Lecture 2: Data Mining

1
Lecture 2 Data Mining
2
Roadmap

• What is data mining?
• Data Mining Tasks
• Classification/Decision Tree
• Clustering
• Association Mining
• Data Mining Algorithms
• Decision Tree Construction
• Frequent 2-itemsets
• Frequent Itemsets (Apriori)
• Clustering/Collaborative Filtering

3
What is Data Mining?

• Discovery of useful, possibly unexpected,
  patterns in data.
• Subsidiary issues
• Data cleansing detection of bogus data.
• E.g., age 150.
• Visualization something better than megabyte
  files of output.
• Warehousing of data (for retrieval).

4
Typical Kinds of Patterns

1. Decision trees succinct ways to classify by
   testing properties.
2. Clusters another succinct classification by
   similarity of properties.
3. Bayes, hidden-Markov, and other statistical
   models, frequent-itemsets expose important
   associations within data.

5
Example Clusters
x xx x x x x x x x x x x x
x
x x x x x x x x x x x x
x x x
x x x x x x x x x x
x
6
Applications (Among Many)

• Intelligence-gathering.
• Total Information Awareness.
• Web Analysis.
• PageRank.
• Marketing.
• Run a sale on diapers raise the price of beer.
• Detective?

7
Cultures

• Databases concentrate on large-scale
  (non-main-memory) data.
• AI (machine-learning) concentrate on complex
  methods, small data.
• Statistics concentrate on inferring models.

8
Models vs. Analytic Processing

• To a database person, data-mining is a powerful
  form of analytic processing --- queries that
  examine large amounts of data.
• Result is the data that answers the query.
• To a statistician, data-mining is the inference
  of models.
• Result is the parameters of the model.

9
Meaningfulness of Answers

• A big risk when data mining is that you will
  discover patterns that are meaningless.
• Statisticians call it Bonferronis principle
  (roughly) if you look in more places for
  interesting patterns than your amount of data
  will support, you are bound to find crap.

10
Examples

• A big objection to TIA was that it was looking
  for so many vague connections that it was sure to
  find things that were bogus and thus violate
  innocents privacy.
• The Rhine Paradox a great example of how not to
  conduct scientific research.

11
Rhine Paradox --- (1)

• David Rhine was a parapsychologist in the 1950s
  who hypothesized that some people had
  Extra-Sensory Perception.
• He devised an experiment where subjects were
  asked to guess 10 hidden cards --- red or blue.
• He discovered that almost 1 in 1000 had ESP ---
  they were able to get all 10 right!

12
Rhine Paradox --- (2)

• He told these people they had ESP and called them
  in for another test of the same type.
• Alas, he discovered that almost all of them had
  lost their ESP.
• What did he conclude?
• Answer on next slide.

13
Rhine Paradox --- (3)

• He concluded that you shouldnt tell people they
  have ESP it causes them to lose it.

14
Data Mining Tasks

• Data mining is the process of semi-automatically
  analyzing large databases to find useful patterns

• Prediction based on past history
• Predict if a credit card applicant poses a good
  credit risk, based on some attributes (income,
  job type, age, ..) and past history
• Predict if a pattern of phone calling card usage
  is likely to be fraudulent
• Some examples of prediction mechanisms
• Classification
• Given a new item whose class is unknown, predict
  to which class it belongs
• Regression formulae
• Given a set of mappings for an unknown function,
  predict the function result for a new parameter
  value

15
Data Mining (Cont.)

• Descriptive Patterns
• Associations
• Find books that are often bought by similar
  customers. If a new such customer buys one such
  book, suggest the others too.
• Associations may be used as a first step in
  detecting causation
• E.g. association between exposure to chemical X
  and cancer,
• Clusters
• E.g. typhoid cases were clustered in an area
  surrounding a contaminated well
• Detection of clusters remains important in
  detecting epidemics

16
Decision Trees

• Example
• Conducted survey to see what customers were
  interested in new model car
• Want to select customers for advertising campaign

training set
17
One Possibility
agelt30
Y
N
citysf
carvan
Y
Y
N
N
likely
unlikely
likely
unlikely
18
Another Possibility
cartaurus
Y
N
citysf
agelt45
Y
Y
N
N
likely
unlikely
likely
unlikely
19
Issues

• Decision tree cannot be too deep
• would not have statistically significant amounts
  of data for lower decisions
• Need to select tree that most reliably predicts
  outcomes

20
Clustering
income
education
age
21
Another Example Text

• Each document is a vector
• e.g., lt100110...gt contains words 1,4,5,...
• Clusters contain similar documents
• Useful for understanding, searching documents

sports
international news
business
22
Issues

• Given desired number of clusters?
• Finding best clusters
• Are clusters semantically meaningful?

23
Association Rule Mining
transaction id
customer id
products bought
sales records
market-basket data

• Trend Products p5, p8 often bough together
• Trend Customer 12 likes product p9

24
Association Rule

• Rule p1, p3, p8
• Support number of baskets where these products
  appear
• High-support set support ? threshold s
• Problem find all high support sets

25
Finding High-Support Pairs

• Baskets(basket, item)
• SELECT I.item, J.item, COUNT(I.basket)FROM
  Baskets I, Baskets JWHERE I.basket J.basket
  AND I.item lt J.itemGROUP BY
  I.item, J.itemHAVING COUNT(I.basket) gt s

26
Example
27
Issues

• Performance for size 2 rules

even bigger!
big

• Performance for size k rules

28
Roadmap

• What is data mining?
• Data Mining Tasks
• Classification/Decision Tree
• Clustering
• Association Mining
• Data Mining Algorithms
• Decision Tree Construction
• Frequent 2-itemsets
• Frequent Itemsets (Apriori)
• Clustering/Collaborative Filtering

29
Classification Rules

• Classification rules help assign new objects to
  classes.
• E.g., given a new automobile insurance applicant,
  should he or she be classified as low risk,
  medium risk or high risk?
• Classification rules for above example could use
  a variety of data, such as educational level,
  salary, age, etc.
• ? person P, P.degree masters and P.income gt
  75,000
•
  ? P.credit excellent
• ? person P, P.degree bachelors and
  (P.income ? 25,000 and P.income ?
  75,000)
  ? P.credit good
• Rules are not necessarily exact there may be
  some misclassifications
• Classification rules can be shown compactly as a
  decision tree.

30
Decision Tree
31
Decision Tree Construction
Employed
Root
No
Yes
ClassNot Default
Node
Balance
gt50K
lt50K
ClassYes Default
Age
Leaf
gt45
lt45
ClassNot Default
ClassYes Default
32
Construction of Decision Trees

• Training set a data sample in which the
  classification is already known.
• Greedy top down generation of decision trees.
• Each internal node of the tree partitions the
  data into groups based on a partitioning
  attribute, and a partitioning condition for the
  node
• Leaf node
• all (or most) of the items at the node belong to
  the same class, or
• all attributes have been considered, and no
  further partitioning is possible.

33
Finding the Best Split Point for Numerical
Attributes
The data comes from a IBM Quest synthetic dataset
for function 0
Best Split Point
In-core algorithms, such as C4.5, will just
online sort the numerical attributes!
34
Best Splits

• Pick best attributes and conditions on which to
  partition
• The purity of a set S of training instances can
  be measured quantitatively in several ways.
• Notation number of classes k, number of
  instances S, fraction of instances in class
  i pi.
• The Gini measure of purity is defined as
• Gini (S) 1 - ?
• When all instances are in a single class, the
  Gini value is 0
• It reaches its maximum (of 1 1 /k) if each class
  the same number of instances.

35
Best Splits (Cont.)

• Another measure of purity is the entropy measure,
  which is defined as
• entropy (S) ?
• When a set S is split into multiple sets Si, I1,
  2, , r, we can measure the purity of the
  resultant set of sets as
• purity(S1, S2, .., Sr) ?
• The information gain due to particular split of S
  into Si, i 1, 2, ., r
• Information-gain (S, S1, S2, ., Sr)
  purity(S ) purity (S1, S2, Sr)

36
Finding Best Splits

• Categorical attributes (with no meaningful
  order)
• Multi-way split, one child for each value
• Binary split try all possible breakup of values
  into two sets, and pick the best
• Continuous-valued attributes (can be sorted in a
  meaningful order)
• Binary split
• Sort values, try each as a split point
• E.g. if values are 1, 10, 15, 25, split at ?1,
  ? 10, ? 15
• Pick the value that gives best split
• Multi-way split
• A series of binary splits on the same attribute
  has roughly equivalent effect

37
Decision-Tree Construction Algorithm

• Procedure GrowTree (S ) Partition (S
  )Procedure Partition (S) if ( purity (S ) gt
  ?p or S lt ?s ) then return for each
  attribute A evaluate splits on attribute
  A Use best split found (across all attributes)
  to partition S into S1, S2, ., Sr, for
  i 1, 2, .., r Partition (Si )

38
Finding Association Rules

• We are generally only interested in association
  rules with reasonably high support (e.g. support
  of 2 or greater)
• Naïve algorithm
• Consider all possible sets of relevant items.
• For each set find its support (i.e. count how
  many transactions purchase all items in the
  set).
• Large itemsets sets with sufficiently high
  support

39
Example Association Rules

• How do we perform rule mining efficiently?
• Observation If set X has support t, then each X
  subset must have at least support t
• For 2-sets
• if we need support s for i, j
• then each i, j must appear in at least s baskets

40
Algorithm for 2-Sets

• (1) Find OK products
• those appearing in s or more baskets
• (2) Find high-support pairs using only OK
  products

41
Algorithm for 2-Sets

• INSERT INTO okBaskets(basket, item) SELECT
  basket, item FROM Baskets GROUP BY item
  HAVING COUNT(basket) gt s
• Perform mining on okBaskets SELECT I.item,
  J.item, COUNT(I.basket) FROM okBaskets I,
  okBaskets J WHERE I.basket J.basket AND
  I.item lt J.item GROUP BY
  I.item, J.item HAVING COUNT(I.basket) gt s

42
Counting Efficiently

• One way

threshold 3
43
Counting Efficiently

• Another way

threshold 3
44
Yet Another Way
threshold 3
false positive
45
Discussion

• Hashing scheme 2 (or 3) scans of data
• Sorting scheme requires a sort!
• Hashing works well if few high-support pairs and
  many low-support ones

iceberg queries
46
Frequent Itemsets Mining
TID Transactions
100 A, B, E
200 B, D
300 A, B, E
400 A, C
500 B, C
600 A, C
700 A, B
800 A, B, C, E
900 A, B, C
1000 A, C, E

• Desired frequency 50 (support level)
• A,B,C,A,B, A,C
• Down-closure (apriori) property
• If an itemset is frequent, all of its subset must
  also be frequent

47
Lattice for Enumerating Frequent Itemsets
48
Apriori

• L0 ?
• C1 1-item subsets of all the
  transactions
• For ( k1 Ck ? 0 k )
• support counting
• for all transactions t ? D
• for all k-subsets s of t
• if k ? Ck
• s.count
• candidates generation
• Lk c ? Ck c.countgt min
  sup
• Ck1 apriori_gen( Lk )
• Answer UkLk

49
Clustering

• Clustering Intuitively, finding clusters of
  points in the given data such that similar points
  lie in the same cluster
• Can be formalized using distance metrics in
  several ways
• Group points into k sets (for a given k) such
  that the average distance of points from the
  centroid of their assigned group is minimized
• Centroid point defined by taking average of
  coordinates in each dimension.
• Another metric minimize average distance between
  every pair of points in a cluster
• Has been studied extensively in statistics, but
  on small data sets
• Data mining systems aim at clustering techniques
  that can handle very large data sets
• E.g. the Birch clustering algorithm!

50
K-Means Clustering
51
K-means Clustering

• Partitional clustering approach
• Each cluster is associated with a centroid
  (center point)
• Each point is assigned to the cluster with the
  closest centroid
• Number of clusters, K, must be specified
• The basic algorithm is very simple

52
Hierarchical Clustering

• Example from biological classification
• (the word classification here does not mean a
  prediction mechanism)
• chordata
  mammalia
  reptilialeopards humans snakes
  crocodiles
• Other examples Internet directory systems (e.g.
  Yahoo!)
• Agglomerative clustering algorithms
• Build small clusters, then cluster small clusters
  into bigger clusters, and so on
• Divisive clustering algorithms
• Start with all items in a single cluster,
  repeatedly refine (break) clusters into smaller
  ones

53
Collaborative Filtering

• Goal predict what movies/books/ a person may be
  interested in, on the basis of
• Past preferences of the person
• Other people with similar past preferences
• The preferences of such people for a new
  movie/book/
• One approach based on repeated clustering
• Cluster people on the basis of preferences for
  movies
• Then cluster movies on the basis of being liked
  by the same clusters of people
• Again cluster people based on their preferences
  for (the newly created clusters of) movies
• Repeat above till equilibrium
• Above problem is an instance of collaborative
  filtering, where users collaborate in the task of
  filtering information to find information of
  interest

54
Other Types of Mining

• Text mining application of data mining to
  textual documents
• cluster Web pages to find related pages
• cluster pages a user has visited to organize
  their visit history
• classify Web pages automatically into a Web
  directory
• Data visualization systems help users examine
  large volumes of data and detect patterns
  visually
• Can visually encode large amounts of information
  on a single screen
• Humans are very good a detecting visual patterns

55
Data Streams

• What are Data Streams?
• Continuous streams
• Huge, Fast, and Changing
• Why Data Streams?
• The arriving speed of streams and the huge amount
  of data are beyond our capability to store them.
• Real-time processing
• Window Models
• Landscape window (Entire Data Stream)
• Sliding Window
• Damped Window
• Mining Data Stream

56
A Simple Problem

• Finding frequent items
• Given a sequence (x1,xN) where xi ?1,m, and a
  real number ? between zero and one.
• Looking for xi whose frequency gt ?
• Naïve Algorithm (m counters)
• The number of frequent items 1/?
• Problem Ngtgtmgtgt1/?

57
KRP algorithm - Karp, et. al (TODS 03)
N30
m12
T0.35
N/ (?1/??) N?
?1/?? 3
58
Enhance the Accuracy
m12
N30
NTgt10
T0.35
?1/?? 3
e0.5 T(1- e )0.175
?1/(?e)? 6
59
Frequent Items for Transactions with Fixed Length
Each transaction has 2 items T0.60
?1/??2 4
