INSYS 300

1
INSYS 300 Week 5Association Analysis

• Dr. Xia Lin
• Associate Professor
• College of Information Science and Technology
• Drexel University

2
Automatic indexing

• 1. Parse individual words (tokens)
• 2. Remove stop words.
• 3. Stemming
• 4. Use frequency data
• decide heading threshold
• decide tail threshold
• decide variance of counting

3

• 5. Create indexing structure
• invert indexing
• other structures

4
Term Associations

• Counting word pairs
• If two words appear together very often, they are
  likely to be a phrase
• Counting document pairs
• If two documents have many common words, they are
  likely related.

5
More Counting

• Counting citation pairs
• If documents A and B both cite document C, D,
  then A and B might be related.
• If documents C and D often be cited together,
  they are likely related.
• Counting link patterns
• Get all pages that have links to my pages.
• Get all pages that contain similar links to my
  pages

6
Google Search Engine

• Link analysis
• PageRank --The ranking of web pages are based on
  the number of links that refer to that web page
• If page A has a link to B, page A has one vote to
  B.
• The more votes a page get, the more useful the
  page is.
• If page A itself receives many votes, its vote to
  B will count more heavily
• Combining link analysis with word matching.

7
Other similarity measurements

• If tik is either 0 or 1.
• D1s terms only n1wx (the number of times
  t1k1)
• D2s terms only n2wy (the number of times
  t2k1)
• Sameness count sc (wz)/(n1n2)
• Difference count dc (xy)/(n1n2)
• Rectangular Distance rd MAX(n1, n2)
• Conditional probability cpmin(n1, n2)
• mean mean (n1n2)/2

8

• Simple measurement of difference/ similarity
• wthe number of times t1k1, t2k1.
• xthe number of times t1k1, t2k0.
• ythe number of times t1k0, t2k1.
• zthe number of times t1k0, t2k0.

9
Similarity Measure

• Dices Coefficient
• Dice(D1, D2) 2w/(n1n2)
• where w is the number of terms that D1, and D2
  have in common n1, n2 are the number of terms
  in D1and D2.
• Jaccard Coefficient
• Jaccard(D1, D2) w/(N-z)
• w/(n1n2-w)

10
Similarity Measure

• Cosine Coefficient
• The same as

11
Similarity Metric

• A metric has three defining properties
• Its value are non-negative
• Its symmetric
• It satisfies the triangle inequality
• AC?ABBC

12
Lp Metrics
13
ConceptLink

• Use terms co-occurring frequencies
• to predict semantic relationships
• to build concept clusters
• to suggest search terms
• Visualization of term relationships
• Link displays
• Map displays
• Drag-and drop interface for searching

14
Similarity Matrix

• Pairwise coupling of similarities among a group
  of documents
• S11 S12 S13 S14 S15 S16 S17 S18
• S21 S22 S23 S24 S25 S26 S27 S28
• S31 S32 S33 S34 S35 S36 S37 S38
• S41 S42 S43 S44 S45 S46 S47 S48
• S51 S52 S53 S54 S55 S56 S57 S58
• S61 S62 S63 S64 S65 S66 S67 S68
• S71 S72 S73 S74 S75 S76 S77 S78
• S81 S82 S83 S84 S85 S86 S87 S88

15
Document Similarity

• Documents
• D1t11, t12, t13, , t1n
• D2t21, t22, t23, , t2n

16
Document clustering

• Grouping similar documents to different sets
• Create similarity matrix
• Apply a hierarchical clustering algorithm
• 1 Identify the two closet documents and combine
  them into a cluster
• 2 Identify the next two closet documents and
  clusters and combine them into a clusters
• 3 If more then one cluster remains, return to
  step 1

17
Application of Document Clustering

• Northern Light
• Cluster search results into different groups
• AltaVista
• Refine search
• Cluster related words into different groups based
  on their co-occurrence rates in documents.

18

•  1. TI   The Truth About Cats and Dogs DE
  Video, Pets, Cats, Dogs,
• 2. TI  National Geographic's Really Wild
  Animals Hot Dogs and Cool Cats DE Video,
  Animals
• 3.  TI  Dogs, Cats Kids
• DE Pets, Pictures, Kids
• 4.  TI  Makita Horsepower 2-1/2 Gallon Hot Dogs
  Oil-Less Air Compressor DE Products, Food
• 5.  TI I Love Hot Dogs
• DE Fictions, Food, Kids Families
• 6.  TI  It's Raining Cats and Dogs
• DE Fictions, Pictures, Kids Families
• 7. TI Infectious Diseases of the Dogs Cats
• DE Non-fictions, cats, dogs,
• 8. TI Handbook of Small Animal Practice
• DE Non-fictions, Animals, Cats, dogs,
