Application Layer Multicast for Earthquake Early Warning Systems

1
Application Layer Multicast for Earthquake Early
Warning Systems

• Valentina Bonsi - April 22, 2008

2
Agenda

• Architecture of an Earthquake Early Warning
  System
• Crisis Alert Early Warning dissemination
• Application Layer Multicast implementation
• Enhancing reliability of ALM

3
Earthquake Early Warning System
Schools
Municipalities

• Earthquake assessment center
• determine magnitude and location of the event
• predict the peak ground motion expected in the
  region around the event

Sensors (Seismometers etc)
Transportation authorities
Companies
Public
Focus of the ElarmS system (www.elarms.com)
Crisis Alert system
4
Crisis Alert current implementation

• Notification can be triggered automatically when
  message from the Earthquake assessment center is
  received
• Dedicated engine to process early warning
  policies
• No human interaction required
• Dissemination modalities
• CREW protocol
• Application Layer Multicast (Scribe on Pastry,
  http//research.microsoft.com/antr/scribe/)
• Organization based dissemination no
  dissemination to the public

5
Application Layer Multicast Scribe
implementation
Scribe application-level multicast infrastructure
Application level
Pastry object location and routing for P2P
systems
Internet
6
Pastry

• Pastry node
• device connected to the Internet and running
  Pastry node SW
• Assigned a unique 128-bit id
• Node state

Leaf set ?L? nodes with the?L?/2 numerically
closest larger NodeId and ?L?/2 numerically
closest smaller NodeId
Routing table ?log2bN? cols, 2b-1 rows Entry in
ith col shares i digits with current node Each
entry is the closest existing node with the
appropriate prefix
Neighborhood set ?M? nodes that are physically
closest to the local node
7
Pastry routing

• Algorithm
• Check if the message key falls in the leaf set ?
  forward message to destination
• Find the node in the routing table that shares
  with the key one more digit than the current node
  ? forward message to the next node
• Find the node in the routing table that shares
  with the key the same number of digit than the
  current node but is numerically closer to the key
  ? forward message to the next node
• It always converges
• Number of routing steps
• Expected ?log2bN?
• worst case (many simultaneous node failures) N
• Delivery guaranteed unless ??L?/2? nodes with
  consecutive ids fail simultaneously

8
Pastry self-organization adaptation

• Node arrival
• New node X must know a nearby pastry node A
• X asks A to forward a JOIN message ? forwarded to
  Z, the node with id closer to X
• All nodes that have seen the JOIN send to X their
  state tables
• X initiate its state with collected info (L
  Z.L, MA.M)
• X notify every node in its state table
• Node departure
• Leaf node failure detected during routing
• Contact the live node in its L with the largest
  index on the size of the failed node X (smaller
  or grater than himself)
• Choose the new leaf among X.L
• Neighbor node failure detected during periodic
  contact
• Contact other members in N
• Choose the closest neighbor to add
• Routing table node failure detected during
  routing
• Contact other members in the same routing table
  row and look for the node in the same position of
  the failed one
• Eventually continue the search among nodes in the
  next routing table row

9
Scribe

• Event notification infrastructure for topic-based
  publish-subscribe applications
• Scribe system network of Pastry nodes running
  the Scribe SW
• Topic creation
• node send a CREATE message with topic id as
  destination ? Pastry delivers it to the node with
  the node id numerically closest to topic id
  (rendez-vous point)

10
Scribe membership management

• Node subscription
• Node sends a SUBSCRIBE message with key topicId
• Pastry routes message to rendez-vous point but
  each node along the route
• Checks if he is a forwarder for the topic
• If not, add the topic to its current list and
  sends a SUBSCRIBE message to the same topic
• Add the sender to the children list for the topic
  and stops the original message
• Node unsubscription
• Node unsubscribes locally and checks if there are
  children for the topic
• If not, sends an UNSUBSCRIBE message to its
  parent (possible only after having received at
  least one event from parent)
• Disseminating a message
• If publisher has rendez-vous IP address send a
  PUBLISH message to it
• Otherwise send uses Pastry to locate it by
  sending a PUBLISH message with topicId as key
• Rendez-vous node disseminate message along the
  tree

11
Scribe Reliability

• Scribe provides reliable ordered delivery if
  the TCP connections between nodes in the tree do
  not fail
• Repairing the multicast tree
• Children periodically confirm their interest in
  the topic by sending a message to their parents
• Parents send heartbeat to children, when child do
  not receive heartbeats sends a SUBSCRIBE message
  with topicId as key. Pastry routes the message to
  the rendez-vous point rebuilding the tree
• Root failure
• Root state is replicated in the k closest nodes
• When children detect failure, new tree is build
  with one of these nodes as root

12
Scribe experimental evaluation

• Setup
• Simulator that models propagation delay but not
  queuing, packet losses or cross traffic.
• 100,000 nodes
• 1,500 groups with different size (11 to 100,000)
• Delay penalty (compared with IP multicast)
• Max delay penalty 1.69 for 50 of groups, 4.26
  max
• Avg delay penalty 1.68 for 50 of groups, 2 max
• Node stress
• Mean number of children tables per node 2.4 (Max
  40)
• Mean number of entries per node 6.2 (Max 1059)
• Link stress (compared with IP multicast)
• Mean number of messages per link Scribe 2.4, IP
  0.7
• Max number of messages per link Scribe 4031, IP
  950
• Scalability with many small groups (50,000 nodes,
  30,000 groups 11 nodes each)
• Mean number of entries per node 21.2, naïve
  multicast 6.6
• Problem is that many long paths with no branches
  are created ? algorithm for collapsing the tree
  removing nodes that are not members and have only
  one child per table

13
Reliability of ALM

• In the ALM implementation we consider, nodes that
  subscribe to a topic are organized in a tree
• If one of the nodes fails, all the sub-tree
  rooted at that node will be unreachable until the
  tree is rebuilt
• Impossible to guarantee that nodes will receive
  early warning since rebuilding the tree can
  require few seconds ? can be too late
• Idea build a graph instead of a tree, where the
  subscription of each node is maintained in k
  nodes
• If we assume single failure model and k2, in
  case of a node failure the sub-tree rooted at
  that node will be notified by the other node that
  maintain those subscription while the graph is
  repaired.

14
Membership management

• Node subscription
• Node sends one subscribe messages to the topic Id
  and waits for k subscribe ack
• Node that receive the subscribe message performs
  the Scribe subscription and disseminates k-1
  subscribe messages to its replicas
• Subscribe node can receive
• SUBSCRIBE ACK ? add new parent
• SUBSCRIBE FAILED ? impossible adding another
  parent in the current situation (retry when a
  node joins or leaves)
• SUBSCRIBE LOST ? re-send subscribe message
• Node unsubscription
• Same as Scribe but UNSUBSCRIBE message is send to
  all parents.
• Message dissemination
• Same as Scribe but each node maintains a cache of
  sent messages in order to avoid re-multicasting

15
Multicast graph maintenance

• Repairing the multicast tree
• Children periodically check that one of their
  parents is alive and confirm their interest in
  the topic by sending a SUBSCRIPTION CONFIRM
  message
• When child detects parents failure sends a new
  SUBSCRIBE message.
• Root failure
• Root state is replicated in the k closest nodes
• If root node fails, messages with key topic Id
  are routed to one of the root replicas (because
  it now has the closest Id to the topic)
• Children of the root will detect the failure and
  send a new SUBSCRIBE message

16
Graph-based ALM issues

• Dissemination path contains loops ? cache sent
  messages
• Cache should contain a unique id
  hash(sourceid)
• How to choose replica nodes
• Pastry routing delivers a message to the node
  with id closest to the message destination ? each
  subscription is maintained in the node that would
  have been the parent in the tree structure Scribe
  generates and in the k-1 nodes with ids closest
  to it
• Root is replicated in the same way ? if it fails
  one of the k-1 replicas will become the new root
  and will already have the list of subscribed
  nodes
• Position of the root is dynamic every time a new
  node is added, can become the new rendez-vous
  point if its Id is the closest to the topic Id
• Issues can arise in this case because potentially
  only the old rendez-vous point will subscribe to
  the new one ? if the old rendez-vous point fails,
  the dissemination stops
• 2 possible solutions
• Impose additional constraints on the fan-out of
  nodes (h children)
• Fix the rendez-vous point to be a stable node

17
Testing plan

• Reliability
• Message dissemination delay in normal conditions
  and with failures
• Failure models
• Independent failures
• Geographical failures
• Scalability
• Set of EEW receivers includes schools,
  transportation companies, cities.
• Test with increasing number of receivers for each
  organization
