Examples of One-Dimensional Systolic Arrays

1
Examples of One-Dimensional Systolic Arrays
2
Motivation Introduction

• We need a high-performance , special-purpose
  computer
• system to meet specific application.
• I/O and computation imbalance is a notable
  problem.
• The concept of Systolic architecture can map
  high-level
• computation into hardware structures.
• Systolic system works like an automobile
  assembly line.
• Systolic system is easy to implement because of
  its
• regularity and easy to reconfigure.
• Systolic architecture can result in
  cost-effective , high-
• performance special-purpose systems for a wide
  range
• of problems.

3
Pipelined Computations
4
Pipelined Computations

• Pipelined program divided into a series of tasks
  that have to be completed one after the other.
• Each task executed by a separate pipeline stage
• Data streamed from stage to stage to form
  computation

5
Pipelined Computations

• Computation consists of data streaming through
  pipeline stages
• Execution Time Time to fill pipeline (P-1)
  Time to run in steady state (N-P1)
• Time to empty pipeline (P-1)

P of processors N of data items (assume P
lt N)
This slide must be explained in all detail. It is
very important
6
Pipelined Example Sieve of Eratosthenes

• Goal is to take a list of integers greater than 1
  and produce a list of primes
• E.g. For input 2 3 4 5 6 7 8 9 10, output is
  2 3 5 7
• A pipelined approach
• Processor P_i divides each input by the i-th
  prime
• If the input is divisible (and not equal to the
  divisor), it is marked (with a negative sign) and
  forwarded
• If the input is not divisible, it is forwarded
• Last processor only forwards unmarked (positive)
  data primes

7
Sieve of Eratosthenes Pseudo-Code

• Code for last processor
• xrecv(data,P_(i-1))
• If xgt0 then send(x,OUTPUT)

• Code for processor Pi (and prime p_i)
• xrecv(data,P_(i-1))
• If (xgt0) then
• If (p_i divides x and p_i x ) then
  send(-x,P_(i1)
• If (p_i does not divide x or p_i x) then
  send(x, P_(i1))
• Else
• Send(x,P_(i1))

/
Processor P_i divides each input by the i-th prime
8
Programming Issues

• Algorithm will take NP-1 to run where N is the
  number of data items and P is the number of
  processors.
• Can also consider just the odd bnys or do some
  initial part separately
• In given implementation, number of processors
  must store all primes which will appear in
  sequence
• Not a scalable approach
• Can fix this by having each processor do the job
  of multiple primes, i.e. mapping logical
  processors in the pipeline to each physical
  processor
• What is the impact of this on performance?

processor does the job of three primes
9
Processors for such operation

• In pipelined algorithm, flow of data moves
  through processors in lockstep.
• The design attempts to balance the work so that
  there is no bottleneck at any processor
• In mid-80s, processors were developed to support
  in hardware this kind of parallel pipelined
  computation
• Two commercial products from Intel
• Warp (1D array)
• iWarp (components for 2D array)
• Warp and iWarp were meant to operate
  synchronously Wavefront Array Processor (S.Y.
  Kung) was meant to operate asynchronously,
• i.e. arrival of data would signal that it was
  time to execute

10
Systolic Arrays
11
Example 1 pipelined polynomial evaluation
12
Example 1 pipelined polynomial evaluation

• Polynomial Evaluation is done by using a Linear
  array with 2D.

• Expression

• Y ((((anxan-1)xan-2)xan-3)xa1)x a0
• Function of PEs in pairs

• 1. Multiply input by x

• 2. Pass result to right.

• 3. Add aj to result from left.

• 4. Pass result to right.

13
Example 1 polynomial evaluation
Y ((((anxan-1)xan-2)xan-3)xa1)x a0
Multiplying processor
X is broadcasted
Adding processor

• Using systolic array for polynomial evaluation.
• This pipelined array can produce a polynomial on
  new X value on every cycle - after 2n stages.
• Another variant you can also calculate various
  polynomials on the same X.
• This is an example of a deeply pipelined
  computation-
• The pipeline has 2n stages.

x
an-1
an-2
an
x
a0
x
x
.
X


X

X
X

14
For you to think about

1. Pipelined Graph Coloring
2. Pipelined Satisfiability
3. Pipelined sorting/absorbing
4. Pipelined decision function like Petrick
   Function.
5. Pipelined multiplication.
6. Pipelined calculation of (A B) (C D) on
   vectors A, B, C, D.

15
Example 2Matrix Vector Multiplication
16
Example 2Matrix Vector Multiplication

• There are many ways to solve a matrix problems
  using systolic arrays, some of the methods are

• Triangular Array performing gaussian elimination
  with neighbor pivoting.

• Triangular Array performing orthogonal
  triangularization.
• Simple matrix multiplication methods are shown in
  next slides.

17
Example 2Matrix Vector Multiplication

• Matrix Vector Multiplication

• Each cells function is

• 1. To multiply the top and bottom inputs.

• 2. Add the left input to the product just
  obtained.
• 3. Output the final result to the right.
• Each cell consists of an adder and a few
  registers. (Booth Algorithm for mul).
• Or, a cell can include a hardware multiplier.

18
Matrix Multiplication
Example 2Matrix Vector Multiplication

• At time t0 the array receives 1, a, p, q, and r
  ( The other inputs are all zero).

• At time t1, the array receive m, d, b, p, q, and
  r .e.t.c
• The results emerge after 5 steps.

19

• Explain how to multiply the first row of the
  matrix by the vector,
• how data are shifted from left to right in the
  architecture

To visualize how it works it is good to do a
snapshot animation
20
Systolic Algorithms and Architectures
21
Systolic Algorithms

• Systolic arrays were built to support systolic
  algorithms, a hot area of research in the early
  80s
• Systolic algorithms used pipelining through
  various kinds of arrays to accomplish
  computational goals
• Some of the data streaming and applications were
  very creative and quite complex
• CMU a hotbed of systolic algorithm and array
  research (especially H.T. Kung and his group)

22
Systolic Arrays from Intel

• Warp and iWarp were examples of systolic arrays
• Systolic means regular and rhythmic,
• data was supposed to move through pipelined
  computational units in a regular and rhythmic
  fashion
• Systolic arrays meant to be special-purpose
  processors or co-processors.
• They were very fine-grained
• Processors implement a limited and very simple
  computation, usually called cells
• Communication is very fast, granularity meant to
  be around one operation/communication!

23
Systolic Processors, versus Cellular Automata
versus Regular Networks of Automata
Data Path Block
Data Path Block
Data Path Block
Data Path Block
Systolic processor
Control Block
Control Block
Control Block
Control Block
Cellular Automaton
These slides are for one-dimensional only
24
Systolic Processors, versus Cellular Automata
versus Regular Networks of Automata
Control Block
Control Block
Control Block
Control Block
Data Path Block
Data Path Block
Data Path Block
Data Path Block
Regular Network of Automata
