Network Coding: A New Direction in Combinatorial Optimization

1
Network CodingA New Direction in Combinatorial
Optimization

• Nick Harvey

2
Collaborators

• David Karger
• Robert Kleinberg
• April Rasala Lehman
• Kazuo Murota

• Kamal Jain
• Micah Adler

UMass
3
Transportation Problems
Max Flow
4
Transportation Problems
5
Communication Problems
A problem of inherent interest in the planning
of large-scale communication, distribution and
transportation networks also arises with the
current rate structure for Bell System
leased-line services.
Motivation for Network Design largely from
communication networks
- Robert Prim, 1957
Spanning Tree
Steiner Forest
Steiner Tree
Multicommodity Buy-at-Bulk
Facility Location
Steiner Network
6
What is the capacity of a network?
s2
s1
t1
t2

• Send items from s1?t1 and s2?t2
• Problem no disjoint paths

7
An Information Network
s2
s1
t1
t2

• If sending information, we can do better
• Send xor b1?b2 on bottleneck edge

8
Moral of Butterfly
Transportation Network Capacity ? Information
Network Capacity
9
Understanding Network Capacity

• Information Theory
• Deep analysis of simple channels(noise,
  interference, etc.)
• Little understanding of network structures
• Combinatorial Optimization
• Deep understanding of transportation problems on
  complex structures
• Does not address information flow
• Network Coding
• Combine ideas from both fields

10
Definition Instance

• Graph G (directed or undirected)
• Capacity ce on edge e
• k commodities, with
• A source si
• Set of sinks Ti
• Demand di
• Typically
• all capacities ce 1
• all demands di 1

• Technicality
• Always assume G is directed. Replace
  with

11
Definition Solution

• Alphabet ?(e) for messages on edge e
• A function fe for each edge s.t.
• Causality Edge (u,v) sendsinformation
  previously received at u.
• Correctness Each sink ti can decodedata from
  source si.

b1
12
Multicast
13
Multicast

• Graph is DAG
• 1 source, k sinks
• Source has r messages in alphabet ?
• Each sink wants all msgs

Thm ACLY00 Network coding solution exists iff
connectivity r from source to each sink
14
Multicast Example
s
m1
m2
t2
t1
15
Linear Network Codes

• Treat alphabet ? as finite field
• Node outputs linearcombinations of inputs
• Thm LYC03 Linear codes sufficient for multicast

16
Multicast Code Construction

• Thm HKMK03 Random linear codes work (over
  large enough field)
• Thm JS03 Deterministic algorithm to construct
  codes
• Thm HKM05 Deterministic algorithm to construct
  codes (general algebraic approach)

17
Random Coding Solution

• Randomly choose coding coefficients
• Sink receives linear comb of source msgs
• If connectivity ? r, linear combshave full rank
• ? can decode!
• Without coding, problem isSteiner Tree Packing
  (hard!)

18
Our Algorithm

• Derandomization of HKMK algorithm
• Technique Max-Rank Completionof Mixed Matrices
• Mixed Matrix contains numbers and variables
• Completion choice of values for variables that
  maximizes the rank.

19
k-Pairs Problemsaka Multiple Unicast Sessions
20
k-pairs problem

• Network coding when each commodity has one sink
• Analogous to multicommodity flow

• Goal compute max concurrent rate
• This is an open question

21
Rate

• Each edge has its own alphabet ?(e) of messages
• Rate min log( ?(S(i)) )
• NCR sup rate of coding solutions
• Observation If there is a fractional flow with
  rational coefficients achieving rate r, there is
  a network coding solution achieving rate r.

Source S(i)
22
Directed k-pairs
s1
s2

• Network coding rate can be muchlarger than flow
  rate!
• Butterfly graph
• Network coding rate (NCR) 1
• Flow rate ½
• Thm HKL04,LL04 ? graphs G(V,E) whereNCR
  O( flow rate V )
• Thm HKL05 ? graphs G(V,E) whereNCR O( flow
  rate E )

t2
t1
23
NCR / Flow Gap
s1
s2
NCR 1Flow rate ½
G (1)
t1
t2

• Equivalent to

Network Coding
Flow
s2
s2
s1
s1
Edge capacity 1
Edge capacity ½
t1
t2
t1
t2
24
NCR / Flow Gap
s3
s4
s1
s2
G (2)
t3
t4
t1
t2

• Start with two copies of G (1)

25
NCR / Flow Gap
s3
s4
s1
s2
G (2)
t3
t4
t1
t2

• Replace middle edges with copy of G (1)

26
NCR / Flow Gap
s3
s4
s1
s2
G (1)
G (2)
t3
t4
t1
t2

• NCR 1, Flow rate ¼

27
NCR / Flow Gap
s1
s2
s3
s4
s2n-1
s2n
G (n-1)
G (n)
t1
t2
t3
t4
t2n-1
t2n

• commodities 2n, V O(2n), E O(2n)
• NCR 1, Flow rate 2-n

28
Optimality

• The graph G (n) provesThm HKL05 ? graphs
  G(V,E) whereNCR O( flow rate E )
• G (n) is optimalThm HKL05 ? graph
  G(V,E),NCR/flow rate O(min V,E,k)

29
Network flow vs. information flow

• Multicommodity
• Flow
• Efficient algorithms for computing maximum
  concurrent (fractional) flow.
• Connected with metric embeddings via LP duality.
• Approximate max-flow min-cut theorems.

• Network
• Coding
• Computing the max concurrent network coding rate
  may be
• Undecidable
• Decidable in poly-time
• No adequate duality theory.
• No cut-based parameter is known to give sublinear
  approximation in digraphs.

No known undirected instance where network coding
rate ? max flow! (The undirected k-pairs
conjecture.)
30
Why not obviously decidable?

• How large should alphabet size be?
• Thm LL05 There exist networks wheremax-rate
  solution requires alphabet size
• Moreover, rate does not increase monotonically
  with alphabet size!
• No such thing as a large enough alphabet

31
Approximate max-flow / min-cut?

• The value of the sparsest cut is
• a O(log n)-approximation to max-flow in
  undirected graphs. AR98, LLR95, LR99
• a O(vn)-approximation tomax-flow in directed
  graphs. CKR01, G03, HR05
• not even a valid upper bound on network coding
  rate in directed graphs!

e
e has capacity 1 and separates 2 commodities,
i.e. sparsity is ½. Yet network coding rate is 1.
32
Approximate max-flow / min-cut?

• The value of the sparsest cut induced by a vertex
  partition is a valid upper bound, but can exceed
  network coding rate by a factor of O(n).
• We next present a cut parameter which may be a
  better approximation

ti
si
sj
tj
33
Informational Dominance

• Definition A e if for every network coding
  solution, the messages sent on edges of A
  uniquely determine the message sent on e.
• Given A and e, how hard is it to determine
  whether A e? Is it even decidable?
• Theorem HKL05 There is a combinatorial
  characterization of informational dominance.
  Also, there is an algorithm to compute whetherA
  e in time O(k²m).

34
Informational Dominance

• Def A dominates B if information in A determines
  information in Bin every network coding solution.

s1
s2
A does not dominate B
t2
t1
35
Informational Dominance

• Def A dominates B if information in A determines
  information in Bin every network coding solution.

s1
s2
A dominates B
Sufficient Condition If no path from any source
? B then A dominates B (not a necessary condition)
t2
t1
36
Informational Dominance Example

• Obviously flow rate NCR 1
• How to prove it? Markovicity?
• No two edges disconnect t1 and t2 from both
  sources!

37
Informational Dominance Example
s1
s2
t1
Cut A
t2

• Our characterization implies thatA dominates
  t1,t2 ? H(A) ? H(t1,t2)

38
Informational Meagerness

• Def Edge set A informationally isolates
  commodity set P if A ? P P.
• iM (G) minA,P for P informationally isolated
  by A
• Claim network coding rate ? iM (G).

39
Approximate max-flow / min-cut?

• Informational meagerness is no better than an
  O(log n)-approximation to the network coding
  rate, due to a family of instances called the
  iterated split butterfly.

40
Approximate max-flow / min-cut?

• Informational meagerness is no better than a
  O(log n)-approximation to the network coding
  rate, due to a family of instances called the
  iterated split butterfly.
• On the other hand, we dont even know if it is a
  o(n)-approximation in general.
• And we dont know if there is a polynomial-time
  algorithm to compute a o(n)-approximation to the
  network coding rate in directed graphs.

41
Sparsity Summary

• Directed Graphs
• Undirected Graphs

Flow Rate ? Sparsity lt NCR ? iM (G)
in some graphs
Flow Rate ? NCR ? Sparsity
Gap can be O(log n) when G is an expander
42
Undirected k-Pairs Conjecture
?
?
?
?
Sparsity
Flow Rate
NCR
Unknown until this work
Undirected k-pairs conjecture
43
The Okamura-Seymour Graph
Every edge cut has enough capacity to carry the
combined demand of all commodities separated by
the cut.
Cut
44
Okamura-Seymour Max-Flow
Flow Rate 3/4
si is 2 hops from ti. At flow rate r, each
commodity consumes ? 2r units of bandwidth in a
graph with only 6 units of capacity.
45
The trouble with information flow

• If an edge combines messages from multiple
  sources, which commodities get charged for
  consuming bandwidth?
• We present a way around this obstacle and
  boundNCR by 3/4.

s1
t3
s2
s4
t1
t4
s3
t2
At flow rate r, each commodity consumes at least
2r units of bandwidth in a graph with only 6
units of capacity.
46
Okamura-Seymour Proof
Thm AHJKL05 flow rate NCR 3/4.

• We will prove
• Thm HKL05 NCR ? 6/7 lt Sparsity.
• Proof uses properties of entropy.
• A ? B ? H(A) ? H(B)
• Submodularity H(A)H(B) ? H(A?B)H(A?B)
• Lemma (Cut Bound) For a cut A ? E,H( A ) ? H(
  A, sources separated by A ).

47

• H(A) ? H(A,s1,s2,s4) (Cut Bound)

Cut A
48

• H(B) ? H(B,s1,s2,s4) (Cut Bound)

Cut B
49

• Add inequalities
• H(A) H(B) ? H(A,s1,s2,s4) H(B,s1,s2,s4)
• Apply submodularity
• H(A) H(B) ? H(A?B,s1,s2,s4) H(s1,s2,s4)
• Note A?B separates s3 (Cut Bound)
• ? H(A?B,s1,s2,s4) ? H(s1,s2,s3,s4)
• Conclude
• H(A) H(B) ? H(s1,s2,s3,s4) H(s1,s2,s4)
• 6 edges ? rate of 7 sources ? rate ? 6/7.

50
Rate ¾ for Okamura-Seymour
s1
s1
t3
s1 t3
i
s4
t4
s2 t1
s3
s3 t2
51
Rate ¾ for Okamura-Seymour
s1 t3
i
s4
t4
s2 t1
i
s3 t2
i
52
Rate ¾ for Okamura-Seymour
s1 t3
i
s4
t4
s2 t1
i
s3 t2
i
53
Rate ¾ for Okamura-Seymour
s1 t3
s4
t4
s2 t1
s3 t2



54
Rate ¾ for Okamura-Seymour
s1 t3
s4
t4
s2 t1
s3 t2


55
Rate ¾ for Okamura-Seymour
s1 t3
s4
t4
s2 t1
¾ RATE
3 H(source) 6 H(undirected edge) 11 H(source)
6 H(undirected edge) 8 H(source)
s3 t2


56
Special Bipartite Graphs

• This proof generalizes to
• show that max-flow NCR
• for every instance which is
• Bipartite
• Every source is 2 hops away from its sink.
• Dual of flow LP is optimized by assigning length
  1 to all edges.

s1 t3
s4
t4
s2 t1
s3 t2
57
The k-pairs conjecture and I/O complexity

• In the I/O complexity model AV88, one has
• A large, slow external memory consisting of pages
  each containing p records.
• A fast internal memory that holds O(1) pages.
  (For concreteness, say 2.)
• Basic I/O operation read in two pages from
  external memory, write out one page.

58
I/O Complexity of Matrix Transposition

• Matrix transposition Given a pp matrix of
  records in row-major order, write it out in
  column-major order.
• Obvious algorithm requires O(p²) ops.
• A better algorithm uses O(p log p) ops.

59
I/O Complexity of Matrix Transposition

• Matrix transposition Given a pp matrix of
  records in row-major order, write it out in
  column-major order.
• Obvious algorithm requires O(p²) ops.
• A better algorithm uses O(p log p) ops.

s1
s2
60
I/O Complexity of Matrix Transposition

• Matrix transposition Given a pxp matrix of
  records in row-major order, write it out in
  column-major order.
• Obvious algorithm requires O(p²) ops.
• A better algorithm uses O(p log p) ops.

s1
s2
s3
s4
61
I/O Complexity of Matrix Transposition

• Matrix transposition Given a pxp matrix of
  records in row-major order, write it out in
  column-major order.
• Obvious algorithm requires O(p²) ops.
• A better algorithm uses O(p log p) ops.

s1
s2
s3
s4
t3
t1
62
I/O Complexity of Matrix Transposition

• Matrix transposition Given a pxp matrix of
  records in row-major order, write it out in
  column-major order.
• Obvious algorithm requires O(p²) ops.
• A better algorithm uses O(p log p) ops.

s1
s2
s3
s4
t3
t4
t1
t2
63
I/O Complexity of Matrix Transposition

• Theorem (Floyd 72, AV88) If a matrix
  transposition algorithm performs only read and
  write operations (no bitwise operations on
  records) then it must perform O(p log p) I/O
  operations.

s1
s2
s3
s4
t3
t4
t1
t2
64
I/O Complexity of Matrix Transposition

• Proof Let Nij denote the number of ops in which
  record (i,j) is written. For all j,
• Si Nij p log p.
• Hence
• Sij Nij p² log p.
• Each I/O writes only p records. QED.

s1
s2
s3
s4
t3
t4
t1
t2
65
The k-pairs conjecture and I/O complexity

• Definition An oblivious algorithm is one whose
  pattern of read/write operations does not depend
  on the input.
• Theorem If there is an oblivious algorithm for
  matrix transposition using o(p log p) I/O ops,
  the undirected k-pairs conjecture is false.

s1
s2
s3
s4
t3
t4
t1
t2
66
The k-pairs conjecture and I/O complexity

• Proof
• Represent the algorithm with a diagram as before.
• Assume WLOG that each node has only two outgoing
  edges.

p1
p2
p1
q
p2
s1
s2
s3
s4
t3
t4
t1
t2
67
The k-pairs conjecture and I/O complexity

• Proof
• Represent the algorithm with a diagram as before.
• Assume WLOG that each node has only two outgoing
  edges.
• Make all edges undirected, capacity p.
• Create a commodity for each matrix entry.

p1
p2
p1
q
p2
s1
s2
s3
s4
t3
t4
t1
t2
68
The k-pairs conjecture and I/O complexity

• Proof
• The algorithm itself is a network code of rate 1.
• Assuming the k-pairs conjecture, there is a flow
  of rate 1.
• Si,jd(si,tj) p E(G).
• Arguing as before, LHS is O(p² log p).
• Hence E(G)O(p log p).

p1
p2
p1
q
p2
s1
s2
s3
s4
t3
t4
t1
t2
69
Other consequences for complexity

• The undirected k-pairs conjecture implies
• A O(p log p) lower bound for matrix transposition
  in the cell-probe model.
• Same proof.
• A O(p² log p) lower bound for the running time of
  oblivious matrix transposition algorithms on a
  multi-tape Turing machine.
• I/O model can emulate multi-tape Turing
  machines with a factor p speedup.

70
Open Problems

• Computing the network coding rate in DAGs
• Recursively decidable?
• How do you compute a o(n)-factor approximation?
• Undirected k-pairs conjectureDoes flow rate
  NCR?
• At least prove a O(log n) gap between sparsest
  cut and network coding rate for some graphs.

71
Summary

• Information ? Transportation
• For multicast, NCR rate min cut
• Algorithms to find solution
• k-pairs
• Directed NCR gtgt flow rate
• Undirected Flow rate NCR in O-S graph
• Informational dominance
