Why does PAT need Rapid Microbiology Methods

1
Why does PAT need Rapid Microbiology Methods?

• S.Lonardi, P.J.Newby, D.Ribeiro, B.Johnson
• PAT Subcommittee meeting October 23, 2002

2
Purpose

• To consider the interrelation between PAT ideals
  and the implementation of Rapid Microbiology
  Methods (RMM)
• To outline the current GSK implementation
  strategy

3
Objectives

• To advance dialogue on the implementation of RMM

• To outline PAT ideals in terms of RMM
  implementation
• To understand if the GSK point of view is
  aligned with agency and industry opinion
• Ultimately to facilitate the introduction of new
  microbial technologies into the pharmaceutical
  sector

4
Outline

• Introduction
• PAT RMM
• Barriers to PAT
• The current position
• Products and processes define the technology
• The technologies
• ATP bioluminescence
• Solid-phase laser cytometry (ScanRDI)
• Proposed approach
• Advantages of RMM to PAT
• Conclusions

5
Proposed PAT definition

• Systems for analysis and control of manufacturing
  processes based on timely measurements, during
  processing, of critical quality parameters and
  performance attributes of raw and in-process
  materials and processes to assure acceptable end
  product quality at the completion of the process.
• ACPS PAT-Subcommittee (Benefits WG)
  Recommendations (02/02 Meeting)

6
PAT - in relation to RMM

• PAT provides an opportunity to move from the
  current testing to document quality paradigm to
  a Continuous Quality Assurance paradigm that
  can improve our ability to ensure quality was
  built-in or was by design - ultimate
  realization of the true spirit of cGMP!
• At/On/In-line measurement of performance
  attributes
• Real-time or rapid feedback controls (focus on
  prevention)
• Greater insight and understating of processes
• Potential for significant reduction in
  production (and development) cycle time
• Reduce (regulatory) concerns and potential for
  remote inspection strategies

FDA Science Board Meeting, 9 April 2002
7
Options for Introducing PAT
A. Currently marketed robust products. PAT to
improve efficiency (minimal improvement in
quality assurance) B. Current marketed products
needing improvement. Step wise PAT approach -
first improve quality and then improve the
efficiency C. New products. PAT used
throughout development and scale-up. Lab
based tests to ensure shelf-life and/or
for establishing public standards.
Presentation of Ajaz S.Hussain at Pittcon March
22, 2002
8
PAT RMM

• Current GSK manufacture/QA approach is
  following option A.
• Attention is focused on improving
• Raw material testing
• End product release tests (non-sterile
  sterile)
• Environmental monitoring
• Water testing
• In-process bioburden testing
• New product introduction follows option C.

9
Barriers to applying PAT

• Technical reasons
• Current microbial tests require 4-14 days
• Overall process optimisation is the recommended
  approach
• Reduced incentive to invest in real time
  chemical controls when finished products cannot
  be released
• Concurrent development of chemical and microbial
  release methodologies will assist PAT ideals
• Guidance is unclear

10
Barriers to applying PAT (contd)

• Cultural and organisational reasons
• Considering microbial rapid methods as part of a
  wider design for the release of finished goods
  under PAT requires
• Spreading the knowledge within the company
• Convince local management regulatory affairs
• Co-ordination between sites located in different
  regional areas
• Significant resources required for development
  and implementation
• Unclear/unknown regulatory process - perceived
  significant risk
• Long time to attain the objective/benefits

11
Current GSK position
12
Current Release tests

• Non-sterile testing
• Microbial Limit Test
• Clean liquids/inhaled/topicals
• Current test is 5 days - or more
• Sterile
• Sterility test
• All terminally sterilised and aseptically
  processed products
• Current test is 14 days - or more
• Current methods are potential bottlenecks to
  product release!

13
In-Process testing

• Environmental monitoring
• Air
• Surfaces
• Personnel
• Raw material testing
• In-process Bioburden
• Water testing
• All rely on microbial growth
• Results take 4 to 5 days
• Real-time results not possible with current
  methods!

14
RMM are needed

• Because current microbiological methods are.
• Potential bottlenecks to product release
• Cannot deliver Real-time results
• PAT improvements must encompass all areas of the
  process to achieve maximum benefits!

15
Products sample types

• Sterile
• Vials
• Ampoules
• Syringes
• Non-sterile
• Clean liquids
• Inhalers
• Topicals
• Water
• WFI
• Purified

• Environmental monitoring
• Air/gas
• Surfaces
• Personnel
• Input raw materials
• In-process bioburdens

16
Products and processes define the technology

• Product and process requirements are paramount
• The technology must satisfy the product
  requirements specifications
• Different technologies offer different
  attributes
• Understanding the process and product will
  dictate the best technology solution
• Different technologies will have different
  implementation requirements
• PDA Technical Report 33 identifies different
  parameters

17
The Technologies
18
The technologies

• ATP bioluminescence
• Non-sterile products
• Qualitative quantitative testing
• Systems Identified
• PallCheck
• Rapiscreen
• MicroStar

• Solid-phase laser cytometry
• Sterile, non-sterile products
• Single cell detection
• Filterable products only
• System Identified
• ScanRDI

19
ATP Bioluminescence PallCheck
20
ATP Bioluminescence Rapiscreen
21
ATP Bioluminescence MicroStar
22
Bioluminescence an example
16
14
12
ln (RLU) after 18h
10
8
6
NC
Anig
Bsub
Calb
Criso
Ecol
Mlut
Paer
Pseud
Sabo
SAur
23
Solid-Phase Laser Cytometry ScanRDI
24
Solid-Phase Laser Cytometry an example
25
RMM implementation

• The GSK implementation strategy is mainly based
  on
• PDA Technical Report 33
• Draft Pharm. Forum Chapter lt1223gt
• Technology choice will be product driven
• Implementation will involve an integrated
  approach for
• Microbiological performance
• Instrument qualification
• Computer system compliance
• Education training

26
Advantages of RMM to PAT

• Increased security of supply to patients
• Reduces potential for product stock-outs
• Significantly faster than current methods
• A step closer to real time results
• Increased sensitivity
• Potential for in-line testing
• Reduces in-process test times
• Reduces potential for batch rejections/re-works
• Builds quality into product/process
• Comparable to duration of chemical methods

27
Conclusions

• RMM will have a significant impact for overall
  PAT
• Concurrent development of chemical and microbial
  release methodologies will assist PAT ideals
• GSK is interested in RMM for product testing and
  in-process control optimisation
• ATP bioluminescence (Pallcheck / Rapiscreen /
  Microstar) Solid-Phase laser Cytometry
  (ScanRDI) are main contenders
• The GSK implementation strategy is based on PDA
  TR 33 and Draft Pharm. Forum Chapter lt1223gt

28
Effective dialogue with regulators and rest of
industry is considered essential for success!
29
END OF PRESENTATION
