The Internet

1
The Internet

• CT101 Computing Systems

2
Contents

• The Internet
• Architecture
• Addressing
• Protocols
• DNS
• E-Mail
• WWW
• Security

3
The Internet

• The Internet An internet that spans the world
• Original goal was to develop a means of
  connecting networks that would not be disrupted
  by local disasters.
• Today it has shifted from an academic research
  project to a commercial undertaking.

4
Internet Architecture

• Internet Service Provider (ISP)
• Tier-1
• Tier-2
• Tire 1 and tier 2ISPs are networks of routers
  that collectively provide the Internets
  communication infrastructure
• Access ISP Provides connectivity to the Internet
• Traditional telephone (dial up connection)
• Cable connections
• DSL
• Wireless

5
Internet Composition
6
Internet Addressing

• IP address pattern of 32 or 128 bits often
  represented in dotted decimal notation
• E.g. 140.203.8.22 represents an Internet address
• 10001100 11001011 00001000 00010110
• Mnemonic address (alternative addressing system
  more suitable for humans)
• Domain names
• Top-Level Domains

7
Package-shipping example
8
Internet Software Layers

• Application Constructs message with address
• Transport Chops message into packets
• Network Handles routing through the Internet
• Link Handles actual transmission of packets

9
Following a message through the Internet
10
Internet Protocols - TCP/IP Protocol Suite

• Transport Layer
• TCP
• UDP
• Network Layer
• IP (IPv4 and IPv6)

11
Choosing between TCP and UDP
12
DNS

• IP addresses are difficult to remember
• JohnDoe_at_140.203.8.22 would be difficult to
  remember
• If JohnDoes mail server moves to another
  machine, then his e-mail address would not be
  valid anymore
• Something like JohnDoe_at_wuzwuz.ucg.ie would be
  appropriate
• Need some mechanisms to translate wuzwuz.ucg.ie
  to the IP address
• To solve this problem DNS was invented
• It is a hierarchical, domain-based naming scheme
  and a distributed database system for
  implementing this naming scheme
• Usage
• Map name onto an IP address, an application
  program calls an library procedure, called
  resolver, passing it the name as a parameter
  (i.e. gethostbyname() is an resolver)
• The resolver sends UDP packet to a local DNS
  server which looks up the name and returns the IP
  address to the resolver
• The resolver returns the IP address to the
  application, which can establish an TCP/IP
  connection with the destination (or send UDP
  packets)

13
DNS Name Space

• Internet is divided into over 200 top level
  domains
• Each domain is divided into sub-domains, which
  are further partitioned, etc..
• All domains can be represented by a tree
• The leaves of the tree represent domains that
  have no sub-domains (but contain machines)
• A leaf domain may contain a single host or
  represent a company and contain thousands of
  hosts
• Top level domains could be generic and country
  domains

14
Domain Names

• Can be either absolute (ends with a period i.e.
  eng.sun.com.) or relative (it doesnt end with a
  dot)
• Relative ones have to be interpreted in a context
  to find the true meaning
• Both of them refers to a specific node in the
  tree and all the nodes under it
• Are case insensitive (edu, Edu, EDU are same
  thing)
• Components names can be up to 63 characters and
  full names should not exceed 255 characters
• There is no rule against registering under two
  top level domains (sony.com and sony.nl)
• Each domain controls how it allocates the domains
  under it
• i.e. Japan makes a domains ac.jp and co.jp that
  mimic edu and com
• Netherlands doesnt make this distinction
• To create a new domain, permission is required
  from the domain that will include it once
  created, it can create sub-domains without having
  to ask permission from the higher up domains.

15
Name servers

• One DNS server could service all requests
• In practice it will be overloaded
• To solve this, DNS name space is divided in non
  overlapping zones
• Each zone contains some part of the tree and name
  servers holding zone info
• A zone would have a primary DNS (gets info from
  disk)
• One or more secondary DNS (get info from the
  primary DNS)

16
Name Servers Lookup mechanism

• In the example, a resolver on flits.cs.vu.nl is
  looking for IP address of linda.cs.yale.edu
  (using recursive query some servers dont
  implement recursive query and return the address
  of the next server to try)
• The resolver sends a query containing the domain
  name sought
• The query is forwarded by the local name server
  to the name server for domain edu, that is found
  in its database.etc
• Once the records get back to cs.vu.nl name
  server, they will be entered in a local cache, in
  case they are needed later

17
Internet Corporation for Assigned Names Numbers
(ICANN)

• Allocates IP addresses to ISPs who then assign
  those addresses within their regions.
• Oversees the registration of domains and domain
  names.

18
Traditional Internet Applications

• Electronic Mail (email)
• Domain mail server collects incoming mail and
  transmits outgoing mail
• Mail server delivers collected incoming mail to
  clients via POP3 or IMAP
• File Transfer Protocol (FTP)
• Telnet and SSH
• WWW (World Wide Web)

19
More Recent Applications

• Voice Over IP (VoIP)
• Internet Radio
• N-unicast
• Multicast

20
E-Mail

• Architecture and services
• User agent
• Message formats
• Message transfer agents
• SMTP
• Final delivery

21
E-Mail Architecture

• E-mail system consists of two parts
• User agents, which allow people to read and send
  email
• Local programs that provide a command based or
  graphical method for interacting with e-mail
  system
• Message transfer agents, which move the messages
  from source to destination
• Are typically system daemons or processes that
  run in background, having the job to move messages

22
E-Mail functions

• E-mail system functions
• Composition refers to the process of creating
  messages and answers although any text editor
  can be used for the text of the message, the
  system itself can provide assistance with
  addressing and numerous header fields attached to
  each message
• Transfer refers to moving messages from the
  originator to the recipient this requires
  establishing a connection to the destination or
  some intermediate machine, outputting the message
  and releasing the connection

23
E-mail functions

• E-mail system functions
• Reporting has to do with telling the originator
  what happened to the message Was it delivered?
  Was it rejected? Was it lost?
• Displaying showing the incoming message is
  important, so the people can read their e-mail
  sometime conversion or a special viewer is
  required (i.e. if the message is a PS message or
  an audio file)
• Disposition what the recipient does after the
  message has been received possibilities include
  throwing it away before reading it, throwing it
  away after reading it, saving it and so on.

24
E-mail architecture and functions

• Distinction between envelope and its contents
• envelope encapsulates the message and contains
  info needed for transporting the message, such as
  destination address, priority and security level
• Message has two parts headers (interpreted by
  the user agent) and body (info for the human
  recipient)

25
E-mail user agent

• Sending e-mail
• User must provide the message and the destination
  address (user_at_dns-address)
• User agents may support mailing lists
• Receiving e-mail
• When an user agent is started, it looks at users
  mailbox before displaying anything
• Then it may announce the number of messages in
  the mailbox

26
E-mail message format

• Basic ASCII e-mail message using RFC 822
• Messages consists of a primitive envelope
  (described in RFC821), some number of header
  fields, a blank line and then the message body
• Each header field (logically) consists of a
  single line of ASCII text, a colon and, for most
  fields, a value
• RFC822 was designed long ago and doesnt clearly
  distinguish between the envelope fields and the
  header fields
• This was revised in RFC 2822, however, wasnt
  possible to completely redo it due to the
  widespread usage

27
Email message transfer

• Message transfer mechanism is concerned with
  relaying messages from the originator to the
  destination
• This can be done by establishing an transport
  level connection between the source and the
  destination and then just transfer the message
• SMPT Simple Mail Transfer Protocol
• Source machine establishes a TCP connection on
  port 25 on destination machine, where SMPT daemon
  listens. This daemon accepts the incoming
  connections and copies messages from them into
  the appropriate mailboxes
• If a message cant be delivered, an error report
  containing the first part of the undeliverable
  message is returned to the sender
• It is a simple ASCII protocol

28
SMTP Protocol

• Connection establishment (on port 25)
• Data exchange
• the client machine (operating as a client) waits
  for the destination machine (operating as a
  server) to talk first
• the server begins by sending a line of text
  giving its identity and telling whether is
  prepared to receive mail
• if it is not, then the client releases the
  connection and tries again latter
• If the server is willing to accept mail, then the
  client announces whom the e-mail is coming from
  and whom it is going to
• If such recipient exists at the server end, then
  the client get the go-ahead to send the message
• The client sends the message, server acknowledges
  it
• Connection is released

29

• Stages of SMTP protocol
• C client
• S server

30
SMTP typical problems

• Some old implementations cant handle more than
  64KB message length
• If the server and client have different timeouts,
  one of them may give up while the other is still
  busy, unexpectedly terminating the connection
• In some situations infinite mail storms can be
  triggered
• If host 1 is holding mailing list A and host 2
  holds mailing list B and each list contains an
  entry for other one, then a message sent to
  either list could generate a never ending amount
  of e-mail traffic unless it is checked
• RFC281 defines ESMTP (Extended SMTP)
• Clients wanting to use it should start initially
  with EHLO instead HELO if this is rejected then
  the server is regular SMTP server

31
Final delivery

• Assuming that all machines can send and receive
  mail all the time, the e-mail model so far works
• This model breaks for people accessing Internet
  over a dialup connection
• What happens when Elinor wants to send Carolyn
  e-mail and Carolyn is not currently online?
• One solution is to have a message transfer agent
  on ISP machine since this transfer agent can be
  online all the time, e-mail can be sent 24 hours
  a day
• This solution creates another problem how does
  the user gets e-mail from ISPs message transfer
  agent
• Solution to create another protocol that allows
  user transfer agents (on client PCs) to contact
  the message transfer agent (on ISPs machine) and
  allow e-mail to be copied from ISP to the user
• One such protocol is POP3 (Post Office Protocol
  Version 3), RFC 1939

32
Final delivery

• Sending and reading mail when the receiver has a
  permanent Internet connection and the user agent
  runs on the same machine as the message transfer
  agent.
• Reading e-mail when the receiver has a dial-up
  connection to an ISP.

33
POP3

• Starts when the user starts the mail reader
• Mail reader calls up the ISP (if there is no
  connection) and establishes a TCP connection with
  the message transfer agent on port 110
• Authorization
• Having user logged in by sending its username and
  password
• Transactions
• User collecting the e-mails and marking them for
  deletion
• Update
• Causes the e-mails to be deleted

34
POP3

• Sequence to receive three messages

35
IMAP

• POP3 works fine for users with one e-mail account
  with one ISP, accessed from one PC
• If mail was accessed from different locations,
  user may loose e-mails, security issues may
  appear, etc
• An alternative final delivery protocol, IMAP
  (Internet Message Access Protocol), defined in
  RFC2060
• Instead assuming that all messages will be
  downloaded and work offline after that (like
  POP3), IMAP assumes that all e-mail will remain
  on the server indefinite in multiple mailboxes
• Provides extensive mechanisms to read messages or
  parts of messages, mechanisms to create, destroy
  and manipulate multiple mailboxes.

36
POP3 vs. IMAP
37
Web Mail

• Various companies (i.e. Hotmail and Yahoo)
  provide e-mail service using Web mail.
• Normal message transfer agents are listening on
  port 25 for incoming SMTP connections
• Messages are delivered using special web pages
  when the user goes to the e-mail Web page, a form
  is presented in which the user is asked for a
  login name and password.

38
WWW

• Architectural Overview
• Static Web Documents
• Dynamic Web Documents
• HTTP The HyperText Transfer Protocol
• Performance Enhancements
• The Wireless Web

39
Architecture Overview

• Web is a collection of web pages
• Each page contains links to other pages
• Hypertext idea of having one page point to
  another. It is text, displayed on a computer,
  with references (hyperlinks) to other text that
  the reader can immediately follow
• Browser program to view pages
• Hyperlinks strings of text that are links to
  other pages
• Example
• Typical web page
• The page reached by clicking on Department of
  Animal Psychology.

40
Architectural Overview

• Browser displays a page on the client machine
• Click on a link, the browser sends a message to
  the abcd.com web server asking it for the page
• When page arrives, it is displayed if it
  contains a hyperlink on a page on xyz.com, that
  is clicked, then the browser will send a message
  to xyz.com server and the process continues

41
Client side

• Pages are named using URL (Uniform Resource
  Locators) (i.e. http//www.abcd.com/products.html)

• Name of protocol (http)
• DNS name of the machine where the page is located
  (www.abcd.com)
• The name of the file containing the page
  (products.html)
• When the link is selected
• Browser detects the URL (by reading the input)
• Browser asks DNS server for IP address of
  www.abcd.com
• DNS replies with IP address 156.106.192.32
• Browser makes a TCP connection on port 80 to
  156.106.192.32
• It sends a request asking for file /products.html
• Web server www.abcd.com sends file /products.html

• TCP connection is released
• Browser displays all the text in /products.html
• Web pages are written in standard language called
  HTML
• A page may consist of a formatted document in PDF
  format, an icon in GIF format, a video in MPEF
  format, a song in MP3 format, or any other format

42
Client side

• The browser may have problems interpreting all of
  these formats rather than making the browsers
  larger and larger, a more general solution is
  adopted.
• When a server returns a page, it usually returns
  some information about the page
• MIME type of the page
• Pages of type text/html are just displayed
  directly
• If MIME type is not of a built in type, then the
  browser consults an internal table with
  associations between MIME types and viewers
• Two possibilities
• Plug-ins special modules that the browser loads
  in its memory space
• Helper applications separate process that takes
  as parameter the name of the file to display

43
Server side

• Typical web server operations
• Accept TCP connection
• Get the name of the file requested
• Get the file (from disk) this can be a lengthy
  operation, since every disk access takes in
  average 5ms (access time) time to read the file
  (up the file length)
• Return the file to the client
• Release the TCP connection

• Improvements
• Maintain a cache with last n most accessed
  files
• Multithreaded server

44
Server side

• If too many requests come into one second, the
  CPU will not be able to manage the load, no
  matter how many disks are used in parallel
• The solution is to add more nodes (computers),
  possible with replicated disks (server farms)
• A front end still accepts incoming requests and
  sprays them over multiple CPUs rather than
  multiple threads
• Individual machines may be multithreaded and
  pipelined as before

45
URL Uniform Resource Locator
46
URL Uniform Resource Locator

• Some common URLs

47
Stateless and cookies

• Web is stateless, no concept of login session
  the browser sends a request to the server, and
  gets back a file server forgets it seen that
  particular client
• A quick solution would be to observe clients IP
  addresses (not good since they could be NAT-ed)
• Cookies (Netscape) solve this problem, by having
  the server supply additional information when a
  client requests a page this info may include a
  cookie, that is a small (4KB) file or string
• Contains up to five fields
• When the browser sends a request to a page, it
  first checks to see if it has an associated
  cookie with the domain the request is going to.
  If yes, then it appends this cookie to the
  request the server gets it and interpret it any
  way it wants

48
HTML HyperText Markup Language

• (a) HTML source code
• Markup language containing explicit commands for
  formatting
• (b) Formatted page

49
Hypertext Document Format

• Encoded as text file
• Contains tags to communicate with browser
• Appearance
• lth1gt to start a level one heading
• ltpgt to start a new paragraph
• Links to other documents and content
• lta href . . . gt
• Insert images
• ltimg src . . . gt

50
A simple Web page
51
A simple Web page (continued)
52
An enhanced simple Web page
53
An enhanced simple Web page (continued)
54
Typical HTML tags
55
HTML versions

• HTML 1.0 was one way
• Large demand for two-way traffic
• HTML 2.0 included forms contain boxes or buttons
  that allow users to fill in information or make
  choices and send the information back to the
  server

56
Forms

• (a) HTML source code (containing forms)
• (b) Formatted page
• Possible response from the user (request from the
  browser to the server, with filled in values)

57
Dynamic Web documents

• So far, the model we have used is a static one
• A client requests a file, the server sends it
  back
• Content has become more and more dynamic
  (generated on demand)
• Content generation can take place at both server
  side and client side.

58
Server side dynamic web page

• Steps in processing a HTML form

59
PHP form processing example

• (a) A Web page containing a form.
• (b) A PHP script for handling the output of the
  form.
• (c) Output from the PHP script when the inputs
  are "Barbara" and 24 respectively.

60
Client-Side Web Page Generation

• CGI, PHP, JSP and ASP solve the problem of
  handling forms and interaction from forms
• They can accept incoming information from forms,
  look up info in one or more databases, generate
  HTML pages with the results
• They cant respond to mouse movements or interact
  directly with users
• Client side web page generation
• It is required to have scripts embedded into HTML
  pages, scripts that will be executed on clients
  machine starting with HTML 4.0, such scripts are
  permitted starting with tag ltscriptgt
• JavaScript is one popular client side scripting
  language
• Use of applets (small java programs compiled for
  JVM)
• They can be embedded into the HTML code between
  ltappletgt lt/appletgt tags and can be interpreted
  by JVM capable browsers
• Use of ActiveX controls (compiled for the native
  processor, very fast)

61
JavaScript used for processing a form

• Same output as the PHP example

62
Dynamic web page generation

• (a) Server-side scripting with PHP.
• (b) Client-side scripting with JavaScript.

63
HTTP

• HyperText Transfer Protocol is the transfer
  protocol used throughout the World Wide Web
• It specifies what messages clients may send to
  servers and what responses they get back in
  return
• Each interaction consists of one ASCII request
  followed by one RFC 822 MIME-like response
• All clients and all servers should obey this
  protocol
• It is defined in RFC 2616
• Connections
• A browser contacts a server by making a TCP
  connection on port 80
• In HTTP 1.0 after a connection was setup, one
  request was sent over, one response was sent
  back then TCP connection was released
• In HTTP 1.1 persistent connections are supported

64
HTTP Methods
The GET method requests the server to send the
page . The page is suitably encoded in MIME. The
vast majority of the requests on the web are
GETs. GET filename HTTP/1.1 Where filename is the
resource name to be fetched and 1.1 is the
protocol version being used
The HEAD method just asks for the message header,
without the actual page. This method can be used
to get a pages time of last modification, to
collect information for indexing purposes, or
just to test an URL for validity
The PUT method is the reverse of GET. Instead of
reading a page, it writes a page. This method
makes it possible to build a collection of web
pages on a remote web server. The body of the
request contains the page. It may be encoded
using MIME, in which case, the lines following
the PUT might include Content-Type and
authentication headers to prove that the caller
indeed has permission to perform the operation
POST is similar to PUT. It too, bears an URL, but
instead of replacing the existing data, it
appends it to any existing data. Posting a
message to a newsgroup or adding a file to a
bulletin board are example of the usage.
DELETE does what you expect deletes a page from
a remote web server authentication and
permissions play a major role here. There is no
guarantee that a DELETE operation is successful
since even if the remote web server is willing to
delete a page, the file permissions may be set in
such a way that the server process doesnt have
rights to do it.
TRACE method is used for debugging. It instructs
the server to send back the request. This is
useful when requests are not processed correctly
and the client wants to know it sent the proper
request. CONNECT is not used at the
moment OPTIONS provides a way for the client to
query the server about its properties or those of
a specified file
65
HTTP methods

• Every request gets back an response consisting of
• A status line
• A three digits status code telling whether the
  request was satisfied and if not, why not
• Possible additional information

66
Message headers

• The request line (i.e. line with GET method) may
  be followed by additional lines, called request
  headers
• Responses may have response headers as well

67
Internet Security

• Attacks
• Malware (viruses, worms, Trojan horses, spyware,
  phishing software)
• Denial of service
• Spam
• Protection
• Firewalls
• Spam filters
• Proxy Servers
• Antivirus software

68
Attacks

• Virus sw that infects a computer by inserting
  itself into programs that already reside in the
  machine. When the host program is executed, the
  virus is also executed.
• Worm autonomous program that transfers itself
  through a network, taking up residence in
  computers and forwarding copies of itself to
  other computers.
• Trojan horse program that enters a computer
  system disguised as a desirable program (such a
  game or utility package) that is willingly
  imported by a victim. Once in the computer, the
  trojan horse performs additional activities (most
  likely with harmful effects).
• Spyware (sniffing) software that collects
  information about the activities of computer that
  it resides and sends that information back to the
  instigator of the attack.
• Phishing rather than obtaining the information
  in secret, this techniques asks explicitly for
  it.
• DoS (Denial Of Service) attack from other
  machines in the network, by overloading the
  victim computer with messages.
• Spam abundance of unwanted messages (e-mail)

69
Protection

• Firewall primary prevention technique to filter
  traffic passing through a point in the network
  (e.g. installed on the router/gateway into an
  organization). Used also to protect individual
  computers too (rather then entire network)
• Spam filters specific purpose firewalls,
  designed to block unwanted e-mail
• Proxy server software unit that acts as
  intermediary between a client and a server with
  the goal of shielding the client from adverse
  actions of the server. This prevents the server
  to find out certain unwanted details about the
  client.
• Antivirus software software used to detect and
  remove presence of known viruses and other
  infections, specialized in virus control and
  spyware protection.

70
Encryption

• FTPS, HTTPS, SSL
• Public-key Encryption
• Public key Used to encrypt messages
• Private key Used to decrypt messages
• Certificates and Digital Signatures

71
Encryption

• Many traditional Internet applications have been
  altered to incorporate encryption techniques,
  producing what are called secure versions.
• FTPS secure version of FTP
• HTTPS secure version of HTTP using SSL (Secure
  Sockets Layer)
• They involve public key encryption
• One public key is used to encrypt messages
• One private key is used to decrypt messages
• Public key is first distributed to those that
  need to send messages in confidence to a
  particular destination.

72
Public-key encryption
73
References

• Andrew S. Tanenbaum Computer Networks, ISBN
  0-13066102-3
• J Glenn Brookshear Computer Science An
  Overview, ISBN 0-321-54428-5
