Title: TTGM Group Brief


1
TTGM Group Brief
A PROFESSIONAL SUPPLIER OF STEEL PIPES AND
DRILLING EQUIPMENT
WWW.TTGM.COM.CN
2
OUTLINE
Company Introduction
Production Introduction
Customer Evaluation
Contact
3
COMPANY INTRODUCTION
  • TTGM is an integrated company (6 affiliated
    companies in China and 3 are located in overseas)
    with 15 years experience producing the Oil pipe,
    drilling Tool, well head device, Oil production
    equipment and even Chemical with groups total
    SALES REVENUE OF 1 billion US dollars per year.
  • The sales volume of TTGM for overseas markets
    consists about 50 of total annual production.
    And the clients for supply of our products are
  • highly experienced in drilling and
  • they include the well-know
  • international ones from Canada,
  • USA, Algeria, Sudan, CIS,
  • Middle East.

4
COMPANY INTRODUCTION
Beyond the self and pursuit of excellence is the
companys philosophy. TTGM is pursuing to become
a national and international star of industry
with sales, management and service globalization,
and products technological advantage.
5
OIL Pipes
CASING ,TUBING, DRILL PIPES, DRILL COLLARS
WELDED PIPE
SUCKER ROD
DRILLING EQUIPMENT
6
TTGM GROUP
CASING, TUBING AND DRILL PIPES
WWW.TTGM.COM.CN
7
CASING, TUBING AND DRILL PIPES
DRILL PIPE SIZE 2.3/8 2.7/8 3.1/2 4
4.1/2 5 5.1/2
6.5/8 GRADE E75, X95, G105, S135 CONNECTION
EU, IU, IEU
  • API-CASING AND TUBING
  • SIZE 2.3/8?20(60.3mm?508mm)
  • GRADE
  • H40, J55, K55, N80, L80, P110
  • CONNECTION
  • LTC, STC, BTC, EUE, NUE

8
Drill pipe
TTGM owns inertial friction welding machine
manufactured by MTI. Use the optimum welding
parameters to ensure welding quality. Use
moderate frequency heat treatment facility to
treat the welding zone ensure the quality of
weld zone.
Intermediate Frequency heat treatment facility
MTI Friction Welder
Production line
9
DRILL PIPE
Use CNC lathing and outer inner grinding to
eliminate stress concentration on welding zone.
Integrated on-line measuring and detection
devices, high quality of weld zone and pipe.
1
2
3
10
State-of-the-art Equipment and equipment for
casing and tubing production line.
11
TTGM owns a heat treatment line whose annual
capacity is 100,000 metric tons, which can
process the API standard casing, tubing, drill
pipe and high collapse, anti-corrosion pipes as
well
12
Certificates for casing, tubing and drill pipe
13
LAB OF TTGM
14
RESEARCH DEVELOPMENT OF CASING AND TUBING
NON-API standard casing tubing
specification (mm) OD (mm) Wall thickness grade connection Related standard typical application
collapse-resistance casing 114.30339.70 5.2115.88 TT55T TT110T S/L/B Technical agreement Salt rock, mud rock, perforated interval water injector and so on
steaming injection well casing 114.30339.70 5.2115.88 TT90H TT100H TT110H S/L/B Technical agreement Thermal recovery steam injection wells for heavy oil
casing with premium thread connections 114.30244.48 5.21 13.84 API grades JIP/TTGM Technical agreement For high thread sealing property in High gas well
tubing with premium thread connections 42.16114.30 3.1816.00 API grades JIP/TTGM Technical agreement For high thread sealing property
15
PREMIUM THREAD CONNECTIONS (NEW PRODUCT)
16
PREMIUM THREAD CONNECTIONS (NEW PRODUCT)
Expandable Tubular Technology was developed in
the United States in 1999. Our company and
Beijing Petroleum Drilling Institute work
together and have developed a stable mechanical
properties and premium connecting thread of new
products. Applications ? the naked eye system
as a contingency casing drilling process in time
complexity of the well condition ? casing
system repair damaged casing, production
returned to normal ? liner hanger system
instead of the conventional liner hanger systems,
access to larger diameter and suspension force ?
ultimate goal the full-well the same size casing
to replace the existing multi-layer casing
structure.
17
TTGM GROUP
WELDED PIPES
WWW.TTGM.COM.CN
18
LINE PIPES
Our company now holds one f140-f406mm middle
straight seam steel pipe production line and four
production lines off219-f2500 double-side spiral
submerged arc welding pipes.
The annual production capacity is of 380,000 tons
of different specifications and the annual output
amounts to RMB1.2 billion.
19
LINE PIPES
SSAW OD219mm to 2500mm, ERW OD 159mm to 406mm

API 5L, ASTM A 53, ASTM A106 GB/T9711, GB/T3091,
GB/T8163 etc. GRADE Q235, Q345, 10,20, 45,
J55, K55, N80, L80, P110, B, X42, X46, X52, X56,
X70, X80.
Annual production capacity is about 500,000.00
tons.
20
LINE PIPES
21
TTGM GROUP
SUCKER ROD
WWW.TTGM.COM.CN
22
Sucker Rod
TTGM has an affiliate company manufacturing
quality sucker rod, sucker rod pump and other
accessories with more than 10 years experience,
which has been granted by API 11B and API 11AX
certificates.
23
SALES NET WORK OF PIPES
24
TTGM GROUP
DRILLING EQUIPMENT
WWW.TTGM.COM.CN
25
DRILLING EQUIPMENT
TOP DRIVE DRILLING EQUIPMENT
DOWNWHOLE MOTER
Air/Foam Drilling Downhole Motor
DRILLING JAR ABSORBOR
Pneumatic Pressure Test Unit
PC Pump
Upper Kelly Valve
CGDS (CNPC Geosteering Drilling System)
26
Production Ability
27
Quality Control
28
API CERTIFICATE
  • API Spec 16D
  • API Spec 7
  • API Spec 8A
  • API Spec 8C

29
18 innovations were patented during last 5 years
  • Top Drive Drilling Equipment
  • A kind of Drilling Jar with Latch Mechanism
  • Multi-position Bi-directional Float Tongs of
    TDDE
  • A Kind of Shock Absorber
  • Upper Kelly Valve
  • A kind of sliding type rotary tongs for TDDE
  • Air Drilling Jar
  • Air Drilling Shock Absorber
  • A kind of Drive Shaft
  • A kind of Universal Joint Assembly

30
Application of TOP DRIVE
Serial Top Drive Drilling Equipments for 4000m,
7000m, 9000m drilling rigs. 24 sets of TDDE have
brought to the market.
  • DQ70BS/03002, Sichuan oilfield (Completion after
    7months)
  • DQ70BS/03003, Xinjiang oilfield (Completion after
    3months)
  • DQ70BS/03004, Sichuan oilfield (Employed in
    Pakistan)
  • DQ70BS/04005, Huabei oilfield (Employed in the
    5th well)
  • DQ70BS/04006, Great wall Drilling Company
    (Employed in Pakistan)
  • DQ40BC/04007, Huabei oilfield (Employed in the
    5th well)
  • DQ70BS/04008, Liaohe oilfield
  • DQ70BS/04009, Rowan (Employed in the 5th well)
  • DQ70BSC/04010, Xinjiang oilfield
  • DQ90BSC/04011, Xinjiang oilfield (Tashen-1)
  • DQ70BSC/05012, Huabei oilfield (Xinglong-1)
  • DQ70BSC/05013, Dagang oilfield (Zhanghai-502)
  • DQ70BSC/05015, Jilin oilfield (Employed in Iraq)
  • DQ70BSC/05016, Great wall Drilling Company
    (Dagang)
  • DQ70BSC/05017, Huabei oilfield
  • DQ70BSC/05018, Sichuan oilfield (An-001)
  • DQ70BSC/05022, Huabei oilfield

31
Distribution Map of TOP DRIVE
32
Typical Application of BPM-TDDE Overseas
03004 Pakistan
04009 America
04006 Kazakstan
05015 Iraq
03003 Iran
July,2004
Feb,2005
Aug,2005
Nov,2005
Dec,2005
33
TTGM GROUP
Downhole Motor
WWW.TTGM.COM.CN
34
Downhole motor
TTGM can provide all sizes of downhole motor,
from O.D. 2 3/8?(60mm) to 9 5/8?(244mm),
including single bent, double bent, adjustable
bent housing with all kinds of stabilizers.
Single bent Normal DHM Adjustable bent housing
DHM Air/Foam Drilling DHM Extended DHM
35
Patent of Downhole Motor
Motor design manufacture technology Adjustable
bent housing patent Oil-sealed drive shaft
assembly design manufacture technology DHM
for air drilling design manufacture
technology Rubber injection technology of the
stator
36
Downhole motor
Oil-sealed Universal Joint
CAE/FEA
Thrust Bearing
37
TTGM GROUP
Air/Foam Drilling Downhole Motor
WWW.TTGM.COM.CN
38
4 ¾ ?Air Drilling DHM Used in Su-lige SU35-18
Test Conclusion OK
39
Report of 9 5/8?Air Drilling downhole motor used
in Iran
Accumulated working time118.5h
The DHM works well, esp. when air drilling,
characterized with higher power and longer
service time.
40
Used in the First Air Drilling Underbalance
Horizontal Well, Sichuan Baiqian-111H
41
TTGM GROUP
Drilling Jar Shock Absorber
WWW.TTGM.COM.CN
42
QJ-K (jar force is unadjustable) Drilling Jar
Drilling Jar
Hydraulic Drilling Jar
Latch Mechanism
Cylinder 3D Modeling
Mechanical-hydraulic Drilling Jar
Cylinder Stress Distribution
Cylinder Gridding
Cylinder Loading
43
Drilling Jar Absorber for Air Drilling

used in Iran
44
TTGM GROUP
Progressing Cavity Pump
Progressing Cavity Pump - for heavy /viscous oil
production - reduce the oil production cost
45
Successful case in Sudan
  • Start to use in 2002
  • Covered 50 of the market share in 2003 (10 sets
    sold to Sudan)
  • Covered 50 of the market share in 2004 (20 sets
    sold to Sudan)
  • Covered 85 of the market share in 2005(win a bid
    with 47 sets of PCPs)

PCP used for Transporting
46
TTGM GROUP
Drill Bits
www.ttgm.com.cn
47
Drill Bits
TTGM Group also provide a complete line of
tricone bits ranging from 4 5/8"OD to 13 3/4"OD,
different type and specifications, such as TCI
and milled tooth, rubber rings sealing and metal
rings
sealing, also additional features etc, which has
been approved by ISO 9001 and API spec 7.
48
TTGM GROUP
Pump Components
www.ttgm.com.cn
49
Certificates and Range of Products
EMSCOF-1000,F-1300,FA-1300,F1600,FA-1600,FB-1300,FB-1600,F-350,F-500,F-650,F-800,F-1000,DB-550D-300,D-375,D-700. IDECOT-500,T-800,T-1000,T-1300,T-1600.GARNDER-DENVERPZ-7,PZ-8,PZ-9,PZ-10,PZ-11,PZ-LPA-8,PAH,FY-FXD,FO-FXO,FD-FXX,FG-GXG. NATIONAL OILWELL10-P-130,12-P-160,8-P-80,7-P-50,K-700,K-700A,K-500,K-500A,K-380,A1700-PT,A1400-PT,A1100-PT, 220P, 218P, A850-PT, A350-PT, JWS ELLIS WILLIAMS W-440-LP,WILSON600,PPWH. OMEGAOPI 1000
50
Pump Parts Series
Valve Assembly
Piston Rod
Modules
Valve Body and Valve Seat
Cylinder
51
TTGM GROUP
Drilling Tools
www.ttgm.com.cn
52
Drilling Tools
Drilling-Rod Nipple
Subs are made of high quality alloy steel through
special heat treatment means, and processed by
means of numerically controlled machine
tools,have good multiple mechanical properties,
conforming to API Spec7.
Joint Drill
53
TTGM GROUP
Cementation Tools
www.ttgm.com.cn
54
Cementation Tools
55
Well Head Assembly
BURGLAR PROOF WELL HEAD
OFF LYING-ROTATIONAL WELL HEAD
SLIPS SINGE STATE CASING HEAD
MANDREL DOUBLE HOLISTIC STATE CASING HEAD
CASING HEAD
56
TTGM GROUP
Chemical additive
www.ttgm.com.cn
57
COMPANY INTRODUCTION
  • TTGM Unibrom is a world leader in the synthesis
    of specialty bromine compounds . and polymer
    additives. Worldwide sourcing bromine volume
    reach more than 30,000Mt from China, India,
    Ukraine, Jordan, provides us with a solid
    foundation from which we can offer a wide range
    of chemicals in research to commercial
    quantities. Currently our customers in the United
    States include Baker Hughes, Halliburton, M I
    Swaco, and possibly soon, Schlumberger.
  • The Head office for Unibrom is based in UK. From
    there we have set up distributors world-wide to
    stock many of our products, making it easy for
    overseas companies to purchase our products with
    a very small lead-time and easy contact points
    should they require any technical support.

58
PRODUCTS
59
Customer Reference
Business negotiation with Indian Jiva
International Petroleum Corp
VISIT of Baker Hughes
Business negotiation with Halliburton
VISIT of NIOC
60
Customer Reference
61
Contact us and Thanks for your attention
TTGM INTERNATIONAL(USA), INC.11211 Katy Freeway
Suite 240Houston, TX 77079Tel 713-776-2425,
Fax 713-776-3424
About PowerShow.com
