Randall von Wedel, Ph'D'

1

• Randall von Wedel, Ph.D.
• BioSolar /CytoCulture International Inc.
• Rvwedel_at_gmail.com
• CalACT Monterey, CA November 6, 2008

2
Biodiesel benefitsgoing green

• A diesel displacement fuel made from plant oils,
  animal fats or recycled cooking oils through a
  chemical process to remove glycerin and yield
  methyl esters optimized for combustion in modern
  diesel engines e.g., common rail
• Renewable, agriculturally produced replacement
  fuel to displace imported petroleum with local
  domestic biofuel
• Biodiesel itself is non-toxic, non-flammable and
  non-volatile, making it safe to handle store as
  B99/B100
• Biodiesel contains very low sulfur and no
  aromatics
• In US, often blended by big fleets to 20 (B20)
  to achieve significant reductions in PM and
  criteria air emissions
• 17 GHG reduction in CO2 emissions by life cycle
  analysis
• EPACT credits for city-county fleets compliance
  with RFS

3
Other incentives to use Biodiesel

• Public support of reduced exhaust smoke and odors
  in blends of 20 or higher
• Proactive move to reduce GHGs and climate change
• Offset carbon footprint of electric power
  generation
• Flexible fuel for fleets in blends Easily
  reversible
• Relatively low cost (similar to ULSD), no capital
  investments in infrastructure as drop in fuel
• Obvious solution for older diesel engines that
  may not be amenable to modern after-treatment
  retrofits
• Lower impact of accidental spills or leaks

4
Challenges for Biodiesel Today

• Availability to small rural transit fleets in
  remote areas
• Education of local transit agencies and
  distributors
• Perception issues regarding warranties and
  operations
• Pricing of biodiesel in more remote areas
• Biodiesel fuel quality issues when improperly
  stored
• Feedstock (raw material) availability keeping up
  with demand for biodiesel across the
  statedisplacing soy biodiesel with locally
  produced, sustainable biodiesel made from
  recycled oil, animal fats and new oil crops

5
Biodiesel Bus Chassis Dynamometer Testing

• B20 vs. conventional diesel fuel
• 2 in-use buses tested (40,000 lb GVWR)
• City Suburban Heavy Vehicle Cycle (CSHVC) at
  35,000 lb inertia
• Cummins ISM 2000 Engine No EGR
• Fuel economy reduction ? 3
• Emission reductions (g/mile basis)
• PM ? 18
• HC ? 29
• CO ? 24
• NOx ? 4
• statistical confidence gt 99
• Data from Dr. Robert McCormick, NREL

6
ENGINE C
ENGINE B
ENGINE A
7
(No Transcript)
8
Particulate Traps and Oxidative Catalysts

• After treatment reduces PM, CO and HC by 50-90
• Retrofitted to most diesel buses, but not to
  2-stroke and some older engines (or use high
  blend biodiesel)
• Biodiesel is compatible with most devices CARB
  certified traps/filters now operating in CA for
  B20
• Excellent B20 results in SF vehicles equipped
  with the Clearaire Longview PM / NOx reduction
  system
• B20 increases PM reduction by 62 in oxidative
  catalysts (NREL study 2005) so improved
  performance
• B20 extends longevity of traps, lower maintenance

9
Using Biodiesel Lowers Greenhouse Gas Emissions
and Carbon Footprint of Fleet Vehicles

• Closed Carbon Cycle CO2 of engine emission can
  be taken up by oil crops in the following season
• 78 life cycle reduction in CO2 from crop to
  tailpipe Midwest B100 translates to about 12-15
  GHG reduction for B20 in California, FL
• Energy Balance 3.5 to 1 for soy, 4.6 1 for
  animal fats, 71 for recycled cooking oil
• Besides reducing idling, retiring old trucks,
  improving engine efficiencies, fleet have few
  options to reduce GHGs

10
San Francisco MUNI B20 Buses

• 520 buses in the City consume 6.2 m gallons
  B20/yr, or about 1.25 m gallons of B100 per year
  (1 rail car per wk)
• 86 of those buses are new true hybrid diesel
  electric
• Most of the regular buses equipped with LongView
  NOx / PM reduction after treatment B20 works
  fine
• Program initiated as 6 month pilot study per
  Mayors Executive order in 2006 full compliance
  all B20 now for over a year without ANY vehicle
  problems
• Lessons learned B20 works, but important to have
  good fuel quality clean tanks before
  implementation

11
Basic Biodiesel Reaction
Liquid Catalyst 1 kg (Na or K Hydroxide)
Combining
Yields

• Degummed vegetable oil, used cooking oil or
  animal fat
• (100 kg)
• Methanol
• (12 kg)

Biodiesel (95 kg) Glycerin (11 kg)
12
Transesterification Reaction (basic)

• H O
• ? ??
• H - C - O - C - CH2 CH2 CH2 CH2 CH2 CH2
  CH2 CH2 CH2 CH2 CH2 CH2 CH2 CH2 CH3
• ?
• ? O
• ? ??
• H - C - O - C - (CH2)7 -CH CH(CH2)7
  CH3 3 H3 - C -OH ---------------?
• ?
  -OH
• ? O Methanol
  Catalyst
• ? ??
• H - C - O - C - (CH2)7 -CH CHCH2 CH
  CH(CH2)4 CH3
• ?
• H
• Vegetable Oil or Animal Fat Triglyceride
• 80 US Biodiesel today is still made from Soybean
  oil, balance is animal fat, canola, cooking
  oil
•


13
Transesterification reaction releases methyl
esters from glycerin

• H O
• ? ??
• H - C - OH CH3 - O - C - (CH2)16 CH3
• ?
• ? Methyl Stearate (saturated ester)
• ? O
• ? ??
• H - C - OH CH3 - O - C - (CH2)7 -CH
  CH(CH2)7 CH3
• ?
• ? Methyl Oleate
  (mono-unsaturated ester)
• ? O
• ? ??
• H - C - OH CH3
  - O - C - (CH2)7 -CH CHCH2 CH CH(CH2)4 CH3
• ?
• H Methyl Linoleate (di-unsaturated
  ester)
•
• Glycerin
• Range of Biodiesel Methyl Esters
•

Process Control and Batch Testing is Essential
14
Mono di glycerides result from incomplete
transesterification

• H O
• ? ??
• H - C - O - C - CH2 CH2 CH2 CH2 CHCH CH2
  CH2 CH2 CH2 CH CH CH2 CH2 CH2 CH2 CH3
• ?
• ?
• ?
• H - C - O - H
• ?
• ?
• ?
• H - C - O - H
• ?
• H Monoglyceride (Linoleic
  182)

Free fatty acids in oxidized feedstock oil
contribute to incomplete conversion of oil to
esters
15
Free fatty acids and polymers result from
oxidation cross linking of unsaturated chains

• O
• ??
• - O - C - CH2 CH2 CH2 CH2 CHCH CH2 CH2
  CH2 CH2 CH CH CH2 CH2 CH2 CH2 CH3
• O
  O
  O
• ??
  / \ /
  \
• - O - C - CH2 CH2 CH2 CH2 CH -- CH C H2
  CH2 CH2 CH2 CH --CH CH2 CH2 CH2 CH2 CH3
• Hydroperoxides form by oxidation
  of double bonds
• Breakdown to smaller fatty acids or cross-link to
  form polymers
• Higher free fatty acids (rancid oil) means lower
  quality biodiesel

16
Important Biodiesel Parameters

• Complete conversion avoid partially reacted
  fuel!
• High oxidation stability avoid unwanted
  reactions
• Removal of glycerin residues accumulate in
  engine
• Removal of catalyst destroys gaskets and seals
• Removal of residual carbon polymers from
  oxidation
• Keep low acid number avoid oxidized fuel
• New pending assay to test for potential
  precipitations
• Insured through ASTM D 6751 specs

17
ASTM D 6751 2008 Feedstock Neutral

• Property Test Method Limits Units
• Calcium Magnesium EN 14538 5
  max ppm (ug/g)
• Flash Point D 93 130 min.
  degrees C
• Water Sediment D 2709 (4176)
  0.05 max. volume
• Kin. Viscosity, 40C D 445
  1.9 - 6.0 mm²/sec.
• Sulfated Ash D 874
  0.02 max. mass
• Sulfur S15 D 5453 0.0015
  max (15) mass (ppm)
• Copper Corrosion D 130 No. 3
  max.
• Cetane number D 613 47 min.
• Cloud Point D 2500
  Report degrees C
• Carbon Residue D 4530 0.05
  max. mass
• Acid Number D 664 0.50 max.
  mg KOH/g
• Free Glycerin D 6854 0.020
  mass
• Total Glycerin D 6854 0.240
  mass
• Phosphorous content D 4951 0.001
  max mass
• Distillation, T90 AET D 1160 360 max
  degrees C
• Na/K, combined EN 14538
  5 max ppm (ug/g)
• Oxidation Stability EN 14112
  3 min hours

18
(No Transcript)
19
ASTM D6751 Highlights for QA protocol

• Total glycerin test for incomplete conversion
• (mono, di and triglcyeride residues in fuel)
• Oxidation stability oxidation intermediates
• Acid number fatty acids from oxidation
• Carbon residues polymers from oxidized chains
• ASTM and EU specs are likely to tighten for
• P, Na, K, Ca, Mg oxidation stability
• NEW cold soak filter assay CSFA pending ASTM
  approval as operational test for precipitations
• Recommend also monitoring KF Moisture

20
Fuel Quality Control A Mindset at 3 Levels from
Plant to Fleet

• Production at the plant feedstock to fuel
• BQ 9000 or other rigorous QA program
• ASTM 6751 specs and certification
• Distribution, storage, blending and handling
• BQ 9000 or other rigorous QA program
• Protocols, documentation, monitoring
• Consumer storage, dispensing use
• Protocols, documentation, monitoring

21
Biodiesel Fuel SpecificationsIts all about
Quality Control

• Most or all problems associated with biodiesel
  use are due to fuel quality issues, not to the
  biodiesel per se
• Quality control problems largely a result of a
  rapidly growing industry, inexperience and lack
  of diligence.
• The problems are NOT caused by inadequate
  specifications or the lack of proper protocols,
  from the plant to the distributor to the user
• Fleet managers can set up their own Quality
  Assurance programs and set requirements for their
  fuel vendors to do the samefrom driver training
  to fuel testing

22
Common Problems with Biodiesel in Transit
Storage

• Biodiesel and blends suffer from condensation
  water and contamination from fuel deliveries
• Bacterial growth (not algae) in water layer
  will deteriorate the fuel, generate acids and
  precipitations
• Acids caused by bacterial biodegradation of fuel
  (short free fatty acids) can damage engine
  components
• Anaerobic conditions in damp tanks promote
  sulfate reduction forming traces of corrosive
  sulfuric acid
• Older tanks or tanks accidentally contaminated
  with infected, deteriorated diesel fuel can
  infect biodiesel

23
www.biodiesel.org
24
Fuel Problems Associated with Increasingly Out
of Spec Biodiesel

• Residues in storage tanks, filters and lines
• Clogged filters can stop vehicles on road
• Dissolved contaminants foul injectors
• Coking of injectors and varnish on valves
• Rough engine operation, smoke, wear
• Catalyst, methanol ruin fuel injection pump
• Crankcase oil deterioration, polymerization
• Long term or catastrophic engine damage

25
Some problems get caught

• Sediments, bacterial slime,
• precipitates and free water
• can be trapped by filters
• along with any insoluble
• impurities associated with
• the fuel
• Butdissolved contaminants
• acids that can damage engines
• pass through the filters

26
Field Test Kit Developed for checking Biodiesel
B100 Quality pHLip Test

• A Quick Check in the field for detecting traces
  of catalyst, mono/di/triglycerides, soaps, acids
  and oxidized (aged) fuel hydroxyesters,
  peroxides
• 10 min test Simply add B100 to test vial, mix by
  flipping let the fuel float to create two
  phases
• Visual indication only but quantitative
  capability
• Unrelated to ASTM yet surprisingly sensitive for
  dissolved contaminants Now a QC protocol test
• Intended to alert a consumer or operator as a
  firewall, then they can request a formal lab
  test

27
pHLip Test Kit Concepts

• Extraction of catalyst or acid from fuel to
  aqueous pH indicator elicits color change from
  neutral red color
• Soluble contaminants in biodiesel can be
• gtExtracted into the aqueous phase
• (fatty acid soaps) as visible
  turbidity
• gtConcentrated at water-fuel interface
• (glycerides, sterols, oxidized esters)
  Lens Effect Signal Amplification
• gtHydrated in the fuel as visible turbidity
• (mono, di triglycerides fatty acids,
  oxidized)
• Endorsed and distributed by the National
  Biodiesel Board

28
Detection of catalyst contamination from poorly
washed biodiesel fuels
Clear Bright Reference Fuel
Contaminated Biodiesel samples become turbid
? Mirror Finish
Alkaline pH creates purple color soaps cause
turbidity
Neutral pH Indicator
www.allthingsbiodiesel.com
29
Aging Oxidized B100 ExamplesRelative to Fresh
Bright Reference Fuel
Fresh
Bright
Haze
Smoke
Mirror
?Residues
Neutral pH
Acidic
30
Detecting near-spec and off-spec fueltop vs.
bottom of rail car tank of B100
Bright Bright B100 reference
Top Sample
Bottom Sample
? Mirror reflection
? Glycerides

• ? Glycerides

0.76 Monoglycerides, 0.38 Diglycerides, 0.62
Triglycerides 0.31 Total Glycerin in composite
of Top and Bottom samples
31
Monitoring Biodiesel Quality for Fleet Deliveries
by Truck/Rail to FL Bus Fleet
Bus Fleet Managers Testing B99 on delivery
32
Biodiesel Quality Status Report (BQSR)
Typical B100 imported to CA now, similar to NREL
2007 Survey average
33
Out-of-spec, incompletely reacted B100
Turbid fuel layer
Top
Middle
Bottom
Note clear and bright B100 samples vs. Turbid
fuel layer in pHLip Tests
34
Oxidized (ruined) ASTM spec B100
35
Biodiesel Quality Status Report 2008
Excellent quality biodiesel by rail 85 Soy /
15 animal fat B100
36
Debunking myths about biodiesel

• Engine conversion needed. No, its a drop in
  fuel blended with ULSD. Most big fleets use B20
  blend
• Biodiesel raises NOx emissions No, B20 blends
  proved to be NOx Neutral on emissions per 2007
  NREL study
• Only pure soy biodiesel is really good quality.
  No, many feedstock result in excellent biodiesel,
  including animal fat, recycled cooking oil
  palm. Process is what varies competence/diligenc
  e in quality control
• Cold flow Biodiesel gels. Not a problem for B20
  made from most feedstock, specify pour
  point/cloud point
• Biodiesel causes increase in food prices. No,
  most grains are not feedstock. Focus on
  industrial crop oils.

37
Research on US feedstock options

• Animal fat methyl ester blended into soy
  biodiesel
• Chicken fat, beef tallow, high grade pork fat
• Recycled cooking oil biodiesel all around the
  country
• Trap grease / brown grease pilot studies in CA,
  PA
• Canola and Winter Rapeseed in Northwest
• Mustard, Canola Camelina in Western states
• Cotton seed oil in Texas and Southwest
• Safflower, Sunflower and high oil Mustard in CA
• Sunflower and Jatropha in Florida (test plots)
• Imports Palm oil biodiesel (mostly for cruise
  ships)

38
Sustainability now a B100 spec Examples of
evolving GHG policies

• Utility fleets developing Corporate Biofuel
  Policies on both coasts already implemented at
  FPL and enforced
• Dupont set precedent in formalizing Sustainable
  Best Practices as high level management corporate
  policy
• New CA Renewable Fuel Standard will set specific
  criteria for sustainable biofuels, land use
  changes, etc.
• US/EU biofuel policies include mandatory 35 net
  reduction in green house gases (GHG) for biofuels
• Tesco in UK (supermarket chain throughout UK, EU)
  had a PR setback when GreenPeace revealed B50
  fleet was using imported Indonesian palm oil
  biodiesel

39
Food (feed) vs. biofuel debate

• On going arguments stemming from papers early
  2008 pointing out land use changes, net energy
  GHG emission reductions good bad cultivation
  practices
• Right now, 16 of total soybean oil in US (2.2 b
  lbs) is used to produce biodiesel, about 10 is
  exported as oil
• Soybean is grown primarily as high protein animal
  feed, same as corn or other feed grains
• 2 lbs grain/lb chicken 4 lbs grain/lb pork, 6
  lbs/lb beef
• Oil is a co-product of soybean meal production
  for feed
• Biofuels accounted for nearly half the world
  demand increase, but only 7 of total vegetable
  oil consumed, while a cut back in subsidies
  reduced oil production

40
Food (feed) price increases

• Primary driver for increased food and grain
  prices is rising demand for meat, particularly
  China, India, Asia
• Wheat consumption exceeded production in 7 of 8
  yrs
• Droughts and dropping water tables sharply cut
  back grain production in China, Australia, and
  Northwest
• Price of petroleum fuel pushed up costs of
  transport, fertilizers, herbicides, insecticides
  and processing
• Aggressive commodity markets domestic hoarding
  contributed to sharp spikes in rice, wheat and
  grains
• For yellow corn, the net gain in US production
  acreage cant meet the demand world wide for
  animal feed

41
Straining world fuel, food and water

• Population increases have been anticipated.China
  India represent over a third of the world
  inhabitants
• Migration from rural areas to crowded cities 44
  now but expecting 66 by 2030 resource
  intensive shift
• Surge in middle classand their meat consumption,
  with 3 x increase in meat eaten in China since
  1983
• India lagging, but expected to follow China, with
  huge spikes in demand for food, fuel and
  commodities
• Will create 10 New York cities in the next 10
  years, with 30,000 new skyscrapers in China alone
• Water tables are dropping, global warming
  reducing yields and climate changes affecting
  crops world wide

42
Biofuel vs. food debate Pendulum swinging back
to center

• Biofuels, like other products, can be produced
  the right way vs. the wrong way, or compare to
  petroleum
• Per Merril Lynch analysis, without biofuel
  programs, price of oil would be 13/BBL higher
  than it is now, so biofuels are saving 65
  billion in foreign oil payments
• EU US Ag Commissions recently reaffirmed
  positive impacts GHG reduction benefits of
  biofuel policies
• Shift to less polluting, more efficient modes of
  transport
• Promote CO2 reduction policies and encourage
  biofuels
• Biofuel are most immediately feasible way to
  lower CO2

43
Biodiesel feedstock evolution diversified fuel
sources

• Early development, then commercialization in
  US/EU
• Soybean (US), Rapeseed (EU) recycled cooking
  oil
• Recent trends in US (2007 -2008)
• Transition from pure soy blends with animal fat
  FAME
• Regional plants using local feedstock Chicken
  fat, beef tallow, pork fat, and recycled cooking
  oil (CA)
• Next 3-5 years More local feedstock, recycled
  oils, trap grease and imported palm oil (summer),
  Jatropha oil
• Locally grown crop oils Sunflower, Canola,
  Safflower
• Imported tropical oils Palm (current) then
  Jatropha

44
Tropical crop oils are promising feedstock for
biodieseland fleets

• Most new crop oils should make high spec
  biodiesel provided the oil is in good condition
  properly degummed, low in oxidation low in free
  fatty acids
• Oxidation issues require special precautions
• Cold flow properties are encouraging for Jatropha
  but not for palm or coconut blends of the two
  are likely
• Specifications could tighten for future engines
  oxidation stability, trace ions (P, K, Na,
  Mg, Ca)
• Sustainability issues and land use changes
  critical

45
Tropical oil plantations/groves
Jatropha at FL test plot
African Red Palm, Central America
46
National Biodiesel Expo Conference San
Francisco February 1-4, 2009
www.biodiesel.org
Jatropha fruit opened 3 oil seeds with over 40
oil by weight
Jatropha fruit ripening on tree
