Title: Parallel neural Circuit SIMulator (PCSIM) - Tutorial


1
Parallel neural Circuit SIMulator (PCSIM) -
Tutorial
  • Dejan Pecevski

Institute for Theoretical Computer Science Graz
University of Technology
FIAS Theoretical Neuroscience Summer School,
Frankfurt, August, 2008
2
Outline of the Tutorial
  • General Info What is PCSIM?
  • Features What is PCSIM useful for?
  • Network elements neurons and synapses
  • Scalability Using clusters for parallel
    simulation.
  • Python Interface
  • PCSIM basic operations
  • Creating and connecting neurons
  • Simulating
  • Recording signals
  • Populations and Projections
  • Summary

3
Who am I?
  • Ph.D. Student at theInstitute for Theoretical
    Computer Science, Graz University of Technology
  • One of the developers of PCSIM.
  • Research Interests
  • Plasticity and Learning mechanisms in neural
    circuits
  • Spiking Neural Networks
  • Simulation technologies/algorithms for biological
    neural networks

4
PCSIM in a nutshell
  • Simulator for parallel simulation of spiking and
    analog neural networks with point neuron models
  • Implemented in C, with Python and Java
    interfaces
  • High-level definition of neural networks
  • Library of built-in neuron and synapse models
  • Part of FACETS standardization efforts the pyNN
    interface http//www.neuralensemble.org
  • Open-source, free, released under the GPL
    license, web page at http//www.igi.tugraz.at/pcs
    im

5
Developers
  • Thomas Natschläger Ph.D.Software Competence
    Center Hagenberg Hagenberg, Austria
  • Dejan Pecevski DIInstitute for theoretical
    computer scienceGraz University of Technology
    Graz, Austria

Other Contributors Klaus Schuch DI (IGI),
Christian Ernstbrunner DI (SCCH),
Walter Hargassner DI (SCCH)
6
Feature Overview
  • Object Oriented Design
  • The user interface/view is object oriented
  • General Communication System
  • Analog and spiking messages
  • Network elements with multiple input and output
    ports
  • Supported in distributed/multi-threaded mode
  • Flexible construction of more complex network
    architectures
  • Populations of simulated objects
  • Projections for connectivity specification

7
Feature Overview
  • Parallel simulation
  • Mixed multi-thread and distributed
  • Easy to use, transparent to the user
  • Easily extensible
  • A compilation tool for creating PCSIM extension
    packages
  • Usable as backend component in C, Python, Java,
  • Easier and faster setup of simulations in Python
    and Java
  • Runs on Linux or other Unix-like platforms
  • can be compiled under Windows (still not tested).

8
PCSIM high-level structure
9
Type of models PCSIM is suitable for
  • Large recurrent networks with simple point
    neurons
  • Distributed and multi-threaded capabilities
  • Efficient simulation engine in C
  • More than 105 spiking neurons and 108 synapses
  • Hybrid models
  • Abstract modules (filters etc.) combined together
    with circuits of analog neurons and spiking
    neurons
  • Extensible with new custom elements
  • Closed loop/feedback models

10
Type of models PCSIM is suitable for
  • Structured models
  • Networks composed of smaller subnetworks
    (Populations)
  • Probabilistic connectivity patterns based on
    neurons attributes
  • Diversity of neurons and synapses
  • Different neuron types in the neuron populations
  • Specifying random distribution for parameter
    values
  • New neuron and synapse types can be implemented

11
Examples of PCSIM usage
  • Spiking neural network model of the V1 area in
    the visual cortex of mammals (Schuch Rasch)
  • Testing the computational performance of laminar
    cortical models based on experimental data.
    (Schuch Haeusler)
  • Experiments to examine the learning capabilities
    of reward-modulated spike-timing-dependent
    plasticity (Legenstein, Pecevski, Maass)

12
A simple model represented in PCSIM
Model equations
  • The equations can be decoupled into separate
    simulated elements.
  • Presynaptic neurons send spikes to the synapses.
  • Synapses inject currents (or modify conductances)
    in the postsynaptic neuron.

13
Network element basic building block
  • Nodes of the network (dynamical systems)
  • Advanced/integrated each time step of the
    simulation
  • Represented by class SimObject
  • Neurons, synapses, recorders are derived from
    this class
  • Multiple input and output ports, either analog or
    spiking.
  • Connections are formed from output to input ports
    of the same type.
  • Every element in PCSIM

14
Neurons and Synapses as Network Elements
  • Synapses as network elements are attached to the
    postsynaptic neuron
  • Synapses have one input port, no output ports
  • Neurons have only one output, no inputs
  • The spiking and analog connections can connect
    neurons on different nodes

15
Built-in Neuron Models
  • Spiking Models
  • LifNeuron, CbLifNeuron
  • Leaky integrate-and-fire
  • HHNeuron
  • Hodgkin-Huxley Neuron
  • IzhiNeuron (Izhikevich, 2004)
  • aeIFNeuron
  • Adaptive Exponential IF
  • (Brette and Gerstner, 2005)
  • LinearPoissonNeuronLeaky integrate with Poisson
    output
  • Input Neurons
  • PoissonInputNeuron
  • SpikingInputNeuron
  • Analog Neurons
  • LinearAnalogNeuron

16
Built-in Synapse Models
  • Type
  • current based
  • conductance based
  • PSR Kernel
  • exponential, alpha, double-exponential, Square
  • Short-term Plasticity
  • (Markram et al. 1998)
  • Spike-timing-dependent Plasticity
  • (Froemke and Dan, 2002)
  • (Gütig et al, 2003)
  • each pair and nearest neighbour
  • Other Mechanisms
  • NMDA(Gabbiani et al. 1994)
  • GabaB (Mainen et al. 1994)
  • Reward-modulated STDP (Izhikevich, 2007)
  • Homeostatic plasticity(Buonomano et al. 2005)
  • Ornstein-Uhlenbeck noise synapse (Destexhe et
    al. 2001)
  • Analog Synapse

17
Simulation Strategy
  • Clock-driven simulation with a fixed time step.
  • Hybrid Integration Strategy
  • Neurons are integrated every time step.
  • Synapses are event driven, i.e. they are
    integrated only after receiving a spike.
  • Numeric Integration Algorithms
  • Exponential Euler Method
  • ODE solvers from GSL

18
Parallel Simulation
  • Each MPI process advances subset of neurons
  • MPI as underlying communication layer
  • spiking and analog messages
  • Each process can have multiple-threads
  • Transparent to the user
  • Default round-robin distribution of the neurons
    over nodes
  • Custom distribution strategies
  • Easy retrieval of recordings (as in single-thread
    case)

19
Parallel Simulation
  • Why?
  • Speed-up simulation of an existing model by using
    more processors
  • Enables simulation of larger models no memory
    limit problem
  • Scale up the number of neurons while keeping the
    simulation time the same.
  • Comparison between single-threaded and
    distributed simulation
  • lt 104 neurons and 107 synapses on a single
    machine
  • gt 105 neurons and 108 synapses on clusters
  • gt 106 neurons and 1010 synapses on
    supercomputers?

20
Scalability of PCSIM
  • Hardware 3.4 Ghz, 512 kb cache, 4GB RAM
  • Model
  • 50000 LifNeurons, 4.0 Hz average firing rate
  • 50?106 synapses, 1.5 ms transmission delay

21
Scalability of PCSIM
  • Hardware 3.4 Ghz, 512 kb cache, 4GB RAM
  • Cuba Model
  • 5000 LifNeurons per node, 4.0 Hz average firing
    rate
  • 103 synapses per neuron, 1.0 ms transmission
    delay, broad distribution of time synaptic
    constants

22
Extending PCSIM
  • What are extensions?
  • User implemented classes that are plugged into
    the PCSIM OO framework
  • usualy coded in C (can be coded also in Python)
  • Compilation of additional separate Python
    extension packages, without the need to recompile
    the main PCSIM code.
  • The extension classes are automatically wrapped
    in Python
  • Usual extensions for PCSIM
  • new neuron/synapse types
  • other user defined network elements
  • custom rules for specific network construction

23
Python Interface
  • What is Python? (taken from www.python.org)
  • Python is a dynamic object-oriented programming
    language
  • offers strong support for integration with other
    languages and tools.
  • comes with extensive standard libraries
    (batteries included).
  • can be learned in a few days.
  • Many Python programmers report substantial
    productivity gains and feel the language
    encourages the development of higher quality,
    more maintainable code.
  • many scientific packages scipy, numpy,
    matplotlib, ipython, Rpy etc.

24
Python Interface
  • PCSIM can be imported as a package within Python
  • The model is represented as a network object
  • Individual neurons and synapses are accessible as
    python objects.
  • Population and Projection objects for high-level
    construction of networks composed of populations
  • Together with the other Python packages for
    scientific computing provides a complete working
    environment for neural simulations.

from pypcsim import
net SingleThreadNetwork()
25
Creating and connecting neurons
  • Creates one LIF neuron with default parameter
    values
  • nrn_model LifNeuron()
  • nrn_id net.create( nrn_model )
  • Creates array of 10 LIFneurons
  • nrn_array net.create( LifNeuron(), 10)
  • Connects the first and the second neuron in the
    array
  • syn_id net.connect( nrn_array0, nrn_array1,
    StaticSpikingSynapse())

26
Specifying neuron/synapse parameters
  • nrn net.create(LifNeuron( Cm2e-10,
  • Rm1e8,
  • Vthresh-50e-3,
    Vresting-60e-3,
  • Vreset-60e-3,
    Trefract5e-3, Vinit-60e-3 ))
  • syn net.connect( pre_nrn, post_nrn,
  • StaticSpikingSynapse( W1e-10,
  • tau
    5e-3,

  • delay1e-3 ))

27
Recording
  • record the output spikes of a neuron
  • rec_spk net.record( nrn, SpikeTimeRecorder() )
  • record the membrane potential
  • rec_vm net.record( nrn, Vm, AnalogRecorder()
    )
  • record the weight of a synapse
  • rec_syn net.record( syn, W, AnalogRecorder()
    )
  • record any field in an element
  • rec net.record( myElement,
  • anyFieldName, AnalogRecorder())

28
Simulate the model
  • simulate the network for 1 second
  • net.simulate(1.0)
  • or advance it for 200 time steps
  • net.advance(200)

29
Accessing individual neurons/synapses
  • creates return an ID of the neuron
  • nrn_id net.create( LifNeuron() )
  • get the actual neuron object from the network
  • nrn_object net.object(nrn_id)
  • Manipulate the neuron object
  • nrn_object.Vthresh -59e-3
  • getting the recorded values from a recorder
  • values list(net.object(rec_id).getRecordedValues
    ())

30
Synapse classes nomenclature
  • StaticCurrExpSynapse (StaticSpikingSynapse)
  • DynamicCondDblExpSynapse
  • StaticStdpCondAlphaSynapse
  • DynamicCurrAlphaSynapse
  • DynamicNMDAAlphaSynapse

Current/conductance based?
Shape of PSR kernel
Short-term plasticity
31
Hello, world!
  • from pypcsim import
  • net SingleThreadNetwork()
  • pre_nrn net.create( LifNeuron(Iinject 5e-8) )
  • post_nrn net.create( LifNeuron(Iinject 5e-8)
    )
  • net.connect( pre_nrn, post_nrn,
    StaticSpikingSynapse())
  • rec net.record( post_nrn, SpikeTimeRecorder() )
  • net.simulate(0.2)
  • print spike times, list(net.object(rec).getReco
    rdedValues())

32
Specifying inputs
  • Create input neuron which spikes at specific
    times
  • net.create(SpikingInputNeuron( 0.1, 0.2, 0.4))
  • Create input neuron with Poisson process spike
    times
  • net.create( PoissonInputNeuron(rate 10,
    duration 10) )
  • Create analog input neuron with an
  • output analog signal specified as array
  • net.create( AnalogInputNeuron( arange(0,10,1e-4)
    1 ) )

33
Creating and connecting many neurons
  • Population of 1000 neurons randomly
    interconnected with 0.1 probability
  • Population of recorders one for each neuron in
    the population
  • create a population of 1000 LIF neurons
  • popul SimObjectPopulation(net, LifNeuron(),
    1000)
  • create the projection
  • proj ConnectionsProjection( popul, popul,
  • StaticSpikingSynapse(), RandomConnections
    ( 0.1 ) )
  • create a recorder population
  • rec_popul popul.record( SpikeTimeRecorder() )

34
Random distributions for parameter values
  • Factory an object that generates PCSIM elements
  • Neuron and synapse objects (used as models for
    creation) are simple clone factories
  • SimObjectVariationFactory factory that attaches
    random distributions to parameter names

nrn_factory SimObjectVariationFactory(
LifNeuron() ) nrn_factory.set( Vinit, Normal
Distribution( -55e-3, 0.1 ) ) popul
SimObjectPopulation(net, nrn_factory, 1000)
35
Spatial heterogenous populations
  • Each neuron has coordinates in 3D space
  • The population is composed of different families
    of neurons (that can be of different type)
  • exc_nrn LifNeuron( Cm 2e-10,
  • Inoise 1e-10)
  • inh_nrn LifNeuron( Cm 3e-10 )
  • popul SpatialFamilyPopulation(net,
  • exc_nrn, inh_nrn,
  • RatioBasedFamilies((4,1) ),
  • CuboidIntegerGrid3D(20,10,10))
  • exc_popul, inh_popul popul.splitFamilies()

36
Distance dependent random connections
Creates random connections with
probability where D is the euclidean
distance between the two neurons
  • proj ConnectionsProjection( popul, popul,
  • StaticSpikingSynapse(),
  • EuclideanDistanceRandomConnections( C, lambda )
    )

37
Saving recorded data
  • from pypcsimplus import
  • Create the recording class
  • r Recordings()
  • Add the recorder populations as attributes to r
  • r.spikes popul1.record( SpikeTimeRecorder() )
  • r.vm_traces popul2.record( Vm,
    AnalogRecorder() )
  • Some additional variables to be saved
  • r.v 5
  • Save the Recordings class to a HDF5 file
  • r.saveInOneH5File(results.h5)

38
Running a parallel simulation
  • Change the network class from SingleThreadNetwork
    to either
  • MultiThreadNetwork( nThreads 4 )
  • DistributedSingleThreadNetwork
  • DistributedMultiThreadNetwork
  • then run the script with mpirun

mpirun n 10 python my_experiment.py
39
Summary
  • PCSIM is a tool for simulation structured random
    neural networks composed of spiking and analog
    point neuron models
  • Has various built-in neuron and synapse models
  • Supports parallel simulation distributed and
    multi-threaded
  • Flexible high-level construction of networks
    based on probabilistic rules
  • The Object-oriented framework is designed to
    support easy extensions
  • Can be used as a package within the Python
    interpreting programming language, together with
    other useful scientific packages

40
PCSIM Resources
  • Web page
  • http//www.lsm.tugraz.at/pcsim
  • On Sourceforge http//www.sourceforge.net/project
    s/pcsim
  • Mailing listhttp//sourceforge.net/mailarchive/fo
    rum.php?forum_namepcsim-users
  • User manualhttp//www.lsm.tugraz.at/pcsim/userman
    ual/html/index.html
  • C class referencehttp//www.lsm.tugraz.at/pcsim
    /cppclassreference/html/hierarchy.html

41
  • Thank you for your attention!
About PowerShow.com
