Continuous Query Languages for DSMS

• CS240B Notes
• by
• Carlo Zaniolo

2
DSMS Languages for Continuous Queries

• Relational Algebra Operators
• SQL and User-Defined aggregates
• The Blocking problem
• The expressive Power problem
• XML streams and their query languages.

3
CQLs for DSMS

• Most of DSMS projects use SQL for continuous
  queriesfor good reasons, since
• Many applications span data streams and DB tables
• A CQL based on SQL will be easier to learn use
• Moreover the fewer the differences the better!
• But DSMS were designed for persistent data and
  transient queries---not for persistent queries on
  transient data
• Adaptation of SQL and its enabling technology
  presents many research challenges
• Lack of expressive powereven worse now since
  only nonblocking operators are allowed.

4
Continuous Query Graph many componentsarbitrary
DAGs
?
Source1
U
Sink
Source2
s
5
Relational Algebra Operators

• Stored data
• Selection, Projection
• Union
• Join (including X) on tables
• Set Difference
• Aggregates
• Traditional Blocking aggregates
• OLAP functions on windows or unlimited preceding

• Data Streams
• ... same
• Union by Sort-Merging on timestamps
• Join of Stream with table
• Window joins on streams (timestamps merged into 1
  column)
• No stream difference (blockingdiff of stream
  with table OK).
• Aggregates
• No blocking aggregate
• OLAP functions on windows or unlimited preceding
• Slides, and tumbles.

6
Bolts and Nuts

• create stream bids(bid, item, offer, Time)
• create stream mybids as (select bid, offer, Time
• from bids
• where itembolt
• union
• select bid, offer,
  Time
• from bids
• where itemnut)
• Result same as select bid, offer, Time where
• item bolt or itemnut

7
Joins

• We could create a stream called interesting bids
  by say joining bids with the interesting_items
  table.
• We next find the bolt bids for which there was a
  nut bid offered in the last 5 minutes for the
  same price.
• create stream selfjoinbids as
• (select S1.bid, S1.offer, S2.bid,
  S2.Time
• from bids as S1, bids as S2 window of
  5 minutes
• where S1.itembolt and S2.itemnut and
• S1.offerS2.offer)
• The window condition implies that S1.Time gt
  S2.Time and S2.Time gt S1.Time-5 minutes.
• Windows on both streams are used very often.

\
8
Processing Unions

• Union When tuples are present at all inputs,
  select one with minimal timestamp and
• Production add this tuple to the output, and
• Consumption remove it from the input.

9
Window Joins
A
B

• Window Join of Stream A and Stream BWhen tuples
  are present at both inputs, and the timestamp of
  A is less or equal than that of B, then perform
  the following operations (symmetric operations
  are performed if timestamp of B is less or equal
  than that of A)
• Production compute the join of the tuple in A
  with the tuples in W(B) and add the resulting
  tuples to output buffer (these tuple have the
  same timestamp a the tuple in A)
• Consumption the current tuple in A is removed
  from the input and added to the window buffer
  W(A) (from which the expired tuples are also
  removed)

10
Relational Algebra Operators

• Stored data
• Selection, Projection
• Union
• Join (including X) on tables
• Set Difference
• Aggregates
• Traditional Blocking aggregates
• OLAP functions on windows or unlimited preceding

• Data Streams
• ... same
• Union by Sort-Merging on timestamps
• Join of Stream with table
• Window joins on streams (timestamps merged into 1
  column)
• No stream difference (blockingdiff of stream
  with table OK).
• Aggregates
• No blocking aggregate
• OLAP functions on windows or unlimited preceding
• Slides, and tumbles.
• Including UDAs

11
User-Defined AggregatesMax Power via Min SQL
Extensions

• Windows (logical, physical, slides, tumbles,)
  flexible synopses that solve the blocking problem
  for aggregates
• DSMS only support these constructs on built-in
  aggregates
• ESL is the first to support the complete
  integration of these two
• User Defined Aggregates (UDAs) the key to power
  and extensibility, and
• And thus can support data mining,
• XML,
• sequences not supported by other DSMS
• One framework for aggregates and windows, whether
  they are built-ins or user-defined, and
  independent on the language used to define
  them.

12
Defining Traditional Aggregates

• Specification consists of 3 blocks of code---
  Written in an external PL (as DBMS and other DSMS
  do), or
• In SQL itself (SQL becomesTuring Complete!)
• INITIALIZE
• Executed upon the arrival of the first tuple
• ITERATE
• Executed upon the arrival of each subsequent
  tuples (an incremental computation suitable for
  streams)
• TERMINATE
• Executed after the end of the relation/stream has
  been reached
• Invocation SELECT myavg(start_price)  FROM
  OpenAuction

13
The UDA AVG in SQL

• AGGREGATE avg(Next Int) Real
• TABLE state(tsum Int, cnt Int)
• INITIALIZE
• INSERT INTO state VALUES (Next, 1)
• ITERATE
• UPDATE state
• SET tsumtsumNext, cntcnt1
• TERMINATE
• INSERT INTO RETURN
• SELECT tsum/cnt FROM state

• INSERT INTO RETURN in TERMINATE ? a blocking
  UDA

14
NonBlocking UDA AVG of last 200 Values

• AGGREGATE myavg(Next Int) Real
• TABLE state(tsum Int, cnt Int)
• INITIALIZE
• INSERT INTO state VALUES (Next, 1)
• ITERATE
• UPDATE state SET tsumtsumNext, cntcnt1
• INSERT INTO RETURN
• SELECT tsum/cnt FROM state
• WHERE cnt 200 0
• UPDATE state SET tsumNext, cnt1
• WHERE cnt 200 1
• TERMINATE

• Empty TERMINATE Denotes a non-blocking UDA

15
UDAs in ESL

• In ESL user-defined Aggregates (UDAs) can be
  defined directly in SQL, rather than in a PL
• Native extensibility in SQL via UDAs (which can
  also be defined in a PL for better performance)
• No impedance mismatch
• Access to DB tables from UDAs
• Data Independence and optimization
• Good ease of use and performance
• Turing completeness nb-completeness.

16
Data Intensive Applications UDAs

• Complex Applications can expressed concisely,
  with good performance
• ATLAS a single-user DBMS developed at UCLA.
• Support for SQL with UDAs
• On top of Berkeley-DB record manager.
• Data Mining Algorithms in ATLAS
• Decision Tree Classifiers 18 lines of codes
• APriori 40 lines of codes
• Modest overhead lt50 w.r.t procedural UDA
• Data Stream Applications in ESL
• Data Stream Mining, approximate aggregates,
  sketches, histograms,

17
SQL2003 OLAP FunctionsAggregates on Windows
CREATE STREAM ClosedAuction (/auction closings
/ itemID, /id of
the item in this auction./ buyerID
/buyer of this item./) Final price real
/final price of the item /,
Current_time) order by source
Auctions

• For each seller, show the average selling price
  over the last 10 items sold (physical window)

CREATE STREAM LastTenAvg SELECT
sellerID, AVG(price) OVER(PARTITION BY sellerID
ROWS 9 PRECEDING), Current_time FROM
ClosedPrice
18
Optimizing Window AVG in ESL

• For each expired tuple decrease the count by one
  and the sum by the expired valueworks for
  logical physical windows

• WINDOW AGGREGATE avg(Next Real) Real TABLE
  state(tsum Int, cnt Real) TABLE
  inwindow(wnext Real)
• INITIALIZE INSERT INTO state
  VALUES (Next, 1)
• ITERATE UPDATE state SET tsumtsumNext,
  cntcnt1 INSERT INTO RETURN SELECT
  tsum/cnt FROM state
• EXPIRE /if there are expired tuples, take the
  oldest / UPDATE state SET cnt
  cnt-1, tsum tsum (select wnext
  FROM inwindow
  WHERE oldest(inwindow))

19
MAX

• System maintains inwindow
• Remove dominated (less older) values
• The oldest is always the max.

WINDOW AGGREGATE max (Next Real) Real TABLE
inwindow(wnext real) INITIALIZE etc.
/system adds new tuples to inwindow/
ITERATE DELETE FROM inwindow WHERE
wnext ltNext INSERT INTO RETURN
SELECT wnext FROM inwindow
WHERE oldest(inwindow)
EXPIRE /expired tuples removed
automatically/
20
For Each Aggregate two versions

• The traditional Base aggregate with terminate
• The Window aggregate with inwindow and expire.
• These definitions will take care of both logical
  and physical windows.
• But there are more complications slides and
• tumbles.

21
Slides and Tumbles

• Every two minutes, show the average selling
  price over the last 10 minutes (logical window)

CREATE STREAM LastTenAvg SELECT sellerID,
max(price) OVER(RANGE 10 MINUTE PRECEDING
SLIDE 2
MINUTE), Current_time FROM ClosedPrice
Here the window is W10 and the slide is S2.
Tumble When S W
22
SLIDEs

• The slide constructs divides a window into panes,
  results only returned at the end of each pane
• Slide is conducive to optimization.
• Combine summaries into the desired aggregation
• E.g. MAX(1, 2, 3, 4) MAX(MAX(1,2), MAX(3,4))
  4
• I.e., for MAX, we can perform MAX on subsets of
  numbers as local summaries, then combine them
  together to get the true MAX
• Proposed before but what constructs should be
  used to integrate these concepts into the
  language?

23
Slides Tumbles--Examples

• Tumble where the SLIDE size is equal or larger
  than the window size
• E.g. Once every 50 tuples, compute and return
  average over the last 10 tuples
• Easy to optimize
• Skip the first 40 tuples of every 50 tuples, and
  compute the blocking base version of the
  aggregate on the last 10
• Slide where slide size is smaller than the
  window size
• E.g. Once every 10 tuples, compute and return
  average over the last 50 tuples
• Naïve implementation--not optimized
• Perform incremental maintenance on every incoming
  tuple
• Ignore RETURN statements for most incoming tuples
• Only invoke RETURN once every 10 tuples

24
Pane-based SLIDE Optimization

• Two-level cascading aggregates using two existing
  aggregates
• Perform sub-aggregation inside each pane using
  the base aggregate No need for incremental
  maintenance here
• Computed with a blocking aggregate once for each
  pane
• Combine the summary tuples using the window
  aggregate that returns on every incoming tuple
  (non-blocking)
• With incremental maintenance here
• At any time, only the last un-finished pane needs
  to store data tuples
• all finished panes are reduced to one reusable
  summary tuple

25
Pane-based SLIDE optimization

• Example SUM with window size 50 tuples, and
  slide size 10 tuples
• First create a stream of summary tuples using
  base aggregate
• CREATE STREAM temp AS (
• SELECT itemID, base_max(sale_price) as s
• OVER(PARTITION BY itemID ROWS 9 PRECEDING
  SLIDE 10)
• FROM Auction)
• Then apply the window version of the aggregate
• SELECT itemID, window_max(s)
• OVER(PARTITION BY itemID ROWS 4 PRECEDING)
• FROM temp

• This simple approach can be used to implement
  very complex aggregations (e.g. ensemble
  classifiers)
• Applies uniformly to logical/physical windows
  defined in SQL or in an external language

26
Summary

• Logical, Physical x tumble, slide,
  unlimited_preceding
• Six different types of calls, supported by two
  definitions
• Both SQL or procedural languages can be used in
  the definition.

27
Window UDAs vs. Base UDAs

• Base UDAs
• called as traditional SQL-2 aggregates, with
• optional GROUP BY
• Window UDAs
• called with SQL2003 OVER clause
• logical or physical windows
• optional PARTITION BY and SLIDE clauses in ESL
• Clear semantics and optimization rules unify
• UDAsSQL or PL-defined, algebraic or not
• window (logical physical), slice, tumbles,
  etc.
• System and user roles in optimization.

28
Window UDAs Physical Optimization

• The Stream Mill System provides efficient support
  for
• Management of new expiring tuples in buffer
• Main memory intelligent paging into disk
• Events caused by tuple expiration
• Users can access the buffer as the table called
  inwindow

29
Conclusion

• Language Technology
• ESL a very powerful language for data stream and
  DB applications
• Simple semantics and unified syntax conforming
  to SQL2003 standards
• Strong case for the DB-oriented approach to data
  streams
• System Technology
• Some performance-oriented techniques
  well-developede.g., buffer management for
  windows
• For others work is still in progressstay tuned
  for latest news
• Stream Mill is up and running http//wis.cs.ucla.
  edu/stream-mill

30

• The End
• THANK YOU !

31
References

• 1ATLaS user manual. http//wis.cs.ucla.edu/atlas
  .
• 2SQL/LPP A Time Series Extension of SQL Based
  on Limited Patience Patterns, volume 1677 of
  Lecture Notes in Computer Science. Springer,
  1999.
• 4A. Arasu, S. Babu, and J. Widom. An abstract
  semantics and concrete language for continuous
  queries over streams and relations. Technical
  report, Stanford University, 2002.
• 5B. Babcock, S. Babu, M. Datar, R. Motwani, and
  J. Widom. Models and issues in data stream
  systems. In PODS, 2002.
• 9D. Carney, U. Cetintemel, M. Cherniack, C.
  Convey, S. Lee, G. Seidman, M. Stonebraker, N.
  Tatbul, and S. Zdonik. Monitoring streams - a new
  class of data management applications. In VLDB,
  Hong Kong, China, 2002.
• 10J. Celko. SQL for Smarties, chapter Advanced
  SQL Programming. Morgan Kaufmann, 1995.
• 11S. Chandrasekaran and M. Franklin. Streaming
  queries over streaming data. In VLDB, 2002.
• 12J. Chen, D. J. DeWitt, F. Tian, and Y. Wang.
  NiagaraCQ A scalable continuous query system for
  internet databases. In SIGMOD, pages 379-390, May
  2000.
• 13C. Cranor, Y. Gao, T. Johnson, V. Shkapenyuk,
  and O. Spatscheck. Gigascope A stream database
  for network applications. In SIGMOD Conference,
  pages 647-651. ACM Press, 2003.
• 14Lukasz Golab and M. Tamer Özsu. Issues in
  data stream management. ACM SIGMOD Record,
  32(2)5-14, 2003.
• 15J. M. Hellerstein, P. J. Haas, and H. J.
  Wang. Online aggregation. In SIGMOD, 1997.
• 16 Yijian Bai, Hetal Thakkar, Chang Luo, Haixun
  Wang, Carlo Zaniolo A Data Stream Language and
  System Designed for Power and Extensibility.
  Proc. of the ACM 15th Conference on Information
  and Knowledge Management (CIKM'06), 2006
• 17 Yijian Bai, Hetal Thakkar, Haixun Wang and
  Carlo Zaniolo Optimizing Timestamp Management in
  Data Stream Management Systems. ICDE 2007.

32
References (Cont.)

• 18 Yan-Nei Law, Haixun Wang, Carlo Zaniolo
  Query Languages and Data Models for Database
  Sequences and Data Streams. VLDB 2004 492-503
• 19 Sam Madden, Mehul A. Shah, Joseph M.
  Hellerstein, and Vijayshankar Raman. Continuously
  adaptive continuous queries over streams. In
  SIGMOD, pages 49-61, 2002.
• 20R. Motwani, J. Widom, A. Arasu, B. Babcock,
  M. Datar S. Babu, G. Manku, C. Olston, J.
  Rosenstein, and R. Varma. Query processing,
  approximation, and resource management in a data
  stream management system. In First CIDR 2003
  Conference, Asilomar, CA, 2003.
• 21R. Ramakrishnan, D. Donjerkovic, A.
  Ranganathan, K. Beyer, and M. Krishnaprasad.
  SRQL Sorted relational query language, 1998.
• 23Reza Sadri, Carlo Zaniolo, and Amir M.
  Zarkesh andJafar Adibi. A sequential pattern
  query language for supporting instant data
  minining for e-services. In VLDB, pages 653-656,
  2001.
• 24Reza Sadri, Carlo Zaniolo, Amir Zarkesh, and
  Jafar Adibi. Optimization of sequence queries in
  database systems. In PODS, Santa Barbara, CA, May
  2001.
• 25P. Seshadri. Predator A resource for
  database research. SIGMOD Record, 27(1)16-20,
  1998.
• 26P. Seshadri, M. Livny, and R. Ramakrishnan.
  SEQ A model for sequence databases. In ICDE,
  pages 232-239, Taipei, Taiwan, March 1995.
• 27Praveen Seshadri, Miron Livny, and Raghu
  Ramakrishnan. Sequence query processing. In ACM
  SIGMOD 1994, pages 430-441. ACM Press, 1994.
• 28M. Sullivan. Tribeca A stream database
  manager for network traffic analysis. In VLDB,
  1996.
• 29D. Terry, D. Goldberg, D. Nichols, and B.
  Oki. Continuous queries over append-only
  databases. In SIGMOD, pages 321-330, 6 1992.
• 30Peter A. Tucker, David Maier, Tim Sheard, and
  Leonidas Fegaras. Exploiting punctuation
  semantics in continuous data streams. IEEE Trans.
  Knowl. Data Eng, 15(3)555-568, 2003.
• 31Haixun Wang and Carlo Zaniolo. ATLaS a
  native extension of SQL for data minining. In
  Proceedings of Third SIAM Int. Conference on Data
  MIning, pages 130-141, 2003.
