifiers
• Abstract methods must be contained in an abstract
  class.
• Static methods cannot be overridden in a child
  class but they can be hidden.
• Methods may not be overridden to be more private.
  For example, a protected method can not be
  overridden by a default one. A default method
  can be overridden by a protected or public method.

22
Field (variable) Only Modifiers

• volatile may be modified by nonsynchronized
  methods in a multithread environment
• transient not part of the persistent state of
  instantiated objects

23
Visibility Modifier

• Properties
• Controls access to class members
• Applied to instance variables methods
• Four types of access in Java
• Public Most visible
• Protected
• Package
• Default if no modifier specified
• Private Least visible

24
Visibility Modifier Where Visible

• public
• Referenced anywhere (i.e., outside package)
• protected
• Referenced within package, or by subclasses
  outside package
• None specified (package)
• Referenced only within package
• private
• Referenced only within class definition
• Applicable to class fields methods

25
Member Visibility Modifiers

• Members of a class that are declared with public
  visibility can be referenced anywhere
• Members of a class that are declared with private
  visibility can be referenced only within that
  class
• Members declared without a visibility modifier
  have default visibility and can be referenced by
  any class in the same package

26
Field Visibility Modifiers

• For instance variables
• Should usually be private to enforce
  encapsulation
• Sometimes may be protected for subclass access

27
Field Visibility Modifiers

• Public variables violate the spirit of
  encapsulation because they allow the client to
  reach in and modify the objects internal
  values directly
• Therefore, instance variables should not be
  declared with public visibility
• It is acceptable to give a constant public
  visibility, which allows it to be used outside of
  the class
• Public constants do not violate encapsulation
  because, although the client can access it, its
  value cannot be changed

28
Method Visibility Modifiers

• For methods
• Public methods provide services to clients
• Private methods provide support other methods
• Protected methods provide support for subclass

29
Method Visibility Modifiers

• Methods that provide the object's services are
  declared with public visibility so that they can
  be invoked by clients
• Public methods are also called service methods
• A method created simply to assist a service
  method is called a support method
• Since a support method is not intended to be
  called by a client, it should be declared with
  private - not with public visibility

30
Modifier - Private

• Private methods and variables are particularly
  useful in two circumstances
• When other classes have no reason to use that
  variable or method
• When another class could wreak havoc by changing
  a variable in an inappropriate way

31
Visibility Modifiers - Summary
Enforce encapsulation
Violate encapsulation
Support other methods in the class
Provide services to clients
32
Static Methods

• Methods declared with static modifier
• Can be defined in any class
• Not associated with an object
• Is not invoked by sending it as a message to an
  object
• The class method foo in the class C is invoked
  using the notation foo.C( )
• It has no receiver and cannot refer to instance
  variables
• It can refer to and manipulate class variables

33
Modifier Static

• Static variable
• Single copy for class
• Shared among all objects of class
• Static method
• Can be invoked through class name
• Does not need to be invoked through object
• Can be used even if no objects of class exist
• Can not reference instance variables

34
Modifier Final

• Final variable
• Value can not be changed
• Must be initialized in every constructor
• Attempts to modify final are caught at compile
  time
• Final static variable
• Used for constants
• Example
• final static int Increment 5

35
Modifier Final

• Final method
• Method can not be overloaded by subclass
• Private methods are implicitly final
• Final class
• Class can not be a superclass (extended)
• Methods in final class are implicitly final

36
Modifier Final

• Final classes
• Prevent inheritance / polymorphism
• May be useful for
• Security
• Object oriented design
• Example class String is final
• Programs can depend on properties specified in
  Java library API
• Prevents subclass from bypassing security
  restrictions

37
Modifier Abstract

• Description
• Represents generic concept
• Can not be instantiated
• Abstract class
• Placeholder in class hierarchy
• Can be partial description of class
• Can contain non-abstract methods
• Required if any method in class is abstract

38
All possible combinations of Features and
Modifiers
Modifier Class Variable Method Constructor
Free-Floating Block Public y y
y y
n Protected n y y
y n Default y y
y y
y Private n y y
y n Final y
y y n
n Abstract y n y
n n Static n
y y n
y
39
All possible combinations of Features and
Modifiers
Modifier Class Variable Method Constructor
Free-Floating Block Native n n
y n
n Transient n y n
n n Volatile n y
n n
n Synchro- n n y
n y nized
40
A variation of Murphys Law

• One of the statements of Murphys law, as applied
  to programming, is
• All variables are constant, and
• All constants are variable
• The final key word is concerned with
  immutability. This final section of the lecture
  is based on a Wikipedia discussion of
  immutability.

41
Introduction to Immutability

• Immutable means not changeable
• All Java variables are by default mutable. You
  can make them immutable by using the final
  keyword.
• The wrapper classes, Byte, Character, Short,
  Integer, Long, Float and Double are all
  immutable.
• Strings are immutable( StringBuffers are mutable
  ). The only way to change the value of the number
  inside the object wrapper is to create a new
  object and point to that instead.

42
Properties of Immutable Objects

• Immutable objects have a number of properties
  that make working with them easier, including
  relaxed synchronization requirements and the
  freedom to share and cache object references
  without concern for data corruption.
• An immutable object is one whose externally
  visible state cannot change after it is
  instantiated. The String, Integer, and BigDecimal
  classes in the Java class library are examples of
  immutable objects -- they represent a single
  value that cannot change over the lifetime of the
  object.

43
Creating an Immutable class

• Writing immutable classes is easy. A class will
  be immutable if all of the following are true
• All of its fields are final
• The class is declared final
• The this reference is not allowed to escape
  during construction

44
References to mutable objects in immutable
classes

• Any fields that contain references to mutable
  objects, such as arrays, collections, or mutable
  classes like Date
• Are private
• Are never returned or otherwise exposed to
  callers
• Are the only reference to the objects that they
  reference
• Do not change the state of the referenced objects
  after construction

45
String example

• String s "ABC"
• s.toLower()
• // The method toLower() will not change the data
  "ABC" that s contains. Instead, a new String
  object is instantiated and given the data "abc"
  during its construction. A reference to this
  String object is returned by the toLower()
  method. To make the String s contain the data
  "abc", a different approach is needed.
• s s.toLower()
• // Now the String s references a new String
  object that contains "abc". The String class's
  methods never affect the data that a String
  object contains.

46
Are constants still variable?

• Immutability does not guarantee that the object
  as stored in the computer's memory is
  unwriteable. Rather, immutability is a compile
  time construct that indicates what a programmer
  should do, not necessarily what he can do (for
  instance, by circumventing the type system or
  violating constant corrections in C or C).
  Java has more protection against violating
  constraints than C or C, but circumvention may
  still be possible.

47
Copy on Write

• A technique which blends the advantages of
  mutable and immutable objects, and is supported
  directly in almost all modern hardware, is
  copy-on-write (COW). Using this technique, when a
  user asks the system to copy an object, it will
  instead merely create a new reference which still
  points to the same object. As soon as a user
  modifies the object through a particular
  reference, the system makes a real copy and sets
  the reference to refer to the new copy. The other
  users are unaffected, because they still refer to
  the original object.

48
Benefit of Copy on Write

• Under COW, all users appear to have a mutable
  version of their objects, although if users do
  not modify their objects, the space-saving and
  speed advantages of immutable objects are
  preserved. Copy-on-write is popular in virtual
  memory systems because it saves memory space in
  the core while still correctly handling anything
  an application program might do.

49
Immutable Colors

• An example of immutability in the Java class
  library is java.awt.Color. While colors are
  generally represented as an ordered set of
  numeric values in some color representation (such
  as RGB, HSB, or CMYK), it makes more sense to
  think of a color as a distinguished value in a
  color space, rather than an ordered set of
  individually addressable values, and therefore it
  makes sense to implement Color as an immutable
  class.

50
Immutable Events

• Events are another example of good candidates for
  implementation with immutable classes. Events are
  short-lived, and are often consumed in a
  different thread than they were created in, so
  making them immutable has more advantages than
  disadvantages.

51
Where to use it ?

• Should containers for multiple primitive values,
  such as points, vectors, matrices, or RGB colors,
  be mutable or immutable objects? It depends on
  how are they going to be used. Are they used
  primarily to represent multi-dimensional values
  (like the color of a pixel), or simply as
  containers for a collection of related properties
  of some other object (like the height and width
  of a window)? How often are these properties
  going to be changed? If they are changed, do the
  individual component values have meaning within
  the application on their own?

52
Benefits of immutability

• Immutable classes, when used properly, can
  greatly simplify programming. They can only be in
  one state, so as long as they are properly
  constructed, they can never get into an
  inconsistent state.
• You can freely share and cache references to
  immutable objects without having to copy or clone
  them.
• Immutable classes generally make the best map
  keys. And they are inherently thread-safe, so you
  don't have to synchronize access to them across
  threads.

53
Freedom to cache

• Because immutable objects do not change their
  value, you can freely cache references to them
  and be confident that the reference will refer to
  the same value later. Similarly, because their
  properties cannot change, you can cache their
  fields and the results of their methods.
• If an object is mutable, you have to exercise
  some care when storing a reference to it.
  Consider the code in Listing 1, which queues two
  tasks for execution by a scheduler. The intent is
  that the first task would start now and the
  second task would start in one day.

54
Potential problem with a mutable Date object

• Date d new Date()
• Scheduler.scheduleTask(task1, d)
• d.setTime(d.getTime() ONE_DAY)
• scheduler.scheduleTask(task2, d)
• Because Date is mutable, the scheduleTask method
  must defensively copy the date parameter
  (clone()) into its internal data structure.
  Otherwise, task1 and task2 might both execute
  tomorrow. Worse, the internal data structure
  could become corrupt.

55
Debugging the mutable Date example (previous
slide)

• It is very easy to forget to defensively copy the
  date parameter when writing a method like
  scheduleTask(). If you do forget, you've created
  a subtle bug that's not going to show up for a
  while, and one that will take a long time to
  track down when it does. An immutable Date class
  would have made this sort of bug impossible.

56
Benefits of Immutability

• The freedom to share references to immutable
  objects across threads without synchronization
  can greatly simplify the process of writing
  concurrent programs and reduces the number of
  potential concurrency errors a program could
  have.

57
Safety with ill-behaved code

• Methods that take objects as arguments should not
  mutate the state of those objects. When we pass
  an object to an ordinary method, we do not expect
  that the object will come back changed. If we
  pass a java.awt.Point to a method such as
  Component.setLocation(), setLocation can modify
  the location of the Point we pass in or store a
  reference to that point and change it later in
  another method. Now, the state of the Point has
  changed without our knowledge, with potentially
  hazardous results.

58
Immutable Keys

• Immutable objects make the best HashMap or
  HashSet keys. Some mutable objects will change
  their hashCode() value depending on their state.
  If you use a mutable object as a HashSet key, and
  then the object changes its state, the HashSet
  implementation will become confused -- the object
  will still be present if you enumerate the set,
  but it may not appear to be present if you query
  the set with contains().

59
Shopping Cart example

• class Cart
• private final List items
• public Cart(List items)
• this.items items
• public List getItems() return items
• public int total()
• / return sum of the prices /

60
Shopping Cart explanation

• An instance of this class is not immutable one
  can add or remove items either by obtaining the
  field items by calling getItems() or by retaining
  a reference to the List object passed when an
  object of this class is created. The following
  code partially solves this problem. In the
  ImmutableCart class, the list is immutable you
  cannot add or remove items.

61
Shopping Cart solution

• The decorator pattern used as a wrapper around
  each of the list's items makes them immutable.
• class ImmutableCart
• private final List items
• public ImmutableCart(List items)
• this.items
• Arrays.asList(items.toArray())
• public List getItems() return
  Collections.unmodifiableList(items)
• public int total() / return sum of the prices
  /

62
Summary of Immutability

• You can share immutable objects between threads
  without danger of changes confusing the other
  thread.
• Once you check the value, you know it has to stay
  safe. No one can pass you a value, then behind
  your back swap it to an unsafe one. This is
  particularly important in high security
  situations where allowing an invalid value to
  sneak in could compromise system integrity, e.g.
  a filename.

63
Summary

• You can share duplicate objects by pointing them
  to a single instance.
• You can create substrings without copying.
  Immutability is the secret behind Java's very
  fast substring implementation.
• Immutable objects are much better suited to be
  Hashtable keys. If you change the value of an
  object that is used as a hash table key without
  removing it and re-adding it you lose the
  mapping.

64
Returning an Immutable Result

• How would you return some data from a method
  without changing the original. Here are four
  ways
• Wrap the reference in an immutable wrapper class
  and return that.
• Give the caller a private copy of the data.
• Request that the user not to modify the data.
• Return an immutable interface to the original
  data. You can then change fields in the object,
  but the caller cannot unless he cheats by
  casting. Expose only the methods you want the
  user to have. Doing this with classes is harder
  since a subclass must expose everything its
  superclass does.

65
Bibliography

• Jia, Xiaoping, Object Oriented Software
  Development, using Java. Addison Wesley, 2003.
• Declarations and access control. Certkey for
  Java2. 26 April 2006 http//www.jchq.net/certkey/
  0102certkey.htm
• Java 2 Basics Modifiers. GARBA.ORG. 26 April
  2006 http//www.garba.org/documents/java2/modifier
  s.html
• http//www.answers.com/topic/immutable-object
