Title: Hall Probe Calibration System


1
Hall Probe Calibration System Using LabVIEW
Joseph Z. Xu August 11, 2003
2
APS INSERTION DEVICES
The magnetic field spatial distribution profiles
of the APS Insertion Devices (ID) are
characterized with Hall Probe Magnetic
Measurement System
3
Hall Effect and Hall Probe
Hall Effect
Hall Probe
  • Hall Probes are used to characterize the magnetic
    field spatial distribution profiles of the APS
    Insertion Devices (ID)
  • The Hall Probe Calibration System is designed to
    calibrate the Hall Probes

4
Hall Probe Calibration System
The Hall Probe Calibration System consists of
Dry Cooper
A Magnetic Power Supply (MPS-853)
An Electrical Magnet
GPIB
An NMR Teslameter (PT-2025)
A Reference Teslameter (DTM-141)
RS-232
A Motorized Probe Stage (SmartMotor)
A Multimeter (HP-3458A)
5
NMR Theory of Operation
G µ/hI
?E µB/I
f ?E/h GB
µ nuclear magnetic moment f resonance frequency
B static magnetic field I spin quantum number
6
Operation Procedure
Electric Magnet Top View
7
What is LabVIEW?
  • A graphical programming language
  • Compiled graphical development environment
  • Similar to flowcharting

8
Virtual Instrument
  • Each program is called a Virtual Instrument (VI)
  • Each VI has a Front Panel and a Block Diagram

Front Panel User Interface (MEDM)
Block Diagram Source Code (IOC Application)
9
Front Panel User Interface
  • Graphical user interface
  • Pre-built user interface objects

10
Block Diagram Source Code
  • Intuitive flowchart-like code
  • Hundreds of pre-built measurement subVIs
  • Self-documenting

11
Debugging
Step in, single step, step out
Highlight execution
12
Application Builder
Compiler Creates Application.exe
and Application.ini files
Installer Creates data.cab, install.msi InstMsi.ex
e, setup.ini, InstMsiW.exe, and setup.exe files
13
Hall Probe Calibration System Software
Main Panel
14
Hall Probe Calibration System Software
Reference Teslameter (DTM-141)
DTM-141 Reference Digital Teslameter Panel
15
Hall Probe Calibration System Software
NMR Teslameter (PT-2025)
PT-2025 NMR High Precision Teslameter Panel
16
Hall Probe Calibration System Software
Magnetic Power Supply (MPS-853)
MPS-853 Magnetic Power Supply Panel
17
Hall Probe Calibration System Software
MPS-853 Magnetic Power Supply Panel Interlock
Pull Down Menu
18
Hall Probe Calibration System Software
Multimeter (HP-3458A)
HP-3458A Panel
19
Hall Probe Calibration System Software
Motorized Probe Stage (SmartMotor)
Motorized NMR Probe Stage Panel
20
Hall Probe Calibration System Software
Plot Panel
21
Hall Probe Calibration System Contents
System Hardware
  1. Danfysik System 8000 MPS-853 Precision Magnet
    Power Supply System
  2. Electric Magnet
  3. Metrolab PT-2025 High Precision NMR Teslameter
    System
  4. Motorized NMR Probe Support Stage System Powered
    by Animatics SmartMotor Servo Motors
  5. Group 3 DTM-141 Digital Teslameter System
  6. HP 3458A Multimeter System
  7. PC with a GPIB PCI card, a RS-232 port, 600 MHz
    or higher CPU, 128 MB or more RAM, and 130 MB or
    more free HD.

System Software and Documents
  1. Windows XP/2K/NT/98 OS.
  2. PC based software package with installer on a CD
  3. Users Guide
  4. Operation Method of Procedure

22
Next Project Integral (Stretch Coil) Measurement
System Upgrade
Field integral (along the z direction) Theory of
Operation
Vertical Component
Horizontal Component
Y
1
4
X
Y
2
3
1
4
2
3
23
Key System Requirements
  • Motion Control SmartMotor via RS-232
  • 2x4 axis x(0-400mm), y(0-400mm), z(0-6000mm),
    w(0-360)
  • Motion Readout Linear (x, y, and z) and Rotary
    (w) Encoders
  • Linear encoder resolutions 25 µm absolute
    position
  • Rotary encoder resolutions 0.1deg absolute angle
    position
  • Linear stage speed up to 50 mm/s at z direction
  • Rotary stage speed up to 1 revolution per second
  • DAQ Coil EM Voltage Measurement
  • Resolution 16 bit (5 digits)
  • Sampling rate 1.5 kS/s
  • Synchronization Absolute Angle Position vs. Coil
    Voltage Measurement w/ at 1.5 kS/s
  • Triggering must be done in referencing of
    absolute positions.
  • Digital I/O Noise Control 10-7

24
Current System Architecture
System A (on the 6 meter bench)
Stepping Motor Drivers Stepping Motor Power
Supplies
To the Stepping Motors
VME
VME44 w-Encoder Board
VMEX xyz-Encoder Board
PCI NIVXI
From the encoders
PCI GPIB
Magnetic Flux Integrator
From the Coil
Amplifier
  • Current Issues
  • Flux start point and finish points (positions)
    are not well defined.
  • Only 4 data points are measured and data analysis
    is not feasible.
  • System is Windows 3.1 based and software is not
    upgradeable.

25
Current System Architecture
System B (on the 3 meter bench)
To the SmartMotors
From the Coil
RS-485
PowerDAQ 16 bit PCI ADC Card
RS-232
RS-232 to RS-485 Converter
Amplifier
  • Current Issues
  • Positioning and measurements are synchronized
    by PC CPU time using software. ( 3 ms?)
  • Start and Finish positions/times are not well
    defined.
  • System is RedHat Linux based and hard to maintain.

26
Proposed System Architecture
From x, y, z, and w encoders
TCP/IP
PXI
FPGA I/O w/ built in 16 bit ADC
From the Encoders
From the Coils
RS-232
To the SmartMotors
  • Key Features
  • Integrated real time encoder readout, triggering,
    and Coil voltage measurement.
  • TCP/IP Interface, securely access the system
    remotely, anywhere, anytime.
  • Commercial off-the-shelf components.
  • Same hardware can be used for both 6 meter bench
    and 3 meter bench Hall Probe Measurement Systems.

27
Why PXI?
  • PXI PCI eXtensions for Instrumentation
  • A specification designed explicitly for
    industrial test and control applications.
  • Industry open standardized PCI backplane at 132
    MB/s or 1 Gbps (32 bits_at_33MHz) plus integrated
    timing and triggering.
  • Well supported by all major operating systems.
  • Large selection of instruments and modules.
  • Low cost and ease of use.

See www.pxisa.org for detailed specifications
28
Conclusion
For isolated control and data acquisition
systems, PC based and/or PXI based platform with
LabVIEW, Visual Basic, or Visual C development
tools shall be adequate.
Hall Probe Calibration System Demo Diagram
TCP/IP
802.11
RS-232
SmartMotor NMR Probes
GPIB
Magnetic Power Supply (MPS-853)
Reference Teslameter (DTM-141)
NMR Teslameter (PT-2025)
Digital Multimeter (HP-3458A)
Electric Magnet
