Knock Code Locks

1
SD Electroniks Products Catalog www.electroniks.c
om/locks
June 2006
2
1. KnocKeys
3
PK116 Package Blister Pack Content PK116BL
KnocKey Lithium Battery (inside) Color Black
KnocKey Model PK116
Size 56mm, 32mm, 19mm Material PC Plastic
injection Keypad Tactile Switches, Black Back
Light Yellow Power CR2 Lithium Battery PTT
Programmable to transmit when pressed
Application Opens all products. Light
Weight. High durability. Recommended for consumer
and commercial applications.
4
PK117 Package Blister Pack Content PK117CR
KnocKey Lithium Battery (inside) Color Chrome
KnocKey Model PK117
Size 56mm, 32mm, 19mm Material PC Plastic
injection Keypad Tactile Switches, Metallic Back
Light Blue Finish Chrome plating. Power CR2
Lithium Battery PTT Programmable to transmit
when pressed
Application Opens all products. Light
Weight. High durability. Recommended for consumer
and commercial applications.
5
KC119 Package Cart Box Content KC119 KnocKey
cover Color Blue, Orange, Red, Green
KnocKey Cover Model KC119
Size 59mm, 35mm, 22mm Material Silicon Rubber
Application Protecting cover for PK116 and PK117.
6
2. Cylinder Locks
7
KS300xx Package Cart Box. Box Size 145mm,
71mm, 55mm Content Indoor Knob Lithium
Battery Outdoor Knob Mounting Screws Allan
Key xx Finish GL Gold ST Steel
Cylinder Lock Model KS300/310
Size Triangle 45mm Knob Zamak Die Cast Power
123A Lithium Battery PC Programmable
Applications Retrofits all Cylinder Lock
applications. Installation is easy as the
installation of a standard mechanical Cylinder
Lock.
Indoor Knob
Outdoor Knob
8
KK252xx Package Cart Box. Box Size 145mm,
71mm, 55mm Content MK252 Keypad Knob Lithium
Battery xx Finish GL Gold ST Steel
Keypad Knob Model KK252
Size Triangle 45mm, 46mm Material Zamak Die
Cast Keypad Tactile Switches, Metallic Back
Light Blue Power 123A Lithium Battery
Applications Cylinder Lock Outdoor
Knob. Recommended for commercial applications
like offices, airports, hospitals, public
buildings, and for private housing (no need to
carry a KnocKey).
9
Cylinder Lock CL300 series Cylinders
Package Cart Box. Box size 133mm, 43mm,
33mm Content Cylinder Mounting Screw Finish
Satin Chrome
 Model Inside mm Outside mm
CL300E3030 30.00 30.00 Euro Profile
CL300E3535 35.00 35.00 Euro Profile
CL300E4330X 43.00 30.00 Euro Profile extendable
CL300E5330X 53.00 30.00 Euro Profile extendable

CL300S3333 33.00 33.00 Swiss Profile
CL300M4330X 43.00 30.00 Mul T Lock retrofit
CL300M5330X 53.00 30.00 Mul T Lock retrofit
Various cylinder profiles and lengths. Single
side or double side clutch.
10
3. Rim Door Locks
11
HD450 Package Cart Box. Content HD450
Lock Strike Strike Spacers Lithium
Battery Mounting Screws Finish Silver Aluminum
Door Lock Model HD450/455 (opens in)
Size 90mm, 63mm, 25.5mm Material Zamak Strike
Stainless Steel Ø15mm Finish Silver
Aluminum Power 123A Lithium Battery PC
programmable
Applications All wood or metal doors. Easy
installation, no need to drill or prepare thru
holes in the door. A knob for opening from the
inside (mechanical). Maximum security, nothing on
the outside!
12
SD460C Package Cart Box. Content SD460C
Lock Strike Inside Opening Button Lithium
Battery Mounting Screws Finish Silver Aluminum
Door Lock Model SD460C/465C (Versatile)
Size 185mm, 32mm, 30mm Material Zamak Strike
Stainless Steel 15mm Finish Silver
Aluminum Power, 123A Lithium Battery PC
programmable
Applications All types of cabinets, containers
and sliding doors. Easy installation, no need to
drill or prepare thru holes in the door. A button
for opening from the inside (mechanical). Maximum
security, nothing on the outside!
13
LM460 Package Cart Box. Content Mounting
Bracket Cover Mounting Screws Finish Aluminum
Anodized Grey cover
Mounting Bracket Model LM460
Size 189mm, 35mm, 36mm Material
Aluminum Finish Aluminum Anodized Cover Plastic
(Grey)
Applications L shape mounting bracket for
installation of the SD460 series locks on various
types of doors that open inside.
14
MK202xx Package Cart Box. Content MK202
unit Mounting Screws Allan Key Mounting Plate 1
Lithium Battery xx Finish GL Gold ST Steel
Mounted Keypad Model MK202
Size 130mm, 60mm, 23mm Material Zamak Die
Cast Back Light Blue Power 2X 123A Lithium
Batteries
Applications Door mounted (indoor only) for use
with Door locks or Drawer Locks. Recommended for
commercial applications Offices, warehouses,
airports, hospitals, public buildings, etc. (no
need to carry a KnocKey).
15
4. OEM Locks
16
CM460 Package Cart Box. Content Lock Mounting
Kit Strike Mounting Kit Mounting Screws Finish
Silver Aluminum
Container Lock Kit Model CM460
Size 200mm, 45mm, 45mm Material
Aluminum Strike Stainless Steel ?15mm Finish
Silver Aluminum
Applications Installation kit for mounting the
SD460 lock on container and truck doors. Easy
installation. A button for opening from the
inside (optional). Maximum security, nothing on
the outside!
17
RM460 Package Cart Box. Content Lock Mounting
Kit Strike Mounting Screws Finish Silver
Aluminum
Roll Up Door Kit Model RM460
Size 185mm, 57mm Material Aluminum Strike
Stainless Steel ?15mm Finish Silver Aluminum
Applications Installation kit for mounting the
SD460 lock on Roll Up doors. Easy installation. A
button for opening from the inside
(optional). Maximum security.
18
CB460 Package Cart Box. Content Bolt Mounting
Kit Mounting Screws Finish Silver Aluminum
Container Bolt Kit Model CB460
Size 82mm, 65mm, 39mm Material Aluminum Bolt
Stainless Steel Ø19mm Finish Silver Aluminum
Applications For container and truck doors. Easy
installation. Designed for mounting on top,
bottom or hinge side of the door. Maximum
security, nothing on the outside!
19
GL600 Package Cart Box. Content GL600
Lock Mounting Plate Lithium Battery
(inside) Finish Green
Protective Cover Model GL600
Cover Size Ø114mm x 66mm Material Reinforced
Plastic Finish Green Power 123A Lithium Battery
Applications Security and safety protecting
cover for valves for chemicals, gases, oil,
water, etc. Also may be used to cover operating
switches or connectors. The mounting plate is
custom designed for the specific application.
20
5. Pad Locks
21
UL500 Package Cart Box. Content UL500
Lock Lithium Battery (inside) Finish Stainless
Steel
U Shape Pad Lock Model UL500
Lock Size 90mm, 64mm, 25mm Material Stainless
Steel Shackle Case Hardened Ø14mm Finish
Polished Stainless Steel Power 123A Lithium
Battery Available end of 2006
Applications Recommended for high security
Padlock applications Stores, warehouses,
industrial and military facilities, motorcycles,
etc.
22
6. KCT Switches
23
KA700BT Package Cart Box Content KA700BT
unit Lithium Battery
Knock Code Switch Model KA700BT/705BT
Size 127mm, 25mm, 22mm Material
Plastic Switching Momentary or Continuous,
Latched Relay (230V AC, 30V DC, 6 Amps) Power
123A Lithium Battery PC programmable
Applications All wood, metal or glass doors or
surfaces. Easy installation, no need to drill or
prepare thru holes in the door. The Knock Code
Switch may be installed to activate any
electronic or electrical equipment Maximum
security, nothing on the outside!
24
KA710VS Package Cart Box Content KA710VS unit
Knock Code Switch Model KA710VS/715VS
Size 100mm, 25mm, 22mm Material
Plastic Switching Momentary or Continuous,
Latched Relay (230V AC, 30V DC, 6 Amps) Power
External supply 6V-30V PC programmable
Applications All wood, metal or glass doors or
surfaces. Easy installation, no need to drill or
prepare thru holes in the door. The Knock Code
Switch may be installed to activate any
electronic or electrical equipment Maximum
security, nothing on the outside!
25
7. Log NLock (PC Program)
26
CC310 Package Blister Pack Content Cable
Connection Cables Model CC310
Connection PC COM port to KS310 Indoor Unit
Applications To connect the PC via the COM port
to the KS310 indoor unit or to the DB310 to
download and upload data between the PC and the
lock.
27
DB310 Package Cart Box Content DB310
unit. DB-Lock Cable 2 CR2032 Lithium Bat.
Data Bank Unit Model DB310
Size 96mm, 54mm, 10mm Power 2 x CR2032
Lithium Connection Use CC310 cable to connect
the DB310 to the PC COM port.
Applications Transfer data between the PC and
many locks via the DB310 unit.
28
Log NLock Version V1.3
The Log NLock Version 1.3 PC software enables
the user to import Audit Trail from all locks,
and to export all the users setup data to the
locks. There are 3 types of lock
configurations 1. Guest Room Lock (for hotels)
25 Fixed Codes for management use. 1 Rolling
Code for guests regenerated by the front
desk. 1,000 audit trail record. The Rolling
Code can be linked to the Entrance Lock. 2.
Standard Lock (general purpose) 250 fixed code
for all users. 1,000 audit trail records. 3.
Entrance Lock (hotel entrance or designated
guests use) 50 fixed codes for management
use. 200 linked code for guests. 1,000 audit
trail record. Log NLock Version 1.3 can
communicate with the DB310 Data Bank units, to
import and export data to multiple number of
locks. Minimum System Requirement Windows
XP 256MB RAM 9-pin D-sub COM port 800X600 256
color display
