Title: Numerical algorithms for power system protection


1
Numerical algorithms for power system protection
  • Prof. dr. sc. Ante Marušic, doc. dr. sc. Juraj
    Havelka
  • University of Zagreb
  • Faculty of Electrical Engineering and Computing
  • ante.marusic_at_fer.hr, juraj.havelka_at_fer.hr
  • 2010/2011.

2
Introduction
  • Quality of digital relays depends on
  • Numerical algorithm quality (software)
  • Hardware quality
  • General digital relay characteristics
    selectivity, stability, satisfactory trip time
    and sensitivity

3
Lecture parts
  • First part
  • Types of signals
  • Sampling theory
  • Sampling and A/D circuits
  • Numerical methods Interpolation formulas
    numerical integration and differentiation, curve
    fitting, Fourier analysis and digital filtering

4
Lecture parts
  • Second part
  • Sinus wave based algorithms
  • Fourier based algorithms
  • Least squares based algorithms
  • Differential equation based algorithms

5
Lecture parts
  • Third part Real time algorithm testing
  • 50 Hz Signal
  • Simulated short circuit
  • Real short circuit

6
Signal classification hierarchy
  • Digital signals
  • 1-0 (On Off or TTL) signal
  • Pulse train (counters, timers)
  • Analog signals
  • DC signal (slow)
  • Signal in time domain (fast)
  • Signal in frequency domain

7
(No Transcript)
8
Basic elements of digital protection
  • AD converter resolution
  • Nyquists theorem
  • Analog filters
  • Transducers
  • Sample and hold circuit

9
  • Let us assume that numerical values of some
    function x(t) are given at equally spaced
    intervals every ?t seconds.
  • 1/?t is then called sampling frequency.
  • Signal can then be represented by discrete set
    of samples
  • x(0), x(?t), x(2?t), , x(k?t),

10
AD converter resolution
  • Every sample of analog signal is converted in to
    digital value with final number of bits
  • Conversion is preformed in AD converter

11
  • 3 bit resolution 238 combinations, which
    means 8 discrete divisions that analog signal can
    be represented with

12
Nyquists theorem
  • Sampling frequency
  • (how often is AD conversion preformed)

13
Nyquists theorem
  • To avoid signal alias sampling frequency must be
    at least two times higher then maximum frequency
    component in analog signal
  • For accurate waveform representation sampling
    frequency should be at least 5 to 10 times higher
    then maximum frequency component in analog signal

14
Analog filtering
15
Transducers and surge protection circuits
  • Reduce voltages and currents (10 V and 20 to 40
    mA) to suit hardware requirements
  • Protect hardware from overvoltages
  • Signal distortion is the problem (current
    transducers saturation)

16
Sample and Hold circuit
17
Basic components of digital relay
18
Numerical differentiation
  • Derivatives in point k is

19
Numerical integration
Lagrange interpolation formula
20
Curve fitting
  • Linear fit
  • Exponential fit
  • General polynomial fit
  • General linear fit
  • Levenberg-Marquardt fit

21
Least square method
22
Fourier analysis
  • Fourier series
  • Fourier transform

23
Discrete Fourier transform DFT
  • Samples of signals from AD time domain
  • No need for curve fitting
  • Use DFT frequency domain

24
Smoothing Windows
25
Smoothing Windows
n0, 1, , N-1
26
Digital filters
  • Input signal is discrete
  • They are software programmable
  • They are stable and predictable
  • They do not drift with temperature or humidity
    and do not require precision components
  • They have superior performance to cost ratio
  • They do not age

27
Digital filters
28
Signal generator
29
Control loop
?t1/fs
30
Sine wave based algorithms
  • Waveform is assumed to be sinusoidal
  • They predict amplitude at every moment
  • They can be used for impedance calculation
  • Six are presented
  • Sample and first derivative with two points
  • Sample and first derivative with three points
  • First and second derivative
  • Two sample technique
  • Three sample technique
  • R i X calculation with three sample technique

31
Sample and first derivative with two points
32
Sample and first derivative with two points
33
Sample and first derivative with three points
34
Sample and first derivative with three points
35
First and second derivative
36
First and second derivative
37
Two sample technique
38
R i X calculation with three sample technique
39
R i X calculation with three sample technique
40
Fourier algorithms
  • Waveform does not have to be pure sine
  • The basic assumption is that the waveform is
    periodic
  • The principle of work is moving frame
  • Moving frame is constant in size which means that
    it always contains the same number of points

41
Fourier series with whole period
If fs is 600 Hz then in one period of 20 ms there
are 12 samples. Weighting factors are calculated
in advance for fixed samplin frequency.
42
Fourier series with whole period
43
Fourier series with whole period third harmonic
n3
44
Fourier series with whole period third harmonic
45
Fourier series with half period
46
FFT algorithm
47
Least squares based algorithms
  • All components of measured waveform must be
    predicted in mathematical model.
  • After curve fitting data about amplitude,
    harmonics, angle, etc. are obtained
  • Downside is large number of calculations
  • They are complex
  • Four of them are presented
  • Algorithm with general polynomial fit
  • LSQ 1, 3 multivariable algorithm
  • LSQ 1, 3, 5 multivariable algorithm
  • LSQ 1, 3, 5 ,7 multivariable algorithm

48
General polynomial fit algorithm
49
General polynomial fit algorithm
50
LSQ 1, 3 multivariable algorithm
51
LSQ 1, 3 multivariable algorithm
52
LSQ 1, 3, 5 multivariable algorithm
53
LSQ 1, 3, 5 multivariable algorithm
54
LSQ 1, 3, 5, 7 multivariable algorithm
55
LSQ 1, 3, 5, 7 multivariable algorithm
56
Differential equation based algorithm
  • There is no need to assume that the waveform is
    sine
  • The fundamental approach is based on the fact
    that all protected equipment can be represented
    by differential equations of first or second
    order.
  • The methods are described by reference to
    transmission line
  • Three algorithms are presented
  • Integration algorithm
  • Third harmonic filtration algorithm
  • Differential algorithm

57
Integration algorithm
58
Integration algorithm
59
Third harmonic filtration algorithm
For fs600 Hz
60
Third harmonic filtration algorithm
61
Differential algorithm
62
Differential algorithm
63
Differential algorithm
64
Algorithms and Real-Time operation
  • System is operating in real-time if it can
    guarantee fulfillment of various tasks in
    specific time
  • OS in real-time
  • Hardware and software in real time
  • Control loop time

65
Algorithms and Real-Time operation
66
Power system signal
67
Sine wave based algorithms
68
Fourier based algorithms
69
Least squares based algorithms
70
Differential equation based algorithms
71
Short circuit
72
Sinus wave based algorithms
73
Fourier based algorithms
74
Least squares based algorithms
75
Differential equation based algorithms
