Title: ACARS Ground Solution


1
B.Rekencentra N.V.
  • ACARS Ground Solution

by
2
Objective
  • Present new ACARS ground solution
  • Describe system components
  • Demonstrate Ar-Com strengths

3
Customer Needs
  • Ease of use
  • Configurable
  • Modern open architecture
  • Adapt to changing needs
  • In house maintenance
  • Secure use

4
System Overview
5
System components
  • Administration program (Client server module)
  • Configuration data dictionary
  • Configuration aircraft
  • Configuration messages and their interpretation
  • Configuration of custom routing
  • Configuration of uplink messages

6
System components
  • ANL (Background processing)
  • Separate modules per network
  • Receives messages from network
  • Transmits messages to network
  • Following network gateways are in place
  • SITA via SITATEX
  • SITA via MQ series
  • Email
  • MQ series
  • Wingspeedcorp via email
  • Wingspeedcorp via MQ series
  • Airinc in development

7
System components
  • APS (Background processing)
  • Message recognition
  • Message interpretation
  • Perform custom routingFor example
  • Receive OOOI, transform to MVA, forward to
    Operations control system
  • Receive loadsheet from WB, uplink to aircraft
  • Receive engine report, transform and transmit to
    engine performance system
  • Receive message from aircraft and transmit to
    other aircraft

8
System components
  • Ar-Com Online (browser enabled)
  • Show inbound message details
  • Alert users about critical messages
  • Uplink to aircraft
  • FSD Flight Situation Display (browser enabled)
  • Show flight on a geographical map
  • Show fuel flight level status
  • Show downlink messages
  • Transmit uplink messages

9
Ease of use
  • Web browser interface
  • On line help available (in development)
  • User interface configurable
  • Windows based administration tool
  • No installation on clients
  • Single server solution possible

10
Open architecture
  • Data stored in ODBC supported relational database
    (e.g.Oracle)
  • 3rd party processing possibility (Plug-in) via
    routing
  • Component based

11
In house maintenance
  • Relational database
  • Modify recognition and interpretation of existing
    messages
  • Self-support for new messages
  • Define /Change uplinks

Fully configurable through ADM2000
12
ADM2000
  • Windows based Administration tool
  • Easy configuration of Ar-Com
  • User groups / security
  • Aircraft
  • Messages
  • Interpretation
  • Uplinks
  • Routing
  • Network links

13
Secure access
  • Group based security providing
  • Controlled aircraft access
  • Controlled uplink possibility
  • Controlled user access
  • Controlled message type access

14
Sample Physical model
  • Single Server running
  • Internet Information Server
  • Oracle database version 10
  • APS
  • ANL Incoming - ANLDirIn
  • ANL Outgoing - SitaFileOut
  • (ANLs use Sitatex file gateway)

15
Benefits
  • Self-support
  • Easy maintenance
  • Extensible
  • Secure storage of data

16
Some Users
  • TUI Airline Group 200 Aircraft
  • Tuifly
  • Thomson
  • Jetairfly
  • Arkefly
  • Neosair
  • Jet4you
  • DHL aviation 50 aircraft
  • TNT airways 40 aircraft

17
Sample downlink
  • Turn this

HEADERRCV,2001/03/07 0415PRIORITYQUDESTINA
TION TYPE BSTX,ORIGINQXSXMXSMSGID070
415SMIDFDTEXTFI /AN DT QXS
1 070415 D95A- TKO1010703041500580016016
43275693790440000934093509650965771782103125041790
42010075007562600490510570070420050030070130163022
5731916803290293177063606441100000011U1541N5228E00
9473993404104971N0123
18
Into data
19
Into an alternate form
20
Sample uplink
Instead of remembering cryptic codes
QU QXSXMXS .XXXXXXX M3L /AN XXXXXXX 0001211203
21
Sample uplink
Just fill in the blanks
22
FSD
  • Shows
  • Geographical map
  • Flexible zoom and pan
  • Planned route with waypoints (Flightplan)
  • Actual Route
  • Actual position of A/C
  • Airports

23
FSD
  • Graph shows
  • Planned fuel
  • Actual fuel
  • Planned flight level
  • Actual flight level

24
FSD
  • Uplink
  • Select message type
  • Input other values
  • Apply Uplink button

25
FSD
  • Airport information
  • METAR
  • Short Term Forecast
  • Long Term Forecast
  • Temperture
  • NOTAM
  • AIRMET
  • SIGMET

? Information retrieved from flight planning
system
26
FSD
  • Flight Plan information
  • Information used to
  • Plot planned route
  • Plot fuel graph
  • Plot Flight Level graph

? Information retrieved from flight planning
system
27
FSD
  • Messages
  • Downlink Uplink per A/C
  • Message details
  • Info
  • Text
  • Alternate text
  • Data elements
  • Routing results
  • Custom flags

28
FSD
  • Critical Messages
  • User is alerted
  • Message details as normal messages

29
FSD
30
FSD
  • Configurable FSD
  • Every window can be viewed or not
  • Windows size and location is stored
  • Windows contents are synchronized

31
On-line Demo
  • A demo version is reachable on our test server.
  • Please browse to one of the following addresses
  • Classic Ar-Com http//maya.rekencentra.be/Arcom
  • FSD http//maya.rekencentra.be/ArComFsdSL
  • Please request username and password to use the
    demo

32
byB.RekenCentra N.V.
  • Thank you

Contact information Karel Tavernier Tel 32 3
470 14 00 Mail Karel.Tavernier_at_Rekencentra.be
