Assessment of Postal Activity

1
Assessment of Postal Activity Case Argentina
2
Aim of the studies done

• Assessing Environmental Features of Simple Letter
  Service based on AECAs interest about showing if
  the activity pollutes the environment

Environmental Impact Study

• Performing the assessment of the life cycle and
  Calculation of Carbon Footprint for Reception
  Service and Sending a Corporative Simple Letter
• Establishing a comparison with respect to
  sending and receiving a commercial e-mail

ALC and Calculation of CO2 Footprint

3
What is it an Study on Environmental Impact (SEI)
Its a description and an analysis of
environmental resources within the area of
influence of the activity being studied,
considering
Environment
Physical Medium
Socioeconomic Medium

• Air quality (emissions)
• Noise
• Liquid Effluent
• Solid Waste
• Flora, Fauna and visual impact

• Employment generation
• Effect on commerce, industry and other services
• Effect on traffic
• Social Welfare and cultural heritage
• Safety

4
SEI Structure
What is it for?
Knowing the situation or environmental baseline
of Postal Activity
Stage 1
Describing processes and activities, resources
consumption, wastes, effluents and emissions from
the activity
Stage 2
Identifying environmental impacts generated by
the activity
Stage 3
Management plans with opportunities of
improvement or mitigation actions of significant
impact
5
Methodology

• Selecting the most representative process of
  postal activity.
• Designing questionnaires to collect environmental
  aspects.
• Selecting samples from establishments to audit
  according to the representativeness of the
  activity under study 86.7 of Postal Production
  is developed in the cities observed.

Planning
Fieldwork

• 1. Audits to 30 establishments head offices
  Distribution Centers Point of Sales
  validation in situ performed by the University
  team.

2. Collate and validate the Postal Activities
observed against legislation on its levels State
Province Municipality.
6
Methodology Leopold Matrix of Cause-Effect (Examp
le)
Process Activities





Distribution
Reception
Pick Up
Air
-19
-3
0
Environmental Factors
Noise
-25
0
-25
Employment
52
52
52
7
Outcomes from Environmental Impact Study
100
Crítical
Regarding environmental impact of Simple
Letter, the study shows that Postal Activity does
not pollute the environment.
75
Severe
50
Moderate
37
25
Compatible
0
8
Compared Legislation Diagram of Environmental
Legislation in Argentina
National Constitution and Laws of Minimal
Budgets
Federal State
Provincial Laws and Decrees
Provinces
Ordinances and Provisions
Municipalities
9
Different Points of View
10
Carbon Footprint

• What is it?
• The Carbon footprint is " the total of
  greenhouse gas (GHG) emissions directly or
  indirectly caused by an individual, organization,
  business, product or service."

Kyoto Protocol
It is an international agreement, which aims to
reduce greenhouse gas emissions that generate
global warning.
Greenhouse Gas Emissions (GHG) Carbon Dioxide equivalent (CO2e) of a gas measure
Carbon Dioxide CO2 Methane CH4 Oxide Nitrous N2O Hydrofluorocarbon HFC Perfluorocarbon PFC Sulphur hexafluoride SF6 1 21 310 740 1.300 23.900
11
Methodology PAS 2050

Emissions are calculated through the analysis
of Products / services Life Cycle

12
Stages of the Study
Improvements
Results
Emissions
Life Cycle Assessment
Fieldwork
Scope
Stages Better Practices
Establishment and Scope of Objectives Inventory Analysis Assessment of Impacts Outcomes Interpretation Complete regarding gases, activities, territories considered, etc. Accurate regarding information and its analysis Clear regarding data sources, methods applied and communication Solid throughout temporal series, this means the use of the same emission factors and methods for the same categories. Comparable this means use of a common methodology

13
Tool Used
Software used to visualize the Life Cycle of
letter and its associated emissions

14
Factors and Procedures involved in the study
Fieldwork
Processes
Production
Energy
Staff
Transport
Waste
Abilities
Distances
Market Share
Paper Specifications
Processes Determination
1. Simple Letter (Client)
2. Pick Up and Reception
3. Production and Treatment
4. Distribution and Delivery
5. Reclassify at Local Centers
6. Distribution to Final User
15
Emissions Detail
Resources
Energy Gas Consumption
Energy Electric Consumption
Commercial Transport
Urban Solid Waste
E-mail
Non Recycled Paper
Non Recycled Paper
Source
SEySD Argentina IPCC
SEySD Argentina - IPCC
SEySD Argentina - IPCC Peugeot
SEySD Argentina - IPCC
Environment and Energy Control Agency of France
Research Institute Cristóbal Colón Cadiz-Spain
ECODES Ecology and Development
Secretariat of Environment and Sustainable
Development Intergovernmental Panel on Climate
Change
16
Life cycle analysis
1. Client Emission
2.Pick Up and r Reception Process
3.Production and Treatment Process CABA
4.Distribution and Delivery Process
5.Reclassify at Provinces Center
6.Distribution to Final User
CABA AMBA
1,20 grs.
Floding, enveloping, stamping, labeling,
classifying, bagged and waste.
Bs. As. (Prov.)
1,20 grs.
Córdoba
1,20 grs.
4,05 grs.
Tucumán
Mendoza
2,98 grs.
Viedma (R.N.)
4,80 grs.
Santa Fé
1,72 grs.
Neuquén
3,67 grs.
0,10 grs. Co2
1,37 grs. Co2
Co2 p/Destino
Co2 x Centro
25 grs. Co2
Co2 Neutral
Model of Simple Letter Reception and Delivery
Service
17
Simple Letter Emissions Results
(Carbon Dioxide Equivalent CO2e)
Process 1 Client Process 2 Pick Up/ Reception Process 3 Production Process 4 Distribution Process 5 Reclassify Process 6 Final User Total emissions for Delivery Service of a Letter Total including envelope and paper
Common Emissions 25 0,10 1,37 CO2 Neutro
CABA AMBA 0,03 1,20 2,70 27,70
Buenos Aires 0,70 1,20 3,37 28,37
Córdoba 1,25 1,20 3,92 28,92
18
Outcomes
  Co2 emissions (grams) for Delivery of a Simple Letter Service per Destiny,
  Co2 emissions (grams) for Delivery of a Simple Letter Service per Destiny Envelope content, Co2 emissions (grams) (4 sheets A4)
  Co2 emissions (grams) for commercial E-mail with attachment, 1 mega
  Co2 emissions (grams) for commercial E-mail with attachment 1 mega printing (4 sheets A4)
19
Outcomes (CO2e grams)
Process Emissions Paper Total Emissions Co2
Simple Letter
E-Mail
3,92
25
28,92
44
19
25

• For example, sending a simple letter to a
  regular destination (700 Km)
• Emissions of sending an E-mail with attachment
  1 MB - Source ADEME

20
Thank you
Contact Graduate Gabriel Perez Environment and
Sustainable Development Committee -
Coordinator Email medioambiente_at_correos.org.ar In
order to download this presentation, please
visit our website www.correos.org.ar
