Title: Sensor Networks

Sensor Networks
  • Introduction and Issues
  • Architecture and Applications
  • Localization
  • Routing and Intercommunication
  • MAC Layer Issues
  • Security Issues

What are Sensor Networks?
  • A group of wireless nodes or embedded devices
  • Collectively the nodes sense, collect, and
    analyze data
  • The sensor nodes are small, low power,
    inexpensive, and have high SNR.
  • The network usually consists of a large number of
    dense nodes distributed at random
  • They can be deployed in any kind of terrain with
    hostile environment places where traditional
    wired network cannot be deployed

Sensor Network Architecture
Internet/ Satellite
Sensor Node Architecture
  • Sensor nodes include a combination of
  • Microelectromechanical systems (MEMS) such as
    sensing devices, actuators, RF components, and
    CMOS building blocks
  • Low power computing and wireless networking

Architecture of a Sensor Node
Trans- ceiver
Sensing Unit
Battery Power
Applications of Sensor Networks
  • Surveillance and security
  • Environmental monitoring
  • Transport monitoring
  • Precision agriculture
  • Smart spaces
  • Manufacturing and inventory control
  • Other specialized tasks

Different from cellular networks and MANETS?
  • Cellular networks and MANETs are designed to
    provide good throughput/delay characteristics
  • Cellular networks and MANETs are supposed to
    facilitate high-bandwidth QoS-sensitive
  • Mobility management is a big concern in cellular
    networks and MANETs.
  • Nodes can be identified by their assigning IP

Differences - continued
  • Sensor networks consists of thousands of nodes
    designed for unattended operations
  • Traffic in sensor networks in statistical in
    nature requires low data rate
  • Addressing may be attribute based
  • The flow of data in sensor networks is
    predominantly unidirectional
  • Prolonging the battery life is a prime goal the
    batteries are usually not rechargeable

Operational Challenges
  • Ad hoc deployment should be able to discover the
    topology and self-configure for
  • Dynamically adapt to changes in topology due to
    node failures and environmental conditions
  • Automatic configuration/reconfiguration
  • Untethered for energy and communication

Localization Issues
  • What is Localization?
  • Why is it important?
  • Categorization
  • Some Localization Mechanisms
  • GPS
  • Beacon based ranging
  • Range free methods

What is Localization?
  • A mechanism for discovering spatial relationships
    between objects

Why is Localization Important?
  • Sensor Network Data is typically interpreted
    based on a sensors location
  • report event origins
  • giving raw sensor readings a physical context
  • Temperature readings ? temperature map
  • objects tracking
  • Enables data-centric network design
  • assist with routing
  • evaluate network coverage

Categorization Bulusu00
  • Coarse-grained Localization
  • Proximity to a given reference point
  • E.g., Active Badge
  • Fine-grained Localization
  • Coordinates estimation
  • E.g., Distance to a given reference point

Fine-Grained Localization
  • Ranging based methods
  • Timing
  • Signal Strength
  • Directionality Based
  • Ranging free methods
  • E.g. Centroid based, DV-hop, APIT

Ranging (Distance Measuring) Techniques
  • Time based methods
  • Time of Arrival (ToA), TDoA
  • Used with radio, IR, acoustic, ultrasound
  • Signal Strength
  • Uses received signal strength indicator (RSSI)
    readings and wireless propagation model
  • Directionality based
  • Angle of Arrival (AoA) measured with directional
    antennas or arrays

  • Time of flight of communication signal
  • Signal Pattern
  • Global Positioning System
  • Local Positioning System
  • Pinpoints 3D-iD
  • Different modalities of communication
  • Active Bat

Signal Strength
  • Attenuation of radio signal increases with
    increasing distance
  • Wall Attenuation Factor based Signal Propagation
  • RF mapping

Directionality Based Fine-Grained Localization
  • Small Aperture Direction Finding
  • Used in cellular networks
  • Requires complex antenna array
  • Disadvantages
  • Costly
  • Not a receiver based approach

Basic Concepts in Ranging
  • Trilateration
  • Triangulation
  • Multi-lateration
  • Considers all available beacons

Sines Rule
Cosines Rule
Localization Mechanisms
  • GPS
  • Beacon based ranging
  • Range free methods

Global Positioning System (GPS) Getting93
  • Started in 1973, built in 1993
  • Wide-area radio positioning system
  • Ranging-based method
  • Using Timing of Arrival (ToA)

GPS System Architecture
  • Constellation of 24 NAVSTAR satellites made by
  • Altitude 10,900 nautical miles
  • Orbital Period 12 hours
  • At least five satellites in view from every point
    in the Globe

How GPS Works
  • The basis of GPS is trilateration" from
  • Distance measuring based on ToA
  • accurate timing is important
  • Along with distance, you need to know exactly
    where the satellites are in space
  • High orbits and careful monitoring are the secret
  • Finally you must correct for any delays the
    signal experiences as it travels through the
  • A Fourth satellite used for correction purpose

Differential GPS
  • Ground-based Station with known location
    information can estimate the GPS measure errors
  • These error estimations are made available to
    other GPS users in the area
  • allow them to mitigate errors in their
  • such differential corrections are transmitted
    in real time over a FM radio link

GPS Not Always Applicable
  • Many contexts you cannot have GPS on every node
  • form factor
  • energy
  • cost
  • obstructions
  • Beacon based approaches for sensor networks
  • Ranging based v.s. ranging free

Beacon Based Location Discovery Savvides01
Beacon Based Location Discovery
  • No need of GPS
  • No infrastructure support
  • Ad hoc deployable
  • Use RSSI for measuring node separation
  • But how should the beacons be placed?
  • Distributed Localization
  • Iterative multilateration

Localization Approach
  • Single hop beaconing
  • Iterative multilateration
  • Dynamic estimate the wireless channel parameters
  • Can be done in conjunction with routing

Iterative Multilateration
  • Start with a small number of beacons
  • Number of beacons increases as more nodes
    estimate their positions

  • Data packets also act as beacon signals
  • Location discovery is almost free
  • Distributed
  • relies on neighborhood information
  • Fault tolerant

However, Ranging still requires expensive
Range Free Methods
  • Centroid approach Bulusu00
  • Adaptive beacon placement Bulusu01
  • Self-configuring localization Bulusu03
  • DV-hop Niculescu01
  • AoA approach Niculescu03
  • APIT He03

Centroid Based Approach Bulusu00
  • Multiple nodes serve as reference points
  • Reference points transmit periodic beacon signals
    containing their positions
  • Receiver node finds reference points in its range
    and localizes to the intersection of connectivity
    regions of these points

Centroid Based Localization
  • (Xest, Yest) (avg(Xi1Xik), avg(Yi1Yik))
  • k No. of beacon nodes within connectivity range
  • Xi1Xik Yi1Yik Beacon nodes locations
  • Disadvantages
  • Design using a idealized radio model with perfect
    spherical radio propagation
  • Assume a regular grid of nodes with known
    location information to serve as Beacons

Impact of Beacon Placement
Beacons randomly placed LARGER mean granularity
Impact of Propagation Vagaries
Self-configuring Beacon Systems
  • Idea
  • Measure and adapt to unpredictable environment
  • Exploit spatial diversity and density of
    sensor/actuator nodes
  • Assuming large solution space, not seeking global
  • Questions
  • What to measure?
  • How to adapt?

Self-configuring Beacon Systems Bulusu02
  • Three schemes
  • GRID
  • HEAP

GRID a Centralized Approach
HEAP a localized approach
  • Given
  • S set of all beacons reachable in grid
  • E - An error estimation model
  • Determine C - (x , y)
  • Such that cumulative localization error in the
  • grid is minimized by adding beacon at C

HEAP Illustration
STROBE Adaptive Density
  • STROBE Selectively TuRning Off BEacons
  • Goals
  • Conserve energy to extend system lifetime without
    diminishing localization granularity
  • Design Goals
  • Localized algorithms
  • Responsive but low adaptation overhead

STROBE Illustration
DV-Hop Niculescu01
  • Standard DV propagation
  • Never measures node distance
  • Insensitive to signal strength errors
  • Basic idea
  • Range hop_count hop_size

DV-Hop How It Works
  • Each node maintains a table Xi, Yi, hi by
    running classic DV
  • Each Landmark Xi, Yi
  • Compute a correction Ci and flood into the
  • Each node
  • Use the correction from the closest landmark
  • Multiply its hop distance by the correction

DV-Hop Example
DV-Hop Example (contd.)
  • Landmarks compute corrections
  • Assume A gets its correction from L2
  • A estimates its ranges to the landmarks
  • L1 316.42, L2 216.42, L3 316.42
  • A performs trilateration with the above ranges

  • Basic idea
  • Point-In-Triangle Test (PIT)
  • three anchors determine a triangle
  • Repeat PIT tests with different anchor
    combination, until accuracy requirement is
  • Calculate center of gravity (COG)

APIT Overview
  • Area-based APIT narrow down the area

Localization Wrap up
  • Localization is important in sensor networks
  • GPS is useful, but not always applicable
  • Beacons (aka, anchors, landmarks) can help
  • Range based methods
  • Range free methods

Routing in Sensor Networks
  • Multihop Routing with the following constraints
    and features
  • Power efficiency
  • Attribute-based addressing
  • Location awareness
  • Data-centric (communication is for named data)

Routing Protocols
  • Flooding
  • Directed Diffusion
  • SPIN
  • Low Energy Adaptive Clustering Hierarchy (LEACH)
  • Rumor Routing

  • Flooding is the simplest form of routing
  • Each node broadcast the packets to all its
    neighbors and the process repeat until a maximum
    number of hops or the packet reaches its
  • Problems
  • Implosion (multiple copies of messages are sent
    to the same node)
  • Overlap (Neighbor nodes receive duplicate
    messages because of overlap in observing region)
  • Resource Blindness (Unaware of resources, energy)

Directed Diffusion Intanagonwiwat00
  • Data-centric routing where sink broadcasts the
  • The sink sends out requirements in terms of
    attribute-value pairs called as interest
  • This dissemination sets up gradients within the
    network designed to draw events
  • Events start flowing towards the originators of
    interests along multiple paths
  • The sensor network reinforces one or a small
    number of these paths.

Directed Diffusion
a) Interest Propagation
c)Data delivery
b) Gradients setup
SPIN Heinzelman99
  • Sensor Protocols for Information via Negotiation
    (SPIN) uses negotiation and resource adaptation
    to address the deficiencies of flooding
  • Propose a family of routing protocols
  • Conserves energy by exchanging metadata during
  • Nodes monitor and adapt to changes in their own
    energy resources to extend the operating lifetime
    of the system

SPIN Protocol
LEACH Heinzelman00
  • LEACH is self-organizing, adaptive clustering
  • Randomly selects nodes as cluster-heads to
    distribute the energy load evenly
  • High-energy dissipation in communicating with the
    base station is distributed among the sensor
  • LEACH performs local data fusion to compress
    the amount of data being sent from the
    cluster-heads to the base station

Dynamic Clusters in LEACH
Rumor Routing Braginsky02
  • A logical compromise between flooding queries and
    flooding event notifications
  • Upon witnessing an event, a node
    probabilistically generates an agent, which
    travels the network, propagating information
    about local events to distant nodes.
  • A query generated by a node traverses in a random
    direction until a TTL value or when it finds a
    node that has the path to the event
  • A query can be retransmitted or flooding can be
    adopted as a last resort.

Medium Access Control
  • Goals
  • Establish communication links
  • Fair and efficient sharing of communication links
  • Should be energy efficient

MAC Layer Issues
  • MAC protocols used for cellular networks or
    MANETs are not suitable
  • Conventional Types
  • Contention-based Channel Access
  • Requires the radio transceivers to monitor the
    channels at all times expensive for low radio
  • Organized Channel Access
  • Requires neighbor discovery and synchronization
    among the nodes expensive for sensor networks

MAC Protocols
  • Self Organized MAC for Sensor Networks (SMACS)
    and Eavesdrop-And-Register (EAR)
  • CSMA-based MAC
  • Hybrid TDMA/FDMA
  • S-MAC

SMACS Protocol Sohrabi00
  • SMACS is a flat and distributed
    infrastructure-building protocol which enables
    nodes to discover neighbors and establish
    transmission/reception schedules for
    communication without any local or global master
  • Neighbor discovery and channel assignment phases
    are combined
  • Nonsynchronous slots in the network and randomly
    chosen frequencies are used for establishing the
    communication links.

EAR Algorithm
  • EAR algorithm provides continuous service to
    mobile nodes
  • Mobile nodes assume full control of the
    connection process
  • The stationary nodes transmit a pilot signal
    periodically. Mobile nodes eavesdrop and records
    information about the connectivity
  • EAR is transparent to SMACS

CSMA-based MAC Woo01
  • The protocol should support highly correlated and
    dominantly periodic traffic
  • Random delays for transmission and phase shifts
    in the backoffs help in robustness and energy
    conservation in sensor networks
  • An adaptive transmission rate control (ARC) is
  • Medium access fairness is achieved by balancing
    the rates of originating and route-thru traffic
  • A progressive signaling scheme is used to adopt a
    linear increase and multiplicative decrease
  • ARC is also extensible for multi-hop environments

Hybrid TDMA/FDMA Shih01
  • Centrally controlled
  • Pure TDMA dedicates full bandwidth to a single
    sensor node pure FDMA allocates minimum signal
    bandwidth per node
  • The Hybrid TDMA/FDMA scheme optimizes the power
    consumption of the transmitter (TDMA) and the
    receivers (FDMA)
  • The hybrid approach results in lowering the
    overall power consumption of the system

S-MAC Ye02
  • Sensor-MAC Inspired by PAMAS, but uses in-band
  • Attempt to address all the following sources of
    power inefficiency
  • Collision - due to follow-on transmissions on
  • Overhearing - node listens to packets meant for
    another destination
  • Control packet overhead
  • Idle listening - listening to receive possible
    traffic that is not sent (consumes 50- 100 of
    energy spent for receiving)

S-MAC overview
  • Avoid collisions
  • uses CSMA/CA (basic 802.11)
  • Avoid overhearing
  • puts a node to sleep when the neighboring nodes
    are transmitting
  • Control overhead
  • Applies message passing
  • Avoid idle listening
  • periodic listen and sleep (scheduled pattern)

Constraints (SmartDust Node link-1)
  • Limited Computational Power
  • 8 bit, 4 MHz
  • Limited Memory
  • 8 KB Instruction Flash (Tiny OS 3500 bytes)
  • 512 bytes RAM, 512 bytes EEPROM
  • Limited Bandwidth and Range
  • 10 Kbps
  • Hence, Public Key and Key Exchange protocols are
    not suitable

SPINS Perrig02
  • Components
  • SNEP Secure Network Encryption Protocol
  • Data Confidentiality
  • Two party data authentication
  • Integrity
  • Freshness
  • µTESLA
  • Authenticated broadcast

SPINS Architecture
  • Base Stations (BS)
  • Trusted
  • Longer lifetime
  • Larger memory
  • Secret key between node and BS
  • Single block cipher implements all cryptographic
  • RC5 algorithm used
  • Loose time synchronization

  • Endpoints(A,B) share a secret symmetric key ?AB
  • Pseudo random function F used to generate
  • Two keys for encryption (KAB and KBA)
  • Two keys for message authentication (KAB and
  • Counters used at both endpoints to ensure data

SNEP Encryption
  • Encryption done in counter mode
  • M(K,ctr)

  • MAC implemented using Cipher Block Chaining
  • MAC(K,x)

  • Authenticated broadcast by BS using MAC
  • Loose time synchronization required
  • Base station sends messages authenticated by key
    that is secret at that time
  • All messages in a single time slot use same key
  • Key revealed d time slots after use
  • Node stores message until key is disclosed

µTESLA (contd.)
  • One way key chain used by sender
  • Last key Kn chose randomly
  • Keys generated by Ki F(Ki1)
  • F one way function
  • Sender can authenticate key by verifiying Ki

  • Bharghavan94 V. Bharghavan, A. Demers, S.
    Shenker and L. Zhang, MACAW a media access
    protocol for wireless LANs, SIGCOMM94.
  • Braginsky02 David Braginsky and Deborah Estrin.
    Rumor Routing Algorithm For Sensor Networks. In
    Proceedings of the First Workshop on Sensor
    Networks and Applications (WSNA), September 28
    2002, Atlanta, GA.
  • Buchegger02 S. Buchegger and J. L. Boudec,
    Nodes Bearing Grudges Towards Routing Security,
    Fairness, and Robustness in Mobile Ad Hoc
    networks, Euromicro Workshop on Parallel,
    Distributed, and Network-Based Processing, 2002.
  • Bulusu01 N. Bulusu, John Heidemann and Deborah
    Estrin. Adaptive Beacon Placement. In Proceedings
    of the Twenty First International Conference on
    Distributed Computing Systems (ICDCS-21), April,
  • Bulusu02 N. Bulusu. Self-Configuring
    Localization Systems, Ph.D Thesis, University of
    California at Los Angeles, October 2002.
  • Bulusu00 N. Bulusu, John Heidemann and Deborah
    Estrin. GPS-less Low Cost Outdoor Localization
    for Very Small Devices. IEEE Personal
    Communications Magazine, Vol. 7, No. 5, pp.
    28-34. October, 2000.
  • Bulusu03 N. Bulusu, J. Heidemann, D. Estrin,
    and T. Tran. Self-configuring Localization
    Systems Design and Experimental Evaluation. ACM
    Transactions on Embedded Computing Systems(TECS),
    Special Issue on Networked Embedded Computing,
    May 2003.
  • Campbell01 A. Veres, A.T. Campbell, M. Barry,
    and L.H. Sun, Supporting service differentiation
    in wireless packet networks using distributed
    control, IEEE J. SAC, Oct, 2001.
  • Chen99 S. Chen and K. Nahrstedt, "Distributed
    Quality-of-Service Routing in Ad-Hoc Networks,"
    IEEE Journal of Selected Areas on Communications,
    vol. 17, No. 8, August 1999.

  • Chiang97 C.-C. Chiang, Routing in Clustered
    Multihop, Mobile Wireless Networks with Fading
    Channel, IEEE SICON (Singapore International
    Conference on Networks) , Apr, 1997
  • Choudhury02 R. R. Choudhury, X. Yang, N.
    Vaidya, R. Ramanathan, Using directional
    antennas for medium access control in ad hoc
    networks, Mobicom, 2002.
  • Dawkins76 R. Dawkins, The Selfish Gene, Oxford
    University Press, 1989 Edition, 1976.
  • Getting93 I. A. Getting, "The Global
    Positioning Systems," IEEE Spectrum, pp. 36--47,
    December 1993.
  • Haas97Z.J. Haas, "A New Routing Protocol for
    the Reconfigurable Wireless Networks", IEEE Intl.
    Conf. on Universal Personal Comm. (ICUPC'97), San
    Diego, Oct. 1997.
  • He03 T. He, C. Huang, B. M. Blum, J. A.
    Stankovic,and T. F. Abdelzaher. Range-Free
    Localization Schemes in Large Scale Sensor
    Networks, the Ninth Annual International
    Conference on Mobile Computing and Networking
    (MobiCom 2003), San Diego, CA, September 2003.
  • Heinzelman99 W. Heinzelman, J. Kulik, and H.
    Balakrishnan, Adaptive Protocols for
    Information Dissemination in Wireless Sensor
    Networks,'' Proc. 5th ACM/IEEE Mobicom Conference
    (MobiCom '99), Seattle, WA, August, 1999.
  • Heinzelman00 Wendi Heinzelman, Anantha
    Chandrakasan, and Hari Balakrishnan,
    Energy-Efficient Communication Protocols for
    Wireless Microsensor Networks, Proc. Hawaaian
    Int'l Conf. on Systems Science, January 2000.
  •  Intanagonwiwat00 C. Intanagonwiwat, R.
    Govindan and D. Estrin. Directed Diffusion A
    Scalable and Robust Communication Paradigm for
    Sensor Networks. In Proceedings of MobiCOM 2000,
    August 2000, Boston, Massachusetts.
  • Johnson96 D.B. Johnson, and D.A. Maltz,
    Dynamic Source Routing in Ad-Hoc Wireless
    Networks, Mobile Computing, T. Imielinkski and
    H. Korth, Eds., Kluwer, 1996, pp 153-181.

  • Karn90 P. Karn, MACA a new channel access
    method for packet radio, Amateur Radio 9th
    Computer Networking Conference, 1990.
  • Kleinrock75 L.Kleinrock and F.A.Tagobi,
    Packet switching in radio channels Part-II The
    hidden terminal problem in carrier sense
    multiple-access modes and the busy tone
    solution, IEEE Trans. Comm. Vol 23, no 12, 1975
  • Ko00 Y.-B. Ko, V. Shankarkumar, N. Vaidya,
    Medium Access Control Protocols using
    Directional Antennas in Ad Hoc Networks, Infocom
  • Ko98 Y. B. Ko and N. H. Vaidya,
    Location-Aided Routing (LAR) in Mobile Ad Hoc
    Networks, Mobicom, 1998.
  • Lai02 B.C. Lai, S. Kim, I. Verbauwhede.
    Scalable session key construction protocol for
    wireless sensor networks. IEEE Workshop on Large
    Scale Real-Time and Embedded Systems (LARTES).
    December 2002
  • Lee99S.J. Lee, M. Gerla, and C.C. Chiang,
    On-Demand Multicast Routing Protocol, IEEE
    WCNC, 1999.
  • Lee98 S. Lee and A. T. Campbell "INSIGNIA
    In-band signaling support for QOS in mobile ad
    hoc networks", Proc of 5thInternational Workshop
    on Mobile Multimedia Communications (MoMuC,98) ,
    Berlin,Germany, October 1998.
  • Li03 J. Li and P. Mohapatra, LAKER Location
    Aided Knowledge Extraction Routing for Mobile Ad
    Hoc Netwoks, WCNC 2003.
  • Li03 Jian Li, and Prasant Mohapatra. "A Novel
    Mechanism for Flooding Based Route Discovery in
    Ad Hoc Networks," IEEE GlobeCom 2003 .
  • Liao01 Wen-Hwa Liao, Yu-Chee Tseng, Shu-Ling
    Wang, Jang-Ping Sheu A Multi-path QoS Routing
    Protocol in a Wireless Mobile ad Hoc Network. ICN
    (2) 2001 158-167.

  • Lin97 C.R. Lin, and M. Gerla, MACA/PR An
    Asynchronous Multimedia Multihop Wireless
    Network, IEEE INFOCOM, 1997
  • Lin99 C. R. Lin and J. S. Liu, QoS routing in
    Ad hoc Wireless Networks", IEEE Journal on
    Selected Areas in Communications, August 1999.
  • Liu01J. Liu, and S. Singh, ATCP TCP for
    mobile ad hoc networks, IEEE J-SAC, July, 2001
  • Liu99M. Liu, R.R. Talpade, A. McAuley, and E.
    Bommaiah, AMRoute Adhoc Multicast Routing
    Protocol, Computer Science Dept. U. Maryland,
  • Mohapatra03 P. Mohapatra, J. Li, and C. Gui,
    QoS in Mobile Ad Hoc Networks, IEEE Wireless
    Communications, June 2003.
  • Murthy96 S. Murthy and J.J. Garcia-Luna-Aceves,
    An Efficient Routing Protocol for Wireless
    Networks, ACM MONET, Oct, 1996, pp 183-197
  • Nasipuri00 A. S. Nasipuri, S. Ye, and R. E.
    Hiromoto, "A MAC Protocol for Mobile Ad Hoc
    Networks Using Directional Antennas", WCNC 2000
  • Niculescu01 D. Niculescu and B. Nath, "Ad hoc
    Positioning System (APS)", GLOBECOM 2001, San
    Antonio, Nov 2001.
  • Niculescu03 D. Niculescu and B. Nath, "Ad hoc
    Positioning System (APS) using AoA", INFOCOM 2003.

  • Perkins94C. Perkins, Highly Dynamic
    Destination-Sequenced Distance-Vector Routing
    (DSDV) for Mobile Computers, ACM SIGCOMM, 1994
  • Perkins99 C.E. Perkins, and E.M. Royer,
    Ad-hoc On-Demand Distance Vector Routing, IEEE
    Workshop on Mobile Computing Systems and
    Applications, Feb, 1999
  • Perrig01 A. Perrig, R. Szewczyk, V. Wen, D.
    Culler, and J. Tygar. SPINS Security Protocols
    for Sensor Networks. In Seventh Annual ACM
    International Conference on Mobile Computing and
    Networks(Mobicom) 2001.
  • Royer99E. Royer, and C.E. Perkins, Multicast
    operations of the ad-hoc on-demand distance
    vector routing protocol, ACM MOBICOM, 1999
  • Sawide01 A. Savvides, C.C. Han and M. B.
    Srivastava, Dynamic Fine Grained Localization in
    Ad-Hoc Sensor Networks, Proceedings of the Fifth
    International Conference on Mobile Computing and
    Networking, Mobicom 2001, pp. 166-179, Rome,
    Italy, July 2001
  • Schurgers02C. Schurgers, V. Tsiatsis, S.
    Ganeriwal, and M. Srivastava, Optimizing Sensor
    Networks in the Energy-Latency-Density Design
    Space, IEEE Tran. Mobile Comp. Vol. 1, No. 1,
    Jan-Mar, 2002
  • Shah01 Samarth H. Shah, Kai Chen, Klara
    Nahrstedt, Cross Layer Design for Data
    Accessibility in Mobile Ad Hoc Networks, in Proc.
    of 5th World Multiconference on Systemics,
    Cybernetics and Informatics (SCI 2001), Orlando,
    Florida, July, 2001.
  • Shih01 Eugene Shih, Seong-Hwan Cho, Nathan
    Ickes, Rex Min, Amit Sinha, Alice Wang, and
    Anantha Chandrakasan. Physical Layer Driven
    Algorithm and Protocol Design for Energy-Ecient
    Wireless Sensor Networks. In Proceedings of
    MOBICOM 2001

  • Singh98 S. Singh and C.S. Raghavendra, PAMAS
    power aware multi-access protocol with
    signaling for ad hoc networks, ACM SIGCOMM, 1998
  • Sinha99a P. Sinha, R. Sivakumar, and V.
    Bharghavan, CEDAR A core extraction distributed
    ad hoc routing algorithm. In Proc. of IEEE
    Infocom, 1999.
  • Sinha99bP. Sinha, R. Sivakumar and V.
    Bharghavan, MCEDAR Multicast extensions to
    Core-Extraction Distributed Ad hoc Routing
    algorithm'', IEEE WCNC, 1999
  • SmartDust http//
  • Sobrinho99 J.L. Sobrinho, and A.S.
    Hrishnakumar, Quality-of-Service in Ad Hoc
    carrier sense multiple access wireless networks,
    IEEE J. SAC, Aug, 1999
  • Sohrabi00 K. Sohrabi, J. Gao, V. Ailawadhi,
    and G.J. Pottie. Protocols for self-organization
    of a wireless sensornetwork. IEEE Personal
    Communications, 7(5)1627, October 2000.
  • Tseng02Y.-C. Tseng, C.-S. Hsu, and T.-Y.
    Hsieh, Power-Saving Protocols for IEEE
    802.11-Based Multi-Hop Ad Hoc Networks, IEEE
    INFOCOM, 2002
  • Woo01 A. Woo, D. Culler, A Transmission
    Control Scheme for Media Access in Sensor
    Networks, Mobicom 2001.
  • Ye02 W. Ye, J. Heidemann and D. Estrin. "An
    Energy-Efficient MAC Protocol for Wireless Sensor
    Networks," In Proceedings of the 21st
    International Annual Joint Conference of the IEEE
    Computer and Communications Societies (INFOCOM
    '02), New York, June 2002.
  • Zheng03R. Zheng, J. Hou, and L. Sha,
    Asynchronous Wakeup for Power Management in Ad
    Hoc Networks, ACM MOBIHOC, 2003
