Fundamentals of Python: From First Programs Through Data Structures

1
Fundamentals of PythonFrom First Programs
Through Data Structures

• Chapter 18
• Hierarchical Collections Trees

2
Objectives

• After completing this chapter, you will be able
  to
• Describe the difference between trees and other
  types of collections using the relevant
  terminology
• Recognize applications for which general trees
  and binary trees are appropriate
• Describe the behavior and use of specialized
  trees, such as heaps, BSTs, and expression trees
• Analyze the performance of operations on binary
  search trees and heaps
• Develop recursive algorithms to process trees

3
An Overview of Trees

• In a tree, the ideas of predecessor and successor
  are replaced with those of parent and child
• Trees have two main characteristics
• Each item can have multiple children
• All items, except a privileged item called the
  root, have exactly one parent

4
Tree Terminology
5
Tree Terminology (continued)
6
Tree Terminology (continued)
Note The height of a tree containing one node is
0 By convention, the height of an empty tree is
1
7
General Trees and Binary Trees

• In a binary tree, each node has at most two
  children
• The left child and the right child

8
Recursive Definitions of Trees

• A general tree is either empty or consists of a
  finite set of nodes T
• Node r is called the root
• The set T r is partitioned into disjoint
  subsets, each of which is a general tree
• A binary tree is either empty or consists of a
  root plus a left subtree and a right subtree,
  each of which are binary trees

9
Why Use a Tree?

• A parse tree describes the syntactic structure of
  a particular sentence in terms of its component
  parts

10
Why Use a Tree? (continued)

• File system structures are also tree-like

11
Why Use a Tree? (continued)

• Sorted collections can also be represented as
  tree-like structures
• Called a binary search tree, or BST for short
• Can support logarithmic searches and insertions

12
The Shape of Binary Trees

• The shape of a binary tree can be described more
  formally by specifying the relationship between
  its height and the number of nodes contained in
  it

13
The Shape of Binary Trees (continued)

• The number of nodes, N, contained in a full
  binary tree of height H is 2H 1 1
• The height, H, of a full binary tree with N nodes
  is log2(N 1) 1
• The maximum amount of work that it takes to
  access a given node in a full binary tree is
  O(log N)

14
The Shape of Binary Trees (continued)
15
Three Common Applications of Binary Trees

• In this section, we introduce three special uses
  of binary trees that impose an ordering on their
  data
• Heaps
• Binary search trees
• Expression trees

16
Heaps

• In a min-heap each node is to both of its
  children
• A max-heap places larger nodes nearer to the root
• Heap property Constraint on the order of nodes
• Heap sort builds a heap from data and repeatedly
  removes the root item and adds it to the end of a
  list
• Heaps are also used to implement priority queues

17
Binary Search Trees

• A BST imposes a sorted ordering on its nodes
• Nodes in left subtree of a node are lt node
• Nodes in right subtree of a node are gt node
• When shape approaches that of a perfectly
  balanced binary tree, searches and insertions are
  O(log n) in the worst case
• Not all BSTs are perfectly balanced
• In worst case, they become linear and support
  linear searches

18
Binary Search Trees (continued)
19
Binary Search Trees (continued)
20
Expression Trees

• Another way to process expressions is to build a
  parse tree during parsing
• Expression tree
• An expression tree is never empty
• An interior node represents a compound
  expression, consisting of an operator and its
  operands
• Each leaf node represents a numeric operand
• Operands of higher precedence usually appear near
  bottom of tree, unless overridden in source
  expression by parentheses

21
Expression Trees (continued)
22
Binary Tree Traversals

• Four standard types of traversals for binary
  trees
• Preorder traversal Visits root node, and then
  traverses left subtree and right subtree in
  similar way
• Inorder traversal Traverses left subtree, visits
  root node, and traverses right subtree
• Appropriate for visiting items in a BST in sorted
  order
• Postorder traversal Traverses left subtree,
  traverses right subtree, and visits root node
• Level order traversal Beginning with level 0,
  visits the nodes at each level in left-to-right
  order

23
Binary Tree Traversals (continued)
24
Binary Tree Traversals (continued)
25
Binary Tree Traversals (continued)
26
Binary Tree Traversals (continued)
27
A Binary Tree ADT

• Provides many common operations required for
  building more specialized types of trees
• Should support basic operations for creating
  trees, determining if a tree is empty, and
  traversing a tree
• Remaining operations focus on accessing,
  replacing, or removing the component parts of a
  nonempty binary treeits root, left subtree, and
  right subtree

28
The Interface for a Binary Tree ADT
29
The Interface for a Binary Tree ADT (continued)
30
Processing a Binary Tree

• Many algorithms for processing binary trees
  follow the trees recursive structure
• Programmers are occasionally interested in the
  frontier, or set of leaf nodes, of a tree
• Example Frontier of parse tree for English
  sentence shown earlier contains the words in the
  sentence

31
Processing a Binary Tree (continued)

• frontier expects a binary tree and returns a list
• Two base cases
• Tree is empty ? return an empty list
• Tree is a leaf node ? return a list containing
  root item

32
Implementing a Binary Tree
33
Implementing a Binary Tree (continued)
34
Implementing a Binary Tree (continued)
35
The String Representation of a Tree

• __str__ can be implemented with any of the
  traversals

36
Developing a Binary Search Tree

• A BST imposes a special ordering on the nodes in
  a binary tree, so as to support logarithmic
  searches and insertions
• In this section, we use the binary tree ADT to
  develop a binary search tree, and assess its
  performance

37
The Binary Search Tree Interface

• The interface for a BST should include a
  constructor and basic methods to test a tree for
  emptiness, determine the number of items, add an
  item, remove an item, and search for an item
• Another useful method is __iter__, which allows
  users to traverse the items in BST with a for
  loop

38
Data Structures for the Implementation of BST
39
Searching a Binary Search Tree

• find returns the first matching item if the
  target item is in the tree otherwise, it returns
  None
• We can use a recursive strategy

40
Inserting an Item into a Binary Search Tree

• add inserts an item in its proper place in the
  BST
• Items proper place will be in one of three
  positions
• The root node, if the tree is already empty
• A node in the current nodes left subtree, if new
  item is less than item in current node
• A node in the current nodes right subtree, if
  new item is greater than or equal to item in
  current node
• For options 2 and 3, add uses a recursive helper
  function named addHelper
• In all cases, an item is added as a leaf node

41
Removing an Item from a Binary Search Tree

• Save a reference to root node
• Locate node to be removed, its parent, and its
  parents reference to this node
• If item is not in tree, return None
• Otherwise, if node has a left and right child,
  replace nodes value with largest value in left
  subtree and delete that values node from left
  subtree
• Otherwise, set parents reference to node to
  nodes only child
• Reset root node to saved reference
• Decrement size and return item

42
Removing an Item from a Binary Search Tree
(continued)

• Fourth step is fairly complex Can be factored
  out into a helper function, which takes node to
  be deleted as a parameter (node containing item
  to be removed is referred to as the top node)
• Search top nodes left subtree for node
  containing the largest item (rightmost node of
  the subtree)
• Replace top nodes value with the item
• If top nodes left child contained the largest
  item, set top nodes left child to its left
  childs left child
• Otherwise, set parent nodes right child to that
  right childs left child

43
Complexity Analysis of Binary Search Trees

• BSTs are set up with intent of replicating O(log
  n) behavior for the binary search of a sorted
  list
• A BST can also provide fast insertions
• Optimal behavior depends on height of tree
• A perfectly balanced tree supports logarithmic
  searches
• Worst case (items are inserted in sorted order)
  trees height is linear, as is its search
  behavior
• Insertions in random order result in a tree with
  close-to-optimal search behavior

44
Case Study Parsing and Expression Trees

• Request
• Write a program that uses an expression tree to
  evaluate expressions or convert them to
  alternative forms
• Analysis
• Like the parser developed in Chapter 17, current
  program parses an input expression and prints
  syntax error messages if errors occur
• If expression is syntactically correct, program
  prints its value and its prefix, infix, and
  postfix representations

45
Case Study Parsing and Expression Trees
(continued)
46
Case Study Parsing and Expression Trees
(continued)
47
Case Study Parsing and Expression Trees
(continued)

• Design and Implementation of the Node Classes

48
Case Study Parsing and Expression Trees
(continued)
49
Case Study Parsing and Expression Trees
(continued)
50
Case Study Parsing and Expression Trees
(continued)

• Design and Implementation of the Parser Class
• Easiest to build an expression tree with a parser
  that uses a recursive descent strategy
• Borrow parser from Chapter 17 and modify it
• parse should now return an expression tree to its
  caller, which uses that tree to obtain
  information about the expression
• factor processes either a number or an expression
  nested in parentheses
• Calls expression to parse nested expressions

51
Case Study Parsing and Expression Trees
(continued)
52
Case Study Parsing and Expression Trees
(continued)
53
An Array Implementation of Binary Trees

• An array-based implementation of a binary tree is
  difficult to define and practical only in some
  cases
• For complete binary trees, there is an elegant
  and efficient array-based representation
• Elements are stored by level
• The array representation of a binary tree is
  pretty rare and is used mainly to implement a heap

54
An Array Implementation of Binary Trees
(continued)
55
An Array Implementation of Binary Trees
(continued)
56
An Array Implementation of Binary Trees
(continued)
57
Implementing Heaps
58
Implementing Heaps (continued)

• At most, log2n comparisons must be made to walk
  up the tree from the bottom, so add is O(log n)
• Method may trigger a doubling in the array size
• O(n), but amortized over all additions, it is O(1)

59
Using a Heap to Implement a Priority Queue

• In Ch15, we implemented a priority queue with a
  sorted linked list alternatively, we can use a
  heap

60
Summary

• Trees are hierarchical collections
• The topmost node in a tree is called its root
• In a general tree, each node below the root has
  at most one parent node, and zero child nodes
• Nodes without children are called leaves
• Nodes that have children are called interior
  nodes
• The root of a tree is at level 0
• In a binary tree, nodes have at most two children
• A complete binary tree fills each level of nodes
  before moving to next level a full binary tree
  includes all the possible nodes at each level

61
Summary (continued)

• Four standard types of tree traversals Preorder,
  inorder, postorder, and level order
• Expression tree Type of binary tree in which the
  interior nodes contain operators and the
  successor nodes contain their operands
• Binary search tree Nonempty left subtree has
  data lt datum in its parent node and a nonempty
  right subtree has data gt datum in its parent node
• Logarithmic searches/insertions if close to
  complete
• Heap Binary tree in which smaller data items are
  located near root
