Let Us Solve Your Technical Needs!

1

• Let Us Solve Your Technical
  Needs!

2
RFI Corporation

• Key Benefits of RFI Corporation
• Company Overview
• Markets Served
• Programs
• Facilities , Standards Quality Systems
• Power Magnetics Products
• EMI/EMC Filter Products
• New Products
• Customer Requirements
• How has RFI Corp met the Requirements of Our
  Customers?
• Summary

3
What Are The Key Benefits Of Using RFI
Corporation?

• Diversified Engineering Talent for Superior
  Pre-Production Analysis, Consulting and Design.
  Saves Project Time to Market
• Proven Track Record of Almost Forty Years of
  Quality Manufacturing and On-Time Performance!
  Lower Risk
• Multiple Process Disciplines in Mil-Standards,
  Industrial ISO Requirements and Commercial Market
  Demands TQM
• Economies-Of-Scale associated with One Stop
  Shopping. Lower Costs

4
Company Overview

• RFI incorporated in 1961.
• Quickly Became Leader in Solving Complex
  EMI/RFI/EMC Problems for the Commercial, Medical,
  Military Industrial Markets.
• Today RFI has over 100,000 existing Designs and a
  Loyal Customer Base Over Several Thousand Strong!
• Sole Source High Voltage Magnetics Supplier to
  Many Fortune 500 Companies Programs, i.e. ITT,
  Raytheon, etc.

5
Major Markets Served

• Industrial
• Shielded Rooms
• Equipment Components
• Major Systems
• Medical
• MRI
• CAT SCAN
• X-RAY
• Military
• Guidance Systems
• Radar Systems
• Weapons Systems
• Communications Electronics

6
Major Markets Served (continued)

• Aerospace
• Aircraft Electronics
• Power Systems
• Commercial
• Systems Components
• Meteorological Systems
• Power Systems
• Telecommunications/Telephone Systems
• OEMs
• Custom Systems
• Transmitters/Receivers

7
Programs(Military Industrial)

• AEGIS
• PCS
• PATRIOT
• AWACS
• SPS-67
• NEXRAD
• VOA
• many more!

• TRC 170
• BRU 32 33
• PHALANX
• SPS-40
• SPS-75
• CASS
• BSY-2

8
Facilities

• State-Of-The-Art Impregnation Sys
• Diversified Manufacturing
• Sheet Metal Fabrication

9
Facilities

• -Screen Rooms for EMC/EMI
  Corona Testing
• -CAE/CAD
  Equipment Personnel

10
Facilities

• 60,000 Square-Foot Manufacturing and
  Administration Space
• Component Manufacturing
• Toroidal Solenoid Inductors
• Paper and Film Dielectric Capacitor Winding
• Vacuum Impregnation Systems for Oils, Epoxies and
  Resins
• Assembly Testing Departments for Diversified
  Product Range
• Engineering Lab for Quality Conformance and
  Environmental Testing
• Numerically Controlled Sheet Metal Fabrication
  Department
• State-of-the-Art CAE/CAD/CAM
• Fully Network-Integrated Sales, Production
  Control, Accounting, etc.
• Published Senior Engineering Staff
• Diversified Disciplines (High Voltage, EMI/EMC,
  and more)

11
Standards/Quality Systems

• MIL STD-220
• J-STD-001
• MIL STD-285
• MIL STD-202
• MIL STD-461
• QPL TO MIL-PRF-15733

• ISO 9001 Compliant
• UL 1283
• TEMPEST
• FCC PART 15
• MIL-PRF-27
• MIL-PRF-19978
• others

12
Power Magnetics Products
13
Power Magnetics Products
14
Power Magnetics Products

• Thru Put Power Levels Ranging From 100W to 100KW
  with Voltage Levels that are Minimal to well in
  Excess of 100KV!
• Capacitors (Reconstituted Mica, Film-Foil,
  Metalized, Feed-Through)
• High Voltage DC, AC, and Pulse
• High Current
• Power Factor Correction
• Repetitive Discharge
• Energy Storage (low inductance)
• High Voltage Transformers (Pulse, Current,
  Isolation, Inverter, Impulse, High Frequency)
• Reactors (DC, Charging)
• Modulators(Line Pulse, Solid State)
• Pulse Forming Networks Packages

15
Design CriteriaPartially Discharged Capacitors

• Type of Capacitor (RECON MICA or Film OIL Filled)
• Application (Short Ckt Description)
• Operating Storage Temperature
• Peak Charging Voltage Time
• of Voltage Discharge or Peak Discharge Current
  and Current Pulse Width
• Repetition Frequency
• Size Limitation (Physical Size)
• Terminal Rating with respect to Ground

16
Design Criteria DC Capacitor

• Type of Capacitor (MICA or OIL Filled)
• Application (Short Ckt Description)
• Capacitance
• DC Operating Voltage
• Ripple Voltage
• Ripple Frequency
• Ambient Temperature
• Physical Size Mounting
• Terminal Rating with respect to Ground
• What Type of MIL-Spec Applies MIL-PRF-19978,
  MIL-C-5 or MIL-PRF-39001

17
Design Criteria AC Capacitor

• Type of Capacitor (MICA or OIL Filled)
• Application (Short Ckt Description)
• Capacitance
• AC Operating Voltage
• Frequency
• Operating Temperature
• Operating Current (Current Limiting Resistor)
• Physical Size Mounting
• Terminal Rating with respect to Ground
• What Type of MIL-Spec Applies MIL-PRF-19978,
  MIL-C-5 or MIL-PRF-39001

18
Design Criteria for Capacitors Used in a Pulse
Forming Network

• Type of Capacitor (MICA or OIL Filled)
• What is the Characteristic Impedance of the PFN?
• What is the Application?
• In What Type of Load is the PFN Terminated?
• What is the Ambient Temperature of the Oil-Filled
  Container that the Coil Capacitor Assembly is
  installed?
• What is the Actual Configuration of the PFN?
• For Example
• How Many Sections?
• What is the Capacitance per Section?
• What is the Charging PFN Current? Do you use
  Resonance Charging?
• What is the Charging Time?
• Physical Size Envelope
• Does a MIL-Spec Apply MIL-N-23182 ?
• Would you prefer RFI to design your PFN?

19
Design Criteria Power Transformers

• Voltage Line-Line, of Phases
• Frequency
• What is the Application?
• Load, Regulation, Expected Efficiency
• Operating or Storage Temperature
• MIL-PRF-27 What Grade (Describe Type of
  Transformer)?
• For Example
• Open Frame, Air Cooled
• Epoxy Encapsulation
• Oil Filled
• What is the Charging Time?
• Physical Size Envelope and Configuration
• Terminal Rating to Ground
• Isolation Voltage

20
Design Criteria High Frequency Transformers

• Operating Frequency
• VA Rating
• What is the Application?
• Primary and Secondary Voltages Currents
• Duty Cycle (if applicable)
• Load, Regulation, Efficiency
• Physical Size Envelope and Configuration
• Operating and Storage Temperature

21
Design Criteria Pulse Transformers

• Load (Full and Complete Description)
• Source (Full and Complete Description)
• Load Voltage Current
• Pulse Width
• PRF (Pulse Repetition Frequency)
• Rise Time (usually in micro seconds)
• Fall Time (usually in micro seconds)
• Operating Storage Temperatures
• MIL-PRF-27 Grade?
• Terminals Rating to Ground
• Physical Size Envelope and Configuration

22
Design Criteria Charging Reactor or Transformer

• Inductance
• Peak Charging Current
• Repetition Frequency
• PFN Capacitor, or Capacitor to be Charged
• Power Supply Voltage
• PFN Charging Voltage
• Operating Storage Temperatures
• MIL-PRF-27 Grade
• Terminals Rating to Ground
• Physical Size Envelope and Configuration

23
EMI/EMC Filter Products
24
EMI/EMC Filter Products

• High Power Facility Filters
• Telephone Data Filters/Cabinets
• Subminiature QPL Filters
• RFI/EMP Transient Energy Filters
• Custom Multi-Circuit Filters
• UL Listed Filters

25
Design Criteria EMI/EMC Filter Products

• Current Rating
• Continuous and Transient
• Voltage Rating
• Maximum Amplitude Frequency
• Voltage Drop
• Insertion Loss
• MIL-STD-220
• Current Injection
• Common Mode
• Differential Mode

• Critical Circuit Requirements/Application
• Mechanical
• Case Size Mounting Type
• Terminal/Connector Type(s)
• Special Finishes
• Environmental
• Temperature
• Shock/Vibration
• Altitude
• Humidity
• Salt Atmosphere

26
New Products

• Filtered Terminal Blocks
• Medical Filters(Low Leakage)
• Power Distribution Panels

27
Customer Requirements

• Performance!
• Products That Meet Complex Specifications
• Quality Reliability
• On-Time Delivery
• Competitive Pricing

28
How has RFI Corp met the Requirements of Our
Customers?

• 100 Total Quality Rating-Sikorsky
• Certified Supplier-Lockheed Martin
• 100 GOLD Rating-McDonnell Douglas
• Best Value Supplier Award-ITT Gilfillan
• Supplier Quality Award-Hazeltine
• Zero Failure Award-DESC
• Outstanding Quality Award-Allied Signal
• Many More......

29
Summary

• Reducing Vendor Base Saves !
• RFI has remained an APPROVED VENDOR with every
  Major Customer that has executed a Reduction in
  their Vendor Base!
• Financial benefits of economies-of-scale, i.e..
  One Stop Shopping.
• RFIs Engineering Experts Are There From Design
  to Delivery Supporting the Customers Unique
  Technical Needs!

30
Next Step

• Customers Engineering and (or) Production Order.
