Complex Waves

1
Complex Waves

• Just like simple waves, only more complex! ?

2
Simple and Complex Waves
Types of Vibration
Simple
Complex

• Periodic (repeats)
• Single frequency
• Sounds like a pure tone (definite identifiable
  pitch)

• Periodic or Aperiodic
• Multiple frequencies
• May sound tonal or not

3
Simple and Complex Waves
Types of Vibration
Simple
Complex
Periodic (harmonic)
Aperiodic (inharmonic)
Quasi- periodic
Periodic (harmonic)
A complex aperiodic sound is one whose component
frequencies occur randomly across some frequency
range
A complex periodic sound is one whose component
frequencies are integer multiples of the lowest
frequency of vibration
4
Ohms Law of Acoustics

• All complex sounds can be broken down into their
  pure tone components

5
(No Transcript)
6
Analogue vs Digital

• Advantages of Digital
• Making copies
• Flexibility
• Disadvantages of Digital
• Speed
• Economy (?)

7
Analogue vs Digital

• Analogue continuous in time and amplitude

1
in msecs
0
5.0
31.25
4.6
amplitude
0
62.5
3.5
93.75
-1
time
125
8
Analogue vs Digital

• Digital discrete in time and amplitude

1
in msecs
0
5.0
31.25
4.6
amplitude
0
62.5
3.5
93.75
-1
time
125
9
Terms/Definitions

• Fundamental Frequency (f0) lowest frequency
  pure tone component present in a complex periodic
  sound
• Harmonic (hn) integer multiple of f0
• Partial any pure tone component of a complex
  sound
• Overtone all partials above f0
• Octave successive doubling of frequency

10
Building a Complex Periodic Vibration
quasi-
/h1
f0
h2
500
h3
1000
h4
inharmonic
1500
h5
2000
3387
h6
2500
h7
3000
amplitude
h8
3500
4000
frequency
11
Fourier Transforms Application of Ohms Law of
Acoustics

• Fourier Analysis a complex waveform can be
  broken down (analyzed) into its pure tone
  components
• Fourier Synthesis a complex waveform can be
  formed (synthesized) by combining pure tone
  components

12
f0/h1
h5
FOURIERANALYSIS
h3
h7
13
Fast Fourier Transform (FFT)
FOURIERANALYSIS
14
f0/h1

h3

FOURIERSYNTHESIS

h5

h7
15
Effect of relative phase
FOURIERSYNTHESIS


Perfect summation
16
Effect of relative phase
FOURIERSYNTHESIS


Perfect cancellation
17
Effect of relative phase
FOURIERSYNTHESIS


Imperfect summation
18
Effect of relative phase




FOURIERSYNTHESIS


19
at t 0
1.0
f 2 Hz

0.33

f 6 Hz
FOURIERSYNTHESIS

0.33
f 10 Hz
0.33
1 sec
20
at t 100ms
1.0
2

0.33

FOURIERSYNTHESIS
amplitude
0

-2
0.33
-1.22
21
Modes of Vibration
