ECE 355: Software Engineering

1
ECE 355 Software Engineering

• CHAPTER 8
• Instructor
• Kostas Kontogiannis

2
Course outline

• Unit 1 Software Engineering Basics
• Unit 2 Process Models and Software Life Cycles
• Unit 3 Software Requirements
• Unit 4 Unified Modeling Language (UML)
• Unit 5 Design Basics and Software Architecture
• Unit 6 OO Analysis and Design
• ? Unit 7 Design Patterns
• Unit 8 Testing and Reliability
• Unit 9 Software Engineering Management and
  Economics

3
References

• The material for this lecture was obtained from
• http//www.dofactory.com/Patterns/Patterns.aspxli
  st
• http//www.developer.com/design/article.php/150269
  1

4
Overview

• Some more patterns
• Adapter
• Bridge
• State
• Factory Method
• Command
• Proxy
• Chain of Responsibility
• Observations and Conclusions
• Further reading

5
Adapter Design Pattern

• The Adapter is intended to provide a way for a
  client to use an object whose interface is
  different from the one expected by the client,
  without having to modify either
• This pattern is suitable for solving issues that
  arise, for example, when
• 1) you want to replace one class with another and
  the interfaces do not match, and
• 2) you want to create a class that can interact
  with other classes without knowing their
  interfaces at design time

6
Adapter Design Pattern - Operation

• First, you create a custom Target class that
  defines methods using an interface as expected by
  the client
• Second, you create a custom Adapter that
  implements the interface expected by the Adaptee.
  The Adapter class subclasses the Target, and
  provides an alternate implementation of the
  client requests in terms that the Adaptee
  expects. Adapter overrides the Target method and
  provides the correct interface for Adaptee.
• This approach has the advantage that it does not
  lead to modifications in the client. Adapter is a
  structural pattern and you can use it to react to
  changes in class interfaces as your system
  evolves, or you can proactively use the Adapter
  pattern to build systems that anticipate changing
  structural details

7
Adapter Design Pattern
8
Adapter Design Pattern

• Participants The classes and/or objects
  participating in this pattern are
• Target
• defines the domain-specific interface that Client
  uses.
• Adapter
• adapts the interface Adaptee to the Target
  interface.
• Adaptee
• defines an existing interface that needs
  adapting.
• Client
• collaborates with objects conforming to the
  Target interface.

9
Adapter Design Pattern
   // "Adaptee"   class Adaptee      public
void SpecificRequest()          Console.WriteLi
ne("Called SpecificRequest()")       //
Client   class MainApp      static void
Main()          // Create adapter and place a
request       Target target new
Adapter()      target.Request()      // Wait
for user       Console.Read()

•   // "Target"   class Target      public
  virtual void Request()          Console.WriteLi
  ne("Called Target Request()")
• class Adapter Target      private
  Adaptee adaptee new Adaptee()    public
  override void Request()          // Possibly
  do some other work       // and then call
  SpecificRequest       adaptee.SpecificRequest()


Output Called SpecificRequest()
10
Bridge Design Pattern - Operation

• Decouple an abstraction from its implementation
  so that the two can vary independently
• The Bridge pattern is useful when there is a
  hierarchy of abstractions and a corresponding
  hierarchy of implementations. Rather than
  combining the abstractions and implementations
  into many distinct classes, the Bridge pattern
  implements the abstractions and implementations
  as independent classes that can be combined
  dynamically. Related patterns are
• Layered Architecture The Bridge design pattern
  is a way of organizing the entities identified
  using the Layered Architecture pattern into
  classes.
• Abstract Factory The Abstract Factory pattern
  can be used by the Bridge pattern to decide which
  implementation class to instantiate for an
  abstraction object

11
Bridge Design Pattern

• Abstraction
• defines the abstraction's interface.
• maintains a reference to an object of type
  Implementor.
• RefinedAbstraction
• extends the interface defined by Abstraction.
• Implementor
• defines the interface for implementation classes.
  This interface doesn't have to correspond exactly
  to Abstraction's interface in fact the two
  interfaces can be quite different. Typically the
  Implementation interface provides only primitive
  operations, and Abstraction defines higher-level
  operations based on these primitives.
• ConcreteImplementor
• implements the Implementor interface and defines
  its concrete implementation.

12
Bridge Design Pattern
13
Bridge Design Pattern
// "Implementor"   abstract class
Implementor      public abstract void
Operation()    // "RefinedAbstraction"
  class RefinedAbstraction Abstraction
 public override void Operation()          impl
ementor.Operation()

•   // "Abstraction"   class Abstraction      p
  rotected Implementor implementor    //
  Property
•     public Implementor Implementor
      set implementor value         public
  virtual void Operation()          implementor.O
  peration()

14
Bridge Design Pattern
// "ConcreteImplementorA"   class
ConcreteImplementorA Implementor      public
override void Operation()          Console.Writ
eLine("ConcreteImplementorA Operation")
  // "ConcreteImplementorB"   class
ConcreteImplementorB Implementor      public
override void Operation()          Console.Writ
eLine("ConcreteImplementorB Operation")

15
Bridge Design Pattern - Client

• class MainApp      static void
  Main()          Abstraction ab new
  RefinedAbstraction()      // Set
  implementation and call       ab.Implementor
  new ConcreteImplementorA()      ab.Operation()
        // Change implemention and call
        ab.Implementor new ConcreteImplementorB(
  )      ab.Operation()      // Wait for user
        Console.Read()

Output ConcreteImplementorA OperationConcreteImp
lementorB Operation
16
State Design Pattern - Operation

• Allow an object to alter its behavior when its
  internal state changes. The object will appear to
  change its class.
• The State pattern is useful when you want to have
  an object represent the state of an application,
  and you want to change the state by changing that
  object.
• The State pattern is intended to provide a
  mechanism to allow an object to alter its
  behavior in response to internal state changes.
  To the client, it appears as though the object
  has changed its class.
• The benefit of the State pattern is that
  state-specific logic is localized in classes that
  represent that state.

17
State Design Pattern

• Participants The classes and/or objects
  participating in this pattern are
• Context
• defines the interface of interest to clients
• maintains an instance of a ConcreteState subclass
  that defines the current state.
• State
• defines an interface for encapsulating the
  behavior associated with a particular state of
  the Context.
• Concrete State
• each subclass implements a behavior associated
  with a state of Context

18
State Design Pattern
19
State Design Pattern
class Context      private State
state    public Context(State
Astate)          this.state
Astate        // Property     public State
State          get return state
      set               state value
        Console.WriteLine("State "
state.GetType().Name)              public
void Request()          state.Handle(this)


• // "State"   abstract class State
•     public abstract void Handle(Context
  context)    // "ConcreteStateA"   class
  ConcreteStateA State      public override
  void Handle(Context context)          context.S
  tate new ConcreteStateB()        //
  "ConcreteStateB"   class ConcreteStateB
  State      public override void Handle(Context
  context)          context.State new
  ConcreteStateA()

20
State Design Pattern - Client

• static void Main()          // Setup context
  in a state       Context c new Context(new
  ConcreteStateA())      // Issue requests,
  which toggles state       c.Request()      c.Re
  quest()      c.Request()      c.Request()
      // Wait for user       Console.Read()


Output State ConcreteStateAState
ConcreteStateBState ConcreteStateAState
ConcreteStateBState ConcreteStateA
21
Factory Method - Operation

• When developing classes, you always provide
  constructors for your clients' use. There are
  certain circumstances in which you do not want
  your clients to know which class out of several
  to instantiate.
• The Factory Method is intended to define an
  interface for clients to use to create an object,
  but lets subclasses decide which class to
  instantiate. Factory Methods let a class defer
  instantiation to subclasses.

22
Factory Method

• The classes and/or objects participating in this
  pattern are
• Product
• defines the interface of objects the factory
  method creates
• ConcreteProduct
• implements the Product interface
• Creator
• declares the factory method, which returns an
  object of type Product. Creator may also define a
  default implementation of the factory method that
  returns a default ConcreteProduct object.
• may call the factory method to create a Product
  object.
• ConcreteCreator
• overrides the factory method to return an
  instance of a ConcreteProduct.

23
Factory Method
24
Factory Method
// "ConcreteCreator"   class ConcreteCreatorA
Creator      public override Product
FactoryMethod()          return new
ConcreteProductA()        //
"ConcreteCreator"   class ConcreteCreatorB
Creator      public override Product
FactoryMethod()          return new
ConcreteProductB()

•   abstract class Product      //
  "ConcreteProductA"   class ConcreteProductA
  Product      // "ConcreteProductB"
    class ConcreteProductB Product      //
  "Creator"   abstract class Creator      publ
  ic abstract Product FactoryMethod()

25
Factory Method - Client

•   class MainApp      static void
  Main()          // An array of creators
        Creator creators new
  Creator2      creators0 new
  ConcreteCreatorA()      creators1 new
  ConcreteCreatorB()      // Iterate over
  creators and create products
•       foreach(Creator creator in
  creators)               Product product
  creator.FactoryMethod()         Console.WriteLi
  ne("Created 0",           product.GetType().Nam
  e)            // Wait for user
  Console.Read()

Output Created ConcreteProductACreated
ConcreteProductB
26
Command Design Pattern - Operation

• The Command pattern is intended to encapsulate a
  request as an object. For example, consider a
  window application that needs to make requests of
  objects responsible for the user interface.
• The client responds to input from the user by
  creating a command object and the receiver. It
  then passes this object to an Invoker object,
  which then takes the appropriate action. This
  allows the client to make requests without having
  to know anything about what action will take
  place.
• In addition, you can change that action without
  affecting the client. Practical uses for Command
  are for creating queues and stacks for supporting
  "undo" operations, configuration changes, and so
  on.

27
Command Design Pattern

• Participants The classes and/or objects
  participating in this pattern are
• Command  (e.g. Command)
• declares an interface for executing an operation
• ConcreteCommand  (e.g. CalculatorCommand)
• defines a binding between a Receiver object and
  an action
• implements Execute by invoking the corresponding
  operation(s) on Receiver
• Client  (e.g. CommandApp)
• creates a ConcreteCommand object and sets its
  receiver
• Invoker  (e.g. User)
• asks the command to carry out the request
• Receiver  (e.g. Calculator)
• knows how to perform the operations associated
  with carrying out the request

28
Command Design Pattern
29
Command Design Pattern
// "Receiver" class Receiver       public
void Action()          Console.WriteLine("Calle
d Receiver.Action()")        // "Invoker"
  class Invoker       private Command
command    public void SetCommand(Command
command)          this.command
command        public void
ExecuteCommand()          command.Execute()


• abstract class Command       protected
  Receiver receiver    // Constructor
      public Command(Receiver receiver)
   this.receiver receiver        public
  abstract void Execute()    //
  "ConcreteCommand"   class ConcreteCommand
  Command      // Constructor     public
  ConcreteCommand(Receiver receiver)
        base(receiver)               public
  override void Execute()          receiver.Actio
  n()

30
Command Design Pattern - Client

•   class MainApp      static void
  Main()          // Create receiver, command,
  and invoker
•       Receiver receiver new
  Receiver()      Command command new
  ConcreteCommand(receiver)      Invoker invoker
  new Invoker()      // Set and execute
  command
•       invoker.SetCommand(command)      in
  voker.ExecuteCommand()      // Wait for user
•       Console.Read()

Output Called Receiver.Action()
31
Proxy Design Pattern - Operation

• Provide a surrogate or placeholder for another
  object to control access to it.
• This pattern is useful for situations where
  object creation is a time consuming process and
  can make an application appear sluggish. A proxy
  object can provide the client with feedback while
  the object is being created.
• Proxy can also be used to provide a more
  sophisticated reference to an object. For
  example, the proxy object can implement
  additional logic on the objects behalf (security,
  remote procedure calls, an so forth).

32
Proxy Design Pattern

• Participants The classes and/or objects
  participating in this pattern are
• Proxy   (MathProxy)
• maintains a reference that lets the proxy access
  the real subject. Proxy may refer to a Subject if
  the RealSubject and Subject interfaces are the
  same.
• provides an interface identical to Subject's so
  that a proxy can be substituted for for the real
  subject.
• controls access to the real subject and may be
  responsible for creating and deleting it.
• other responsibilites depend on the kind of
  proxy
• remote proxies are responsible for encoding a
  request and its arguments and for sending the
  encoded request to the real subject in a
  different address space.
• virtual proxies may cache additional information
  about the real subject so that they can postpone
  accessing it. For example, the ImageProxy from
  the Motivation caches the real images's extent.
• protection proxies check that the caller has the
  access permissions required to perform a request.

• Subject   (IMath)
• defines the common interface for RealSubject and
  Proxy so that a Proxy can be used anywhere a
  RealSubject is expected.
• RealSubject   (Math)
• defines the real object that the proxy represents

33
Proxy Design Pattern
34
Proxy Design Pattern
  // "Proxy"   class Proxy Subject      Rea
lSubject realSubject    public override void
Request()          // Use 'lazy
initialization'       if (realSubject
null)              realSubject new
RealSubject()            realSubject.Request(
)

• // "Subject"   abstract class Subject
        public abstract void Request()
    // "RealSubject"   class RealSubject
  Subject      public override void
  Request()          Console.WriteLine("Called
• RealSubject.Request()")


35
Proxy Design Pattern - Client

•   class MainApp      static void
  Main()          // Create proxy and request a
  service
•       Proxy proxy new Proxy()      proxy.Req
  uest()      // Wait for user
        Console.Read()

Output Called RealSubject.Request()
36
Chain of Responsibility Design Pattern

• One of the tenets of software engineering is to
  keep objects loosely coupled. The Chain of
  Responsibility is intended to promote loose
  coupling between the sender of a request and its
  receiver by giving more than one object an
  opportunity to handle the request.
• The receiving objects are chained and pass the
  request along the chain until one of the objects
  handles it.
• The result is to avoid coupling the sender of a
  request to its receiver by giving more than one
  object a chance to handle the request. Chain the
  receiving objects and pass the request along the
  chain until an object handles it.

37
Chain of Responsibility Design Pattern

• Participants The classes and/or objects
  participating in this pattern are
• Handler
• defines an interface for handling the requests
• (optional) implements the successor link
• ConcreteHandler
• handles requests it is responsible for
• can access its successor
• if the ConcreteHandler can handle the request, it
  does so otherwise it forwards the request to its
  successor
• Client
• initiates the request to a ConcreteHandler object
  on the chain

38
Chain of Responsibility Design Pattern
39
Chain of Responsibility Design Pattern

• // "Handler"
• abstract class Handler
• protected Handler successor
• public void SetSuccessor(Handler
  successor)    this.successor successor
•  public abstract void HandleRequest(int
  request)

// "ConcreteHandler1"   class ConcreteHandler1
Handler      public override void
HandleRequest(int request)          if
(request gt 0 request lt 10)              Con
sole.WriteLine("0 handled request 1",
          this.GetType().Name,
request)            else if (successor !
null)              successor.HandleRequest(requ
est)
40
Chain of Responsibility Design Pattern
// "ConcreteHandler3"   class ConcreteHandler3
Handler      public override void
HandleRequest(int request)          if
(request gt 20 request lt 30)              Co
nsole.WriteLine("0 handled request 1",
          this.GetType().Name,
request)            else if (successor !
null)              successor.HandleRequest(requ
est)

• // "ConcreteHandler2"   class ConcreteHandler2
  Handler      public override void
  HandleRequest(int request)          if
  (request gt 10 request lt 20)              Co
  nsole.WriteLine("0 handled request 1",
            this.GetType().Name,
  request)            else if (successor !
  null)              successor.HandleRequest(requ
  est)

41
Chain of Responsibility Design Pattern

• class MainApp      static void
  Main()          // Setup Chain of
  Responsibility       Handler h1 new
  ConcreteHandler1()      Handler h2 new
  ConcreteHandler2()      Handler h3 new
  ConcreteHandler3()      h1.SetSuccessor(h2)
     h2.SetSuccessor(h3)      // Generate and
  process request       int requests 2, 5,
  14, 22, 18, 3, 27, 20      foreach (int
  request in requests)              h1.HandleRequ
  est(request)            // Wait for user
        Console.Read()

Output ConcreteHandler1 handled request
2ConcreteHandler1 handled request
5ConcreteHandler2 handled request
14ConcreteHandler3 handled request
22ConcreteHandler2 handled request
18ConcreteHandler1 handled request
3ConcreteHandler3 handled request
27ConcreteHandler3 handled request 20
42
(Design) Pattern References

• The Timeless Way of Building, Alexander Oxford,
  1979 ISBN 0-19-502402-8
• A Pattern Language, Alexander Oxford, 1977 ISBN
  0-19-501-919-9
• Design Patterns, Gamma, et al. Addison-Wesley,
  1995 ISBN 0-201-63361-2 CD version ISBN
  0-201-63498-8
• Pattern-Oriented Software Architecture,
  Buschmann, et al. Wiley, 1996 ISBN
  0-471-95869-7
• Analysis Patterns, Fowler Addison-Wesley, 1996
  ISBN 0-201-89542-0
• Smalltalk Best Practice Patterns, Beck Prentice
  Hall, 1997 ISBN 0-13-476904-X
• The Design Patterns Smalltalk Companion, Alpert,
  et al. Addison-Wesley, 1998 ISBN 0-201-18462-1
• AntiPatterns, Brown, et al. Wiley, 1998 ISBN
  0-471-19713-0

43
More Books

• Pattern Languages of Program Design
  (Addison-Wesley)
• Vol. 1, Coplien, et al., eds. 1995 ISBN
  0-201-60734-4
• Vol. 2, Vlissides, et al., eds. 1996 ISBN
  0-201-89527-7
• Vol. 3, Martin, et al., eds. 1998 ISBN
  0-201-31011-2
• Vol. 4, Harrison, et al., eds. 2000 ISBN
  0-201-43304-4
• Concurrent Programming in Java, Lea
  Addison-Wesley, 1997 ISBN 0-201-69581-2
• Applying UML and Patterns, Larman 2nd edition,
  Prentice Hall, 2002 ISBN 0-13-092569-1
• Pattern Hatching Design Patterns Applied,
  Vlissides Addison-Wesley, 1998 ISBN
  0-201-43293-5
• The Pattern Almanac, Rising Addison-Wesley,
  2000 ISBN 0-201-61567-3

44
More Books

• Advanced C, Coplien, Addison-Wesley, 1992
• Effective C 50 Specific Ways to Improve Your
  Programs and Design (2nd Edition), Scott Meyers,
  Addison-Wesley, (September 1997)
• More Effective C 35 New Ways to Improve Your
  Programs and Designs, Scott Meyers,
  Addison-Wesley (December 1995)

45
Early Papers

• Object-Oriented Patterns, P. Coad Comm. of the
  ACM, 9/92
• Documenting Frameworks using Patterns, R.
  Johnson
• OOPSLA '92
• Design Patterns Abstraction and Reuse of
  Object-Oriented Design, Gamma, Helm, Johnson,
  Vlissides, ECOOP '93.
• Columns
• C Report, Dr. Dobbs Sourcebook, JOOP, ROAD

46
Conferences

• PLoP Pattern Languages of Programs, Monticello,
  Illinois, USA (September)
• EuroPLoP, Kloster Irsee, Germany (July)
• ChiliPLoP 2000,
• March 2000, Wickenburg, Arizona, USA
• KoalaPLoP 2000, May 2000, Melbourne, Australia
• See http//hillside.net/patterns/conferences for
  up-to-the-minute information.

47
Mailing Lists

• patterns_at_cs.uiuc.edu present and refine patterns
• patterns-discussion_at_cs.uiuc.edu general
  discussion on patterns
• gang-of-4-patterns_at_cs.uiuc.edu discussion on
  Design Patterns
• siemens-patterns_at_cs.uiuc.edu discussion on
  Pattern-Oriented Software Architecture
• ui-patterns_at_cs.uiuc.edu discussion on user
  interface design patterns
• business-patterns_at_cs.uiuc.edu discussion on
  patterns for business processes
• ipc-patterns_at_cs.uiuc.edu discussion on patterns
  for distributed systems
• See http//hillside.net/patterns/Lists.html for
  an up-to-date list.

48
URLs

• General
• http//hillside.net/patterns
• http//www.research.ibm.com/designpatterns
• Conferences
• http//hillside.net/patterns/conferences/
• Books
• http//hillside.net/patterns/books/
• Mailing Lists
• http//hillside.net/patterns/Lists.html
• Portland Patterns Repository
• http//c2.com/ppr/index.html
