The performance of NAMD on a large Power4 system

• Joachim Hein
• EPCC, The University of Edinburgh

2
Measurement based load balancing

• NAMD measures its performance for the first 200
  steps
• Redistributes the work load to optimise the
  performance
• Performance benefit for larger number of
  processors
• Benchmark time Better estimate for production
  jobs from short jobs

3
Measurement based load balancing
4
Loadbalance

• Example
• 128 CPUs
• 96769 atoms
• 32000 iters
• All but one CPUs in a narrow Window
• Effect of slow guy negligible

5
MP_EAGER_LIMIT

• Environment variable MP_EAGER_LIMIT changes the
  behaviour of MPI
• Messages smaller than MP_EAGER_LIMIT are send
  instantaneous
• Messages larger than MP_EAGER_LIMIT are send
  using hand-shake
• Default value is small and not optimal for NAMD

Tune it!
6
MP_EAGER_LIMIT
7
Sample loadleveler script

• _at_ shell /bin/ksh
• _at_ job_type parallel
• _at_ network.MPI csss,shared,us
• _at_ account_no z001
• _at_ output namd_run.(schedd_host)_(jobid).out
• _at_ error namd_run.(schedd_host)_(jobid).err
• _at_ wall_clock_limit 003000
• _at_ node 1
• _at_ tasks_per_node 8
• _at_ queue
• export MP_SHARED_MEMORYyes
• export MP_EAGER_LIMIT65536
• poe path/namd2 inputfile

8
Benchmark

• Joint Amber Charm (JAC) Benchmark
• Dihydrofolate reductase in water, 23558 atoms
• www.scripps.edu/brooks/Benchmarks
• Apo A-1 benchmark
• Apolipoprotein A-1, 92224 atoms
• www.ks.uiuc.edu/Research/apoa1
• TCR peptide-MHC
• 96796 atoms
• www.hpcx.ac.uk/about/newsletter/HPCxNews02.pdf
• F1-ATP synthase
• F1 subunit of ATP synthase, 327506 atoms
• www.sc-2002.org/paperpdfs/pap.pap277.pdf

9
The HPCx system

• Presently
• 40 IBM p690 Regata H frames
• 32 POWER4 processors per frame (1.3 GHz)
• Frames subdivided into LPARs of 8 processors
• 8 GB of main memory per LPAR
• IBM SP Switch2 (Colony) network
• 2 switch adapters per LPAR
• Dual plane
• Future (Summer 2004)
• Upgrade to p690 frames (1.7 GHz)
• LPARs of 32 processors
• IBM HPS (Federation) network

10
Time per step for 32 processors
Benchmark NAMD 2.4 NAMD 2.5 Comment
dhf reductase 23558 atoms 0.051s 0.032s Too small for 32 cpus
APO A-1 92224 atoms 0.28s 0.19s
TCR MHC 96796 atoms 0.30s 0.21s
F1-ATP 327506 atoms 0.58s

• NAMD 2.5 substantially faster than NAMD 2.4

11
Large number of processors
12
Further Reading

• Full technical report
• The performance of NAMD on HPCx
• Joachim Hein
• www.hpcx.ac.uk/research/hpc/technical_reports/HPCx
  TR0310.pdf
