Java Portlets (JSR-168)

1
Java Portlets(JSR-168)

• SSE USTC
• Qing Ding

2
Agenda

• Java Portlet (JSR 168)
• WSRP
• Products (only a few slides)
• Sun Java Enterprise Systeem Portal Server,
  Portlet Builder

3

• What is a Portlet?

4
What is a Portlet?

• Java technology based web component
• Managed by a portal container
• Generates a piece of markup called fragment
• Adheres to certain rules such as no lthtmlgt tags,
  for instance
• Fragment generated by a Portlet aggregates with
  that from other Portlets to form a portal page
• Fragment generated by a Portlet may vary from one
  user to another depending on the user
  configuration

5
What does JSR-168 define?

• Portlet API
• Portlet Requests
• Preferences
• User information
• Security
• Deployment packaging
• Portlet Container
• Extension of servlet container
• Contract between component and container

6
What are out-scope of JSR 168?

• Aggregation
• Layout management
• Page personalization and configuration engines
• Portal administration and configuration

7
Default Desktop
8
Portal/Portlet Architecture
9
Portal and Portlet Interaction
10

• Why Portlet?
• (Why can't we use Servlet?)

11
Why Portlets?

• Servlet architecture does not define the Desktop
  metaphor where markup aggregation can occur
• Servlet architecture does not define the possible
  states and transitions of an included Servlet or
  JSP
• Servlet architecture does not define how the
  state of one Servlet or JSP affects the display
  of the other included Servlets or JSPs

12
Why Portlets?

• Servlet architecture does not define a
  personalization interface nor the idea of
  persisting the personalization information
• Servlet architecture does not define URLrewriting
  functions to allow the creation of links and
  actions targeted to a specific form within the
  fragment of a page (Portlet markup fragment)
• Servlet architecture does not support caching
  scheme of fragments

13
(No Transcript)
14

• Portlet Architecture

15
Portal ArchitectureWith JSR 168 Support
16
Portal

• A specialized web application that provides
  value-added services such as
• Personalization
• Single Sign-On
• Content aggregation from various sources
• Secure search facilities
• Localization of content
• A Portal page represents a complete markup
  document consisting of several Portlet components

17
Portlet Container

• Portlets are deployed in a Portlet container such
  that container can
• Provides runtime environment for Portlets
• Manage life cycle of Portlets
• Provide persistent storage for storing Portlet
  preferences
• Cache the portlets
• Receive requests from the portal to execute
  requests on the portlet
• Not responsible for contents aggregation

18

• Portlet vs. Servlet
• (Portlet is built over
• Servlet Architecture)

19
Similarity with Servlet

• Both are Java technology based web components
• Life-cycle is managed by a specialized container
• Servlet by servlet container
• Portlet by portlet container
• Both generate dynamic content
• Both interact with web client via a
  request/response paradigm

20

• Deployment model
• Classloading
• Packaging and deployment
• Lifecycle management
• Session management
• Request dispatching

21
Differences from Servlet

• Portlets only generate markup fragments, not
  complete documents
• Portlets are not directly bound to a URL
• Web clients interact with portlets through a
  portal system
• Portlets have a more refined request handling
• action requests and render requests
• Portlets have predefined states
• portlet modes and window states
• Portlets can exist many times in a portal page

22
Extra Features of Portlets

• Portlets have means for accessing and storing
  persistent configuration and customization data
• Portlets have access to user profile information
• Portlets have URL rewriting functions for
  creating hyperlinks within their content
• allow portal server agnostic creation of links
  and actions in page fragments
• Portlets can store transient data in the portlet
  session in two different scopes
• application-wide scope
• the portlet private scope

23
Servlet Features Forbidden to Portlets

• Setting the character set encoding of the
  response
• Setting HTTP headers on the response
• The URL of the client request to the portal

24
Servlet Features that are leveraged by Portlets

• Portlets can leverage servlets, JSPs and JSP
  tag-libraries for generating content
• Content should be markup fragment
• A portlet can call servlets and JSPs using a
  request dispatcher

25
Integration between the two

• Attributes set in the portlet request are
  available in the included servlet request
• Attributes set in the portlet session are
  accessible from the servlet session and vice
  versa
• Portlet and the included servlet or JSP share the
  same output stream

26

• Portlet and
• Web App. Frameworks

27

• Struts/JSF are built over Servlets
• Struts/JSF can be built over Portlets
• APIs exposed to Struts/JSF developers should
  remain the same
• Struts/JSF developers must be aware of the markup
  fragment he has to produce
• The markup fragment must follow the rules
• Generate Portlet URL

28
Exo Portal Build on JSF, Struts
29

• Portlet Modes
• Windows State

30
Portlet Modes

• Indicates function that a portlet performs
• Execute different tasks and generate different
  content based on the function they perform
• Portals must support three modes
• VIEW
• Portlet renders markup fragment in this mode
• EDIT
• Used to change per-user settings to customize
  rendering
• HELP
• Used to display help information

31
Portlet Modes (Contd.)

• Portals might support other custom modes
• ABOUT
• CONFIG
• EDIT_DEFAULTS
• PREVIEW
• PRINT
• Portals might support other vendor specific modes

32
Windows State

• Is an indicator of the amount of portal page
  space that will be assigned to the content
  generated by a portlet
• Provided by portlet container
• Three states
• NORMAL
• MAXIMIZED
• MINIMIZED
• Custom states are possible

33

• Portlet Features

34
Portlet Persistence

• Portlets can store persistent data for a given
  user in a PortletPreferences object
• Preferences are read-write in the action phase
  (processAction()) and read-only in render phase
• Usually user preferences are modified in EDIT
  mode

35
User Profile Attributes

• Can store information about user that can be used
  to personalize content for that user
• User profile information is represented as a
  USER_INFO structure which is then mapped to the
  real information in datastore
• Portlet defines the attributes it wants to access
  in the deployment descriptor

36
Portal context

• Can provide information on
• Portal vendor
• Version
• Used by portlets to find out more information
  about additional extensions supported by Portal

37
Security

• Authentication is left to the underlying servlet
  container
• Authorization
• Follows J2EE roles model
• Supports programmatic role checking

38
Session Management

• Facade on top of the HttpSession
• Two scopes APPLICATION PORTLET
• PORTLET is a convenience namespacing
• Its common for portlets to appear more than once
  in a page (i.e. EU-News, US-News)
• Servlets, JSPs and Portlets within a Portlet
  Application share the same session
• Session creation event notification is supported

39
Portlet Request Dispatcher

• Portlets can include Servlets, JSPs and static
  content during a render request
• Similar to Servlets RequestDispatcher

40
Localization

• Portlets can be localized by using resource
  bundles
• Resource bundles are specified in deployment
  descriptor
• Portlet can access resource bundle via
  PortletContext.getResourceBundle() API

41
Caching

• Expiration based caching
• Declarative caching
• Specify ltexpiration-cachegt element in deployment
  descriptor for the portlet
• Programmatic caching
• Modify EXPIRATION_CACHE property of render
  response

42
Portlet URL

• Portlets are always accessed through a Portal
• Portlets do not have a direct URL mapping
• Portlet URLs allow Portlets to create URLs that
  target to themselves (through the Portal
  end-point)

43

• Portlet API's

44
(No Transcript)
45
Portlet Life Cycle
46
GenericPortlet class

• Implements Portlet interface
• Render()--like service() in servlets, calls
  specified render methods based on Portlet mode
• doView() for View mode
• doEdit() for Edit mode
• doHelp() for Help mode
• Is extended by portlet developers
• Override render methods as necessary

47
DoView()
48
DoEdit()
49
ProcessAction()
50
Other Interfaces/Classes

• PortletConfig, PortletContext,
• PortalContext,PortletSession
• PortletPreferences interface
• WindowState (MINIMIZED,
• NORMAL MAXIMIZED)
• PortletMode (VIEW, EDIT HELP)
• PortletURL
• PortletRequestDispatcher
• Portlet Tag Library

51
PortletPreferences

• Persistent read/write Portlet configuration
• getValues(), setValues() to access
  PortletPreferences
• May modify attributes and store() in persistence
  during processAction()
• Normally, portlet preferences are per portlet/per
  user
• Persistency is managed by the portletcontainer
• Default values are defined in the portlet.xml
  deployment descriptor

52
Portlet Example portlet class
53

• Packaging
• Deployment

54
Portlet Web Application

• All resources, portlets, deployment descriptors
  are packaged in one web application archive (WAR
  file)
• PortletApp\
• jsp
• htmls
• WEB-INF\
• web.xml
• portlet.xml
• sun-portlet.xml
• classes\
• Lib\

55
Portlet Example portlet.xml
56

• WeatherPortlet
• Sample Code

57
WeatherPortlet
58
WeatherPortlet (1 of 7)
59
WeatherPortlet (2 of 7)
60
WeatherPortlet (3 of 7)
61
WeatherPortlet (4 of 7)
62
WeatherPortlet (5 of 7)
63
WeatherPortlet (6 of 7)
64
portlet.xml
65

• WSRP
• (Web Services for
• Remote Portlet)

66
WSRP Value Proposition

• Provides protocols and metadata for
• Presentation-oriented Web services
• Meant for aggregation and syndication with no
  programming on the consumer side
• Roles
• WSRP Producers (Web service provider)
• WSRP Consumers (Web service consumer)

67
Portal ArchitectureWith WSRP Support
68
JSR168 and WSRP

• They were designed in collaboration mode
• Their functionality is fully aligned
• PortletPortlet.processAction()
• WSRP WSRP.performBlockingInteraction()
• Portlet Portlet.render()
• WSRP WSRP.getMarkup()

69

• Sun Java SystemPortal Server

70
Integrated CommunicationsDesktop and Wireless
Access
71
Personalization

• Modify any aspect of the desktop (as allowed by
  the Administrator)
• Add or delete portlets
• Customize the desktop layout
• Use or create personalized themes
• Modify or create multiple tabs
• Update user profile information
• Modify portlets settings and properties

72
Sun Java System Portal Server andPortal standards

• Sun Java System Portal Server supports JSR 168
• WSRP will be supported in the first Sun Java
  System update

73
Sun Java SystemPortal Server Architecture

• How do JSR168 and WSRP fit in ?

74
Sun ONE Portal Server withJSR 168 and
integration to EIS
75

• Sun Java Studio
• Portlet Builder

76
Portlet Builder

• Portlet development plug-in for Sun JavaTM Studio
• Easy development
• It has wizards
• It creates and updates the portlet.xml
• Supports portlets execution, debugging and
  deployment within the Studio IDE
• Runs in Sun JavaTM Studio 4.x and 5.x

77
(No Transcript)
78
(No Transcript)
79

• Resources

80
Resources

• JSR 168
• http//www.jcp.org/jsr/detail/168.jsp
• SunTM ONE Portal Server
• http//wwws.sun.com/software/products/portal_srvr/
  home_portal.html
• Sun ONE Portlet Builder
• http//wwws.sun.com/software/download/products/3f1
  87b02.html
• WSRP _at_ OASIS
• http//www.oasis-open.org/committees/wsrp/
• WSRP _at_ XML Cover Pages
• http//xml.coverpages.org/wsrp.html
