1 Sinnotec GmbH

1
Siolit A/S The world of silicate
technology Corrosion
protection for steel and concrete
Tough and tight
Long term waterproof
Salt water
Extreme durability
resistant
Flexible if needed
Optimum adhesion
Best UV stability
Chemicalresistant
Heat resistant
Flexible in design
1 Dr. Jörg Rathenow
2
Agenda

• Sinnotec Innovation Consulting

• Silicate Technology

• Silicate Technology

• Challenges in the reality

• Solutions by Silicate-technology
• - Corrosion protection of concrete
  Tunnel and channel construction -
  Corrosion protection Joint sealing
• - Corrosion protection Steel construction
  - Waterproofing Design and floor coating
• Siolit A/S

3
Silicate technology Room temperature curing
ceramic
Unique future materials trouble shooting,
development, production and sales of innovative,
durable, certified base materials for the
construction- and steel industry with low raw
material effort as long lasting, environmentally
friendly, easy and safe corrosion protection and
construction material with sales through the
channels of the cooperation partners. Siolit
A/S
4
Sinnotec Innovation Consulting GmbH

• Start up company, based in Wiesbaden
• More than 15 years international experience
  network and know-how in silicate FE and cement
  replacement materials
• Focus areas
• High performance silicate materials
• Low carbon footprint innovations
• Our core business is RD with customer oriented
  and flexible product development
• contract manufacturer up to 10to/day
• Siolit A/S

4
5
Customer benefit

• High resistant which means long lifetime
  without corrosion (e.g. colour, cracks,
  abrasion, etc.)
• Easy and simple to apply, even one layer is
  water tight for eccellent corrosion
  protection!
• Exceptional adhesion also on dusty, mineral
  substrates, glass and metal
• Comfortable room climate water tight but
  still water vapour diffusion possible
• Environment- and application friendly (label
  free product, CO2 neutral raw materials)
• Siolit A/S

6
Siolit A/S Silicate Technology
Green Products for sealing slurries, renders,
coatings and much more
7
Siolit A/S Silicate Technology
Applications

• Products Markets

• Waterproofing design home construction
• Corrosion protection chemical industry,
  navigation,
•
  farming, oil and steel industry
• Concrete restoration all kind of
•
  concrete constructions
• Concrete technology ready-mix concrete,
  prefab
• Floor coating home and
  industrial user
• Water pollution control chemical industry
• Joint sealing water
  constructions,
•
  food industry

8
Siolit A/S Silicate
Technology

• Extreme resistance and easy to apply

• extreme chemical and mechanical
  resistance

• easy to apply

• produced from eco-friendly raw material

• best adhesion to most substrates

• worldwide unique technology

• no labelling requirements, total
  inorganic

• extreme abrasion resistance

• extremely good performance, much better than
  epoxy and concrete based product systems!

9
Siolit A/S Silicate Technology
Comparison
9
9
10
Siolit A/S
Silicate Technology

• REM picture of microstructure

• typical polymer coating, scale 10 µm

• innovative silicate products, scale 7 µm

• typical cement C30/37, scale 23 µm

11
Siolit A/S Concrete
Properties 1

• Concrete is capillary active and has to be
  coated for pressure water resistance
• Concrete is good pressure stabel (needels stick
  together) but poor tear stabel
• Concrete contains app. 25 Calciumhydroxide, is
  therefore very alcalic and reacts with acids (CO2
  of the air)
• Concrete is a multi phase system, shrincs with
  drying and get's therefore easily cracs and has
  to be armed with steel
• Steel reinforcement needs a 3 cm concrete
  coverage for corrosion protection

12
Concrete Properties 2 Siolit A/S

• Steel and concrete are heavy, therefore are
  only limited hight and span with for construction
  are possibel
• Concrete is only limited temperatur stabel and
  need fire protection
• Concrete reacts as a solid binder system with
  poor adhesion to substrates and themselve
• The cement production leads to 5 of worldwide
  CO2 emission
• Concrete as powder or liquid is heaviliy
  alcalic and need therefore safety labeling
  (working and environment safety)

13
Sinnodur silicate products Properties 1 Siolit
A/S

• Sinnodur is threedimentional crosslinked and so
  pressure water tight without coating
• Sinnodur contains pure CSH phases (without
  Ca(OH)2) and is so stabel against acids, bases,
  UV, abraision and temperature
• One phase system, drying without cracs,
  shrinkage and salt efflorescence
• Low alkali content, so with cheap, durable
  glass fibers reinforment possibel, with excellent
  adhesion to the glass fibers
• Liquid binder system for good underground
  penetration and adhesion

14
Sinnodur silicate products Properties 2 Siolit
A/S

• Sinnodur reaches high stability (120 N/mm2,
  without reinforcement, UHPC) for cheap,
  filigrane, high and wide span constructions
• Sinnodur is easily reworkable even after
  drying you can realize a monolytic bonding
• Sinnodur is temperature stabel up to 500C
  (temperatur shock resistant) an with this fire
  protected
• Sinnodur contains environmentally friendly
  recycling raw materials (low CO2 foodprint) and
  is label free

15
Silicate Technology Approved by the building
authorities, Available products and certificates

• Sinnodur Protective high resistant, rigid
  coating for steel and concrete, chemical
  resistance following DIN 12808-1, water
  penetration following DIN 12390-8, adhesive
  tensile strength following DIN-EN 1015-12
• Sinnodur 2k Flexible crack bridging coating,
  water vapour diffusion Sd 1,61m
• Sinnofloor floor coating excellent abrasion-
  and chemical resistance, pressure water tight,
  crack free drying from 1 to 70 mm thickness
• Sinnodur Concrete innovative transparent
  sealer to protect mineral surfaces against
  chemicals and efflorescence
• Siolit A/S

16
Ultimate protection Test results Siolit A/S
16
17
Siolit A/S Silicate Technology
Application

• long processing time
• fast water resilience
• application by brush, scraper, spray,
• even at temperatures around 5C
  processable
• fast drying and reworkability
• processable by machines

18
Siolit A/S Solutions by
silicate technology

• 1. Tunnel and channel construction
• Sinnodur Protection
• Sinnodur Waterprooving
• Sinnodur Flexibel
• 2. Corrosion protection, for steel and concrete

• Sinnodur Protection
• Sinnodur Concrete
• 3. Design, construction materials
• Sinnofloor

19
Siolit A/S Solutions by
silicate technology
1. Tunnel and channel construction

• Drinking water tank
• Thin rigid sealing
• Levelling and sealing in one
• Elastic 2k product for crack vulnerable
  substrates
• Smooth finish for easy to clean properties

20
Siolit A/S Solutions by
silicate technology
1. Tunnel and channel construction

• cleaning for better adhesion and removal of
  contaminant substances

• watering

• protection- and sealing layers

21
Siolit A/S Solutions by
silicate technology
1. Tunnel and channel construction

• leveling and sealing coves

• sealing coves

• protection- and sealing layers

22
Siolit A/S Solutions by
silicate technology
2. Corrosion protection for steel and concrete
Steel construction and pipelines Hydraulic
ingineering construction Waste water
plants Bridge construction Chemical plants
23
Siolit A/S Solutions by
silicate technology
2. Corrosion protection for steel and concrete
Steel construction and pipelines Excellent
adhesion and abrasion resistance!
24
Siolit A/S Solutions by
silicate technology
2. Corrosion protection for steel and concrete
Steel construction and pipelines Excellent
flexibility, tight after break of ductile steel
casting tube!
25
Siolit A/S Solutions by
silicate technology
2. Corrosion protection for steel and concrete
Steel construction and pipelines Excellent
abrasion resistance and durability for rigid
outside coating (also with glass fiber
reinforcement)!
26
Siolit A/S Solutions by
silicate technology
2. Corrosion protection for steel and concrete
Wast water plants Excellent adhesion and
protection for mineral substrates and steel!
27
Siolit A/S Solutions by
silicate technology
2. Corrosion protection for steel and concrete
Wast water plants Perfect pressure water tight
and chemical resistant!
28
Siolit A/S Solutions by
silicate technology
2. Corrosion protection for steel and concrete
Wast water plants Excellent processability with
normal machine equipment!
29
Siolit A/S Solutions
by silicate technology
3. Design and construction
materials
Wellness and swimming pools Water
tanks Drinking water tanks
30
Siolit A/S Solutions by
silicate technology
3. Design and construction materials

• Maritim Hotel Fulda
• 190 m², Pool area, shower, toilette, 21.8.2003
  grouted
• Very good condition in wet and dry areas

31
Siolit A/S Solutions by
silicate technology
3. Design and construction materials

• BV Bad Kissingen
• 260 m² wall surface, outdoor pool, grouting
  05.10. 2003 with cold weather (5 10C)?
• Inspection after 6 weeks, water filling January,
  2004, extreme high rigidity

32
Siolit A/S Solutions by
silicate technology
3. Design and construction materials

• Kurfürstenbad, Bad Godesberg
• 160 m², 2 filter basins, 25.8. 2003 grouted

33
Siolit A/S Solutions by
silicate technology
3. Design and construction materials
Home construction
1. All in one render
2. Indoor protection
3. Floor coating
33
34
Siolit A/S Crack free even
with high thickness
s
34
35
Siolit A/S No cracks in
critical areas
35
36
1. All in one Render Summary

• Extreme good adhesion
• No shrinkage and cracking
• Useable as single layer up to 20 mm
• Lower Carbon footprint then conventional mortars
• Saltwater and acid resistance
• Colour stable and improved stain resistance
• No efflorescence
• No problem with soft water
• Siolit A/S

36
37
Siolit A/S Solutions
by silicate technology
3. Design and construction materials
Floor coating Excellent adhesion Extreme
abrasion resistance Label- and solvent free,
green product Pressure water tight from 1 to 70mm!
38
Siolit A/S Solutions by
silicate technology
3. Design and construction materials
Floor coating Excellent adhesion Extreme
abrasion resistance Label- and solvent free,
green product Pressure water tight from 1 to 70mm!
39
The world of silicate technology from Siolit A/S
made by
Huge Advantage No binder system doeshave such
outstanding properties
39
40
Summary
A unique, cut across technology
With unique product advantages
and a team, on which you can relay.

You are invited!
Thank you very much for your attention!
Next steps? Siolit A/S
41
Contact
Contact Siolit A/S Address Fuglebakken
43 5610 Assens Denmark   Fone 45 6471
1115 Mobil 45 2019 2316 E-Mail siolit_at_siolit
.com www.siolit.com
