Title: COPD


1
COPD
2
Chronic Obstructive pulmonary Disease
  • Two distinct processes are involved, most often
    in combination.
  • Chronic Bronchitis dx on history
  • Emphysema dx previously on histology, nowadays
    clinically (good clinical-pathologic-radiologic
    correlation)

3
Def Chronic Bronchitis
  • Excessive tracheobronchial mucus production
    sufficient to cause cough with expectoration for
    most days of at least 3 months of the year for 2
    consecutive years.
  • Classification
  • Simple chronic bronchitis
  • Chronic mucopurulent bronchitis
  • Chronic bronchitis with obstruction
  • Chronic bronchitis with obstruction and airway
    hyperreactivity.

4
Def Emphysema
  • Permanent abnormal distention of air spaces
    distal to the terminal bronchiole with
    destruction of alveolar septa (containing
    alveolar capillaries) and attachments to the
    bronchial walls.
  • Classification
  • Centriacinar ( centrilobular) emphysema
  • Panacinar emphysema
  • Paraseptal emphysema
  • Senile emphysema

5
(No Transcript)
6
Def COPD
  • Chronic obstruction to airflow due to chronic
    bronchitis and/or emphysema.
  • Degree of obstruction may be less when the
    patient is free from respiratory infection and
    may improve with bronchodilator drugs
  • Significant obstruction is always present

7
Epidemiology of COPD
  • 30 of smokers develop COPD
  • 20 of adult males have COPD
  • 15 of COPD patients are severely symptomatic
  • 4 th leading cause of death (USA)
  • Mortality rate still rising
  • ?prevalence in low birth weight and low
    socioeconomic status
  • Tuberculosis in smokers predisposes to COPD

8
(No Transcript)
9
PathogenesisEffects of Smoking -1
  • Oxidative stress O2-, OH-,H2O2, HOCl source of
    Fe2 ? catalizes production of OH- by
    neutrophils, eosinophils, alveolar macrophages
    tar (cigarettes) contains NO and induces
    iNOS?toxic peroxynitrites
  • Elastin breakdown- activated neutrophils
    ?neutrophil elastases and oxidants ?-1-AT and
    metalloproteinase inhibitors (lung defenses)
    inactivated by smoke
  • Chemoattractant, upregulation of adhesion
    molecules ? neutrophil sequestration in lungs
  • ?expression of pro-inflammatory mediators IL-8,
    NF-?B ?recruitment of N, B, E and T lymphocytes

10
Effects of smoking -2
  • ? levels of myeloperoxidase and eosinophilic
    cationic protein ? bronchoconstriction
  • ? levels of TGF-? (transforming growth factor)
    ?fibrogenesis
  • Lipid peroxidation and DNA damage ?point
    mutations 0f the p53 gene locus ?epithelial
    dysplasia and lung cancer
  • ? ciliary function ? retained secretions ?
    airway resistance ?vagal-mediated smooth muscle
    contraction
  • Hypertrophy and hyperplasia of mucus secreting
    glands ??secretions

11
(No Transcript)
12
Pathogenesis-3
  • Air pollution ?exacerbations of CB related to
    heavy pollution with SO2 and NO2
  • Occupation ? exposure to organic and inorganic
    dust or noxious gases ?accelerated decline in
    lung function
  • Infection ? even mild viral respiratory
    infections ( rhino virus) may be a major factor
    associated with etiology as well as progression
    of disease severe viral pneumonia early in life
    may lead to COPD
  • Genetic factors - ?-1-antitrypsin deficiency
    PIZZ, PISZ, PI00 (PI null null), ? susceptibility
    to effects of smoking

13
Pathophysiology
  • Air trapping- RV and FRC elevated
  • Hyperinflation TLC elevated
  • ? elastic recoil pressure ? dynamic collapse of
    airways during expiration ?ineffective cough
    mechanism and pursed lips breathing (emphysema)
  • ? compliance (emphysema)
  • ? airway resistance
  • Prolonged forced expiratory time (Nlt6 seconds)

14
Pathology CB
  • Hypertrophy of mucus-producing glands in
    submucosa of large cartilaginous airways
  • Goblet cell hyperplasia, mucosal and submucosal
    inflammatory cell infiltrate, oedema,
    peribronchial fibrosis, intraluminal mucus plugs
    and increased smooth muscle in small airways
  • The major site of airflow obstruction is in the
    small airways and the inflammatory infiltrate
    consists of neutrophils (in asthma eosinophils)

15
Pathology Emphysema
  • ?in number and size of alveolar fenestrae
    ?eventual destruction of alveolar septa and their
    attachments to terminal and respiratory
    bronchioles ?distention of alveolar spaces
  • Centriacinar E- respiratory bronchioles (central)
    affected
  • Panacinar E- central and peripheral portions of
    acinus affected
  • Senile E- alveoli and alveolar ducts enlarge (gt
    50 Y)
  • Periacinar/paraseptal E- distention of alveolar
    spaces adjacent to septal and pleural surfaces

16
Physical signs of COPD
  • Ronchi- in early disease present on forced
    expiration, later present in inspiration and
    expiration
  • Prolonged forced expiratory time (gt 6 seconds)
  • Hyperinflation ? cardiac dullness, liver
    dullness displaced downwards, ? A-P chest
    diameter, ? heart and breath sounds, Hoover sign
  • Inspiratory crepitations (lung bases)
  • Pursed lips breathing (?? dynamic airway
    collapse)
  • Use accessory respiratory muscles
  • Signs of cor pulmonale and PHT

17
EmphysemaChronicBronchitis
  • Emphysema pink puffer
  • Age (Dx) 60 y
  • Rest dyspnea mild-mod
  • Exer dyspnea severe
  • Cough
  • Sputum scanty, mucoid
  • Resp infect less often
  • Resp failure terminal
  • Cor pulmonale terminal
  • Chronic Bronchitis blue
  • bloater
  • 50 y
  • none
  • moderate
  • prominent
  • large volume, purulent
  • often
  • repeatedly
  • common

18
EmphysemaChronic Bronchitis
  • PHT (rest) 0-mild
  • (exertion) moderate
  • Build Asthenic, cachectic
  • Hematocrit 35-45
  • Breath pattern use accessory muscles of
    respiration
  • Sleep pattern Normal
  • XRC Hyperinflation
  • Bullae
  • Mild-moderate
  • severe
  • obese, cyanosed
  • 50-55
  • do not use accessory muscles of respiration
  • sleep apnea
  • bronchovascular markings

19
EmphysemaChronic Bronchitis
  • Blood gas
  • PaO2 65 mm Hg
  • PaCO2 35-40
  • Elastic recoil ?
  • AW resistance N-?
  • Diffusion Cap ?
  • FEV1 ? ?
  • Bronchodilator
  • response Poor
  • 45-60
  • 50-60
  • Normal
  • ?
  • N- ?
  • ?
  • Better but lt 12 and 200ml

20
(No Transcript)
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Spirometric classification of COPD severity using
post-bronchodilator FeV1
  • Stage I (Mild) FeV1/FVC lt0.7 FeV1 80 of
    predicted
  • Stage II (Moderate) FeV1/FVC lt0.7 FeV1 50- lt80
    of predicted
  • Stage III (Severe) FeV1/FVC lt0.7 FeV1 30-lt50
  • Stage IV (Very severe) FeV1/FVC lt0.7 FeV1 lt30
    or lt50 but chronic respiratory failure is
    present. (GOLD 2007)

28
Treatment Goals of management -1
  • Recognition of disease (early Diagnosis and
    staging)
  • Smoking cessation (secondary prevention) nicotine
    replacement and Zyban
  • Improvement of breathlessness (Rx of airflow
    obstruction- bronchodilator drugs)
  • 1.Methylxanthines
  • 2.Short and long-acting B2adrenergic agonists (?
    incidence of pneumonia with ICS and LABA
    combinations)
  • 3.Short and long-acting Anticholinergics- BD of
    choice in COPD

29
Treatment -2
  • Respiratory infections AB when ?sputum volume
    and/or purulence (exacerbation of COPD)
    Influenza and Streptococcus pneumoniae
    vaccination
  • Bronchopulmonary drainage and postural drainage
    (physiotherapy) for patients with CB
  • Oxygen therapy for patients with hypoxia (PaO2lt55
    mmHg, SaO2 lt88 ) and erythrocytosis
    (Hematocritgt55)
  • Pulmonary rehabilitation and education (
    improving quality of life)- exercise program and
    improved nutrition
  • Prevention and treatment of complications (cor
    pulmonale) and limitation of disease progression

30
Treatment -3
  • Glucocorticoids only 10 of COPD patients show
    subjective benefit and improved lung function
    (FeV1 increase of 20 or more) on systemic GCs
    with COPD exacerbation a course of prednisone 40
    mg/d for 2 weeks are usually prescribed
  • Inhaled GCs may ? severity of exacerbations and
    need for hospitalisation. Benefit of 10-14 day
    trial of 30-40mg prednisone for Stage III COPD
    patients remains to be proven.
  • Lung volume reduction surgery
  • Transplantation

31
Airway Diseases - COPD
  • Smoking
  • Hyperinflation
  • Airway collapse
  • Respiratory infection
  • Bronchospasm
  • Allergy
  • Inflammation

32
Airway Diseases Asthma
  • Allergy
  • Inflammation
  • Bronchospasm
  • Hyperinflation
  • Respiratory infection

33
AirwayDiseasesBronchiectasis
  • Respiratory infection
  • Hyperinflation
  • Bronchospasm
  • Inflammation
  • Allergy
