Stream Database Systems' Survey

1
Stream Database Systems.Survey

• Moustafa A. Hammad
• Jan. 2003

2
Introduction to data streams.

• New applications
• Emerging applications (e.g., pervasive computing
  and sensor-based environments),
• Habitat monitoring- Bird Counter Query Keep a
  count of the number of times birds have entered a
  particular nest. http//hake.stanford.edu/stream/
  sqr/birdmon.html
• Real-time business processing and network
  management,
• Monitoring Sales from Different Department
  Stores
• Report the count of sales items sold by all
  stores in the last two hours categorized by each
  store.
• Customer Monitoring Query Maintain the fraction
  of packets on a particular backbone link B
  generated by a particular customer network C in
  the past hour.
  http//hake.stanford.edu/stream/sqr/netmon.html
• Telecommunication management,
• Video security monitoring and surveillance
  applications.

3
Introduction.

• New requirements
• Input streams with infinite supply of data,
  arriving on real-time, not necessary
  synchronized.
• long-running Continuous Query (CQ), large number
  of concurrent CQs, exact and approximate answers
  are relevant, quality of service (QoS), (e.g,
  real-time requirement).
• Human Active Database Passive (HADP) versus
  Database Active Human Passive (DAHP) model.
  Aurora-VLDB02
• Traditional query processing needs rethinking to
  deal with data streams.

4
Background
Time

• Stream Model
• Data stream
• Unlimited sequence of data items, ordered by the
  time-stamp at which each item is added to the
  stream.
• A single data item is a binary tuple (value(s),
  Sequence_order),
• Sequence_order
• time-stamp time of creation (valid time) or
  time when received by the system (transaction
  time), or
• (1,2,3,.)
• Sensor (a source of data stream).
• Continuously send (pushing) or
• Asynchronously retrieve (based on a request).

t5
t4
t3
t2
t1
Old tuples
New tuples
5
Outline

• Aurora, Aurora-VLDB03
• Aurora, Medusa. Aurora-CIDR03
• STREAM, STREAM-CIDR03
• Telegraph, Tele-CIDR03
• Eddy, SteM, PSoup

6
Aurora
Aurora-VLDB02
7
Aurora Operators

• Windowed operators (group operators)
• Slide, (e.g., report count over last hour)
• Tumble, (e.g., report daily count)
• Latch, like Tumble, however maintain states
  between Tumble windows
• Resample, interpolate tuples between actual
  tuples of an input stream
• Filter (e.g., report tuples with input value gt 5)
• Drop (e.g., drop an input tuple every 10 tuples)
• Map (e.g., get the square of every input tuple)
• GroupBy (e.g., categorize stream reading by
  location value)
• Join (e.g., find similar values in two input data
  streams in the last 30 minutes)

8
Aurora Query Model
Aurora-VLDB02
9
Aurora Run-time Architecture

• Train scheduler
• ( a set of heuristics to minimize trips to disk
  and reduces processing time per box)
• Load Shedding by dropping tuples or applying
  filters

Aurora-VLDB02
10
Aurora and Medusa

• Aurora Intra-participant Distribution
• Multiple Aurora nodes each execute sub-query (sub
  network), single administrative control for load
  balancing and dynamic reconfiguration.
• Medusa Inter-participant Federated Operation
• Provides service delivery among multiple
  participant. A single participant may be
  configured as Aurora architectures.
• Further reference, Aurora-CIDR03

11
STREAM

• Centralized system (similar to Aurora).
• Carries much similarity with Aurora system.
• Current published work is distinguished by
  providing new Query definition and semantic over
  data streams.

12
Query Syntax

• Modified SQL language, Continuous Query Language
  (CQL).
• A stream in the From clause may be followed by an
  optional sliding window specification, enclosed
  in brackets, and an optional sampling clause.
• A window specification consists of an optional
  partitioning clause, a mandatory window size, and
  an optional filtering predicate.
• Example
• Select Count()
• From Requests S Partition By S.client_id Rows 10
  Preceding Where S.domain stanford.edu Sample
  (10)
• Where S.URL Like http//cs.stanford.edu/
• A similar query without sample clause appears in
  STREAM-CIDR03

13
Query Semantic
STREAM-CIDR02
14
Telegraph

• Emphasize on execution model for continuous
  queries over data streams
• Introduces Eddy, SteM, Psoup,
• Integrating the above technologies in a dataflow
  processing system using

15
Eddy SteM
Tele-CIDR03

• Adaptive routing and processing using eddies and
  SteM.
• Eddy routes tuples to next operator. Each SteM
  acts as half join in traditional join operators.

16
PSoup
Tele-CIDR03
17
Related Work

• Aurora-CIDR03 M. Cherniack, H. Balakrishnan,
  M. Balazinska, D. Carney, U. Cetintemel, Y. Xing,
  S. Zdonik. Scalable Distributed Stream
  Processing. In proceedings of the First Biennial
  Conference on Innovative Database Systems
  (CIDR'03), Asilomar, CA, January 2003.
• Aurora-VLDB02 D. Carney, U. Cetintemel, M.
  Cherniack, C. Convey, S. Lee, G. Seidman, M.
  Stonebraker, N. Tatbul, S. Zdonik. Monitoring
  Streams A New Class of Data Management
  Applications. In proceedings of the 28th
  International Conference on Very Large Data Bases
  (VLDB'02), August 20-23, Hong Kong, China.
• Tele-CIDR03 TelegraphCQ Continuous Dataflow
  Processing for an Uncertain World. Sirish
  Chandrasekaran, Owen Cooper, Amol Deshpande,
  Michael J. Franklin, Joseph M. Hellerstein, Wei
  Hong, Sailesh Krishnamurthy, Samuel R. Madden,
  Vijayshankar Raman, Fred Reiss, and Mehul A.
  Shah, 1st CIDR Conf., Jan 2003, Asilomar, CA.
• STREAM-CIDR03 R. Motwani, J. Widom, A. Arasu,
  B. Babcock, S. Babu, M. Datar, G. Manku, C.
  Olston, J. Rosenstein, and R. Varma. Query
  Processing, Resource Management, and
  Approximation in a Data Stream Management System.
  In Proc. of the 2003 Conference on Innovative
  Data Systems Research (CIDR), January 2003.
