An Energy Technology Company. Leading the
Industry with Development of Independent Negative
Power Systems
2
ELECTRIC CITY CORPORATION
ES/GC system is Competitive at the Wholesale Level
3
ELECTRIC CITY CORPORATION

• EnergySaver/GlobalCommander Uniquely Designed to
  Take Advantage of Market
• Fully Automatic and Transparent Energy Savings
  and Demand Curtailment Tool for the Commercial,
  Industrial and Government Market and Dispatchable
  by Utility
• Fully Operable and Measurable over the Internet
  or Other Types of Communication
• Proven Performance
• Competitive and Scalable A True Power Delivery
  System or Virtual Negawatt Power
• First, 25 Million 50 Megawatt VNP System for
  ComEd

4
ELECTRIC CITY CORPORATION

• Competitive Curtailment and Efficiency Remain One
  of the Most Cost Effective Long Term Solutions to
  Meeting Peak Demand
• Provide better balance against poor AC Driven
  Annual Load Factor/Utilization
• Better for a Utility when compared to a massive
  reduction in base consumption
• Can be provided at market driven rates
• Better than above market, demonstration projects
• Can Provide Utility with Real Control over Load
• Measurable, Controllable in Real Time

5
EnergySaver
Reduces Energy While Keeping Lights On
6
LIGHTING

• Why Lighting?
• A Primary Base Load
• Non-Seasonal - Always on when facility is in
  use.
• Steady Load Load varies very little from day to
  day.
• Easiest to Implement and Measure

7
Lighting Power Reducer

• System Integration and Communication
• WAN
• LAN
• Ethernet
• Internet
• Power Line Carrier
• Fiber Optic
• Radio
• Cellular

8

• GlobalCommander
• Minor Bandwidth Requirements
• Can Coexist and Operate Transparently Over
  Existing Ethernet Systems

• GlobalCommander Shown Operating Over National
• Retailers Existing Ethernet,
• Point of Sales System

9
Lighting Power Reducer

• Features
• Keypad or PC programmable
• Open Protocol
• Native BACnet
• ISO 16484-5
• ANSI/ASHRAE Standard 135-2001
• RS-232 COM Port
• Modem or Direct PC Com Port
• RS-485 COM Port
• Networking Other Automation Systems
• Internet (MS/TP Protocol)
• Ethernet Card Optional

10
Lighting Power Reducer

• System Benefits
• Enables Variable Base Load Control for
  Demand-Side Management
• Curtailment (ISO or utility request)
• Interruption
• SCADA Interface
• PLC (Programmable Logic Controllers)
• Demand Trading (Direct Utility Control Via
  Utility Transaction Software)
• Windows ODBC Interface
• Can Interface Directly with Microsoft SQL, Oracle
  or Sybase

11
Functional Control Arenas

• Stand-Alone
• System has its own network and control
• Operates totally independent of any other control
  or automation software
• Legacy Interface
• Universal I/O (digital or analog)
• Has additional inputs that will accept signals
  from other automation or control equipment
• 21 inputs and 20 outputs
• Has additional outputs to send status or alarm
  signals to other automation or control equipment

12
Functional Control Arenas

• Open Protocol
• BACnet (Building Automation Control Network)
• Supported by ASHRAE (American Society of Heating,
  Refrigeration Air-Conditioning Engineers)
• ANSI 135-2001
• Major building automation systems
• EnergySaver simply becomes an additional node or
  panel on any BACnet compatible system.

13

• Other VNPP Loads
• Lighting - EnergySaver
• HVAC
• Chillers
• Pumps
• Fans
• On-Site Generation
• Process Control

14
Integrated Network
15
VNPP Benefits

• Methods of Control
• Emergency
• Scheduled in Advance
• Preset Variables
• Price/kW (Demand)
• Price/kWh (Usage)
• Demand Limit (do not exceed XXX kW)
• Ability to Curtail Large Aggregated Loads from
  Unrelated Facilities in Minutes
• Measurement Verification
• Historical Verification of Curtailment (last 50
  events)
• Current, Monthly or Annual History of Avoided
  Usage
• Assist in Avoiding Brown-Outs or Black-Outs
• Curtailment can be targeted down to substation or
  even feeder level
• Reduce Reserve Requirement
• Peak Load Generators Off Line
• Utility Excess Power Sale

16
What is a Reserve Margin?
Purchases
Reserve Margin
Total Available Capacity
Available Generation
Firm Load

• Utilities do not plan reserves for non-firm load.
• The EnergySaver can convert a portion of the
  Firm load into Non-Firm load.

17
(No Transcript)
18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Pre-Curtailment kW
kW During Curtailment
Beginning End
Demand Avoided
Avoided Usage
23
(No Transcript)
24
(No Transcript)
25
ELECTRIC CITY CORPORATION

• ELCs 50 Megawatt VNP System for ComEd
• Provide 50 MWs of Curtailment at wholesale Market
  Rates
• No Up-front Payment Required of ComEd
• Financed By CIT through a Capacity PPA
• ELC Takes Full Installation and Long-term
  Performance Risk no curtailment no payment.
• ComEd helps promote to customers
• ComEd has a fully dispatchable, automatic and
  measurable, real-time curtailment system which
  operates on an open protocol, through the
  internet if desired
• ComEd takes industry lead with Innovative
  approach to long-term load management

26
ELECTRIC CITY CORPORATION

• ComEds VNP Offering to Customers
• Free, powerful control and measurement technology
• Free, steady state energy savings and associated
  cash flow (recommend 5)
• Offering similar to Natures First for
  Residential market
• Program Represents an expansion of the Energy
  Coop and other curtailment programs.
• Program utilizes proven, state of the art
  technology to capture more curtailment with a
  fully automatic system that protects the customer
  at all times
• Would represent one of the industrys largest
  automatic curtailment systems
• Entirely green, yet truly competitive and with
  favorable economic impact to all ComEd ratepayers
