Logic gate level

1
Logic gate level

• Part 4 combinational devices

2
K-maps dont care conditions

• It isnt always necessary to process all possible
  input combinations, since some are never expected
  to be present
• Such input combinations are called dont care
  conditions, since we dont care about the outputs
  theyd produce should they ever be present

3
K-maps dont care conditions

• With dont care condition present, you can
  arbitarily choose either 1 or 0 for output
• Choice of output (1 or 0) for dont care
  conditions can aid in minimization
• Sigma notation for dont care conditions
• ?(x,y,z) d(a,b) where x,y,z,a and b all
  represent lines in the functions truth table
• We represent dont care conditions in a K-map
  with Xs

4
Example

• K-map for X(a,b,c) ?(2,4,6) d(0,7)

X 1
1 X 1

• With d.c. conditions, since we dont care, we can
  choose to include, or not include, boxes with X
  designations in K-maps
• X is wildcard condition can be treated as
  either 1 or 0
• In K-map above, if minterm 0 is treated as 1 and
  7 as 0, get
• ?(0,2,4,6) c

5
Combinational Devices

• Many devices have input line called an enable,
  which acts like on/off switch
• if enable is 0, all outputs are 0 regardless of
  other inputs
• if enable is 1, output depends on input to
  function that specifies device
• AND gate can implement an enable

6
AND gate as enable
7
Selective inverter

• Has data line invert line
• If invert 1, output is complement of data
• If invert 0, output is data unchanged
• Implement with XOR gate

8
Multiplexer

• Device that selects one of several inputs to
  route to single output
• Consists of set of data lines control lines
• control lines determine which data input will be
  output
• n control lines can control 2n data lines

9
8-input multiplexer
Combination of control line (s0-s2) inputs
determines which of 8 data lines (d0-d7) is
expressed as output value
10
Implementation of multiplexer

• Each data line ANDed with combination of control
  lines
• Result of ANDs is ORed together to get output
• Illustration on next slide shows 4-input version
  of this scheme 8-input version (like previous
  example) would involve 8 4-input AND gates

11
4-input mux implementation
12
Binary decoder

• Takes input from control lines and sets one of
  several output lines to 1, rest to 0
• Output value depends on input value(s)

13
Binary decoder implementation
14
Decoder with enable

• When enable line is 1, device operates normally
• When enable line is 0, all outputs are 0
• Requires extra input to each AND gate

15
Demultiplexer

• Routes single input value to one of several
  output lines
• Really just decoder with enable input line
  connected to enable

16
Building the CPU

• Control unit portion of CPU that
• ensures synchronization of events i.e. sending
  receiving bits on the bus
• selects next instruction
• stores values in appropriate locations
• Made up of combinational devices

17
Bus

• Internal bus common path connecting all
  registers in a register machines CPU
• each register composed of multiple bits, all of
  which can be transferred simultaneously to
  another register
• bus composed of parallel wires as many lines as
  there are bits in registers
• may also include control lines indicating which
  registers should send receive
• action must be coordinated, as bits from only one
  register at a time can be broadcast over bus
• coordination requires timing mechanism

18
Putting it together

• Parallel AND gates used to connect registers to
  bus
• One input line to each gate is data waiting to be
  transmitted, second is select signal (CLOCK)
• Date transmitted only if select signal is 1

19
Example 2 8-bit registers tied to 8-bit bus with
select (clock) signal
20
Strobing

• When select signal is high, each gate allows
  signal to flow
• clock (select) ANDed with each bit from registers
• all bits transmitted simultaneously, and received
  simultaneously at destination register

21
Clock

• Source of all select signals generates pulses at
  fixed rate
• Normal state is low (0) transmits 1 at regular
  interval
• Speed measured in hertz
• 1 Hz 1 cycle/second
• 1 MHz 1,000,000 cycles/second
• 1 cycle 1 step of fetch/execute cycle
• Time interval between pulses measured in
  fractions of seconds for PC, typically
  nanoseconds (1 ?s 1/1,000,000,000 second)

22
Arithmetic Logic Unit

• Part of the computer that computes
• All operations performed using combinations of
  logic circuits
• logical operations are performed by connecting
  operands bit-wise through ganged gates of
  appropriate type
• arithmetic operations are also performed
  logically operands connected bit-wise through
  ganged gates of appropriate type(s)

23
Performing arithmetic operations

• Can break down any binary arithmetic operation
  into set of operations on pairs of bits
• Each unique pair of bits combines to produce
• result (0 or 1)
• carry (0 or 1) when result is larger than either
  of the two operands
• These 2 output bits can be viewed as single 2-bit
  number representing result of arithmetic
  operation on two 1-bit operands

24
Performing arithmetic operations

• Example addition of two operands produces the
  results shown in the truth table below
• Notes on truth table
• First output (Sum) same as XOR
• Second output (Carry) same as AND

25
Half adder

• A half adder is the logical construction that
  implements the truth table on the previous slide
• Half adders take single bits as input, produce 2
  outputs

26
Full adder

• Addition of two bits accomplishes only half the
  task of binary addition, unless were satisfied
  with working in single-digit numbers
• To complete an addition operation, we must add
  the carry to the next (left) bit
• Can construct full adder from half adders carry
  from previous bit sum is ORed with carry from
  correct bit

27
Implementation of full adder from two half-adders
By chaining together several of these constructs,
we can build adders for multiple-digit numbers
28
Block diagram fo 4-digit adder
29
Subtraction

• Result column (difference) can be expressed as
• ab ab
• Carry column
• ab

A B Result (A-B) carry
0 0 0 0
0 1 1 1
1 0 1 0
1 1 0 0
30
Same device built with NAND gates
31
Notes on adders

• If last bit in series of half adders produces an
  non-zero carry, result will overflow
• An adder constructed from a series of half adders
  is called a cascading adder results cascade
  from right to left as previous carries must be
  determined before subsequent adds are performed

32
Adder as black box

• Control unit delivers data to input registers in
  ALU
• Device select signal triggers ALU to perform
  addition send result to result register
• Control unit causes result to be copied to its
  destination
