Understanding Audio Video
2
Understanding Audio Video
  • Presented by
  • Hubbell Premise Wiring
  • Glenn Kierstead
  • Senior Product Manager Copper Systems
  • gkierstead_at_hubbell-premise.com

3
Convergence
  • Convergence The Underlying Trend
  • One LAN Voice, Data, Audio-Video, HVAC,
    Security, Lighting, Asset/Device Management PoE
    Appliances
  • Expand capabilities Unified Messaging
  • Video Conferencing
  • Web-based conferencing with voice and
    presentations
  • Long Distance Learning
  • Home Offices
  • Connection point-to-point to packet based
    networks
  • Wireless, VoIP
  • Collaboration
  • Whiteboarding
  • Drivers
  • Major Endorsement
  • Cisco, HP, Microsoft, Apple, etc.
  • AVIT, Crestron, Extron, AMX, etc.
  • High level customer interest
  • Cost savings / Revenue opportunity
  • Enhanced productivity

4
Why Convergence?
  • IP convergence benefits business and employees
  • Reducing complexity and improving asset
    management
  • Reducing the Total Cost of Ownership (TCO)
  • Enhancing business communications
  • Increasing employee productivity and mobility
  • Improving customer satisfaction
  • Future proof investment

5
AVIT What has Changed
  • Convergence
  • The Evolution of AV Systems
  • Ol Ma Bell (99.999)
  • Customers Expectation
  • IT has Set the Bar
  • Higher Standards for AV Integration

6
Market Drivers
  • Products driving demand
  • Displays, Wireless, Control Systems and
    Projectors.
  • Growth is driven by display systems
  • Expected to grow with an average of 12 annually
    over the next five years.
  • Display Systems Growth Led several IT
    companies to enter the market to offer
    competitive products.

7
Who is the AV Market?
  • Vertical Market Segments
  • Business and Corporate
  • Government and Military
  • Education
  • House of Worship
  • Broadcasting
  • Hospitality
  • Healthcare
  • Museums
  • Retail
  • Legal and Courts
  • Transportation
  • Sports, Entertainment and Theme Parks

8
Audio Connections Applications
9
RCA Connector
  • RCA Connector
  • Type of standard, low-level signal interconnect
    termination or connector featuring a single,
    cylindrical metal rod and an outer, round metal
    belt.
  • RCA interconnects are unbalanced designs used in
    almost all systems and between almost any type of
    audio/video component.
  • Applications
  • Most Consumer electronic equipment
  • Home Theater (Surround Sound)
  • DVD, CD, Receivers, Cassette, VCR, Cable Box,
    etc.
  • Pro Audio
  • Mixing Boards, Amplifiers Component Units
  • Speaker connections
  • Broadcast studios
  • Speakers
  • Computers
  • Video Cameras
  • Home recording equipment

10
RCA Connector Applications
Audio Applications
11
Speaker/Binding/Banana Jacks
  • Binding Posts
  • A high-quality terminal connection able to accept
    multiple types of speaker wire with a variety of
    terminations or ends.
  • Bindings screw down onto bare wire or utilize
    Banana jacks for connecting.
  • Banana Jacks
  • A speaker wire termination consisting of a
    single, fat shaft which bulges on the sides
    similar to a banana.
  • The banana termination provides the most contact
    area of any other speaker wire termination.
  • Ensuring maximum signal and power transfer
  • Speaker Terminal
  • A quick release spring loaded pushbutton terminal
    allowing for easy termination of speaker wire.
  • Applications
  • Speakers
  • Most Consumer electronic equipment
  • Home Theater (Surround Sound)
  • DVD, CD, Receivers, Cassette, VCR, Cable Box,
    etc.
  • Pro Audio Equipment
  • Test Equipment

Color-Code
Red Active or positive terminal Black Inactive
or negative terminal
12
3.5mm Stereo Jacks
  • 3.5mm Stereo Jack
  • Designed in todays electronic equipment that
    features remote speakers, headsets, and
    headphones.
  • Applications
  • Computers
  • Video Cameras
  • Personal/Portable Devices
  • Consumer electronic equipment
  • Test equipment
  • Speakers
  • Headphones

13
3.5mm Stereo Jacks
  • Todays most common Audio interfaces available.
    Designed in portable and computer based
    electronic equipment, this connection allows for
    Audio in and out, for headsets, headphones,
    Line-In , microphones, speakers surround sound
    applications.

14
¼ Stereo Jacks
  • 1/4 Stereo Jacks
  • Designed for use in broadcasting, intercom and PA
    systems, switchboards, and commercial, industrial
    and military communications equipment.
  • Commonly mounted in panels or chassis
  • Applications
  • Pro Audio
  • PA Systems, Mixing Boards, Amplifiers Component
    Units
  • Guitars Speaker connections
  • Broadcast studios
  • Intercom Systems
  • Home recording equipment
  • Test equipment

15
Stereo Jacks
  1. Sleeve usually ground
  2. Ring Right channel for stereo signals, negative
    phase for balanced mono signals
  3. Tip Left channel for stereo signals, positive
    phase for balanced mono signals, signal line for
    unbalanced mono signals
  4. Insulating rings

Unbalanced Balanced Stereo
Tip Signal Positive Hot Left Channel
Ring Not available Negative Cold Right Channel
Sleeve Ground Return Ground Ground
16
3-Pin XLR
  • XLR
  • The standard connector for digital and analog
    balanced line interconnect between audio
    equipment.
  • The balanced nature of XLR connections result in
    very low distortion due to noise.
  • XLR cable uses three wires, one for the positive
    signal, one for the negative signal and one for
    the ground.
  • Applications
  • Pro Audio
  • PA Systems, Mixing Boards, Amplifiers Component
    Units
  • Microphones Speaker connections
  • Broadcast studios
  • Auditoriums
  • Gymnasiums
  • Churchs
  • Intercom Systems

17
Balanced Audio
  • Balanced audio is a method of interconnecting
    audio equipment using impedance-balanced lines.
    Balanced connections use three-conductor
    connectors, usually the XLR or TRS jack plug.
    XLR connectors are the preferred connector of
    choice, because of their durable construction.
  • The balanced nature of XLR connections result in
    very low distortion due to noise.

18
Speakon Connector
  • Speakon
  • Speakon connector is commonly used in pro audio
    systems,connecting loudspeakers to amplifiers.
  • It features a quick-locking system with options
    for soldered or screw-type for easy repair in the
    field.
  • Patch Cords female only mate with male only
    panel connectors
  • Speakon is an alternative to 1/4", two-pole twist
    lock, and XLR connectors for loudspeaker
    Applications
  • Superior to 1/4" jack because of its ability to
    lock the plug to the socket preventing the
    speaker from becoming disconnected by movement or
    other forces.
  • Provides a fully-insulated connection to
    equipment, eliminating electrical shock risks
    associated with high power audio amplifiers.
  • Applications
  • Pro Audio
  • PA Systems, Amplifiers Component Units
  • Speaker connections
  • Cable Assemblies
  • Broadcast studios
  • Auditoriums
  • Entertainment Industry

19
Video Connections Applications
20
Video Connection Types
  • F-Connector CATV
  • RCA Composite
  • S-Video
  • BNC Component
  • 15-Pin VGA Style
  • DVI
  • HDMI

21
Video Applications
  • Digital
  • HDMI
  • DVI
  • Analog
  • RGB
  • Component
  • S-Video
  • Composite
  • NTSC

22
F-Connector
  • F-Connector
  • The F-Connector features a single thin metal
    shaft in its center with a round metal band
    around the outside. The band is machined to screw
    onto an F-jack on the back of a TV or VCR.
  • TV Channels
  • Standard Broadband
  • F-Connector RG6 Coax
  • Audio and Video on the same line
  • Applications
  • TV, CCTV, CATV Satellite
  • Home Theater Entertainment Systems
  • Security Surveillance Systems
  • VCR
  • Computer Capture Cards

23
Television Standards
  • National Television Standards Committee (NTSC)
  • Japan and North America (4.43 3.58) analog
    standard
  • Phase Alternating Line (PAL)
  • Asia, UK, Europe analog standard
  • SEquential Couleur Avec Memoire (SECAM)
  • France and Russia analog standard
  • ATSC (Advanced Television Systems Committee)
  • New U.S. digital (DTV) standard incl. HDTV
    formats
  • 8 different image formats

24
RCA Connector
  • RCA
  • Type of standard, low-level signal interconnect
    termination or connector featuring a single,
    cylindrical metal rod and an outer, round metal
    belt.
  • RCA interconnects are unbalanced designs used in
    almost all systems for video.
  • Composite
  • Y/C
  • Component
  • Applications
  • Most Consumer electronic equipment
  • Home Theater Entertainment Systems
  • DVD, VCR, CATV, Satellite, Game Box, etc.
  • Computers
  • Video Capture Cards
  • Video Editing
  • Cameras, Camcorders Projectors
  • Security Surveillance Systems

25
RCA Connector Applications
  • Video
  • Applications

26
Composite Video
  • Composite video combines all the aspects of a
    video (RGBHV) into one single signal
  • One of the most common video signals
  • Issues
  • Decoding Artifacts
  • Dot crawl
  • Color Errors
  • Low Detail

27
S-Video Connector
  • S-Video Connectors
  • 4-Pin mini din connector, separating video
    signals into 2 signals Y/C, chrominance (C)
    (color) and luminance (Y) (brightness) portions
    of the video signal resulting in superior picture
    quality versus composite video.
  • Applications
  • Video Distribution
  • TV, Cable, Satellite
  • DVD, Game Boxes
  • Cameras, Camcorders Projectors
  • Security Surveillance Systems
  • Home Theater Entertainment Systems

28
S-Video (Y/C)
  • S-Video or Y/C
  • Method of transmitting video signals by
    separating out the chrominance (C) (color) and
    luminance (Y) (brightness) portions of the video
    signal resulting in superior picture quality.
  • By separating the color from the brightness, the
    distortions encountered can be eliminated.

29
S-Video Signals
  • Chrominance
  • Chrominance is abbreviated with the letter C
  • The color portion of a video signal carrying the
    saturation and tint (hue) information for any
    given point in the image.
  • Higher chrominance levels produce more powerful
    or stronger colors

30
S-Video Signals
  • Luminance
  • Luminance is abbreviated with the letter Y.
  • The black and white portion of a video signal
    which carries the information for brightness and
    darkness and contrast. Luminance ranges from pure
    black to pure white. When combined with the color
    portion (chrominance), a complete video image can
    be developed.

31
BNC-Connector
  • BNC-Connector
  • A professional quality cable termination which is
    used primarily in labs and professional studios
    as an interconnect.
  • The BNC connector has a thin central pin and an
    outer rounded metal belt. The connector pushes
    onto its jack and twists to the side locking in
    place.
  • Applications
  • TV, CCTV, CATV, Satellite Monitors
  • Home Theater Entertainment Systems
  • Security Surveillance Systems
  • Projectors
  • Computers
  • Audio Speaker Connections
  • Test Equipment
  • Wireless

32
Component Video
  • Use Red Blue Green Cables
  • 3 Wire for Y, Pr, Pb
  • An alternative type of componentization
  • Multiple chrominance channels allow for more
    precision and speed in mapping the RGB color
    space.
  • This scheme is the type of signal is usually what
    is meant when people talk of component video.
  • High Definition Format

33
15-Pin High Density D-Sub
  • HD 15-Pin
  • Is a standardized connector that is used in
    connecting monitors to a PC. Transmits high
    quality component video signal (RGBHV)
  • Applications
  • HDTV, Computer Viewing Monitors, Projectors,
    Flat screens, Plasma Screens
  • Computers, Laptops
  • Security Surveillance Systems
  • High End Home Theater Entertainment Systems

34
SVGA Style Video
  • High Density 15-Pin D-Sub Connector
  • Transferring analog video information from one
    device to a monitor or viewing station using a
    high density 15-Pin D-Sub connection. The signal
    being transmitted is component video which is
    individual signals such as red, green and blue
    (RGB) resulting in the highest quality signal
    transfer and lowest distortion. SVGA Style
    applications also utilize pins 10, 13 14 to
    transmit Vertical and Horizontal Sync signals.

35
Video Terms and Resolutions
36
RGBHV
  • 5 Separate Signals RGBHV
  • No encoding or decoding
  • Wide Bandwidth
  • Standard on PCs and Laptops
  • Projectors
  • Connections
  • 15-Pin HD
  • 5 BNCs

37
DVI
  • DVI
  • Digital Video Interface
  • Is a standardized connector that is The Digital
    Visual Interface (DVI) is a video interface
    standard designed to maximize the visual quality
    of digital display devices such as flat panel LCD
    computer displays and digital projectors.
  • Applications
  • HDTV, Computer Viewing Monitors, Projectors,
    Flat screens, Plasma Screens
  • Computers, Laptops
  • Security Surveillance Systems
  • High End Home Theater Entertainment Systems

38
DVI Connections
  • Digital Video Interface (DVI)
  • DVI or Digital Visual Interface, a digital
    interface standard created by the Digital Display
    Working Group (DDWG) to convert analog signals
    into digital signals to accommodate both analog
    and digital monitors.
  • Data is transmitted using the transition
    minimized differential signaling (TMDS) protocol,
    providing a digital signal from the PC's graphics
    subsystem to the display.
  • A single connection encompass both digital and/or
    legacy VGA interfaces
  • DVI handles bandwidths supporting UXGA and HDTV.
  • Component Video is being transmitted

39
DVI Connections
  • DVI Connectors
  • The DVI connector come in 3 different styles,
    depending on signal transmission.
  • DVI-D (digital only)
  • DVI-A (analog only)
  • DVI-I (digital analog)
  • Video signal
  • Digital video stream
  • (Single) WUXGA 1920 1200 _at_ 60 Hz
  • (Dual) WQXGA (2560 1600) _at_ 60 Hz
  • Analog RGB video (-3 db at 400 MHz)
  • Data signal
  • R,G,B data clock and display data channel
  • Bandwidth
  • (Single) 3.7 Gbit/s
  • (Dual) 7.4 Gbit/s or more
  • Pins 29
  • Cable Type
  • Standard DVI Cable Assemblies
  • Note Can Not Be Field Terminated

40
480p, 720i, 1080p What?
  • 1080i/p What does this mean?
  • The number 1080 stands for the number of lines of
    vertical resolution (1080)
  • The Letter (i/p) represents the type of video
    Interlaced or Progressive Scan
  • Ultra High Definition 1440 2160

41
What is Interlaced?
  • Interlace is a technique of improving the picture
    quality of a video signal by removing flicker
    without consuming any extra bandwidth giving the
    perception of more detail. (half of the
    bandwidth)
  • Interlaced Scanning is the separating the frame
    into two fields
  • Odd and Even

Odd Field
Even Field
42
What is Progressive Scan?
  • Progressive what?
  • Progressive or noninterlaced scanning is any
    method for displaying, storing or transmitting
    moving images in which all the lines of each
    frame are drawn in sequence.
  • Full image
  • Line scanned in top to bottom sequence
  • Twice the amount of Bandwidth
  • Advantages
  • Easier video authoring
  • Subjectively higher vertical resolution
  • Eliminates visual artifacts
  • Intentional blurring
  • Faster video processing from source to display

43
HDMI
  • HDMI High Definition Multimedia Interface
  • HDMI is an all-digital audio/video interface
    capable of transmitting uncompressed streams.
    HDMI provides an interface between any compatible
    digital audio/video source, such as a set-top
    box, a DVD player, or an AV receiver and a
    compatible digital audio and/or video monitor,
    such as a digital television (DTV).
  • Applications
  • HDTV, Computer Viewing Monitors, Projectors,
    Flat screens, Plasma Screens
  • Digital Signage
  • Computers
  • High End Home Theater Entertainment Systems

44
HDMI
  • Standard HDMI Distance Limitation
  • 28 AWG Cable Assemblies 5-Meters
  • 24 AWG Cable Assemblies 12-Meters
  • Always Check Cable/Device Manufacturers
    Specifications
  • Audio signal
  • PCM, DVD-Audio, Super Audio CD, Dolby True HD,
    DTS-HD Master Audio
  • Video signal
  • 480i, 480p, 576i, 576p, 720p,1080i, 1080p
  • HDMI Connectors
  • Type A connector has 19 pins, bandwidth
    supporting SDTV, EDTV, HDTV. The outside
    dimensions of the plug is 13.9 mm wide by 4.45 mm
    high. Type A is electrically compatible with
    single-link DVI-D.
  • Type B connector is a higher resolution version
    defined in HDMI 1.0. 29 pins (21.2 mm wide by
    4.45 mm high), allowing it to carry an expanded
    video channel for use with very high-resolution
    future displays (WQSXGA (3200x2048). Type B is
    electrically compatible with dual-link DVI-D, but
    is not in general use.
  • The Type C mini-connector is designed for
    portable multimedia devices (camcorders, cameras,
    etc). Outside dimensions (10.42 mm by 2.42 mm).
    Type C has the same 19-pin configuration as Type
    A.

45
HDMI Standards
46
HDMI 1.3
  • What is HDMI 1.3
  • Higher speed - 10.2 Gbps
  • Bandwidth more than doubled from 165 MHz (4.95
    Gbps) to 340 MHz (10.2 Gbps) to support Higher
    Resolution, Faster Refresh, and Deep Color
  • Lip sync correction
  • Audio Sync timing Compensation
  • New mini connector
  • Cameras and Camcorders
  • Deep Color support
  • Extended color gamut for more natural and
    realistic color
  • Broader color space xvYCC
  • Meets the next generation High Definition Color
    space

47
USB Connectors
  • USB
  • Universal Serial Bus (USB) is a serial bus
    standard to interface devices. It was originally
    designed for personal computers, but it has
    become commonplace on scanners, printers,
    handheld devices such as portable memory devices,
    video game consoles, PDAs and portable media
    players
  • Applications
  • Connecting Peripherals to a Computer(s)
  • KVM Keyboards Mouse devices, Printers,
    Scanners, External Storage, Networking components
  • PDAs, Phones, MP3 Players, Gamepads and
    Joysticks, Digital Voice Recorders, Digital
    Cameras and Video Recorders

48
Thanks For Your Time!!
About PowerShow.com
