Title: Threads


1
Threads
  • Fred Kuhns
  • fredk_at_cse.wustl.edu
  • Applied Research Laboratory,
  • Department of Computer Science and Engineering,
  • Washington University in St. Louis

2
Introduction to Threads
Multithreaded Process Model
Single-Threaded Process Model
Thread
Thread
Thread
Thread Control Block
Thread Control Block
Thread Control Block
Process Control Block
User Stack
Process Control Block
User Stack
User Stack
User Stack
Kernel Stack
User Address Space
User Address Space
Kernel Stack
Kernel Stack
Kernel Stack
3
Processes and Threads
  • Process model
  • Unit of dispatching process is an execution path
    through one or more programs set of threads
    (computational entities)
  • execution may be interleaved with other processes
  • Unit of resource ownership process is allocated
    a virtual address space to hold the process image
  • What if we separate notion of execution from
    Process abstraction? Answer we get threads.

4
Threads
  • Dynamic object representing an execution path and
    computational state.
  • threads have their own computational state PC,
    stack, user registers and private data
  • Remaining resources are shared amongst threads in
    a process
  • Effectiveness of parallel computing depends on
    the performance of the primitives used to express
    and control parallelism
  • Useful for expressing the intrinsic concurrency
    of a program regardless of resulting performance
  • We will discuss three examples of threading
  • User threads,
  • Kernel threads and
  • Scheduler Activations

5
Common Thread Models
  • User level threads - user libraries
    implementation
  • Benefits no kernel modifications, flexible and
    low cost
  • Drawbacks thread may block entire process, no
    parallelism
  • Kernel level threads - kernel directly supports
    multiple threads of control in a process.
  • Benefits scheduling/synchronization
    coordination, less overhead than process,
    suitable for parallel application
  • Drawbacks more expensive than user-level
    threads, generality leads to greater overhead
  • Light-Weight Processes (LWP) Kernel supported
    user thread
  • LWP bound to kernel thread a kernel thread may
    not be bound to an LWP
  • LWP is scheduled by kernel
  • User threads scheduled by library onto LWPs
  • Multiple LWPs per process

6
Thread States
  • Primary states
  • Running, Ready and Blocked.
  • Operations to change state
  • Spawn new thread provided register context and
    stack pointer.
  • Block event wait, save user registers, PC and
    stack pointer
  • Unblock moved to ready state
  • Finish deallocate register context and stacks.

7
Threading Models
  • User threads Many-to-One
  • kernel threads One-to-One
  • Mixed user and kernel Many-to-Many

8
User Level Threads
  • User level threads - supported by user level
    threads libraries
  • Examples
  • POSIX Pthreads, Mach C-threads, Solaris threads
  • Benefits
  • no modifications required to kernel
  • flexible and low cost
  • Drawbacks
  • can not block without blocking entire process
  • no parallelism (not recognized by kernel)

9
Kernel Level Threads
  • Kernel level threads - directly supported by
    kernel, thread is the basic scheduling entity
  • Examples
  • Windows 95/98/NT/2000, Solaris, Tru64 UNIX, BeOS,
    Linux
  • Benefits
  • coordination between scheduling and
    synchronization
  • less overhead than a process
  • suitable for parallel application
  • Drawbacks
  • more expensive than user-level threads
  • generality leads to greater overhead

10
Threading Issues
  • fork and exec
  • should fork duplicate one, some or all threads
  • Cancellation cancel the target thread, issues
    with freeing resources and inconsistent state
  • asynchronous cancellation target is immediately
    canceled
  • deferred cancellation target checks
    periodically. check at cancellation points
  • Signals generation, posting and delivery
  • Every signal handled by a default or user-defined
    handler
  • Signal delivery
  • to thread for which it may apply
  • to every thread in process
  • to certain threads
  • specifically designated thread (signal thread)
  • synchronous signals should go to thread causing
    the signal
  • what about asynchronous signals?
  • Solaris deliver to a special thread which
    forward to first user created thread that has not
    blocked the signal.
  • Bounding the number of threads created in a
    dynamic environment
  • use thread pools
  • Al threads share some address space
  • use of thread specific data

11
First Class threads (Psyche OS)
  • Thread operations in user space
  • create, destroy, synch, context switch
  • kernel threads implement a virtual processor
  • Course grain in kernel - preemptive scheduling
  • Communication between kernel and threads library
  • shared data structures.
  • Software interrupts (user upcalls or signals).
    Example, for scheduling decisions and preemption
    warnings.
  • Kernel scheduler interface - allows dissimilar
    thread packages to coordinate.

12
Scheduler Activations
  • Attempt to combine benefits of both user and
    kernel threading support
  • blocking system call should not block whole
    process
  • user space library should make scheduling
    decisions
  • efficiency by avoiding unnecessary user, kernel
    mode switches.
  • Kernel assigns a set of virtual processors to
    each process. User library then schedules
    threads on these virtual processors.

13
Scheduler Activations
  • An activation
  • serves as execution context for running thread
  • notifies thread of kernel events (upcall)
  • space for kernel to save processor context of
    current user thread when stopped by kernel
  • Library schedules user threads on activations.
  • space for kernel to save processor context of
    current user thread when stopped by kernel
  • upall performed when one of the following occurs
  • user thread performs blocking system call
  • blocked thread belonging to process, then its
    library is notified allowing it to either
    schedule a new thread or resume the preempted
    thread.
  • kernel is responsible for processor allocation gt
    preemption by kernel.
  • Thread package responsible for scheduling threads
    on available processors (activations)

14
Pthreads
  • a POSIX standard (IEEE 1003.1c) API for thread
    creation and synchronization.
  • API specifies behavior of the thread library,
    implementation is up to development of the
    library.
  • Common in UNIX operating systems.

15
UNIX Support for Threading
  • BSD
  • pthreads and similar user space implementations
  • process model only. 4.4 BSD enhancements.
  • BSD based OSes are adding support for threads
  • Solaris
  • user threads, kernel threads, LWPs and in 2.6
    Scheduler Activations
  • Mach
  • kernel threads and tasks. Thread libraries
    provide semantics of user threads, LWPs and
    kernel threads.
  • Digital UNIX - extends MACH to provide usual UNIX
    semantics Pthreads library.

16
Solaris Threads
  • Supports
  • user threads (uthreads) via libthread and
    libpthread
  • LWPs, abstraction that acts as a virtual CPU for
    user threads.
  • LWP is bound to a kthread.
  • kernel threads (kthread), every LWP is associated
    with one kthread, however a kthread may not have
    an LWP
  • interrupts as threads

17
Solaris kthreads
  • Fundamental scheduling/dispatching object
  • all kthreads share same virtual address space
    (the kernels) - cheap context switch
  • System threads - example STREAMS, callout
  • kthread_t, /usr/include/sys/thread.h
  • scheduling info, pointers for scheduler or sleep
    queues, pointer to klwp_t and proc_t

18
Solaris LWP
  • Kernel provided mechanism to allow for both user
    and kernel thread implementation on one platform.
  • Bound to a kthread
  • LWP data (see /usr/include/sys/klwp.h)
  • user-level registers, system call params,
    resource usage, pointer to kthread_t and proc_t
  • All LWPs in a process share
  • signal handlers
  • Each may have its own
  • signal mask
  • alternate stack for signal handling
  • No global name space for LWPs

19
Solaris User Threads
  • Implemented in user libraries
  • library provides synchronization and scheduling
    facilities
  • threads may be bound to LWPs
  • unbound threads compete for available LWPs
  • Manage thread specific info
  • thread id, saved register state, user stack,
    signal mask, priority, thread local storage
  • Solaris provides two libraries libthread and
    libpthread.
  • Try man thread or man pthreads

20
Solaris Thread Data Structures
proc_t
p_tlist
kthread_t
t_procp
t_lwp
klwp_t
t_forw
lwp_thread
lwp_procp
21
Solaris Threading Model (Combined)
Process 2
Process 1
user
Int kthr
kernel
hardware
22
Solaris User Level Threads
Stop
Wakeup
Runnable
Continue
Stop
Stopped
Sleeping
Preempt
Dispatch
Stop
Sleep
Active
23
Solaris Lightweight Processes
Timeslice or Preempt
Stop
Running
Wakeup
Dispatch
Blocking System Call
Runnable
Stopped
Continue
Wakeup
Stop
Blocked
24
Solaris Interrupts
  • One system wide clock kthread
  • pool of 9 partially initialized kthreads per CPU
    for interrupts
  • interrupt thread can block
  • interrupted thread is pinned to the CPU

25
Solaris Signals and Fork
  • Divided into Traps (synchronous) and interrupts
    (asynchronous)
  • each thread has its own signal mask, global set
    of signal handlers
  • Each LWP can specify alternate stack
  • fork replicates all LWPs
  • fork1 only the invoking LWP/thread

26
Mach
  • Two abstractions
  • Task - static object, address space and system
    resources called port rights.
  • Thread - fundamental execution unit and runs in
    context of a task.
  • Zero or more threads per task,
  • kernel schedulable
  • kernel stack
  • computational state
  • Processor sets - available processors divided
    into non-intersecting sets.
  • permits dedicating processor sets tasks
  • Mach C-Threads
  • Coroutine-based - multiple user threads onto a
    single-threaded task
  • Thread-based - one-to-one mapping from c-threads
    to Mach threads. Default.
  • Task-based - One Mach Task per c-thread.

27
Continuations
  • Address problem of excessive kernel stack memory
    requirements
  • process model versus interrupt model
  • one per process kernel stack versus a per thread
    kernel stack
  • Thread is first responsible for saving any
    required state (the thread structure allows up to
    28 bytes)
  • indicate a function to be invoked when unblocked
    (the continuation function)
  • Advantage stack can be transferred between
    threads eliminating copy overhead.

28
Digital UNIX
  • Based on Mach 2.5 kernel
  • Provides complete UNIX programmers interface
  • 4.3BSD code and ULTRIX code ported to Mach
  • u-area replaced by utask and uthread
  • proc structure retained
  • Threads
  • Signals divided into synchronous and asynchronous
  • global signal mask
  • each thread can define its own handlers for
    synchronous signals
  • global handlers for asynchronous signals

29
Windows 2000 Threads
  • Implements the one-to-one mapping.
  • Each thread contains
  • - a thread id
  • - register set
  • - separate user and kernel stacks
  • - private data storage area

30
Linux Threads
  • Linux refers to them as tasks rather than
    threads.
  • Thread creation is done through clone() system
    call.
  • Clone() allows a child task to share the address
    space of the parent task (process)

31
4.4 BSD UNIX
  • Initial support for threads implemented but not
    enabled in distribution
  • Proc structure and u-area reorganized
  • All threads have a unique ID
  • How are the proc and u areas reorganized to
    support threads?
About PowerShow.com
