IT Briefing

1
IT Briefing

• August 2006

2
IT Briefing Agenda 8/17/06

• Organization tweaks
• EOL Demo
• Symantec Reporting demo
• VPN Update
• Email IdM
• NetCom QA

• Karen Jenkins
• John Maxwell
• Daniel Palmer
• Jay Flanagan
• John Ellis
• Paul Petersen

3
Organization Tweaks

• Windows, Unix teams moved from OIS to CTS
• ERP systems moved from ADS to CTS
• Improve efficiencies and planning
• OIS focus on major data center initiatives
• Steve Siegelman Interim IT Technical Lead for the
  Systems group (Windows, Unix, and ERP

4
Organizational Tweaks (cont.)

• Jay Flanagan responsible for the Security, Email,
  and IdM teams
• Linda Erhard, IT Governance Liaison, moved from
  CTS to directly reporting to Rich Mendola
• OIS special projects position expanded to also
  support CTS
• AAIT will continue to adjust as/if needed to
  address strategic initatives

5

• John Maxwell

6
Key changes to Emory Online

• Standalone software installers no longer included
  on Emory Online
• Includes Emory Unplugged configuration tools and
  documentation
• Better integration with Residential Network
  Registration
• Internet shortcuts provide tie-ins for spreading
  the word about campus IT services.

7
Emory Online Fall 2006 Process

1. Welcome
2. Security Scan
3. Configure Wireless
4. Get Connected!

8
Process Breakdown Windows

• Security Scan
• InstallScript application that secures, scans,
  and patches a users Windows installation
• Configure Wireless
• AutoIt script configures users wireless
  connection for Emory Unplugged
• Emory Unplugged PDF for Windows XP
• Get Connected!
• Sets IE homepage to IT orientation site and
  places a internet shortcut (.url) on their
  desktop
• AutoIt script that tests for a 10.140 connection
  and launches CAT executable

9
Process Breakdown MacOS X

• Security Scan
• Advises user to use Software Update early and
  often and to download NAV for Mac from Software
  Express
• Configure Wireless
• AppleScript application configures local AirPort
  connection for Emory Unplugged
• Emory Unplugged PDF for OS X
• Get Connected!
• Sets Safari homepage to IT orientation site and
  places an internet shortcut (.url) on their
  desktop
• Opens Safari to http//netreg.service.emory.edu/
  for network registration

10
Security Scan

1. Enables Windows XP firewall
2. Enables Automatic Updates
3. Installs and runs CCleaner
4. Runs McAfee Stinger
5. Installs Symantec AntiVirus
6. Installs and runs SpybotSD
7. Installs Service Pack (if Emory-owned)
8. Installs Critical Updates (if Emory-owned)
9. Instructs user to set passwords on all Windows
   accounts.

11
Emory Online Fall 2006

• Demonstrate new features

12
Emory OnLine
13
Special Thanks to

• All the testers
• Lee Clontz
• Donna Price

14
Feedback Questions to

• john.maxwell_at_emory.edu

15
Symantec AV Reporting _at_ Emory

• Daniel Palmer

16
Symantec AV Reporting

• Glimpse of current AV _at_ Emory
• 1 Managed Campus server (Wolf)
• Several Departmental Servers
• (AAIT, Emory College, Law School, etc)
• 1 Reporting Server (sesa)
• AV client count varies based on the dept
• Wolf - 9900 clients
• AAIT - 250 clients

17
Symantec AV Reporting

• Good Info but got anything useful?
• How about..
• On Wolf in the past 24 hours ..
• 6001 of 9904 clients have checked in
• 2947 clients with 10.1.0.401
• 263 clients with 10.0.2.2001 are infected
• 23 clients checked in with Auto Protect
  disabled
• How about..
• PC named pickle (mub is the user) hasnt
  checked in since
• 07/20/2006 175447
• Def Date 7/19/06 Rev 24
• AV Version - 10.0.2.2001

18
Symantec AV Reporting

• Symantect AV Reporting Server
• 1 Reporting Server running IIS and MSSQL Server
• Pros
• Web Interface
• Very Simple Dashboard
• Lots of canned reports
• Cons
• Some functions need Internet Explorer
• Does NOT authenticate to LDAP

19
Symantec AV Reporting
20
Symantec AV Reporting

• Wanna Join?
• Requirements-
• Must have some delimiting criteria
• i.e. Managed Server
• Single naming convention (PSFT)
• Single IP subnet (170.140.187.x)
• Let us know if you are interested in using the
• Symantec AV Reporting Server
• Send an email to ci-desktop_at_listserv.cc.emory.edu

21
Symantec AV Reporting
22
F5 VPN Update

• Jay D. Flanagan
• Andy Efting

23
Background

• Replacement for SecuRemote
• Usage http//vpn.emory.edu
• Documentation available online at
• it.emory.edu/showdoc.cfm?docid6389

24
Future

• Proposed replacement for vpn.service.emory.edu
• Targeting January 1, 2007 for decommissioning
• GINA

25
GINA

• Requires simple client install
• Creates VPN tunnel during logon
• Passes authentication credentials as if sitting
  on the network

26
(No Transcript)
27
(No Transcript)
28
(No Transcript)
29
(No Transcript)
30
Upgrade

• Firepass 5.5 to version 6.0
• Friday morning (Aug. 18), 630 AM
• Provide GINA functionality for production

31
Summary

• Successful transition to F5 for Admin Core users
• Planned transition to F5 to replace
  vpn.service.emory.edu
• Planned upgrade to provide GINA support

32
VPN / GINA
33
Email and IdM Updates

• John Ellis

34
Emory Backbone Upgrade Status and Timeline

• Paul Petersen

35
Agenda

• New Core Status
• New Firewall Status
• Working Timeline

36
New Core

• New Core Status
• All Routers installed
• Router code issues resolved
• Cautiously moving LANs
• 8/14 - Anatomy Basement
• 8/15 - The Depot
• 8/16 - Facilities Management
• 8/17 - Schwartz Performing Arts Center
• 8/18 - Cox Hall

37
New Firewall

• New Firewall Status
• The New Firewalls are installed
• The Management System is installed
• Each Virtual Firewall Context has been built
• Migration will start after border network is
  formed

38
Working Timeline
Date Task
09/15 Continue to migrate targeted LANs to the new core
09/18 Post new comprehensive upgrade schedule on the web
09/29 Border Network Consolidated
09/29 Internet2 Uplink upgraded to 10 Gigabit
09/29 Academic Border Firewall migration to new firewalls
39
Working Timeline
Date Task
10/10 ResNet Firewall and LANs migrated to new hardware
10/20 Secure Admin and DMZ firewalls migrated to new core
11/03 Healthcare firewalls migrated to new core
01/16 Academic, Secure Academic, and DMZ migrated to new core
01/31 Healthcare LANs migrated to new core
40
NetCom
