TDC 363 Local Area Networks

1
TDC 363 Local Area Networks

• Metropolitan Area Networks (MAN)

2
MAN Definition

• Not a precise definition available
• Somewhere between a LAN and a WAN with some
  features of each
• Serves a geographic area larger than a LAN, such
  as a city or metropolitan region

3
Definition Continued

• MANs can interconnect various sites for one
  company, or interconnect many companies
• MANs transfer data at LAN speeds (and higher) but
  often use more complicated protocols

4
MAN Application Areas

• Interconnection and consolidation of corporate
  data centers
• Transparent extension of the LAN by
  interconnecting distributed corporate locations
• Support of SAN (storage area networks)
• Server-less offices

5
MAN Application Areas

• Real-time transaction backups
• High-speed disaster recovery
• Interconnection between corporate data center and
  ISP
• Government, business, medicine and education
  high-speed interconnections

6
SANs

• Latest evolution of mass data storage for large
  corporations and institutions
• Normally data storage is attached to the LAN via
  a server
• But with a SAN high-volume disk arrays and tape
  storage occupy a network separate, but connected
  to, a LAN

7
MAN Features

• Why use a MAN?
• Very high speeds (Gbps possible)
• Self-healing networks
• Bandwidth on demand
• MANs cover distances that LANs cannot
• But MANs often provide a lower level of
  complexity than many WANs

8
MAN Topologies

• Point-to-point
• Characterized by very high speeds (10 to 40 Gbps)
• Often DWDM over fiber
• Redundancy is provided at the card level -
  parallel fiber links with redundant equipment at
  the endpoints

9
MAN Topologies

• Ring
• Most common architecture
• Can span tens of kilometers
• Data rates range from 622 Mbps to 10 Gbps per
  channel
• SONET rings a typical example
• Multiple rings with very fast failover provide
  stability

10
MAN Topologies

• Mesh
• The future of MANs?
• A natural extension of point-to-point MANs
• Can also connect to established rings
• High speeds, long distances, good redundancy

11
Support Technologies

• SONET/SDH
• ATM
• Gigabit Ethernet
• IP
• Fibre Channel
• FDDI

12
Support Technology - SONET

• Currently most MANs are supported by SONET rings
• SONET is the fundamental transmission technology
  for both TDM-based circuit switched networks, and
  most overlay data networks
• Unfortunately, SONET has a number of shortcomings

13
Support Technology - SONET

• SONET disadvantages
• Still fairly expensive
• Problems adapting data services to the
  voice-designed and voice-optimized hierarchy
• Inflexible multiplexing hierarchy (SONET
  increments in terms of DS-0s / DS-1s)
• SONET cannot be provisioned dynamically

14
Support Technology - ATM

• Favored by many service providers because it can
  support different protocols and different traffic
  types into a common protocol format for
  transmission over SONET
• Unfortunately, ATM is complex, costly, and
  provides an extra layer of complexity

15
Support Technology - Gigabit Ethernet

• A very interesting newcomer to MAN technology
• A very common and well-understood technology
• Can scale from 10 Mbps, 100 Mbps, 1000 Mbps, to
  10 Gbps easily
• Low cost
• No need for ATM or SONET

16
Support Technology - IP

• Almost entire data world uses IP
• Also well known, widely adopted, reasonably
  flexible, relatively simple
• IP is a layer 3 protocol, so question is IP over
  ATM over SONET? IP over SONET? IP over Ethernet?

17
Support Technology - Fibre Channel

• Predominant data link technology used in SANs
• Economical replacement for SCSI
• Interfaces available at 100 MBps with 200 MBps
  soon and 400 MBps testing
• Does not have a short distance limitation like
  SCSI
• Found in point-to-point, mesh, and arbitrated
  loops

18
Support Technology - FDDI

• Basically a legacy technology
• Being replaced by Gigabit Ethernet or ATM
• Can be transparently transported over the optical
  layer using DWDM

19
SONET vs. Gigabit Ethernet

• Lets examine the two more interesting support
  technologies
• Why more interesting?
• SONET is the ruler
• Gigabit Ethernet is trying to dethrone that ruler

20
SONET vs. Gigabit Ethernet

• Ethernet is 10 times less expensive than current
  SONET technology
• Ethernet is a simple and widely understood
  technology
• Ethernet is the best technology for carrying IP
  traffic - IP and Ethernet have matured together

21
SONET vs. Gigabit Ethernet

• Optical Ethernet can support links in the network
  range from 3 to 6 miles using single mode 1310
  nm wavelength and up to 43.4 miles for 1550 nm
  wavelength
• Optical Ethernet can segregate traffic of
  different users and deliver the particular
  service level each user purchases

22
SONET vs. Gigabit Ethernet

• Traffic segregation is accomplished by using the
  IEEE 802.1pQ VLAN standard
• With this standard, each users frame is marked
  with a VLAN tag as it enters the network
• This tag keeps each users traffic separate as it
  crosses the network

23
SONET vs. Gigabit Ethernet

• Optical Ethernet can also deliver guaranteed
  levels of latency, jitter, and bandwidth
• To provide these levels of latency and jitter,
  IETF created the Differentiated Services
  (Diff-Serv) project
• Diff-Serv - as each frame enters a network,
  information from the frame is used to assign it
  to a particular class of service

24
SONET vs. Gigabit Ethernet

• User contracts also specify bandwidths, which
  network operators guarantee by limiting the
  aggregate of guarantees to network capacity
  (similar to frame relay and ATM)

25
(No Transcript)
26
SONET vs. Gigabit Ethernet

• One of the big advantages of Gigabit Ethernet
  over SONET is the levels of complexity
• SONET has multiple layers - the router network
  running over the ATM network running over the
  SONET network running over a collection of
  point-to-point DWDM links

27
SONET vs. Gigabit Ethernet
28
SONET vs. Gigabit Ethernet

• Gigabit Ethernet, however, does not have all the
  levels, making the technology much simpler and
  much less expensive

29
SONET vs. Gigabit Ethernet
30
Yipesthats fast!

• 15 months old (as of Fall 2000)
• Up and running in 20 cities
• A disruptive approach to networking
• The first fully managed, all-IP regional optical
  networks using Gigabit Ethernet for linking
  businesses to eadch other and to the Internet

31
Yipesthats fast!

• Fully scalable bandwidth-on-demand from 1 Mbps up
  to 1 Gbps in 1 Mbps increments
• Busting the regional bandwidth bottleneck between
  corporate LANs and cross-country fiber networks
  to drive a new generation of bandwidth-intensive
  applications
• Unprecedented levels of customer control via the
  Yipes Care Service Portal

32
Yipes - Typical Regional Network

• Diversely sourced dark fiber
• Concatenated local access loops
• Less than 10 ms latency regional ring
• Multiple peering arrangements
• Several WAN connections
• 24x7 redundant monitoring

33
Yipes - Extending the LANExperience

• Fiber to business locations
• Familiar computing environment
• Granular bandwidth increments - 1 Mbps to 1 Gbps
  in 1 Mbps increments
• Scalability on demand - no forklift upgrade -
  upgrade with a phone call, and soon with via a
  Web site

34
Yipes - QoS

• Traffic engineering
• know bandwidth at access points and in metro
  network for all customers
• no over subscribing
• IEEE standard (802.1pQ) for VLANs
• identify customer packets with different tags
• prioritize packets

35
Yipes - QoS

• Hardware
• equipment has separate queues and can prioritize
  frames
• Can prioritize at IP layer
• Based on IETFs Diff-Serv

36
Yipes - Security, Survivability and Reliability

• Security
• Layer 2 switching using VLAN tags based on IEEE
  802.1q/p
• Survivability
• Dual fiber entrance to customer premises
• Failover
• 2-3 seconds for layer 3 routing
• 30 - 40 seconds for layer 2 bridging/switching (5
  seconds in future)
• Reliability
• 99.99 migrating to 99.999 by mid 2001

37
