Title: New Product


1
  • 2011
  • New Product
  • Draft version

2
Super Audio CD Transport P-02
Dual Mono D/A Converter D-02
3
Super Audio CD Transport P-02
4
Dual Mono D/A Converter D-02
5
SACD separated system (P/D)
4 series7 models
01 03 05
07
VRDS
VRDS
VRDS
P-01/D-01
P-03/D-03
P-05/D-05
D-07
6
SACD separated system (P/D)
4 series7 models
01 02 05
07
VRDS
VRDS
P-01/D-01
P-02/D-02
P-05/D-05
D-07
7
P-02 D-02Philosophy
8
P-02 D-02 Philosophy
Reproduce the inspiration of the original musical
recording, free from stress and coloration
Esoterics new reference level transport / DAC
system designed for ultimate audio experience
9
P-02 D-02 Philosophy
ES-LINK3DUAL AES 8Fs
ES-LINK3 is Esoterics proprietary brand new
PCM digital link format enables extremely high
definition 48bit/176.4kHz data transmission.The
system also supports DUAL AES 8Fs format, which
allows 24bit/352.8kHz data transmission.
10
P-02 D-02 Philosophy
35bit D/A Processing (PAT.P)
The D-02 is implemented with highly advanced
patent pending technology 35bit D/A Processing
algorithm.Digital data processing is done with
35bit basis, which definition is 2048 times
higher than 24bit based DAC system.Ultimate high
definition digital processing contributes to the
D-02s pure, smooth analog sound quality.
11
P-02 D-02 Philosophy
PLL-less Direct Master Clock Link
Direct, pure and precise.22.5792MHz master
clock is used to link two digital devices to
maximize digital signal purity.
12
P-02 D-02 Philosophy
Isolated Clock Technology
The clock module each unit has, is completely
isolated from other digital and analog circuits
to keep clock signal as pure as possible.
13
P-02 D-02 Philosophy
SACD Multi-channel playback
The P-02/D-02 system is equipped with i.LINK
terminals, and supports SACD multi-channel
playback when 3sets of D-02 is connected to the
P-02.
14
Super Audio CD Transport P-02
15
P-02
16
P-02
Tray shutter
Disc indicator LED
i.LINK(4p/6p)
10MHz clock input
17
(No Transcript)
18
P-02
TOP
BOTTOM
19
P-02VRDS-NEOSACD/CD Transport Mechanism
20
P-02
VRDS-NEO ?VMK-3.5-20S?
21
P-02
VRDS-NEO?VMK-3.5-20S? Following the P-03
mechanism.
Shaft sliding Pick up (VOSP)
Net Weight 5.2kg
20mm steel bridge duralumin turntable
Three-phase brushless spindle motor
Ceramic ball bearing x 2
22
P-02
VRDS-NEO?VMK-3.5-20S? New Spindle Servo Driver
?VS-DD? Circuit VS-DD VRDS Spindle Discrete
Driver A discrete amplifier circuit dedicated to
drive only the spindle motor. This achieves
smoother spindle rotation and smoother rotation
provides more accurate data retrieval.
TOP
BOTTOM
?VS-DD? Transformer The VS-DD power supply
ensures highly stable power supply capability,
being free from power fluctuations associated
with shared power supplies. This power supply
is fully isolated from the audio circuit, free
from motor noise and vibration.
23
P-02
High sampling / high bit digital output
XLR x2?ES-LINK3? 88.2176.4kHz/48bit ?DUAL AES
8Fs? 88.2352.8kHz/24bit AES/EBU ES-LINK1,
2 DSD RCA x1 S/PDIF 44.1176.4kHz /
24bit i.LINK 4p/6pi.LINK AUDIO 44.1176.4kHz /
24bit DSD
24
Dual Mono D/A Converter D-02
25
D-02
26
D-02
Input indicator LED
Reserved for future up-grade service
10MHz clock input
USB(192kHz/24bit, Async)
i.LINK (4p/6p)
27
D-02
TOP
BOTTOM
28
D-02 35bit D/A ProcessingDual mono DAC
29
D-02
35bit D/A Processing dual mono DAC
35bit D/A 35bit D/A processing is a brand new
PAT.P technology from Esoteric. By using multiple
32bit ICs, the algorithm processes signal in 35
bit resolution. Very smooth, high resolution
sound. 8 DACs /ch High linearity and low
noise AK4399 (32bit)Flagship device from Asahi
Kasei Electronics. Dual mono config.Each
channel has dedicated power supply circuits and
power transformers
BOTTOM
30
D-02
35bit D/A processing (PAT.P)
The D-02 applies a completely new technology,
"35-bit D/A processing" (patent pending)
algorithm. This process enhances the reproduction
of analog waveforms by implementing even finer
bit gradation. In comparison with 24-bit data
processing, 32-bit processing can theoretically
have 256 times higher resolution. 35-bit
processing is 8 times higher than the resolution
of 32-bit processing, that is 2,048 times higher
than the resolution of 24-bit processing. The
final analog output signal has a very smooth
sound quality with ultimate resolution, and a
distinctive power of expression, even for
extremely small signal levels.
31
D-02
Full discrete class A buffer amplifier
Class A discrete buffer 22 high voltage power
supply x 4 class A buffer amps / channelThe amp
circuitry is expanded to double scale from the
K-01. XLR Fully balanced 2 parallel buffer
amp output RCAUnbalanced 4 parallel buffer
amp output
K-01
D-02
32
D-02Digital inputD/D convertDigital filter
33
D-02
High sampling / high bit digital input
XLR x2?ES-LINK3? 88.2192kHz/48bit ?DUAL AES
8Fs? 88.2384kHz/24bit AES/EBU, ES-LINK1, 2,
DSD RCA x2, OPT x1, USB x1 S/PDIF 32192kHz /
24bit i.LINK 4p/6pi.LINK AUDIO 32192kHz /
24bitDSDSupports SACD multi-channel playback
when using x 3 sets of D-02. RESERVE x1 Offers
future upgradability.
RIGHT
LEFT
34
D-02
USB
192kHz/24bit For Studio master quality music
data Asynchronous USB High speed
1(asynchronous) 192kHz/24bit High speed
2(adaptive) 192kHz/24bitFull speed
(adaptive) 96kHz/24bit Exclusive
PC driver softwareSupplied from Esoterics web
site. USB Isolator Isolates power and signal
paths from USB input. Eliminates interference
from an external PC
192/24
Async
35
D-02
Digital Processing
D/D convert function 1. PCM signal from CD and
external digital equipment ? Up
convert ORG/2Fs/4Fs/8Fs ? PCM gt DSD
conversion 2. DSD signals from SACD
? DSD native playback
Digital filter 1. FIR(2 types)
(Finite impulse response).

Acknowledged conventional type. 2. Short
Delay(2 types) Pre-echo reduction for more
natural sound. 3. Digital filter OFF
36
D-02
Superior usability
high bit precision digital attenuation
Controls volume without degradation of sound
quality by high bit range. Connects
directly to power amplifier. Use as a
digital pre-amp, combined with a multi input
digital source selector XLR pin assign
selection (No. 2 / 3 HOT) XLR output level
selection (0 dB/6 dB) to match with input
sensitivity of amplifiers. Analogue output
selection (XLR/RCA)
37
New generation clocking1. Isolated Clock
Technology
38
P-02/D-02
Isolated Clock Technology
Isolated clock module Quality of the isolated
clock is comparable to high precision external
clock unit Stabilized power supply Dedicated
power supply circuit and dedicated
transformer GND isolation to prevent random
jitter potentially caused by ground current
fluctuation. 0.5ppm VCXO VCXOvoltage
controlled crystal oscillator Dual PLL
functionlock range 15ppm Narrow lock range
for high quality sound.
39
New generation clocking2. PLL-less DirectMaster
Clock Link
40
P-02/D-02
Conventional Word Sync
The DAC provides 44.1176.4kHz word clock to
the transport, and inside the transport, the
clock signal will be converted to higher
frequency (22. 5792MHz) at internal PLL circuit
to match with digital output circuit.
PLL
44.1176.4kHz Word Clock
Digital Audio
44.1176.4kHz Word Clock
41
P-02/D-02
PLL-less Direct Master Clock Link
NEW
22.5792MHz Master clock directly fed to
transport and bypasses internal PPL circuit
direct, precise clocking
PLL
22.5792MHz Master Clock
Digital Audio
22.5792MHz Master Clock
42
P-02/D-02
G-0Rb
PLL
22.5792MHz Master Clock
44.1176.4kHz Word Clock
43
P-02/D-02
10MHz external clock system
PLL
22.5792MHz Master Clock
10MHz Master Clock
44
P-02 D-02 Summery
Reproduce the inspiration of the original musical
recording, free from stress and coloration
VRDS-NEOVS-DD (Advanced spindle drive
design) ES-LINK3,DUAL AES 8Fs high rez PCM
link (192kHz/48bit?)
(384kHz/24bit?) ?Max output freq from the P-02 is
176.4kHz/352.8kHz35bit D/A Processing dual
mono DAC (32bit AK4399 x 8 circuit / ch)Full
discrete class A buffer amp (22V high
voltage power supply, 4 amps/channel doubled
scale of the K-01)
45
P-02 D-02 Summery
Reproduce the inspiration of the original musical
recording, free from stress and coloration
x 8 toroidal power supply / systemIsolated
Clock Technology (Isolated power supply
GND to keep potential random jitter at minimum
level)PLL-less Direct Master Clock Link
(22.5792MHz master clock direct, precise,
short signal path) Supports SACD multi-channel
/ PC Audio playback (i.LINK?192kHz/24bit
Async USB)
46
Super Audio CD Transport P-02
Dual Mono D/A Converter D-02
47
END
48
Super Audio CD Transport P-02
Dual Mono D/A Converter D-02
49
V R D S
Vibration-free Rigid Disc-clamping System
50
Horizontal disc shaking allowance is /- 0.5mm
(by Red Book standard)
Conventional CD/SACD transport
51
Large size disc clamp implementaion
VRDS Mechanism
52
VOSP Pickup
? The laser axis is NOT always aligned vertically
to the disc
? The laser axis is ALWAYS aligned vertically to
the disc surface. ? High precision data
retrieval capability is achieved!!
53
VOSP Pickup
Laser optical axis will not tilt, always
maintaining the vertical axis.
