Title: MANAGEMENT OF EXPOSURE TO HYDROGEN FLOURIDE OR HF


1
MANAGEMENT OF EXPOSURE TO HYDROGEN FLOURIDE OR HF
  • PRESENTED BY
  • Miguel Trevino, M.D.
  • Occupational Medicine
  • U.de M - U.C.S.C - FACOEM
  • MRO

2
GENERAL INFORMATION ABOUT HF
3
USES OF HF
  • ELECTRONICS.- Production of microchips,
    electronic circuit cleaners.
  • METALURGY.- Metal pickling/Aluminum manufacture
  • PETRO CHEMICALS.- As a catalyst in the
    alkalization of gasoline.
  • GLASS INDUSTRY. Glass edging.
  • REFRIGERENT GASES.- For automotive, air
    conditioning, refrigerator home/industry.
  • FIRE EXTINGUISHERS.- Fluorocarbons.

4
USES OF HF
  • FLUOROCHEMICALS.- Fluorinated Salts Production.
  • ANTIADHERENTS.- Production of Teflon.
  • MEDICINE.- Propellants for medication, anesthetic
    gases, antibiotic production, production and
    finishes of surgical prosthesis.
  • NUCLEAR INDUSTRY.- Purification of uranium ore.
  • AGROCHEMICALS. Pesticides.
  • CLEANING SOLUTIONS. Rust removers.

5
PHYSICAL CHEMICAL PROPERTIES
  • FREEZING POINT -118ºF -83ºC
  • VAPOR DENSITY 3.0 AT 25ºC
  • SPECIFIC GRAVITY (2514) 0.97
  • VAPOR PRESSURE AT 20ºC 775MM Hg
  • BOILING POINT 67ºF 19ºC
  • VOLATILITY 100
  • SOLUBILITY IN WATER 100
  • ODOR PUNGENT IRRITATING
  • PHYSICAL STATE GAS
  • DISSOCIATION K3.5 x 10-4

6
PHYSIOPATHOLOGY OF EXPOSURES KNOWN TOXICOLOGY
7
  • HF
  • ?
  • //////////////////

TISSUE
8
(No Transcript)
9
ENTRY ROUTES
  • SKIN
  • RESPIRATORY TRACT
  • EYES
  • GASTRO-INTESTINAL

10
TYPES OF EXPOSURE
  • LIQUID EXPOSURE (SPLASH BURN).
  • GAS EXPOSURE (INHALATION, SKIN EYES).
  • LIQUID GAS (MIXED EXPOSURE).
  • LOW CONCENTRATION HF SOLUTIONS.

11
Once ionized, the fluoride creates two types of
salts
  • INSOLUBLE SALTS
  • F Ca ( ) Ca F(2) Calcium Fluoride
  • F Mg( ) Mg F Magnesium Fluoride
  • This can lead to Hypoglycemia that in turn
  • can lead to Cardio Respiratory Arrest,
  • Hypomagnesaemia, Na (Sodium) and K
  • (Potassium) alterations.

12
  • SOLUBLE SALTS
  • F Na() Na F Sodium Fluoride
  • F K() KF Potassium Fluoride
  • Which target
  • The Kidneys Nefro - Toxic
  • The Liver Liver - Toxic
  • And are the cause of Acute Fluoride
    Intoxication if sufficient quantities are
    created.

13
SO, WHY IS HF A HAZARDOUS MATERIAL?
  • It is a Corrosive. (Acid)
  • It is a Poison. (Toxic)
  • It is an Inhalation Hazard.

14
INTRINSIC PROCESS RISK FACTORS IN RELATION TO HF
CHEMICAL FACTORS CHEMICAL FACTORS CHEMICAL FACTORS
PHOSGENE CYLINDERS 200
HCN RAILROAD TANK 10
H2S PRESSURIZED TANK 10
C12 RAILROAD TANK 9
SO2 IN CYLINDER 8
AHC1 ROAD TANK 2.5
AHF IN A RAILROAD TANKER 1
Br2 PRESSURIZED TANK 0.80
SO3 PRESSURIZED TANK 0.60
NH3 NORMAL ATM CONDITIONS 0.30
OLEU PRESSURIZED TANK 0.20
NH3 AT 33ºC 0.09
MMA TANK 0.05
Br2 NORMAL ATM CONDITIONS 0.05
POC13 PRESSURIZED TANK 0.04
RISK FACTORS IN RELATION TO HF WHEN HF 1.0 RISK FACTORS IN RELATION TO HF WHEN HF 1.0 RISK FACTORS IN RELATION TO HF WHEN HF 1.0
15
KNOWN TOXICOLOGY
  • Acute Corrosive Effects (Burns)
  • Acute Fluoride Intoxication
  • Sub-Acute Impaired Breathing (hours after)
  • Delayed appearance of skin injury (hours after)
  • Chronic or Long Term
  • Injury to tissue due to corrosive and toxic
    effects. No other effects documented or
    reported. Possible Fluorosis after chronic
    exposure to low concentrations of HF.

16
KNOWN TOXICOLOGY
  • Reproductive Developmental
  • None described or found
  • Immuno-Toxicity
  • None described or found
  • Cancer Forming
  • No human reports or studies
  • Cardiac Muscular Toxicity
  • Yes, due to Fluoride binding to Calcium,
  • and Magnesium.

17
KNOWN TOXICOLOGY
  • Hepatic Nefro Toxicity
  • Yes, due to creation of Sodium
  • Fluoride and Potassium Fluoride
  • after exposure (untreated).

18
KNOWN TOXICOLOGY
  • TWA
  • Time weighted average concentration for a
    normal 8 hour workday and a 40 hour work week to
    which nearly all workers may be repeatedly
    exposed, day after day, without
    adverse effects for all of their
    working life 3PPM (ACGIH).

19
KNOWN TOXICOLOGY
  • IDLH 30 ppm
  • Immediately dangerous to life and health
  • (NIOSH).

20
KNOWN TOXICOLOGY
  • ERPG 1 5 ppm
  • The maximum airborne concentration
    below which it is believed that nearly all
    individuals could be exposed for up to 1 hour
    without experiencing other than mild, transient
  • adverse health effects or without perceiving
    a clearly defined objectionable odor.

21
KNOWN TOXICOLOGY
  • ERPG 2 20 ppm
  • The maximum airborne concentration
    below which it is believed that nearly all
    individuals could be exposed for up to 1 hour
    without experiencing or developing irreversible
  • or other serious health effects or symptoms
    which could impair an individuals ability to
    take protective action.

22
KNOWN TOXICOLOGY
  • ERPG 3 50 ppm
  • The maximum airborne concentration
    below which it is believed that nearly all
    individuals could be exposed for up to an hour
    without experiencing or developing life-
    threatening health effects.

23
PRIMARY DECONTAMINATION PROCEDURES
24
DECONTAMINATION PROCEDURES
  • GO TO THE NEAREST FUNCTIONAL DECON UNIT.
  • OPEN THE WATER VALVE.
  • TAKE OFF ALL CLOTHING, SHOES JEWELRY.
  • REMOVE GOGGLES LAST, FACE THE WATER FLOW, CLOSE
    YOUR EYES, PULL GOGGLES OVER YOUR HEAD.
  • REMEMBER, MAXIMUM TIME UNDER SHOWER IS 5 MINUTES.
  • This is a Dilution Technique.

25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
TRIAGE
33
PRIMARY TRIAGE
  • 1ST To Go Many Signs Symptoms of Exposure
  • 2nd To Go Signs and Symptoms Present and
  • Possible Systematic
    Effects in Near
  • Future
  • 3rd To Go Minor or No Signs Symptoms
  • Do Not Go Fatalities

34
SUGGESTED TREATMENT THROUGH HISTORY
  • WASH COPIOUSLY WITH WATER FOR 15 MINUTES.
  • SODIUM BICARBONATE SOLUTIONS
  • MAGNESIUM SULFATE PASTE.
  • MAGNESIUM OXIDE PASTE.
  • AMMONIA SOLUTIONS INHALANT.
  • HYAMINE SOLUTIONS 0.2 (2 gm BENZEHTONIUM
    CHLORIDE IN 1 LITER OF ICE WATER).

35
SUGGESTED TREATMENT THROUGH HISTORY
  • ZEPHIRAN 0.13 (1.3 gm BENZALKONIUM CHLORIDE IN 1
    LITER OF ICE WATER).
  • CALCIUM GLUCONATE SOLUTIONS 10, 5, 2.5, 1
  • CALCIUM GLUCONATE GEL 2.5.
  • CALCIUM ACETATE SOLUTIONS.
  • ORAL CALCIUM MAGNESIUM BASED ANTACIDS AND
    SOLUTIONS.

36
SUGGESTED TREATMENT THROUGH HISTORY
  • INTR-ARTERIAL CALCIUM TECHNIQUE (BOLUS AND SLOW
    INFUSION).
  • INTRA-VENOUS CALCIUM TECHNIQUE (BIEAR BLOCK).
  • HEXAFLUORINE RINSING SOLUTION.
  • DMSO CALCIUM GLUCONATE SOLUTION.

37
FIRST AID PROCEDURES
38
FIRST AID SKIN EXPOSURE
  • MINOR BURNS
  • Burns smaller than 2 square inches of body
  • surface, such as small droplets, or very
    small
  • skin burns, low concentration gas or solution
  • exposures.
  • MAJOR BURNS
  • Burns larger than 2 square inches with A.H.F.

39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
(No Transcript)
49
(No Transcript)
50
(No Transcript)
51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
(No Transcript)
55
(No Transcript)
56
(No Transcript)
57
(No Transcript)
58
(No Transcript)
59
(No Transcript)
60
(No Transcript)
61
(No Transcript)
62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
(No Transcript)
66
(No Transcript)
67
(No Transcript)
68
(No Transcript)
69
(No Transcript)
70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
(No Transcript)
76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
89
(No Transcript)
90
(No Transcript)
91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94
(No Transcript)
95
(No Transcript)
96
(No Transcript)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
100
(No Transcript)
101
(No Transcript)
102
(No Transcript)
103
(No Transcript)
104
(No Transcript)
105
(No Transcript)
106
(No Transcript)
107
(No Transcript)
108
(No Transcript)
109
(No Transcript)
110
(No Transcript)
111
(No Transcript)
112
(No Transcript)
113
(No Transcript)
114
(No Transcript)
115
AFTER DECONTAMINATION
  • Initiate calcium gluconate 2.5 gel inunction.
    Note the time you start this step.
  • Obtain medical attention (call).
  • If pain does not subside in 20-30 minutes, go to
    medical treatment.

116
FIRST AID EYES
  • ALL EXPOSURES ARE CONSIDERED SEVERE.
  • DECON
  • USE EYEWASH, A GLASS OR LOW PRESSURE WATER HOSE.
    MAXIMUM TIME IS 5 MINUTES.
  • IRRIGATE 500cc to 1000cc OF A 1 CALCIUM
    GLUCONATE SOLUTION IN NORMAL SALINE PER EYE.

117
FIRST AID EYES
  • SEEK SPECIALIZED MEDICAL ATTENTION IMMEDIATELY.
    USE CALCIUM GLUCONATE AT 1 CONCENTRATION UNTIL
    MEDICAL HELP IS REACHED.
  • IF THERE IS SKIN EXPOSURE, ALSO FOLLOW SKIN
    DECONTAMINATION AND FIRST-AID PROCEDURES.

118
(No Transcript)
119
(No Transcript)
120
(No Transcript)
121
(No Transcript)
122
FIRST AID INHALATION
  • DECON
  • ADMINISTER OXYGEN AT 12 LTS. PER MINUTE.
  • START NEBULIZING A 2.5 SOLUTION OF CALCIUM
    GLUCONATE IN NORMAL SALINE, USING A STANDARD
    NEBULIZER OR ULTRA NEBULIZER. PREFERABLY NOSE
    AND MOUTH MASK AND ¾ IN. TUBING
  • OBTAIN MEDICAL ASSISTANCE.

123
(No Transcript)
124
FIRST AID INGESTION
  • CONCIOUS PATIENT
  • GIVE ORALLY HIGH AMOUNTS OF ANY CALCIUM OR
    MAGNESIUM BASED ANTACID, EFFERVESCENT CALCIUM IN
    WATER, MILK OR WATER.
  • DO NOT INDUCE VOMITING!
  • UNCONCIOUS PATIENT
  • OBTAIN MEDICAL ASSISTANCE IMMEDIATELY.
  • DO NOT FORGET TO DECONTAMINATE SKIN OR EYES IF
    THEY WERE EXPOSED.

125
SECONDARY DECONTAMINATION PROCEDURES
126
(No Transcript)
127
(No Transcript)
128
(No Transcript)
129
(No Transcript)
130
(No Transcript)
131
SECONDARY DECONTAMINATION
  • EXAMINE DECONTAMINATE
  • -EAR CANALS
  • -MOUTH
  • -NOSE
  • -ANUS
  • -VAGINA
  • EXAMINE DECONTAMINATE SKIN FOLDS
  • -NECK

132
SECONDARY DECONTAMINATION
  • -AXILARY REGIONS
  • -SUB-MAMMARIAN FOLDS
  • -GROIN
  • -BEHIND THE KNEES
  • -INTER-DIGITAL FOLDS
  • EXAMINE DECONTAMINATE BELOW THE NAILS OF
  • -HANDS
  • -FEET

133
SECONDARY DECONTAMINATION
  • EXAMINE DECONTAMINATE AREAS COVERED WITH HAIR
  • -SCALP
  • -PUBIS
  • -OTHER AREAS AS NEEDED

134
ELECTROCARDIOGRAPHIC EFFECTS
  • PROLONGED Q-T INTERVAL
  • (DUE TO HYPOCALCEMIA).
  • NORMAL SERUM CALCIUM LEVELS
  • 2.25 TO 2.6 mmol/lt
  • 9 TO 10.5 mg/dl

135
MEDICAL TREATMENT PROCEDURES
136
FLUORIDE IN SERUM OR IN URINE
  • CLINICALLY- THE BEST INDICATOR IS URINE
    FLUORIDES. EASY TO DO, RESULTS IN MINUTES AND
    DEPENDABLE .
  • FLUORIDES IN SERUM ARE NOT RELIABLE INDICATORS
    BECAUSE IT DOES NOT PROVIDE A GOOD MEASURE OF
    EXPOSURE TO FLUORIDES, AND IS COMPLICATED TO
    PERFORM, MAY TAKE DAYS BEFORE REPORTED.

137
LONG TERM EFFECTS
  • FIRST
  • SEQUELA NORMALLY ARE ESTABLISHED IN THE
    SUB-ACUTE TIME PERIOD AFTER EXPOSURE AND ARE
    NORMALLY STABLE, SUCH AS
  • SKIN HYPO-PIGMENTATION
  • KELOID SCARING
  • DEEP SEATED SCARING
  • SURGICAL SCARS
  • NEUROLOGIC, LIVER AND KIDNEY
  • DISFUNCTION MAY PERSIST IF DAMAGE IS
  • SEVERE.

138
LONG TERM EFFECTS
  • SECOND
  • THE FOLLOWING HAVE NOT BEEN OBSERVED
  • HYPER-REACTIVE AIRWAYS
  • KIDNEY, LIVER OR CNS DYSFUNCTION
  • CANCER
  • REPRODUCTIVE PROBLEMS, ETC
  • (SEE TOXICOLOGY)

139
CALCIUM GLUCONATE AS THE TREATMENT OF CHOICE
140
WHY ?
  • EASY TO USE.
  • CAN BE USED IN FIRST AID MEDICAL
  • TREATMENT.
  • CAN BE USED TOPICALLY, INFILTRATED,
  • INHALED, OPTHAMICALLY AND
  • INTRAVENOUSLY.
  • NO SOPHISTICATED MEDICAL EQUIPMENT
  • REQUIRED, SUCH AS ARTERIAL CATHETERS,
  • IV INFUSERS, ETC.

141
  • EASY TO PREPARE IN GEL FORM OR
  • SOLUTIONS.
  • TREATMENT IS FAST AND EFFECTIVE.
  • THE RESULTING REACTION CHEMICAL
  • IS PRIMARILY GLUCOSE AS COMPARED
  • TO AMMONIUM FLUORIDE ACETIC
  • ACID, IN THE CASE OD AMMONIA
  • COMPOUNDS OR CALCIUM ACETATE,
  • RESPECTIVELY.

142
  • CALCIUM IS MUCH MORE FAVORED TO BIND
  • WITH FLUORIDE IN THE BODY.
  • NONE OR MINOR TISSUE IRRITATION AT
  • DESCRIBED CONCENTRATIONS.
  • EXCELLENT RESULTS IN BOTH HIGH LOW
  • CONCENTRATION EXPOSURES OF HF.
  • NO SECONDARY EFFECTS AT THERAPEUTIC
  • LEVELS.
  • NO NEED FOR SOAKING OR COOLING WITH
  • RESULTING HYPOTHERMIC OR VASCULAR
  • RISKS.

143
IT IS AN EXCELLENT OUTSIDE SOURCE OF CALCIUM
THAT WILL BIND THE FLUORIDE, AND IN DOING SO,
WILL HELP AVOID HYPOCALCEMIA, AND THE CREATION
OF TOXIC COMPOUND IN THE BODY.CAN BE USED
IN THE PRODUCTION FIELD, IN TRANSPORTATION
INCIDENTS AND IN HOSPITALS.
144
ALGORITHMS FOR EMERGENCY MEDICAL PROCEDURES FOR
HYDROFLUORIC ACID EXPOSURE
145
(No Transcript)
146
(No Transcript)
147
(No Transcript)
148
(No Transcript)
149
Respiratory Exposure
  • Decontamination Procedures.
  • Not Possible
  • If gaseous exposure occurs skin and eye
    decontamination
  • is necessary.

DECON
Minor Exposure
Major Exposure
  • Signs Symptoms.
  • Coughing
  • Labored Breathing.
  • Shortness of Breath
  • Erithema
  • Swelling
  • Bleeding
  • Upper Airway Edema.
  • Pulmonary Edema.
  • Cardiac Arrithmia. (Irregular heart beats).
  • Signs Symptoms.
  • No signs symptoms.
  • Minor coughing.
  • Minor swelling and Eritlema.

SIGNS SYMPTOMS
  • First-Aid Procedures.
  • Administer O2 at a rate of 12 Lts./min.
  • Nebulize calcium gluconate 2.5 in
  • normal saline for 15 to 20 min.
  • Obtain Medical Evaluation and
  • observe.

  • First-Aid Procedures.
  • Administer O2 at a rate of 12 lts./min.
  • Continuously nebulize calcium
  • gluconate 2.5 in normal saline until
  • medically evaluated.
  • If respiratory assistance is needed -
  • use indirect methods - (Bag-micro-
  • shield).-

FIRST-AID
  • Medical Treatment Procedures.-
  • Respiratory Track Systemic Toxicity.
  • Air Way Breathing must be secured. Evaluate
    ABC and
  • follow ACLS procedures.
  • Positive Pressure Assistance and Positive end
    expiratory
  • pressure (peep). Are necessary.- until edema has
    resolved.
  • Evaluate and monitor.- Chest x Rays, Blood
    Gases, ECG,
  • Electrolytes with special interest in Ca, Mg, Na,
    and K, Blood
  • Chemistry, fluorides in urine and blood, liver
    Kidney functions.
  • Start IV drip of 1000 cc in normal seline. 20 cc
    of 10 Calcium
  • Gluconate.
  • The amount of the solution will depend on the
    levels of serum
  • calcium.
  • Consider Hemodialisis for the removal of serum
    Fluorides.-

MEDICAL TREATMENT
150
Respiratory Exposure
  • Decontamination Procedures.
  • Not Possible
  • If gaseous exposure occurs skin and eye
    decontamination
  • is necessary.

DECON
Minor Exposure
Major Exposure
  • Signs Symptoms.
  • Coughing
  • Labored Breathing.
  • Shortness of Breath
  • Erithema
  • Swelling
  • Bleeding
  • Upper Airway Edema.
  • Pulmonary Edema.
  • Cardiac Arrithmia. (Irregular heart beats).
  • Signs Symptoms.
  • No signs symptoms.
  • Minor coughing.
  • Minor swelling and Eritlema.

SIGNS SYMPTOMS
151
(No Transcript)
152
(No Transcript)
153
Eye Exposure
  • Decontamination Procedure.
  • Go to the nearest water source or eye wash.
  • Open the valve.
  • Mechanically maintain eye lids open, or ask for
    help.
  • Wash for five minutes (5) and no more.

DECON
Major Exposure
Minor Exposure
  • Signs Symptoms.
  • Irritation of conjunctiva layer and
  • eye lid skin (minor).
  • Conjuctival injection.
  • No evidence of corneal injury.
  • No vision loss.
  • Signs Symptoms.
  • Severe irritation of the conjunctival
  • eye, and skin burn to eye lids.-
  • Conjuctival injection and swelling.
  • Corneal Opacification or Pitting.
  • Vision loss.

SIGNS SYMPTOMS
154
  • First-Aid Procedures.
  • Irrigate eyes with a 1 calcium
  • gluconate solution in normal
  • saline 1000 cc per eye (15 min. Aprox.).-
  • The use of an irrigating system
  • (Morgan Lens) after using a local
  • eye anesthetic (one or two drops
  • per eye)
  • should be considered.
  • Specialized Medical Evaluation
  • should be done (Slit lamp, etc).
  • First-Aid Procedures.
  • Irrigate eyes with a 1 Calcium
  • gluconate solution in normal saline
  • 1000 cc per eye (15 min. aprox.).
  • The use of an irrigating system
  • (Morgan Lens) after using a local eye
  • anesthetic (one or two drops per eye)
  • should be considered.
  • Obtain specialized medical evaluation.

FIRST-AID
  • Medical Treatment Procedures.-
  • If necessary continue treatment with a 1
    solution of calcium
  • gluconate in normal saline.-
  • Antibiotics and steroids can be used as indicated
    by eye
  • specialist.
  • Monitor ocular pressure.
  • Evaluate corneal opacification regularly.-
  • If skin, ingestion or inhalation exposure occurs
    do not forget to
  • decontaminate, and follow systemic toxicity
    treatment protocols.
  • Psychological support may be necessary.

MEDICAL TREATMENT
155
Ingestion
  • Decontamination Procedures.
  • Not Possible
  • If skin or eyes have been exposed decontamination
  • procedures should be followed.

DECON
Minor Exposure
Major Exposure
  • Signs Symptoms.
  • Erithema of oral mucousa.
  • Oral injury.
  • Bleeding of the oral cavity.
  • Systemic Toxicity.
  • Possible bronchial or pulmonary
  • problems if the patient vomited.

SIGNS SYMPTOMS
ALL EXPOSURES ARE CONSIDERED MAJOR.
  • First-Aid Procedures.
  • Do Not induce Vomiting.
  • If patient is able to swallow give oral
  • calcium solutions - or - calcium based
  • antacids - milk or water.
  • If unconscious obtain Medical Attention
    Immediately

FIRST-AID
  • Medical Treatment Procedures.-
  • HF destroys fiber optics - consider before using
    endoscopic
  • techniques.
  • Establish IV drip 1000 cc Normal Saline 20cc -
    10 calcium
  • gluconate.
  • If possible install a naso-gastric or
    oral-gastric tube.
  • Gastric Lavage with calcium solutions, calcium or
    magnesium
  • based antacids.
  • Systemic Toxicity Control.
  • The amount of calcium or magnesium to be
    administed will
  • depend on the serum levels.
  • Monitor ECG, Electrolytes, with special interest
    on Ca, Mg, K,
  • and Na, Chest X Rays may be necessary, blood
    gases, blood
  • Chemistry, Kidney and Liver functions.
  • Follow ACLS ATLS procedures.
  • Consider Hemodialisis for the removal of
    fluorides in Blood.

MEDICAL TREATMENT
156
Ingestion
  • Decontamination Procedures.
  • Not Possible
  • If skin or eyes have been exposed decontamination
  • procedures should be followed.

DECON
Major Exposure
Minor Exposure
  • Signs Symptoms.
  • Erithema of oral mucousa.
  • Oral injury.
  • Bleeding of the oral cavity.
  • Systemic Toxicity.
  • Possible bronchial or pulmonary
  • problems if the patient vomited.

ALL EXPOSURES ARE CONSIDERED MAJOR.
SIGNS SYMPTOMS
157
  • First-Aid Procedures.
  • Do Not induce Vomiting.
  • If patient is able to swallow give oral
  • calcium solutions - or - calcium based
  • antacids - milk or water.
  • If unconscious obtain Medical Attention
    Immediately

FIRST-AID
  • Medical Treatment Procedures.-
  • HF destroys fiber optics - consider before using
    endoscopic
  • techniques.
  • Establish IV drip 1000 cc Normal Saline 20cc -
    10 calcium
  • gluconate.
  • If possible install a naso-gastric or
    oral-gastric tube.
  • Gastric Lavage with calcium solutions, calcium or
    magnesium
  • based antacids.
  • Systemic Toxicity Control.
  • The amount of calcium or magnesium to be
    administed will
  • depend on the serum levels.
  • Monitor ECG, Electrolytes, with special interest
    on Ca, Mg, K,
  • and Na, Chest X Rays may be necessary, blood
    gases, blood
  • Chemistry, Kidney and Liver functions.
  • Follow ACLS ATLS procedures.
  • Consider Hemodialisis for the removal of
    fluorides in Blood.

MEDICAL TREATMENT
158
PATIENTS PROGNOSIS LONG-TERM EFFECTS WILL
DEPEND UPON
  • EXPOSURE TIME.
  • DECONTAMINATION
  • ROUTE OF ENTRY
  • CONCENTRATION OF HF.
  • TYPE OF TREATMENT GIVEN
  • HOW FAST TREATMENT WAS GIVEN.
  • GENERAL STATE OF THE PATIENT.
  • IF THE TREATMENT IS OPPORTUNE AND
  • ADEQUATE, PROGNOSIS WILL BE GOOD IN
  • MOST CASES.

159
MEDICATION DRESSING MATERIALS THAT SHOULD
EXIST WHEREVER HF IS HANDLED
160
1. IN THE FIELD
161
  • DECONTAMINATION UNITS CONSIST OF
  • vSAFETY SHOWER
  • vEYEWASH
  • vSEALED BOX WITH
  • PAIRS OF GLOVES
  • 2 TUBES OF HF GEL 30 GRAMS EACH
  • 1 ALUMINIZED PLASTIC SHEET

162
2. IN AN AMBULANCE, MEDICAL AREAS, OR ANY
WHERE MEDICALLY TRAINED PROFESSIONALS ARE
AVAILABLE
163
  • ALUMINIZED PLASTIC SHEETS
  • HF GEL 2.5
  • EYE IRRIGATION SOLUTION 1
  • NEBULIZING SOLUTION 2.5
  • 5 CALCIUM GLUCONATE AMPS
  • NORMAL SALINE IV SOLUTION
  • WATER SOLUBLE LUBRICANT GEL
  • LOCAL OPTHAMALIC ANESTHETIC
  • GLOVES LATEX, PVC OR NEOPRENE
  • HYPODERMICS, SEVERAL SIZES CALIBERS, STAINLESS
    STEEL NEEDLES
  • MORGAN LENS

164
  • MORGAN LENS DELIVERY SYSTEM (Y)
  • IV DELIVERY SYSTEMS
  • COLD PACKS
  • TRACHEOSTOMY KIT
  • WELL STOCKED EMERGENCY CART
  • DEFIB / MONITOR UNIT
  • INHALATION THERAPY EQUIPMENT
  • NEBULIZERS
  • MINOR SURGICAL KIT
  • CALCIUM EFFERVESCENT TABLETS
  • DRESSING MATERIALS

165
3. HYDROFLUORIC ACID KIT
166
  • ?SHOULD BE IN CONTROL ROOMS OR WELL
  • CONTROLLED AREAS. THEY ARE COMPOSED OF
  • TWO MAIN PARTS
  • INHALATION THERAPY UNIT O(2) CYLINDER
  • VALVE, FLOWMETER PRESSURE METER
  • NEBULIZER, TUBING MASK.
  • ONE PORTABLE CONTAINER THAT CONTAINS
  • 4 PAIRSOF GLOVES LATEX, PVC, NEOPRENE
  • 1 FLASHLIGHT
  • 1 LITER OF 1 CALCIUM SOLUTION IN
  • NORMAL SALINE

167
  • 1 LITER OF 2.5 CALCIUM SOLUTION IN
  • NORMAL SALINE
  • 8 TUBES OF HF GEL, 2.5
  • 5 AMP OF CALCIUM GLUCONATE, 10 SOL
  • 5 NEEDLES, 25 CAL 1 ½ LONG, STAINLESS
  • STEEL
  • 20 STERILE GAUZE
  • 2 TOURNIQUETS
  • 2 IV TUBING SETS
  • 4 BOTTLES OF ANTACID (CALCIUM OR
  • MAGNESIUM BASED)

168
  • 2 IV TUBING SETS
  • 4 BOTTLES OF ANTACID (CALCIUM OR
  • MAGNESIUM BASED)
  • 1 BOTTLE OF EFFERVESCENT CALCIUM
  • TABLETS
  • 1 BOTTLE OF LOCAL EYE ANESTHETIC
  • 2 COLD PACKS
  • 2 MAYO CANULAS
  • 2 ALUMINIZED PLATIC SHEETS
  • 1 TUBE OF LUBRICATING GEL
  • 2 STERILE CONTAINERS
  • 1 IV INFUSOR
  • 4 MORGAN LENSES

169
KEYS TO GOOD CONTROL WITH HF
  • AVOID EXPOSURES THROUGH
  • CONTINUOUS EDUCATION.
  • GOOD INDUSTRIAL HYGIENE PRACTICES.
  • MAXIMUM SAFETY IN HANDLING HF ON OFF-SITE.
  • CONTINOUS MEDICAL TRAINING ON OFF-SITE.
  • PARTICIPATE IN NEIGHBORING COMMUNITY HOSPITALS,
    EMS, AND OTHER AGENCIES, SO THAT YOU MAY BE
    PREPARED FOR ANY CONTIGENCY.

170
(No Transcript)
171
(No Transcript)
172
(No Transcript)
173
SO , PRODUCE, STORE, HANDLE AND DISPOUSE ALL
HAZARDOUS CHEMICALS WITH RESPECT AND KNOWLEDGE
174
FOR YOUR ATTENTION AND PATIENCE THANK YOU VERY
MUCH !!!
Write a Comment
User Comments (0)
About PowerShow.com
