Search Techniques for Multimedia Databases

1
Search Techniques for Multimedia Databases

• Similarity-Based Queries
• Similarity Computation
• Indexing Techniques
• Data Clustering
• Search Algorithms

2
Characteristic ofMultimedia Queries

• We normally retrieve a few records from a
  traditional DBMS through the specification of
  exact queries based on the notions of equality.
• The types of queries expected in an image/video
  DBMS are relatively vague or fuzzy, and are based
  on the notion of similarity.

3
Content-Based Retrieval

• It is necessary to extract the features which are
  characteristic of the image and index the image
  on these features.
• Examples Shape descriptions, texture
  properties.
• Typically, there are a few different quantitative
  measures which describes the various aspects of
  each feature.
• Example The texture attribute of an image
  can be modeled as a 3-dimensional vector with
  measures of directionality, contrast, and
  coarseness.

4
Measure of Similarity

• A suitable measure of similarity between an image
  feature vector F and query vector Q is the
  weighted metric D
• where W is an nxn matrix which can be used to
  specify suitable weighting measures.

W1(F1-Q1)2 W2(F2-Q2)2 Wn(Fn-Qn)2
Square of weighted Euclidean Distance
5
Measure of Similarity

• A suitable measure of similarity between an image
  feature vector F and query vector Q is the
  weighted metric D
• where W is an nxn matrix which can be used to
  specify suitable weighting measures.

W1(F1-Q1)2 W2(F2-Q2)2 Wn(Fn-Qn)2
Square of weighted Euclidean Distance
6
Similarity Based on Euclidean Distance
A Identity Matrix
3
2
3
2
é
ù
é
ù
é
ù
é
ù
ê
ú
ê
ú
ê
ú
ê
ú
F
F
F
Q
4
4
4
4






ê
ú
ê
ú
ê
ú
ê
ú
1
2
3
6
7
7
6
ê
ú
ê
ú
ê
ú
ê
ú
ë
û
ë
û
ë
û
ë
û
7
Similarity Based on Euclidean Distance (cont.)
Features 1 2 are treated equally

Feature 2
Feature 1
Points which lie at the same distance from the
query point are considered equally similar, e.g.,
F1 and F2.
8
Similarity Based on Weighted Euclidean Distance

• Where W is the diagonal.

Example
4
3
3
1
0
0
é
ù
é
ù
é
ù
é
ù
ê
ú
ê
ú
ê
ú
ê
ú
F
F
Q
W
5
5
5
0
1
0







ê
ú
ê
ú
ê
ú
ê
ú
1
2
7
8
7
0
0
2
ê
ú
ê
ú
ê
ú
ê
ú
ë
û
ë
û
ë
û
ë
û
1
0
0
1
é
ù
é
ù
ê
ú
ê
ú
Dissimilarity in 3rd dimension emphasized


D(F1 ,Q)
0
1
0
0
1




1
0
0
ê
ú
ê
ú
ê
ú
ê
ú
0
0
2
0
ë
û
ë
û
1
0
0
0
é
ù
é
ù


ê
ú
ê
ú
0
1
0
0
2



D(F2 ,Q)
0
0
1

ê
ú
ê
ú
ê
ú
ê
ú
0
0
2
1
ë
û
ë
û
D(F1 ,Q) lt D(F2 ,Q) ? F1 is more similar to Q
9
How to determine the weights ?
The variance of the individual feature measures
can be used to determine their weights.
0
0
1/s12
si2 Statistical variance of the i th feature
measure.
A

0
0
1/s22
0
0
1/s32

• Rationale
• Variance characterizes the dispersion among the
  measures
• Use larger weight for feature with smaller
  variance.

10
Effect of Weights
Shape
A cluster of similar objects (e.g., cars)
Color
This feature has larger variance, use smaller
weight
11
Distance in Euclidean Space
1-norm distance (Manhattan distance)
2-norm distance (Euclidean distance)
p-norm distance (Minkowski distance)
Infinity norm distance (Chebyshev distance)
Maximum distance between any component of the two
vectors
12
Common Properties of a Distance

• Distances, such as the Euclidean distance, have
  some well known properties.
• Positive Definiteness d(p, q) ? 0 for all p
  and q and d(p, q) 0 only if p q.
• Symmetry d(p, q) d(q, p) for all p and q.
• Triangle Inequality d(p, r) ? d(p, q) d(q, r)
  for all points p, q, and r.
• where d(p, q) is the distance (dissimilarity)
  between points (data objects), p and q.
• A distance that satisfies these properties is a
  metric

13
Query Types

• k-Nearest-Neighbor (k-NN) Queries The user
  specifies the number of close matches to the
  given query point.
• Retrieve 10 images most similar to this sample
• Range queries An interval is given for each
  dimension of the feature space and all the images
  which fall inside this hypercube are retrieved.

.
.
.
.
.
Q
.
.
.
Q
Q
.
.
.
.
.
.
.
.
.

.
r
.

.
.
.
r is large r
is small range query ?
vague query ?
4-nearest-neighbor
query
14
Multiattribute and Spatial Indexing

• Spatial Databases Queries involve regions that
  are represented as multidimensional objects.
• Example A rectangle in a 2-dimensional space
  involves four values - two points with two values
  for each point (4D vector).
• Access methods that index on multidimensional
  keys yield better performance for spatial
  queries.

(X1,Y1)
(X2,Y2)
15
Multiattribute and Spatial Indexing of Multimedia
Objects

• Multimedia Databases Multimedia objects
  typically have several attributes that
  characterize them.
• Example Attributes of an image include
  coarseness, shape, color, etc.
• Multimedia databases are also good candidates for
  multikey search structures.

shape
Coarseness
Average color
16
Indexing Multimedia Objects

• Cant we index multiple features using a B-tree
  ?
• B-tree defines a linear order (e.g., according
  to X)
• Similar objects (e.g., O1 and O2) can be far
  apart in the indexing order
• Why multidimensional indexing ?
• A multidimensional index defines a spatial
  order
• Conceptually similar objects are spatially near
  each other in the indexing order (e.g., O1 and
  O2)

17
Some Multidimensional Search Structures

• k-d Tree
• Multidimensional Trie
• Grid File
• R Tree
• Point-Quad Tree
• D-Tree

18
k-d Tree

• Each node consists of a record and two
  pointers. The pointers are either null or point
  to another node.
• Nodes have levels and each level of the tree
  discriminates for one attribute.
• The partitioning of the space with respect to
  various attributes alternates between the various
  attributes of the n-dimensional search space.

Discriminator
Example 2-D tree
A(65, 50)

X Y Y
Input Sequence A (65, 50) B (60, 70) C
(70, 60) D (75, 25) E (50, 90) F
(90, 65) G (10, 30) H (80, 85) I
(95, 75)
B(60, 70)
C(70, 60)


F(90, 65)


X


D(75, 25)
G(10,30)
E(50,90)


Insertion order can affect performance
H(80, 85)
I(95, 75)
19
k-d Tree Search Algorithm

• Notations
• Algorithm Search for P(K1, ..., Kn)
• Q Root / Q will be used to navigate
  the tree /
• While NOT DONE DO the following
• if (Ki(P) Ki(Q) for i 1, ..., n) then
  we have / Agree in each /
• located the node and we are
  DONE / dimension /
• Otherwise if A Disc(Q) and KA(P) lt
  KA(Q)
• then Q High(Q)
• else Q Low(Q)
• Performance O(logN), where N is the number of
  records

Disc(L) The discriminator at Ls level Ki(L)
The i-attribute value of node L Low(L) The
left child of L High(L) The right child of L
(..., Ki(L), ...)
L
N High(L)
M
N
M Low(L)
20
Multidimensional Trie

• Multidimensional tries, or k-d tries, are similar
  to k-d tree except that they divide the embedding
  space.
• ? Each split evenly divides a region

Example Construction of a 2D trie
Y

C(70, 60)


B(60,70)
Partitioning the space
A(65,50)

D(75,25)
X
20
21
Disadvantages of k-d Trie

• The maximum level of decomposition depends on the
  minimum separation between two points
• A solution Split a region only if it contains
  more than p points (i.e., using buckets)
• Not a balanced tree
• ? unpredictable performance

22
Grid File
Split Strategy The partitioning is done with
only one hyperplane, but the split extends to all
regions in the splitting direction
23
Grid File - Potential Issues
Grid directory
A
B
C
K
D
E
F
K
H
I
J
K
Data bucket H
L
L
M
K
1
2
3
4
75
100
0
25
50
Data basket K

• The directory can be quite sparse.
• Many adjacent directory entries may point to the
  same data block.
• For partial-match and range queries, many
  directory entries, but only few data blocks, may
  have to be scanned (i.e., sequential search might
  be faster)

24
Point-Quad Tree

• Each node of a k-dimensional quad tree partitions
  the object space into k quadrants.
• The partitioning is performed along all search
  dimensions and is data dependent, like k-d tree.

Partitioning of the space
D(35,85)


B(75,80)

A(50,50)

E(25,25)

• To search for P(55, 75)
• Since XAlt XP and YA lt YP ? go to NE (i.e., B).
• Since XB gt XP and YB gt YP ? go to SW, which in
  this case is null.

25
R-tree (RegionTree)

• Root and intermediate nodes correspond to the
  smallest rectangle that encloses its child nodes,
  i.e., containing r, ltpage
  pointergt pairs.
• Leaf nodes contain pointers to the actual
  objects, i.e., containing r, ltRIDgt .
• A rectangle may be spatially contained in several
  nodes (e.g., J ), yet it can be associated with
  only one node.

May incur redundant search
A
B
C

• R-tree is a higher generalization of B-tree
• The nodes correspond to disk pages
• All leaf nodes appear at the same level

Root
Level 2
Level 3
26
R-tree Insertion

• A new object is added to the appropriate leaf
  node.
• If insertion causes the leaf node to overflow,
  the node must be split, and the records
  distributed in the two leaf nodes.

• Minimizing the total area of the covering
  rectangles (compact clusters)
• Minimizing the area common to the covering
  rectangles (to minimize redundant search)
• Splits are propagated up the tree (similar to
  B-tree).

27
R-tree Delete

• If a deletion causes a node to underflow, its
  nodes are reinserted (instead of being merged
  with adjacent nodes as in B-tree).
• Reason There is no concept of adjacency in an
  R-tree.

28
D-tree Domain Decomposition

• If the number of objects inside a domain exceeds
  a certain threshold, the domain is split into two
  subdomains.

29
D-tree Split Example
D-tree
Embedding Space
Internal node
D
External node
D22.P
30
D-tree Split Examples
D-tree
Embedding Space
D
A domain node
Original domain
A data node
A subdomain
D1
D2
D11
D12
31
D-tree Split Example (continued)
D-tree
Embedding Space
After 3rd split
D11
D2
D121
D122
D11
D2
D121
D122
Internal node
After 4th split
D1
D2
External node
D11
D21
D122
D121
D22
D11
D121
D122
D21
D22
D22.P
32
D-tree Search Algorithm

• Search(D_tree_root, search_object )
• Current_node D_tree_root
• For each entry in current-node, say (D, P ), do

• if D contains search_object, we do the
  following
• if Current_node is an external node
• retrieve the objects through D.P
  compare them
• if Current_node is an internal node
• call Search(D.P, search_object) /
  Recursive call

33
D-tree Range Query
Discard this object

• A range query can be represented as a hypercube
  embedded in the search space
• Search Strategy
• Use D-tree to retrieve all subdomains which
  overlap with the query cube.
• For each such subdomain which is not fully
  contained in the query cube, discard the objects
  falling outside the query cube.

Range query
34
D-tree Range Query

• Search(D_tree_root, search_cube)
• Current_node D_tree_root
• For each entry in Current_node, say (D, P), if D
  overlaps with search_cube, do
• If Current_node is an external node, retrieve the
  objects in D.P, which fall within the overlap
  region.
• If Current_node is an internal node,
• call Search(D.P, search_cube).

35
D-tree Desirable Properties

• D-tree is a balanced tree
• Search path for an object is unique
• No redundant search
• More splits occur in denser regions of the search
  space.
• No unnecessary splits
• Objects evenly distributed among data nodes
• Similar objects are physically clustered in the
  same, or neighboring data nodes.
• Good performance is ensured regardless of the
  insertion order of the data.

36
Curse of Dimensionality

• As the number of dimensions (D) increases, the
  probability of finding data in the sphere
  (Vol-S/V0l-C) decreases exponentially
• Most data are in corners of the cube
• More dimension we have, more similar things
  appear (i.e., data have equi-distance)

D Vol-S/Vol-C
1 100
2 78
3 52
4 31
5 17
6 9
Corners are very dense in high dimensional spaces
37
Effect on High Dimensionality

• Figure (a) As dimensionality increases, it
  requires a substantially greater search radius to
  retrieve the same percentage of data (Note 0.02
  means retrieving 3 from 16,000 images.)
• Figure (b) In a high dimensional space, the
  approximating hypercube query returns
  substantially more candidate data items as the
  search radius increases
• Figure (c) The retrieval time increases
  exponentially with the increases in the number of
  dimensions (for a given selectivity) after a
  certain high dimensionality

1
1
Long retrieval time
Need larger approximate query
Mostly irrelevant data in corners
38
Effect on k-NN Queries

• Process k-NN query
• Use an approximating hypercube query to find kc
  candidate neighbors
• Examine the candidates to determine the k nearest
  neighbors
• Effect of high dimensionality
• In a high dimensional space, kc gtgt k
• When kc is a very large percentage of the
  database, no index structure is helpful

39
Sequential Scan is Better

• In a high-dimensional space, tree-based indexing
  structures examine large fraction of leaf nodes
• Instead of visiting so many tree nodes, it is
  better
• to scan the whole data set, and
• avoid performing seeks altogether

40
Vector Approximation (VA) File

• How to speed-up linear scan ?
• A Solution - use approximation
• Divide data space into cells and allocates a
  bit-string to each cell
• Vectors inside a cell are approximated by the
  cell
• VA-file is an array of these geometric
  approximations
• For search,
• the VA-file is scanned to select candidate
  vectors (i.e., relevant cells).
• Candidates are then verified by visiting the
  vector files (i.e., the original vectors)

41
VA-File Example
Vectorfile
Vector Data Vector Data
O1 (0.1, 0.9)
O2 (0.7, 0.7)
O3 (0.3, 0.4)
O4 (0.8, 0.2)
Approximation Approximation
O1 00 11
O2 10 10
O3 01 01
O4 11 00
VA file
42
Principle Component Analysis

• Principle Component Analysis (PCA)
• Goal is to find a projection that captures the
  largest amount of variation in data
• transforms a number of possibly correlated
  variables (X1 and X2) into a smaller number of
  uncorrelated variables called principle
  components
• This technique can be used to reduce the number
  of dimensions in content-based image retrieval
  (CBIR)

e
X2
X1
43
Review Variance
44
Covariance
45
Covariance Matrix
X1 X2 X3 X4 X5 X6 X7 X8
X1
X2
X3
X4
X5
X6
X7
X8








Cov(X3,X4)
Cov(X7,X7) s7
46
Review Transformation Matrix
47
Review Eigenvector (2)
Not an eigenvector

• A matrix acts on a vector by changing both its
  magnitude and its direction
• This matrix may act on certain vectors by
  changing only their magnitude, and leaving their
  direction unchanged (or possibly reversing it)
• These vectors are the eigenvectors of the matrix

Eigenvector
48
A Transformation Example

• This transformation matrix does not change the
  direction or magnitude of the vectors along the
  central vertical axis (e.g., the red vector)
• All the pixels along the central vertical axis
  are the eigenvectors of this transformation matrix

Apply transformation
49
Eigenvector Properties

• Eigenvectors can only be found for square
  matrices
• Not every square matrix has eigenvectors
• If an nxn matrix does have eigenvectors, there
  are n of them
• If we scale the vector by some amount before the
  multiplication, we still get the same multiple of
  it as a result
• All the unit eigenvectors (i.e., length is 1) are
  perpendicular

50
Eigenvalue
The amount by which the original vector was
scaled after multiplication by the square matrix
is the same
Eigenvector
Scaled vector
Scale the eigenvector
Eigenvalue

• No matter what multiple of the eigenvector we
  take before the multiplication, we always get 4
  times the scaled vector as the result
• 4 is the eigenvalue associated with this
  eigenvector

51
Principal Components Analysis (1)

1. Prepare the matrix Data to hold the original data
   set, with a data item in each column and each row
   holding a separate dimension.

52
Principal Components Analysis (2)

1. Compute the mean for each dimension of the data
   set (i.e., averaging each row in Data)

Compute means
53
Principal Components Analysis (3)

• Compute the matrix DataAdjust by subtracting
  each entry in Data by the mean of the
  corresponding dimension
• Note This produce a data set whose mean in each
  dimension is zero

Adjusted entry
54
Principal Components Analysis (4)

1. Compute the covariance matrix for the dimensions

55
Principal Components Analysis (5)

• Calculate the unit eigenvectors and eigenvalues
  of the covariance matrix.
• Note Most math packages give unit eigenvectors

56
Principal Components Analysis (6)

• Sort the eigenvectors in descending order
  according to their eigenvalue.
• The eigenvector with the largest eigenvalue is
  the principal component
• The sorting order gives the components in order
  of significance

More significant
57
PCA Dimension Reduction

• The eigenvectors corresponding to the principle
  components are orthogonal
• We can map data from the original space into the
  new space defined by the orthogonal vectors
• We can reduce the number of dimensions by
  dropping some of the less important components

58
PCA Deriving the New Data Set

• Choose the components (eigenvectors) we want to
  keep and form a transformation matrix F, with an
  eigenvector in each row
• Compute the new data set by applying the
  transformation F to the adjusted data matrix
  (coordinate transformation)
• FinalData F x DataAdjust T

• We have projected the data from the original
  coordinate system to a lower dimensional space
  defined by the chosen eigenvectors
• The relative spatial distances among the original
  data items are mostly preserved in the lower
  dimensional space

59
PCA - Summary

• Determine the eigenvectors of the covariance
  matrix
• These eigenvectors define the new space with
  lower dimensionality

60
Data Clustering

• Supervised Classification
• Semi-supervised Classification
• Unsupervised kMeans Clustering
• Semi-Supervised kMeans Clustering
• Constrained kMeans Clustering

61
Supervised Classification
Training data (labeled data)
62
Supervised Classification
Result of supervised learning
63
Supervised Classification
Item to be classified
64
Supervised Classification
Classified based on the dividing line
65
Supervised Classification

• Support Vector Machine (SVM)
• Artificial Neural Networks (ANN)

66
Support Vector Machine (1)

• The dashed lines mark the distance between the
  dividing line and the closest vectors (points) to
  the line
• The vectors that constrain the width of the
  margin are the support vectors
• SVM analysis finds the dividing line that
  maximizes the margin

Large margin
Small margin
Support vectors
67
Support Vector Machine (2)

• Points on a 2-dimensional plane can be separated
  by a 1-dimensional plane (i.e., a line)
• Points in an d-dimensional plane can be separated
  by a (d-1)-dimensional hyperplane

68
Support Vector Machine (3)

• Problem What if the points are separated by a
  nonlinear region

69
Semi-supervised Learning

• Labeling a lot of data can be expensive
• Solution Semi-supervised learning
• Make use of unlabeled data in conjunction with a
  small amount of labeled data
• Examples
• Semi-supervised EM Ghahramani,NIPS94,
  Nigam,ML00
• Transductive SVM Joachims,ICML99
• Co-training Blum,COLT98

70
Co-training (1)

• Many problems have two complimentary views that
  can be used to label data
• Example Faculty home pages
• my advisor pointing to a page is a good
  indicator that it is a faculty home page
• I am teaching in a page is a good indicator
  that it is a faculty home page

71
Co-training (2)

• Features can be split into two sets, i.e.,
  x(x1,x2).
• L set of labeled examples U set of
  unlabeled examples
• Repeat k times
• Use L to train a classifier c1 that considers
  only x1
• Use L to train a classifier c2 that
  considers only x2
• Apply c1 to label p positive and n negative
  examples from U
• Apply c2 to label p positive and n negative
  examples from U
• Move these self-labeled examples from U to L
• / c1 adds labeled examples to L that c2
  will be able to use for learning, and vice verse
• Assumption The class of each instance can be
  accurately predicted from each of the two feature
  subsets alone

72
Unsupervised Clustering kMeans
Randomly initialize k means
73
Unsupervised Clustering kMeans
Assign points to clusters
74
Unsupervised Clustering kMeans
Re-estimate means
75
Unsupervised Clustering kMeans
Re-assign points to clusters
76
Unsupervised Clustering kMeans
Re-estimate means
77
Unsupervised Clustering kMeans
Assign points to clusters
These are the clusters
No changes ? Converge
78
Unsupervised Clustering kMeans

• Initialize k cluster centers
• Repeat until convergence
• Assign points to the cluster with the closest
  center
• For each cluster, re-estimate the center as the
  mean of the points in that cluster

Choose well-separated centers
Property Locally minimizes sum of distances
between the data points and their corresponding
cluster center ? More compact clusters
79
Semi-supervised Clustering
Idea Uses small amount of labeled data to guide
(bias) the clustering of unlabeled data Example
Use the labeled data to initialize clusters in
k-Means algorithm
Labeled data
80
Semi-supervised Clustering
There are three clusters
81
Constrained kMeans Clustering

• Must-link constraints specify that the two points
  have to be in the same cluster
• Cannot-link constraints specify that the two
  points must not be placed in the same cluster

Con Set of must-link constraints
D Data set
Con? Set of cannot-link constraints
82
Constrained kMeans Clustering Wagstaff, ICML01

1. Let C1 Ck be the initial cluster centers
2. For each point di in D, assign it to the closest
   cluster Cj such that VIOLATION(di, Cj, Con,
   Con?) is false. If no such cluster exists, fail
   (return )
3. For each cluster Ci , update its center by
   averaging all of the points di that have been
   assigned to it
4. Repeat (2) and (3) until convergence
5. Return C1 Ck

Can we assign d to C without violating any
constraint

• VIOLATION(data point d, cluster C, must-link
  constraints Con , cannot-link constraints Con?)
• For each (d, d) ? Con , If d is in some C,
  return true
• For each (d, d?) ? Con? , If d? is in C, return
  true
• Otherwise, return false

83
Content-Based Image Indexing

• Keyword Approach
• Problem there is no commonly agreed-upon
  vocabulary for describing image properties.
• Computer Vision Techniques
• Problem General image understanding and object
  recognition is beyond the capability of current
  computer vision technology.
• Image Analysis Techniques
• It is relatively easy to capture the primitive
  image properties such as
• prominent regions,
• their colors and shapes,
• and related layout and location information
  within images.
• These features can be used to index image data.
• Challenge Semantic gap !

84
Features Acquisition Image Segmentation

• Group adjacent pixels with similar color
  properties into one region, and
• segment the pixels with distinct color properties
  into different regions.

Original Segmented Contour

85
Image Indexing by contents

• By applying image segmentation techniques, a set
  of regions are detected along with their
  locations, sizes, colors, and shapes.
• These features can be used to index image data.

86
Color

• We can divide the color space into a small number
  of zones, each of which is clearly distinct with
  others for human eyes.
• Each of the zones is assigned a sequence number
  beginning from zero.

Notes Human eyes are not very sensitive to
colors. In fact, users only have a vague idea
about the colors they want to specify.
87
Shape

• Shape feature can be measured by two properties
  circularity and major axis orientation.
• Circularity
• Major Axis Orientation

The more circular the shape, the closer to one
the circularity
88
Location

• Image is divided into sub-areas.
• Each sub-area is labeled with a number.
• Region location is represented by ID of the
  sub-area in which the gravity center of the
  region is contained.
• Note When a user queries the database by visual
  contents, approximate feature values are used.
• It is meaningless to use absolute feature values
  as indices.

1
0
2

• Location of A is 4
• Location of B is 1

5
4
3
6
7
8
89
Size

• The size range is divided into groups.
• A regions size is represented by the
  corresponding group number.
• Example

Cell area is Asub
ASSIGNED SIZE ACTUAL SIZES
1 ¼ Asub ? S ½ Asub
2 ½ Asub ? S Asub
3 Asub ? S 2 Asub
4 2 Asub ? S 3 Asub
5 3 Asub ? S 4 Asub
6 4 Asub ? S 5 Asub
7 5 Asub ? S 6 Asub
8 6 Asub ? S 7 Asub
9 7 Asub ? S 8 Asub
10 8 Asub ? S 9 Asub
Notes Only regions more than one-fourth of the
sub-area are registered.
90
Texture Areas

• Texture areas and images with dominant high
  frequency components are beyond the capacity of
  image segmentation techniques.
• Matching on the distribution of colors (i.e.,
  color histograms) is a simple yet effective means
  for these areas.
• Strategy Dividing an image into sub-areas and
  creating a histogram for each of the sub-areas.
• Potential Issue the partitioning of the
  image is to capture locality information. We
  dont want to match an image with a red balloon
  on top with an image with a red car in the bottom.

91
Histograms

• Gray-Level Histogram It is a plot of the number
  of pixels that assume each discrete value that
  the quantized image intensity can take.
• Color Histogram It holds information on color
  distribution. It is a plot of the statistics of
  the R, G, B components in the 3-D color space.

92
Histograms (cont.)
Most histogram bins are sparsely populated, with
only a small number of bins capturing the
majority of pixel counts.

• We can use the largest, say 20, bins as the
  representative bins of the histogram.
• these 20 bins form a chain in the 3-D color
  space.

93
Histograms (cont.)

• If we can represent such chains using a numerical
  number, then we can index the color images using
  a B-tree.
• Connecting order Representative bins are sorted
  in ascending order by their distance from the
  origin of the color space.
• Weighted Perimeter
• Weighted Angle
• Format of index key

93
94
Video Content Extraction

• Other forms of information extraction can be
  employed

• Close-captioned text
• Speech recognition
• Descriptive information from screenplay
• Key frames that characterize a shot

• These content information can be associated with
  the video story units.

95
Story Units

• Shot Frames recorded in one camera operation
  form a shot.
• Scene One or several related shots are combined
  in a scene.
• Sequence A series of related scenes forms a
  sequence.
• Video A video is composed of different story
  units such as shots, scenes, and sequences
  arranged according to some logical structure
  (defined by the screen play).
• These concepts can be used to organize video data

96
Video Modeling Approaches

• Physical Feature based Modeling
• Semantic Content based Modeling

97
Physical Feature based Modeling

• A Video is represented and indexed based on
  audio-visual features
• Features can be extracted automatically
• Queries are formulated in terms of color,
  texture, audio, or motion information
• Very limited in expressing queries close to human
  thinking
• It would be difficult to ask for a video clip
  showing the sinking of the ship in the movie
  Titanic using only color description

98
Semantic Content based Modeling

• Video semantics are captured and organized to
  support video retrieval
• Difficult to automate
• Partially rely on manual annotation
• Capable of supporting natural language like
  queries.

99
Semantic-Level Models

• Segmentation-based Models
• Stratification-based Models
• Temporal Coherent Model

100
Segmentation-based Modeling

• A video stream is segmented into temporally
  continuous segments
• Each segment is associated with a description
  which could be natural text, keywords, or other
  kinds of annotation.
• Disadvantages
• Lack of flexibility
• Limited in representing semantics

gt gt
101
Stratification-based

• We partition the contextual information into
  single events.
• Each event is associated with a video segment
  called a stratum.
• Strata can overlap or encompass each other.

102
Temporal Coherent

• Each event is associated with a set of video
  segments where it happens.
• More flexible in structuring video semantics.

103
Stratum
The concept of stratification can be used to
assign descriptions to video footage. - Each
stratum refers to a sequence of video frames. -
The strata may overlap or totally encompass each
other.
Advantage Allowing easy retrieval by keyword,
e.g., using inverted index
104
Inverted Index
Inverted Index Inverted Index
ANSI D1, D2
C D3, D4, D5
DB2 D1, D6, D21
GUI D2, D8. D11
SYBASE D2, D6, D17
MULTIMEDIA D5, D15
ORACLE D3, D11, D19
RELATIONAL D2, D3, D11, D19
SQL D2, D11, D20
JAVA D3, D20
Each document entry contains

• frequency of the term in the document,
• locations of the term in the document,
• other information pertaining to the relationship
  of the term and the document.

105
Video Algebra

• Goal To provide a high-level abstraction that
• models complex information associated with
  digital video data, and
• supports content-based access
• Strategy
• The algebraic video data model consists of
  hierarchical compositions of video expressions
  with high-level semantic descriptions
• The video expressions are constructed using video
  algebra operations

106
Presentation

• The fundamental entity is a presentation
• A presentation is described by a video
  expression.
• A video expression describes a multi-window
  spatial-temporal, and content combination of
  video segments.

A presentation
107
Presentation

• The fundamental entity is a presentation
• A presentation is described by a video
  expression.
• A video expression describes a multi-window
  spatial-temporal, and content combination of
  video segments.
• An algebraic video node provides a means of
  abstraction by which video expressions can be
  named stored, and manipulated as units

Primitive video expression creates a
single-window presentation from a raw video
segment
Compound video expression constructed from
simpler expressions using video algebra operations
An algebraic video node
video expression
video expression
video expression
video expression
Raw video
108
Video Algebra Operations

• The video algebra operations fall into four
  categories
• Creation defines the construction of video
  expressions from raw video.
• Description associates content attributes with a
  video expression.
• Composition defines temporal relationships
  between component video expressions.
• Output defines spatial layout and audio output
  for component video expressions.

109
Descriptions

• description E1 content specifies that E1 is
  described by content.
• a content is a Boolean combination of attributes
  that consists of a field name and a value.
• some field names have predefined semantics (e.g.,
  title), while other fields are user-definable.
• values can assume a variety of types, including
  strings and video node names.
• field names or values do not have to be unique
  within a description.
• hide-content E1 defines a presentation that
  hides the content of E1 (i.e.., E1 does not
  contain any description).
• This operation provides a method for creating
  abstraction barriers for content-based access.

Example title CNN Headline News
110
Composition
The composition operations can be combined to
produce complex scheduling definitions and
constraints.
create a video presentation raw video
segment
C1 create Cnn.HeadlineNews.rv 10 30 C2
create Cnn.HeadlineNews.rv 20 40 C3 create
Cnn.HeadlineNews.rv 32 65 D1 (description
C1 Anchor speaking) D2 (description C2
Professor Smith) D3 (description C3 Economic
reform)
D3 follows D2 which follows D1, and common
footages are not repeated. (It creates a
non-redundant video stream from three overlapping
segments.)
C1
C3
C2
Anchor speaking
Professor Smith
Economic reform
111
Composition Operators (1)
Operator Description
E1 ? E2 defines the presentation where E2 follows E1
E1 È E2 defines the presentation where E2 follows E1 and common footage is not repeated
E1 Ç E2 defines the presentation where only common footage of E1 and E2 is played
E1 - E2 defines the presentation where only footage of E1 that is not in E2 is played
E1 E2 E1 and E2 are played concurrently and terminate simultaneously
(test) ? E1E2...En Ei is played if test evaluates to i.
loop E1 time defines a repetition of E1 for a duration of time
112
Composition Operators (2)
Operator Description
stretch E1 factor sets the duration of the presentation equal to factor times duration of E1 by changing the playback speed of the video segment
limit E1 time sets the duration of the presentation equal to the minimum of time and the duration of E1, but the playback speed is not changed
113
Composition Operators (3)

• transition E1 E2 type time defines type
  transition effect between E1 and E2 time defines
  the duration of the transition effect
• The transition type is one of a set of
  transition effects, such as dissolve, fade, and
  wipe.
• contains E1 query defines the presentation that
  contains component expressions of E1 that match
  query. (similar to FROM clause in SQL)
• A query is a Boolean combination of attributes
• Example text smith and text question

114
Output Characteristics

• Video expressions include output characteristics
  that specify the screen layout and audio output
  for playing back children streams.

A presentation
115
Output Characteristics

• Video expressions include output characteristics
  that specify the screen layout and audio output
  for playing back children streams.
• window E1 (X1 , Y1 ) - (X2 , Y2 ) priority
• specifies that E1 will be displayed with
  priority in the window defined by the top-left
  corner (X1 , Y1) and the bottom-right corner (X2
  , Y2) such that Xi in 0, 1 and Yi in 0, 1.
• Window priorities are used to resolve overlap
  conflicts of screen display.
• audio E1 channel force priority
• specifies that the audio of E1 will be output to
  channel with priority if force is true, then the
  audio operation overrides any channel
  specifications of the component video expressions.

116
Output Characteristics example

• C1 create MagicvsBulls.rv 300 500
• P1 window C1 (0, 0) - (0.5, 0.5) 10
• P2 window C1 (0, 0.5) - (0.5, 1) 20
• P3 window C1 (0.5, 0.5) - (1, 1) 30
• P4 window C1 (0.5, 0) - (1, 0.5) 40
• P5 (P1 P2 P4)
• P6 (P1 P2 P3 P4)
• (P5
• (window
• (P5 (window P6 (0.5, 0.5) - (1, 1)
  60))
• (0.5, 0.5) - (1, 1) 50))

Since expressions can be nested, the spatial
layout of any particular video expression is
defined relative to the parent rectangle.
Larger means higher priority
Top-left corner
Bottom-right corner
A presentation
117
Scope of a video node description

• The scope of a given algebraic video node
  description is the subgraph that originates from
  the node.
• The components of a video expression inherit
  descriptions by context.
• i.e., content attributes associated with some
  parent video nodes are also associated with all
  its descendant nodes.

118
Content Based Access

• Search query Search a collection of video
  nodes for video expressions that match query.
• Example search text smith AND text
  question
• Strategy Matching a query to the attributes of
  an expression must take into account all of the
  attributes of that expression including the
  attributes of its encompassing expressions.

Smith on economic reform
Result of the query
?
This node also satisfies the query but is not
returned because its a descendant of a node
already in the result set
Smith
Anchor
O
Question from audience
O
Question
.
Raw video
119
Browsing and Navigation

• Playback video-expression
• Plays the video expression. It enables the user
  to view the presentation defined by the
  expressions.
• Display video-expression
• Display the video expression. It allows the
  user to inspect the video expression.
• Get-parent video-expression
• Returns the set of nodes that directly point to
  video-expression.
• Get-children video-expression
• Returns the set of nodes video-expression
  directly points at.

120
Algebraic Video System Prototype

• The implementation is build on top of three
  existing subsystems
• The VuSystem is used for managing raw video data
  and for its support of Tcl (Tool command
  language) programming. It provides an environment
  for recording, processing, and playing video.
• The Semantic File System is used as a storage
  subsystem with content-based access to data for
  indexing and retrieving files that represent
  algebraic video nodes.
• The Web server provides a graphical interface to
  the system that includes facilities for querying,
  navigating, video editing and composing, and
  invoking the video player.
