technical datas of lubrication pumps of oil
loaded gas compressorsmedium lubrication oil
with flare gas
Low pressure compressors on oil platform
6 Application Flow Inlet
pressure Differential pressure Control oil on
main gate-valve 20 l/min max. 24 bar 8
bar Our solution BP10001345 Lubrication of
compressor-stage 624 l/min max. 24 bar 8
bar Our solution BP10001343 High pressure
compressor on oil platform 6 Application
Flow Inlet pressure Differential
pressure Control oil on main gate-valve
20 l/min max. 51 bar 8 bar Our solution
BP10001342 Lubrication of compressor-stage
644 l/min max. 51 bar 8 bar Our solution
BP10001346
3
technical datas of lubrication pumps of oil
loaded gas compressorsmedium lubrication oil
with flare gas
Low pressure compressors on oil platform 7
Application Flow Inlet
pressure Differential pressure Control oil on
main gate-valve 20 l/min max. 12 bar 8
bar Our solution BP10001340 Lubrication of
compressor-stage 70 l/min max. 12 bar 8
bar Our solution BP10001339 High pressure
compressor on oil platform 8 Application
Flow Inlet pressure Differential
pressure Control oil on main gate-valve
20 l/min max. 42 bar 8 bar Our solution
BP10001342 Lubrication of compressor-stage
274 l/min max. 42 bar 8 bar Our solution
BP10001341
4
technical datas of lubrication pumps of oil
loaded gas compressorsmedium lubrication oil
with flare gas
Low pressure compressors on oil platform
7 Application Flow Inlet
pressure Differential pressure Control oil on
main gate-valve 20 l/min max. 24 bar 8
bar Our solution BP10001340 Lubrication of
compressor-stage 583 l/min max. 24 bar 8
bar Our solution BP10001343 High pressure
compressor on oil platform 7 Application
Flow Inlet pressure Differential
pressure Control oil on main gate-valve
20 l/min max. 61 bar 8 bar Our solution
BP10001342 Lubrication of compressor-stage
746 l/min max. 61 bar 8 bar Our solution
BP10001344
5
technical datas of lubrication pumps of oil
loaded gas compressorsmedium lubrication oil
with flare gas
e.g. BP1342 Control oil on main gate-valve
flow 20 l/min p1 max. 51 bar delta p
8 bar
6
technical datas of lubrication pumps of oil
loaded gas compressorsmedium lubrication oil
with flare gas
e.g. BP1341 Lubrication of compressor-stage
flow 274 l/min p1 max. 42 bar delta p
8 bar
