Cache-Aware Partitioning of Multi-Dimensional
Iteration Spaces

• Arun Kejariwal (Yahoo!Inc. Santa Clara, CA)
• Alexandru Nicolau, Utpal Banerjee, Alexander V.
  Veidenbaum (UC Irvine, CA)
• Constantine D. Polychronopoulos (UI Urbana, IL)
• Presenter Olga Golovanevsky

2
Outline

• Motivation
• Motivating examples
• The Techniques
• Results
• Conclusion

3
Motivation

• Multi-cores becoming ubiquitous
• Examples Intels Sandybridge, IBMs Cell and
  POWER Suns UltraSPARC T family
• Number of cores is expected to increase
• Large-scale hardware parallelism available
• Software challenges
• Thread-level application parallelization
• How to map threads on different cores
• Load balancing
• Data affinity

4
Application Parallelization

• Loops account for most of application run-time
• Loop classification
• DOALL No loop-carried dependence
• Amenable to auto-parallelization
• Execute iterations in parallel on different
  threads
• Non-DOALL
• Thread synchronization
• support needed for
• parallelization

5
Parallel Execution of DOALL Loops

• Auto-parallelized
• Directive-driven parallelization
• Example OpenMP pragmas
• Issue with parallel execution
• Load balancing
• How to partition the iteration space for best
  performance?
• Naïve way Partition the iteration space
  uniformly amongst the different threads
• Doesnt yield the best performance!

6
Iteration Space Partitioning

• Why is it non-trivial?
• Non-rectangular geometry of iteration space

7
Iteration Space Partitioning (contd.)

• Why is it non-trivial?
• Use of indirect referencing
• Non-uniform cache miss profile
• Variation in L1 cache misses
• 462.libquantum

8
Iteration Space Partitioning (contd.)

• Why is it non-trivial?
• Non-perfect multi-way loops
• Outermost loop may have multiple
• loops at the same nesting level
• Conditional execution of inner loops

do k2, nk -1 do j1, ny ? first loop
do i1, nx read Ak,j,i
end do end do do j2, ny-1 ? second loop
do i2, nx-1 write Ak,j,i
end do end do end do
T1 k1
T2 k4
9
Iteration Space Partitioning (contd.)

• Why is it non-trivial?
• Presence of conditionals in the loop body
• Non-uniform workload
• distribution
• Variation in Inst Retired
• 403.gcc

10
How to partition?

• Guiding factors
• Partition the outermost loop
• Minimizes scheduling overhead
• Geometry-aware
• Model the iteration space as a convex polytope
• Loop indices are affine functions of outer loop
  indices
• Cache-Aware
• Account for non-uniform cache miss profile across
  the iteration space
• Account for non-uniform workload distribution
  across the iteration space

11
Algorithm

• High-level steps
• Obtain the cache miss profile
• Obtain the workload distribution
• Compute the total volume of iteration space
• Weighted by cache misses and instructions retired
• Given n threads
• Compute n-1 breakpoints along the axis
  corresponding to the outermost loop wherein
• Each breakpoint delimits a set
• Each set has equal weighted volume
• Map each set on to a different thread

12
Experimental Setup

• Use in-built hardware performance counters
• MEM_LOAD_RETIRED.L1D_MISS
• Obtain cache miss profile
• INST_RETIRED.ANY
• Obtain instructions retired profile

13
Kernel Set
14
Results (contd.)

• Compute two metrics
• Speedup (tco tca) 100
• tca
• tco cache-oblivious
• tca cache-aware
• Deviation
• Difference between proposed
• technique and worst case

15
Thank You!
16
Results (contd.)

• Performance variation with different partitioning
  planes
• 3 threads

17
Results

• Performance variation with different partitioning
  planes
• A kernel from 178.galgel
• Nested non-perfect
• multiway DOALL
• loop
• 2 threads
