CS%20461:%20Machine%20Learning%20Lecture%209

1
CS 461 Machine LearningLecture 9

• Dr. Kiri Wagstaff
• kiri.wagstaff_at_calstatela.edu

2
Plan for Today

• Review Reinforcement Learning
• Ensemble Learning
• How to combine forces?
• Voting
• Error-Correcting Output Codes
• Bagging
• Boosting
• Homework 5
• Evaluations

3
Review from Lecture 8

• Reinforcement Learning
• How different from supervised, unsupervised?
• Key components
• Actions, states, transition probs, rewards
• Markov Decision Process
• Episodic vs. continuing tasks
• Value functions, optimal value functions
• Learn policy (based on V, Q)
• Model-based value iteration, policy iteration
• TD learning
• Deterministic backup rules (max)
• Nondeterministic TD learning, Q-learning
  (running avg)

4
Ensemble Learning

• Chapter 15

5
What is Ensemble Learning?

• No Free Lunch Theorem
• No single algorithm wins all the time!
• Ensemble collection of base learners
• Combine the strengths of each to make a
  super-learner
• Also considered meta-learning
• How can you get different learners?
• How can you combine learners?

6
Where do Learners come from?

• Different learning algorithms
• Algorithms with different choice for parameters
• Data set with different features
• Data set different subsets
• Different sub-tasks

7
Combine Learners Voting

• Linear combination(weighted vote)
• Classification

Alpaydin 2004 ? The MIT Press
8
Exercise xs and os
9
Different Learners ECOC

• Error-Correcting Output Code
• how to define sub-tasks to get different
  learners
• Maybe use the same base learner, maybe not
• Key want to be able to detect errors!
• Example dance steps to convey secret command
• Three valid commands

Attack Retreat Wait
R L R L L R R R R
Attack Retreat Wait
R L R L L L R R L
10
Error-Correcting Output Code

• Specifies how to interpret (and detect errors in)
  learner outputs
• K classes, L learners
• One learner per class, LK

Column defines task for learner l
Row encoding of class k
Alpaydin 2004 ? The MIT Press
11
ECOC Pairwise Classification

• L K(K-1)/2
• 0 dont care

Alpaydin 2004 ? The MIT Press
12
ECOC Full Code

• Total columns 2(K-1) - 1
• For K4
• Goal choose L sub-tasks (columns)
• Maximize row dist detect errors
• Maximize column dist different sub-tasks
• Combine outputs by weighted voting

Alpaydin 2004 ? The MIT Press
13
Different Learners Bagging

• Bagging bootstrap aggregation
• Bootstrap draw N items from X with replacement
• Want unstable learners
• Unstable high variance
• Decision trees and ANNs are unstable
• K-NN is stable
• Bagging
• Train L learners on L bootstrap samples
• Combine outputs by voting

14
Different Learners Boosting

• Boosting train next learner on mistakes made by
  previous learner(s)
• Want weak learners
• Weak P(correct) gt 50, but not necessarily by a
  lot
• Idea solve easy problems with simple model
• Save complex model for hard problems

15
Original Boosting

• Split data X into X1, X2, X3
• Train L1 on X1
• Test L1 on X2
• Train L2 on L1s mistakes on X2 (plus some right)
• Test L1 and L2 on X3
• Train L3 on disagreements between L1 and L2
• Testing apply L1 and L2 if disagree, use L3
• Drawback need large X

16
AdaBoost Adaptive Boosting

• Arbitrary number of base learners
• Re-use data set (like bagging)
• Use errors to adjust probability of drawing
  samples for next learner
• Reduce probability if its correct
• Testing vote, weighted by training accuracy
• Key difference from bagging
• Data sets not chosen by chance instead use
  performance of previous learners to select data

17
AdaBoost
Alpaydin 2004 ? The MIT Press
18
AdaBoost Applet

• http//www.cs.ucsd.edu/yfreund/adaboost/index.htm
  l

19
Summary Key Points for Today

• No Free Lunch theorem
• Ensemble combine learners
• Voting
• Error-Correcting Output Codes
• Bagging
• Boosting

20
Homework 5
21
Next Time

• Final Project Presentations(no reading
  assignment!)
• Use order on website
• Submit slides on CSNS by midnight March 7
• No, really
• You may not be able to present if you dont
• Reports are due to CSNS midnight March 8
• Early submission March 1
