VALMONT WIND ENERGY, INC. MODULAR TOWER SYSTEMS
2
Presentation Overview

• Bigger Machines
• Modular Tower Systems (MTS)
• Transportation Restrictions
• Flexible site Management
• Standardized Transportation Loads
• Cost Benefits and Comparisons

3
Is BIGGER always better?

• Larger wind turbines
• 2.5 MW 3 MW w/ 100 meter rotors
• Larger Tower
• 70 100 meters
• 100 200 tons
• Larger Trucks
• Custom heavy haul trailers

4
Is BIGGER always better? (Cont.)

• Larger Cranes
• 400 600 ton crawlers with 400 booms
• This all equals more efficient turbines
• But also
• More expensive transportation and installation

5
Tower Transportation today

• Over length 85
• Over width 14
• Over height 14
• Over weight 115,000 lbs
• Painted surfaces prone to scratch RUST
• Tower is often an afterthought by the turbine
  manufactures

Base section 80m tower
6
(No Transcript)
7
TRANSPORTATION

• Conventional 80m Tower
• Over Length / Over Width / Over Height / Over
  Weight
• Cost 60-80K for 500 Miles Transportation
• MTS
• Ships Via Standard Flatbed Trailers
• Cost Savings on Freight 50-70

8
MTS Modular Tower Systems

• Broad Market Application
• Mimics Industry Standard Tapered Design
• Increased Bottom Diameter Options
• Conventional Crane Installation
• Low Freight Costs
• Multiple Coating Options
• Simple, Low-Labor Content

9
MTS PRIMARY COMPONENTS
PETAL
FRICTION PLATE
T-FLANGES
TRANSITION CASTING
10
PETALS

• Allows For Very Large Diameters
• Enables Increased Tower Heights
• Opportunity To Use Lower Strength Steel (A-36)
• Dependent Upon Use Of Bolted Connections
• Can Be Galvanized
• Thickness Range 3/8-1 For Towers Up To
  2.5MW/80m

11
FRICTION PLATES

• Bolted Friction Connection
• Excellent Fatigue Characteristics
• Commonly Used in Bridge Construction World Wide
• Allows for Complete Installation from Inside the
  Tower

12
T-FLANGES

• Segmented Base Flange Design
• Addresses Freight Field Installation Objectives
• Standard Anchor Bolt Connection to Foundation
• Friction Plate Connection to Tower

13
TRANSITION CASTING

• Cast Design
• Solves Geometry Transition Issues
• Mates Seamlessly with Turbine Base Flange
• Most Technically Complex Component of MTS Design

14
(No Transcript)
15
(No Transcript)
16
(No Transcript)
17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
WIND ENERGY
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
WIND ENERGY
31
(No Transcript)
32
(No Transcript)
33
Hub height 65 meters Weight 220.000
lbs Sections 4 Petals per section 4 Standard
trucks 7 First installation December 2nd 2005
34
(No Transcript)
35
Competitive Advantages

• Standard transportation to site
• 70,000 vs. 16,000 (500 miles)
• Site assembly
• Less than 9,000 per tower
• Tower price FOB factory
• Same or lower than conventional

36
Competitive Advantages (Cont.)

• Tower Installation
• 4 sections vs. 3 sections
• Savings are site dependent
• Faster lead time than conventional towers
• Working closely with Developers and Manufactures
  to optimize savings.

37
Recent Market Trends

• Surging fossil fuel prices put alternatives in
  the spotlight
• With low volatility, wind is becoming interesting
  to large utilities
• Disruption of the U.S. oil production as a result
  of Hurricane Katrina and Rita has put upward
  pressure on the oil prices

38
Recent Market Trends (Cont.)

• Elevated natural gas price and high volatility
  plus political initiatives, should spur broader
  interest for alternative energy among U.S.
  utilities.
• Wind is currently the lowest cost alternative
• Declining interest rates will improve wind energy
  competitiveness further.

39
THANK YOU!
