The Bar Graph or Bar Chart

1
The Bar Graph or Bar Chart

• What is it? How to Draw it

2
What is a Bar Graph?

• A bar graph is a graph that displays the
  frequency or numerical distribution of a
  categorical variable, showing values for each bar
  next to each other for easy comparison.
• Alternate Name
• Bar Chart

3
Bar Graph Example

• In June 2005, the US Dept of Transportation
  reported the following data by observing 1700
  motorcyclists nationwide at randomly selected
  roadway location
• Proper Helmet 731
• Insufficient Helmet 153
• No Helmet 816
• Total 1,700

4
Vertical Bar Graph Example
5
x-axis y-axis Variables

• On a vertical bar graph, the y-axis variable is
  normally a quantitative variable.
• Is it discrete or continuous?
• On a vertical bar graph, the x-axis variable is
  normally a categorical variable

Categorical Variable
6
Type of Variables on the Previous Motorcycle Bar
Graph

• x-axis?
• Categorical Variable.
• Name the categories
• Proper, Insufficient, None
• y-axis
• Discrete Quantitative Variable
• What are the units?
• Helmets

7
Making a Bar Graph Look Better

• What would make this bar graph look better?
• If we ranked the numbers by either increasing or
  decreasing value, the appearance would be less
  jagged, making a Pareto Chart.
• What is a Pareto Chart?
• A bar graph in which the bars are ordered
  according to value, in either increasing or
  decreasing order.
• Why Pareto Charts? Graph is named for Vilfredo
  Pareto, an Italian mathematician economist.
  1848-1923.

8
Vertical Bar Graph as Pareto Chart
9
Education Annual Income Survey
10
(No Transcript)
11
Retail Sales
12
Pareto Chart of Sales At Retail Outlets
13
Non Pareto Version of Sales
14
Bar Graphs VERY FLEXIBLE FORMAT

• Advantage over Pie Charts
• Bar Graphs are easier to make to read than pie
  charts.
• How are they similar to Pie Charts?
• Both pie charts bar graphs can display the
  distribution of a categorical variable
• How are they different from Pie Charts?
• A bar graph can also compare any set of
  quantities measured in the same units.

15
Psychic Phenomena
16
Pareto Chart of Psychic Phenomena
17
In Class SurveyDo you believe in Supernatural
Phenomena?
18
In Class SurveyDo you believe in Supernatural
Phenomena?
19
In Class Survey Results from 2009Do you believe
in Supernatural Phenomena?
20
In Class Survey Results from 20093-Level
Comparative Bar Graph
21
In Class Survey Results from 2009 Simple Bar
Graph
22
In Class Survey Results from 2009 Pie Chart
23
Rainfall In Hawaii
24
(No Transcript)
25
Bar Graph Characteristics

1. Data can be quantitative or categorical
2. Bars can be vertical or horizontal
3. The x-axis represents the category displayed
4. The y-axis represents the quantitative values of
   the variable being displayed
5. Bars are of uniform width and uniformly spaced

26
Bar Graph Characteristics

1. A consistent measurement scale is used for each
   vertical bar
2. Height of bars represent the values of the
   variable displayed, the frequency of occurrence
   or percentage of occurrence
3. The graph is well-annotated with title, labels
   for each bar, vertical scale, horizontal
   categories, source

27
Changing Scale The Squiggle

• What is a squiggle?
• At least a 2-angle line on a bar graph axis that
  abbreviates a scale.
• When do you use a squiggle?
• Use a squiggle on the changed axis whenever you
  change scale in a bar graph.
• Horizontal Squiggle Vertical Squiggle

or
28
Pie to Bar Spending On NY Lottery
29
Spending On NY Lottery
30
Spending On NY Lottery
31
(No Transcript)
32
Turning a Pie Chart into a Bar Graph
33
Turning a Pie Chart into a Bar Graph
34
Turning a Pie Chart into a Bar Graph
35
Turning a Pie Chart into a Bar Graph
36
Would The Bar Graph Make a Good Pie Chart?

• Only when Bar Graphs represent parts of a whole,
  can it be made into a Pie Chart.
• If the answer is NO, you could write
• No, because these values are comparative data
  only.
• No, because these values DO NOT represent parts
  of the whole.
• If the answer is YES, you could write
• Yes, because these values represent parts of the
  whole.

37
Bar Graph Pie Chart Relationship Summary

• Every Pie Chart COULD be made into a Bar Graph
• BUT
• NOT all Bar Graphs CAN be made into Pie Charts
• Pie Chart Þ Bar Graph
• Bar Graph Þ Pie Chart

38
Turning a Pie Chart into a Bar Graph
39
Turning a Pie Chart into a Bar Graph
40
Turning a Pie Chart into a Bar Graph
41
Turning a Pie Chart into a Bar Graph
42
Turning a Pie Chart into a Bar Graph
43
Turning a Pie Chart into a Bar Graph
44
Turning a Pie Chart into a Bar Graph
45
Turning a Pie Chart into a Bar Graph
46
Deciding Which Graph is Better

• The Chicago Tribune polled 380 randomly selected
  Chicago residents from August 27 to 31, 2009 on
  the subject of the potential Chicago Olympics of
  2016.
• The question asked was, Do you favor or oppose
  Chicago hosting the 2016 Olympic games? The
  results of the poll were

• Supply the remainder of the data labels

47
Could the Pie Chart Become a Bar Graph?

• The answer is obviously yes,
• But the question remains,
• Which Graph looks better? Which Graph is better
  for display purposes?
• This is a matter of opinion

• Supply the remainder of the data labels

48
Examining a Bar Chart for Meaning

• Whats the question?
• Whats the title?
• Whats the population?
• Whats the sample?
• How many variables?
• What are they?
• Whats the conclusion?
• Good pie chart?
• Is this a Pareto chart?

49
Turning a Pie Chart into a Bar Graph
50
Turning a Pie Chart into a Bar Graph
51
Turning a Pie Chart into a Bar Graph
52
Turning a Pie Chart into a Bar Graph
53
Turning Pie Charts to Bar Graphs
54
Turning Pie Charts to Bar Graphs
55
Turning Pie Charts to Bar Graphs
56
Turning Pie Charts to Bar Graphs
57
Turning Pie Charts to Bar Graphs
58
Turning Pie Charts to Bar Graphs
59
Turning Pie Charts to Bar Graphs
60
Turning Pie Charts to Usual Bar Graphs
61
Turning Pie Charts to Pareto Bar Graphs
62
Steps in Bar Chart Construction

1. Use a straight edge on a piece of graph paper
2. Make a first-quadrant x-y axis, unless some of
   your data is negative
3. Examine the data and determine the maximum value
   of the quantitative data. Your y-scale must be at
   least this high

63
Steps in Bar Chart Construction

1. Choose an appropriate scale for the y-axis.
2. Mark scale ticks consistently label them, until
   you reach a mark greater than the highest value
   of data.
3. Mark of the bar width of each piece of
   categorical data you will be using on the x-axis.

64
Steps in Bar Chart Construction

1. Make sure you place a space between each of the
   data bars.
2. Plot each data point by drawing a bar of the
   correct width height for each.
3. Label the top of each bar with a value.
4. Label both x- and y-axes with a title
5. Title the graph
6. Label the source of the data.

65
What Comes After High School?
66
(No Transcript)
67
Pareto Chart of Path After Graduation
68
Kids Borrowing Money (Replace)
69
(No Transcript)
70
Mountains to Climb
71

72
Quiz 103 Bar Charts

• Hints
• Complete the Vocabulary
• Then do the front page
• Place your HW in the HW box

You need Pencil, Eraser Calculator Graph Paper
(for 2 graphs one sheet okay) No bags on
desk Clear all lists in Calculator
