MOHAMMAD AKTERUZZAMAN

1

MODELING and SIMULATION OF HYDRAULIC POWER
STEERING SYSTEM WITH MATLAB

• MOHAMMAD AKTERUZZAMAN
• Advisor DR. SHUVRA DAS

2
MODELING and SIMULATION OF HYDRAULIC POWER
STEERING SYSTEM

• MODELING OF the MECHANICAL and HYDRAULIC
  COMPONENTS of a POWER STEERING SYSTEM.
• SIMULATION OF THE MODEL BY MATLAB.
• Model REPRESENTS THE DYNAMIC RESPONSES OF THE
  power Steering System AND is CAPABLE OF
  ESTIMATING the effect of parameters on system
  response.
• Model is used to study the effect of various
  system parameters on system response.

3
PRIOR WORK

• Discussion of Reference Model
• Ali Keyhani He presents the identification of
  the dynamic model for a power steering system
  constructed using a rotary valve based on
  Mathematical (ODE).
• Jose J. Granda Analyze a multi energy non
  linear system using a bond graph model.
• Joel E. Birching He describes a method of
  applying the orifice equation to a steering valve
  along with the procedure for experimentally
  determining the flow Co-efficient for this
  equation.

4
Prior Work

• AMESim (Object oriented software) This case
  study gives us a good understanding of how AMESim
  can be used to construct parameterize and analyze
  complex hydro-mechanical dynamic model like power
  steering system.
• N.Riva, E.Suraci (ADAMS based work) A methology
  has developed to simulate the vehicle dynamics
  through Adams Car and Matlab co-simulation.

5
Prior Work

• We took Ali Keyhanis dynamic power steering
  model consisting of ordinary differential
  equations for Mechanical and Hydraulic system.
• Some of the design Parameters are difficult to
  obtain. Ali Keyhani used experimental data
  least square approach to determine these
  parameters.

6
(No Transcript)
7
(No Transcript)
8
ACTUAL POWER STEERING SYSTEM
9
SCHEMATIC DIAGRAM OF HYDRO-POWERSTEERING SYSTEM
10
ALI KEYHANI MODEL Mechanical subsystem
11
ALI KEYHANI MODEL Mechanical subsystem

• The equations for the steering column, pinion and
  rack can be written
• Equation 1
• Equation 2

12
ALI KEYHANI MODEL Mechanical subsystem

• Where TdTorque generated by the driver,
• Theta1rotational displacement for the steering
  column,
• K2tire stiffness
• B2Viscous damping coefficient
• B1friction constant of the upper-steering column
• Xdisplacement of the rack
• m mass of pinion
• Ap Piston area
• K1torsion bar stiffness
• J1Inertia constant of the upper steering column

13
ALI KEYHANI MODEL Mechanical subsystem

• The following assumptions were made
• -the pressure forces on the spool are neglected.
• -the stiffness of the steering column is
  infinite.
• -the inertia of the lower steering column (valve
  spool and pinion) is lumped into the rack mass.

14
ALI KEYHANI MODEL hydraulic subsystem
15
ALI KEYHANI MODEL hydraulic subsystem

• By applying the orifice equations to the rotary
  valve metering orifices and mass conservation
  equations to the entire hydraulic subsystem the
  following equation are obtained
• Equation 1
• Equation 2
• Equation 3

16
ALI KEYHANI MODEL hydraulic subsystem

• Where Ps and Po supply and return pressure of
  the pump.
• Pl and Pr cylinder pressure on the left and
  right side.
• Q supply flow rate of the pump
• A1 and A2 are the metering orifice area
• Rho density of the fluid
• Betabulk modulus of fluid
• Llength of the cylinder
• Cd discharge co-efficient

17
ALI KEYHANI MODEL hydraulic subsystem

• The following assumption were made
• -there is no pressure drop on the fluid
  transmission lines between the pump and the valve
  and the cylinder.
• -the wave dynamics on the fluid transmission
  lines are neglected
• -the bulk modulus of the fluid is considered
  constant
• -the inertance of the fluid is neglected
• -there is no leakage at the piston-cylinder
  interface
• -the return pressure dynamics are negligible

18
ALI KEYHANIS PARAMETER TABLE from experimental
19
ALI KEYHANIS PARAMETER TABLE from experimental
20
Information lacking in ALI KEYHANIs Work

• -Missing relationship for variation of A(theta),
  Torque and Flow rate Q.
• -His established parameters do not say from which
  type of vehicle they were obtained.

21
How We got the value of A(theta)
22
Value of Q

• Q1.5 GPM (gallon per minute) for reasonable
  minimum with the quicker steering ratios for
  pavement cars.
• Q2.5 GPM for dirt .
• (reference power steering Tech,
  www.woodwardsteering.com)
• ? Q.0002 m3/s
• (reference H.Chai. Electromechanical Motion
  Devices, Upper addle River, NJPrentice Hall
  PTR,1998)

23
Value of Torque

• Td0-8 N-m is not enough to excite the lower
  steering column modes.
• (reference Ali Keyhani)
• Td0-2 N-m is required at the handwheel during
  normal driving ranges.
• Td15 N-m in extreme cases.
• (reference H.Chai. Electromechanical Motion
  Devices, Upper addle River, NJPrentice Hall
  PTR,1998)

24
Model

• Using the equations and input data a MATLAB based
  program was written
• Model parameters were adjusted to obtain the
  results reported by Ali Keyhani

25
ResultsComparison from Ali-keyani model
26
ResultsComparison from Ali-keyani model
27
ResultsComparism from ali-keyani model
28
Resultsfrom different study (Tom Wong)
29
Results from different study

• Include the other results that I had suggested.
  (driver torque Vs. assist torques, also in
  previous pages copy fig from reference)

30
Response graph Effect on theta(radians) Torque
Td2, 9, 15 N-m
31
Response graph Effect on cylinder pressure
Torque Td2, 9, 15 N-m
32
Response graph Effect on rack Assist pressure
vs. rotation angle (theta)Torque Td2, 9, 15 N-m
33
Response graph Effect on pump pressureTorque
Td2, 9, 15 N-m
34
Response graph Effect on assist pressure w.r.t
rotation on degreePump flow rate,
Q0.00014,0.00016,0.00024 m3/S.
35
Response graph Effect on Pump pressurePump
flow rate, Q0.00014,0.00016,0.00024 m3/S.
36
Response graph Effect on displacement (X)Pump
flow rate, Q0.00014,0.00016,0.00024 m3/S.
37
Response graph Effect on cylinder pressurePump
flow rate, Q0.00014,0.00016,0.00024 m3/S.
38
Response graph Effect on thetaPump flow rate,
Q0.00014,0.00016,0.00024 m3/S.
39
Response graph Effect on Assist pressure on
rotation angle (degree)J1.0000322, .0000598
N-m-s2/rad
40
Response graph Effect on pump pressure
J1.0000322, .0000598 N-m-s2/rad
41
Response graph Effect on rack displacement (X)
in meterJ1.0000322, .0000598 N-m-s2/rad
42
Response graph Effect on right cylinder
pressure( N/m2)J1.0000322, .0000598 N-m-s2/rad
43
Response graph Effect on Rotation(
radians)J1.0000322, .0000598 N-m-s2/rad
44
Response graph Effect assist pressure( N/m2) on
rotation angle ( degree)When m4.76, 8.84 Kg
45
Response graph Effect pump pressure( N/m2)
When m4.76, 8.84 Kg
46
Response graph Effect displacement(X) When
m4.76, 8.84 Kg
47
Response graph Effect on cylinder pressure
When m4.76, 8.84 Kg
48
Response graph Effect on assist pressure with
rotation when K127.651,31.33N-m/rad
49
Response graph Effect on pump pressure When
K127.651,31.33N-m/rad
50
Response graph Effect on rack displacement
When K127.651,31.33N-m/rad
51
Response graph Effect cylinder pressure When
K127.651,31.33N-m/rad
52
Response graph Effect on theta When
K127.651,31.33N-m/rad
53
Summery and conclusion

• A model has been developed for the Hydraulic
  Power steering system
• Several realistic assumptions were used in model
  development.
• The model uses driver torque and pump flow rate
  as inputs.
• The rotation of the torsion bar, the displacement
  of the rack, and the pressures in the cylinder
  are outputs from model.

54
Summery and conclusion

• The model was used to develop response curves
  similar to published work
• The model was used to simulate the effect of
  driver torque on the system response. As the
  torque increases.....
• The model was also used to simulate the effect of
  pump flow rate on the system response. As the
  flow rate increases....

55
Our Model description

• We got five equation from Ali-keyhani model of
  hydraulic power power steering system
• Equation 1
• Which is second order equation.
• For Matlab programing we can break the second
  order differential equation by two first order
  equation which is below
• Let, y(1)theta, y(2)theta , so we can write
• Y(1)y(2)
• y(2)1/J1(Td-B1 y(2)K1(y(1)-y(3)/r))
• Where y(3) X ( comes from equation 3)

56
Our Model description

• Similarly for equation 2 also second order
  equation can write by two first order
  differential equation,
• If y(3)X, y(4)X
• So, y(3)y(4)
• Y(4)1/m(K1/r(y(1)-y(3)/r)P.Ap-B2.y(4)K2.y(3))

57
Our Model description

• For hydraulic equation 3,4 and 5,
• If we let y(5)Ps
• y(6)Pr
• y(7)Pl
• Then
• y(5)Beta/Vs(Q-A1CdSqrt 2(y(5)-y(6))/d-A2CdS
  qrt 2(y(5)-y(7))/d)

58
Our Model description

• y(6)Beta/(Ap(L/2-y(3)))(A1 Cd Sqrt
  2(y(5)-y(6))/d-A2CdSqrt 2(y(5)-Po)/d)Apy(4))

• y(7)Beta/(Ap(L/2y(3)))(A2CdSqrt
  2(y(5)-y(7))/d-A2CdSqrt 2(y(7)-Po)/d)Apy(4))


59
Our Model description

• So, our equation is seven and variable is seven,
  see below
• Variables are
• y(1)theta, y(2)theta,y(3)X,y(4)X , y(5)Ps
  ,y(6)Pr,y(7)Pl
• Equations are
• Y(1)y(2)
• y(2)1/J1(Td-B1 y(2)K1(y(1)-y(3)/r))

60
Model description

• 3. y(3)y(4)
• 4. Y(4)1/m(K1/r(y(1)-y(3)/r)PAp-B2y(4)K2y(3
  ))
• 5. y(5)Beta/Vs(Q-A1 Cd Sqrt 2(y(5)-y(6))/d-A2C
  dSqrt 2(y(5)-y(7))/d)
• 6. y(6)Beta/(Ap(L/2-y(3)))(A1CdSqrt
  2(y(5)-y(6))/d-A2 Cd Sqrt 2(y(5)-Po)/d)Apy(4))

• 7. y(7)Beta/(Ap(L/2y(3)))(A2 Cd Sqrt
  2(y(5)-y(7))/d-A2 Cd Sqrt 2(y(7)-Po)/d)Apy(4))


61
Showing program and Simulation in Matlab

• function Fodefile(t,y)
• thetay(1),theta'y(2),Xy(3),X'y(4),Psy(5),Pr
  y(6),Ply(7)
• Ap12.60.0001
• Td15
• B1.10831200
• B22679
• J1.000046
• m7.5
• K11.843420
• K216072117
• r.008
• Q0.0002
• Q.00027
• d825
• Vs8.190.000001
• beta5515100000
• L.15
• Po0.0
• Cd0.6

62
Showing program and Simulation in Matab

• if y(1) lt -63.14159/180
• r13 0.0
• r23 200.000001
• end
• if y(1) gt 63.14159/180
• r13 200.000001
• r23 0.0
• end
• if -63.14159/180 lt y(1) lt 0.0
• r13 0.0001909y(1)200.000001
• r23 200.000001
• end
• if 63.14159/180 gt y(1) gt 0.0
• r13 200.000001
• r23 -0.0001909y(1)200.000001
• end
• r13
• r23

63
Showing program and Simulation in Matab

• clear
• y00000000
• tspanlinspace(0,2,5000)
• optionsodeset('reltol',1e-6,'abstol',1e-8,'output
  fcn','odeplot')
• t yode23tb('odefile13',tspan,y0,options)
• figure(1)
• plot(t,y(,1),'r')
• axis(0 2 -0.2 1.2)
• xlabel('time')
• ylabel('theta in radians')
• title('theta Vs time')
• hold on
• figure(2)
• plot(t,y(,6),'b')
• axis(0 2 -10 8000000)
• xlabel('time')
• ylabel('right cylinder pressure in N/m2')
• title(' right cylinder pressure Vs time')
• hold on

64
Showing program and Simulation in Matab

• figure(4)
• plot(t,y(,5),'b')
• axis(0 2 -10 8000000)
• xlabel('time')
• ylabel('pump pressure in N/m2')
• title(' pump pressure Vs time')
• hold on
• figure(5)
• plot(((180/3.14159)y(,1)),y(,6),'g')
• axis(0 2 0 8000000)
• xlabel('valve rotation')
• ylabel('assit pressure')
• title('assit pressure Vs rotation')
• hold off

65
References

• Dr.Christan Ebner, Steer-by-wire BMW technik,
  May-00, seite-1
• Paul Yih, Toward Steer by wire Dynamic Design
  lab, November 30, 2001
• Tom Wong, Hydraulic power system design and
  optimization simulation SAE technical paper
  series, 2001-01-0479

66
References

1. Ali Keyhani Identification of Power steering
   system Dynamic Models ,Mchatronics Journal,
   February 1998
2. Granda J.J. Computer Aided Simulation of a
   Hydraulic Power Steering System with Mechanical
   Feedback
3. Joel E. Birching Two Dimensional Modeling of a
   Rotary Power steering valve International
   Congress and Exposition, Detroit, March 1-4, 1999
4. AMESim Power steering system studied Technical
   Bulletin n 107

67
References

• Sanket Amberkar, Mark Kushion, Diagnostic
  Development for an Wlectric Power steering
  system, SAE 2000 World Congress, Detroit ,
  Michigan,March 6-9,2000.
• Paper No. 993079, An ASAE Meeting
  Presentation,Adaptivecontrol of Electric
  Steering system fro wheel-type Agricultural
  Tractors by D.Wu, Q.Zhang.

68
references
69
references
70
Response graph Effect on rack displacement (X)
mTorque Td2, 9, 15 N-m
