Hyper-Threading Technology

1
Hyper-Threading Technology

• Presented By
• Nagarajender Rao Katoori

2
  Introduction

• To Enhance Performance-
• Increase in clock rate
•
• Involves reducing clock cycle time
• Can increase the performance by increasing
  number of instructions finishing per second
• H/w limitations limit this feature
• Cache hierarchies
• Having frequently used data on the processor
  caches reduces average accesses time

3

• Pipelining
• Implementation Technique whereby multiple
  instructions are overlapped in execution
• Limited by the dependencies between instructions

• Effected by stalls and effective CPI is greater
  than 1
• Instruction Level Parallelism
• It refers to techniques to increase the number
  of instructions executed in each clock cycle.
• Exists whenever the machine instructions that
  make up a program are insensitive to the order in
  which they are executed if dependencies does not
  exist, they may be executed.

4

• Thread level parallelism
• Chip Multi Processing
• Two processors, each with full set of execution
  and architectural resources, reside on a single
  die.
• Time Slice Multi Threading
• single processor to execute multiple threads by
  switching between them
• Switch on Event Multi Threading
• switch threads on long latency events such as
  cache misses

5

• Thread level parallelism (cont..)

• Simultaneous Multi Threading
• Multiple threads can execute on a single
  processor without switching.
• The threads execute simultaneously and make much
  better use of the resources.
• It maximizes the performance vs. transistor count
  and power consumption.

6

•    Hyper-Threading Technology
• Hyper-Threading Technology brings the
  simultaneous multi-threading approach to the
  Intel architecture.
•   Hyper-Threading Technology makes a single
  physical processor appear as two or more logical
  processors
•  Hyper-Threading Technology first invented by
  Intel Corp.
•  Hyper-Threading Technology provides
  thread-level-parallelism (TLP) on each processor
  resulting in increased utilization of processor
  and execution resources.
• Each logical processor maintain one copy of the
  architecture state

7
Hyper-Threading Technology Architecture
Processor Execution Resources
Processor Execution Resources
Arch State
Arch State
Arch State
Processor with out Hyper-Threading Technology
Processor with Hyper-Threading Technology
Ref Intel Technology Journal, Volume 06 Issue
01, February 14, 2002
8
Following resources are duplicated to support
Hyper-Threading Technology

• Register Alias Tables
• Next-Instruction Pointer
• Instruction Streaming Buffers and Trace Cache
  Fill Buffers
• Instruction Translation Look-aside Buffer

9
Figure Intel Xeon processor pipeline
10

• Sharing of Resources
•
• Ø     Major Sharing Schemes are-
• o Partition
• o Threshold
• o Full Sharing
• Partition
•
• Ø     Each logical processor uses half the
  resources
• Ø     Simple and low in complexity
• Ø     Ensures fairness and progress
• Ø     Good for major pipeline queues

11
Partitioned Queue Example

• Yellow thread It is faster thread
• Green thread It is slower thread

12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
Partitioned Queue Example

• Partitioning resource ensures fairness and
• ensures progress for both logical processors.

16

•  Threshold
•  Ø     Puts a threshold on number of resource
  entries a logical processor can use.
• Ø     Limits maximum resource usage
• Ø     For small structures where resource
  utilization in burst and time of utilization is
  short, uniform and predictable
•
• Ø     Eg- Processor Scheduler

17

•  Full Sharing
• Ø     Most flexible mechanism for resource
  sharing, do not limit the maximum uses for
  resource usage for a logical processor
• Ø     Good for large structures in which working
  set sizes are variable and there is no fear of
  starvation
• Ø     Eg All Processor caches are shared
• o       Some applications benefit from a shared
  cache because they share code and data,
  minimizing redundant data in the caches

18
Netburst Microarchitectures execution pipeline
19
SINGLE-TASK AND MULTI-TASK MODES

• Two modes of operations
• single-task (ST)
• multi-task (MT).
• MT-mode- There are two active logical processors
  and some of the resources are partitioned.
• There are two flavors of ST-mode single-task
  logical processor 0 (ST0) and single-task logical
  processor 1 (ST1).
• In ST0- or ST1-mode, only one logical processor
  is active, and resources that were partitioned in
  MT-mode are re-combined to give the single active
  logical processor use of all of the resources

20
SINGLE-TASK AND MULTI-TASKMODES
21

• HALT instruction that stops processor execution.
• On a processor with Hyper-Threading Technology,
  executing HALT transition the processor from
  MT-mode to ST0- or ST1-mode, depending on which
  logical processor executed the HALT.
• In ST0- or ST1-modes, an interrupt sent to the
  halted logical processor would cause a transition
  to MT-mode.

22
OPERATING SYSTEM

• For best performance, the operating system should
  implement two optimizations.
• The first is to use the HALT instruction if one
  logical processor is active and the other is not.
  HALT will allow the processor to transition MT
  mode to either the ST0- or ST1-mode.
• The second optimization is in scheduling software
  threads to logical processors. The operating
  system should schedule threads to logical
  processors on different physical processors
  before scheduling two threads to the same
  physical processor.

23

• Business Benefits of Hyper-Threading
• Technology
• Higher transaction rates for e-Businesses
• Improved reaction and response times for
  end-users and customers.
• Increased number of users that a server system
  can support
• Handle increased server workloads
• Compatibility with existing server applications
  and operating systems

24
Performance increases from Hyper-Threading
Technology on an OLTP workload
Web server benchmark performance
25
Conclusion

• Intels Hyper-Threading Technology brings the
  concept of simultaneous multi-threading to the
  Intel Architecture.
• It will become increasingly important going
  forward as it adds a new technique for obtaining
  additional performance for lower transistor and
  power costs.
• The goal was to implement the technology at
  minimum cost while ensuring forward progress on
  logical processors, even if the other is stalled,
  and to deliver full performance even when there
  is only one active logical processor.

26
References

• HYPER-THREADING TECHNOLOGY ARCHITECTURE AND
  MICROARCHITECTURE by Deborah T. Marr, Frank
  Binns, David L. Hill, Glenn Hinton,David A.
  Koufaty, J. Alan Miller, Michael Upton, intel
  Technology Journal, Volume 06 Issue 01, Published
  February 14, 2002. Pages 4 15.
• HYPERTHREADING TECHNOLOGY IN THE NETBURST
  MICROARCHITECTURE by David Koufaty,Deborah T.
  Marr, IEEE Micro, Vol. 23, Issue 2, MarchApril
  2003. Pages 56 65.
• http//cache-www.intel.com/cd/00/00/22/09/220943_
  220943.pdf
• http//www.cs.washington.edu/research/smt/papers/t
  lp2ilp.final.pdf
• http//mos.stanford.edu/papers/mj_thesis.pdf

27
