Programming in C

1
Programming in C

• Miscellaneous Topics

2
Fixed 2-d Arrays

• Number of rows and columns fixed at compile
  timeint gameBoard 5 3
• 5 rows, 3 columns
• Use 2-d indexingint x gameBoard row col

(0,0) (0,1) (0,2)
(1,0) (1,1) (1,2)
(2,0) (2,1) (2,2)
(3,0) (3,1) (3,2)
(4,0) (4,1) (4,2)
3
Dynamic 2-d Arrays (1)

• Number of rows fixed at compile time, but
  variable number of columns in each row
• Really an array of int, where each int points
  to the row.
• Indexing with row / column still ok
• 3 rows, each dynamically allocated with
  (possibly) different number of columns (row
  sizes)
• int gameBoard 3
• The rows, possibly different sizes
• gameBoard 0 (int )malloc( 4 sizeof( int
  )) gameBoard 1 (int )malloc( 6 sizeof(
  int )) gameBoard 2 (int )malloc( 8
  sizeof( int ))

4
Dynamic 2-d Arrays (2)

• Number of rows and columns dynamically allocated.
• Indexing with row / column still ok
• A pointer to the (first element of the) array of
  row pointers
• int gameBoard
• The array of row pointers
• gameBoard (int )malloc( 3 sizeof( int
  ))
• The rows, possibly different sizes
• gameBoard 0 (int )malloc( 4 sizeof( int
  ))gameBoard 1 (int )malloc( 6 sizeof(
  int ))gameBoard 2 (int )malloc( 8
  sizeof( int ))

5
Compiler directives

• Compiler directives begin with and are
  interpreted by the preprocessor
• The most common directives are
• include
• Used for file inclusion (See KR 4.11.1)
• define
• Used for constant/macro definitions (see KR
  4.11.2)
• if, ifdef, ifndef, else, elif, endif
• Used for conditional compilation (see KR 4.11.3)

6
include

• The include directive is used to include the
  contents of another file into the file being
  compiled. It is usually used to include header
  (.h) files into the source. include files may
  be nested so that one .h file may include
  another .h file
• A line of the form include ltfilenamegt
• causes replacement of that line by the entire
  contents of the file filename. The named file is
  searched for in implementation specific places,
  usually /usr/include on Linux
• Similarly, a line of the form
• include filename
• first searches in the same directory as the
  source file, and if that search fails, continues
  searching as above.

7
define

• A line of the formdefine identifier
  token-sequence
• Causes the preprocessor to replace all
  occurrences of identifier with the token-sequence
  (except in quoted strings). Note that this is a
  text replacement.
• defines are most commonly used to give names to
  magic constants
• For example
• define MAXSIZE 100
• replaces every occurrence of MAXSIZE with 100 as
  in int tableMAXSIZE

8
define macros

• The define directive may also be used to create
  a simple macro.
• Care must be taken when writing macros and when
  calling macros because the arguments are copied
  literally.
• For example, the simple macro below doesnt work
  properly in all instances.
• define SQUARE(x) x x
• Assuming int z 4, what is the value of y after
  the assignment
• int y SQUARE( z - 1 )
• Even when written correctly as
• define SQUARE(x) (x) (x)
• Calling the macro may result in erroneous side
  effects.
• Assuming again that int z 4, what is the value
  of z after the assignment
• int y SQUARE( z )
• Nonetheless, macros like this can make code
  easier to read as well see later

9
Importing defines

• The most common way to define symbols is within
  your .c file
• define DEBUG
• define MAX 100
• It is also possible to import defines on the
  compiler command line
• gcc -o myProg -DDEBUG -DMAX100 myProg.c
• You cannot use the command line to redefine a
  symbol already defined in your .c file

10
Predefined Constants

• The C pre-processor predefines several define
  constants
• __FILE__ is the name of the file being compiled
• __LINE__ is the current line number being
  compiled
• These may be helpful if printed as part of debug
  output
• printf(Bad Input s, d\n, __FILE__,
  __LINE__)

11
assert( )

• The C library provides a macro named assert( )
  which can be very helpful for debugging
• The parameter to assert is any boolean expression
  -- assert( expression )
• If the boolean expression is true, nothing
  happens and execution continues on the next line
• If the boolean expression is false, a message is
  printed to stderr and your program terminates
• To use assert( ), you must include ltassert.hgt
• assert( ) may be disabled by define NDEBUG
  prior to include ltassert.hgt
• Or by importing NDEBUG via the command line

12
Using assert( )

• Use assert( ) to verify an array index
• int scores100
• int k ltsome complicated calculation gt
• assert( k gt 0 k lt 1000 )
• Use assert( ) to check for NULL pointers
• int ptr malloc( 4 sizeof( int ) )
• assert( ptr ! NULL)
• Use assert( ) to check functions that shouldnt
  fail
• int errorCode foo ( )
• assert( errorCode 0) / but NOT assert(foo(
  ) 0) /

13
Conditional Compilation

• The preprocessor directives ifdef (read as if
  defined), ifndef (read as if not defined),
  if, else, elif (read as else if), and endif
  (together with defines) can be used to control
  which lines in a course file are compiled and
  which are not. Each directive appears on a
  separate line.
• Each if and subsequent elif is evaluated as
  true (1) or false (0) based on the definition (or
  lack of definition) of the identifier that
  follows. Lines that follow a false (0)
  evaluation are skipped.
• Conditional compilation is frequently used to
  avoid multiple inclusions of the same header (.h)
  file, compiling lines used for debugging, and (in
  system level .h files) to compile certain lines
  based on the type of system on which the program
  is being compiled.

14
Conditional Compilationfor header files

• Header (.h) files should only be included once in
  a source file to avoid compilation errors.
  Suppose the file myheader.h is included into
  some source file. The .h files should be
  guarded as follows
• ifndef MYHEADER_H / same as if
  !defined(MYHEADER_H) /
• define MYHEADER_H
• ....
• ...
• endif
• How does this work?
• Whenever the compiler includes myheader.h, the
  ifndef checks to see if the identifier
  MYHEADER_H has be defined. The first time
  myheader.h is included, MYHEADER_H will not have
  been defined so the lines in the header file (in
  particular define MYHEADER_H) will be included
  into the source file. Thereafter, when the
  compiler subsequently tries to include
  myheader.h, the ifndef will evaluate to false
  (because MYHEADER_H is now defined) and all lines
  in myheader.h will be skipped, avoiding duplicate
  inclusion.

15
Conditional Compilation for Debugging

• One simple way of debugging a program is to
  insert printf( ) statements are strategic points
  in the code. When the program is run, the output
  of these printf( ) statements help you debug your
  program. When the program is bug free, these
  printf( ) statements are removed from your code.
• Rather than removing the printf( ) statements by
  editting your code, conditional compilation can
  be used to allow or prevent them from being
  executed.

16
debug.c

• ifdef DEBUG_ON
• define DEBUG(x) printf(x)
• else
• define DEBUG(x)
• endif
• int main (int argc, char argv )
• int i, count, sum 0
• assert( arcg 2)
• DEBUG( "Command Line arg is s\n,
  argv1)
• count atoi( argv1 )
• DEBUG( "Entering for loop\n")
• for (i 0 i lt count i)
• sum i
• DEBUG ("exited for loop\n")
• printf("sum d\n", sum)

17
Program organization

• main( ) is generally defined in its own .c file
  and generally just calls helper functions
• Program-specific helper functions in another .c
  file
• If there are very few helpers, they can be in the
  same file as main( )
• Reusable functions in their own .c file
• Group related functions in the same file
• Each struct or union
• Defined in a separate .h file
• Related functions in a separate .c file
• File names should be indicative of the struct
  name

18
Variable Scope and Lifetime

• The scope of a variable refers to that part of a
  program that may refer to the variable.
• The lifetime of a variable refers to the time in
  which a variable occupies a place in memory
• The scope and lifetime of a variable are
  determined by how and where the variable is
  defined

19
Global Variables

• Global (external) variables are defined outside
  of any function, near the top of your .c file.
• May be used anywhere in the .c file in which they
  are defined.
• Exist for the duration of your program
• May be used by any other .c file in your program
  that declares them as extern (unless also
  defined as static)
• Static global variables may only be used in the
  .c file that declares them
• extern declarations for global variables should
  be placed into a header file

20
Local variables

• Local variables are defined within the opening
  and closing braces of a function, loop,
  if-statement, etc. Function parameters are local
  to the function.
• Are usable only within the braces in which they
  are defined
• Exist only during the execution of the block
  unless also defined as static
• Static local variables retain their values for
  the duration of your program. Usually used in
  functions, they retain their values between calls
  to the function.

21
Function Scope

• All functions are external because C does not
  allow nesting of function definitions.
• So no extern declaration is needed
• All functions may be called from any .c file in
  your program unless they are also declared as
  static.
• Static functions may only be used within the .c
  file in which they are defined

22
variableScope.c - part 1

• include ltstdio.hgt
• // extern definition of randomInt and prototype
  for getRandomInt
• include randomInt.h
• / a global variable that can only be used
• by functions in this .c file /
• static int inputValue
• / a function that can only be called by other
  functions
• in this .c file /
• static void inputPositiveInt( char prompt )
• / init to invalid value to enter while loop
  /
• inputValue -1
• while (inputValue lt 0)
• printf( "s", prompt)

23
variableScope.c - part 2

• / main is the entry point for all programs /
• int main( )
• / local/automatic variables that can only be
  used in this function and that are destroyed when
  the function ends /
• int i, maxValue, nrValues
• inputPositiveInt("Input max random value to
  generate ")
• maxValue inputValue
• inputPositiveInt("Input number of random ints
  to generate ")
• nrValues inputValue
• for (i 0 i lt nrValues i)
• getRandomInt( maxValue )
• printf( d d\n", i 1, randomInt )
• return 0 / successful completion /

24
randomInt.c

• / a global variable to be used by code in other
  .c files.
• This variable exists until the program ends
• Other .c files must declare this variable as
  "extern"
• holds the random number that was generated /
• int randomInt
• / a function that can be called from any other
  function
• returns a random integer from 1 to max,
  inclusive /
• void getRandomInt( int max )
• / a local variable that can only be used
  inside this function,
• but persists between calls to this function
  /
• static long lastRandom 100001
• lastRandom (lastRandom 125) 2796203
• randomInt (lastRandom max) 1

25
randomInt.h

• ifndef RANDOMINT_H
• define RANDOMINT_H
• // global variable in randomint.c
• // set by calling getRandomInt( )
• extern int randomInt
• // prototypes for function in randomInt.c
• void getRandomInt(int max )
• endif
