Title: Abstract Base Classes


1
Abstract Base Classes
  • Chapter 9

2
Objectives
  • Polymorphism
  • Abstract Base Classes
  • Virtual Functions

3
Base and Derived Pointers
vehicle
truck
car
motorcycle
  • Base class pointers can point to derived class
    objects
  • E.g., all trucks are vehicles, so a vehicle
    pointer can point to a truck.
  • Derived class pointers cannot point to base class
    objects
  • Not all vehicles are trucks, so a truck pointer
    cannot point to a vehicle.

4
Base and Derived Pointers
class truck public vehicle protected int
capacity class car public vehicle
protected int numPassengers class
bicycle public vehicle protected int
serialNum
class vehicle protected char type50
5
Base and Derived Pointers 2
void main() vehicle v bicycle b
truck t new truck() v t // b v
(WRONG) car c new car() v new
bicycle() delete t delete c delete
v
6
Polymorphism
  • Method to allow programs to generically process
    objects
  • Dont have to know all about derived classes in
    advance
  • Good for modular reusable code
  • Generic linked lists, a queue of different types
    of people, etc.

7
Object Polymorphism
  • A method expecting a Car object can only accept
    Car objects
  • A method expecting Vehicle objects can accept any
    object derived from the Vehicle class
  • Car
  • Truck
  • Bus
  • Theres also function polymorphism

8
Polymorphism 2
  • Normally, when an object or pointer to an object
    calls a function, it does so statically
  • I.e., determined at compile time
  • Another way is to allow for it to be DYNAMIC, and
    determined at run-time
  • This allows you to treat objects generically,
    provided they have the same interface
  • This is called polymorphism

9
Virtual Functions
  • How do we do this? Base classes with virtual
    functions.
  • When a virtual function is called, the computer
    determines at runtime the appropriate derived
    function to execute.
  • The base class has the virtual functions
  • New derived classes can be added that implement
    their own versions of these functions
  • Override the base virtual functions in derived
    classes!

10
Virtual Functions Example
class student public person protected int
studentID public student(int id) void
print() class teacher public person
protected int deptID public
teacher(int d) void print()
class person protected char name char
phone public person(char n, char p)
virtual void print()
11
Virtual Functions Example 2
void personprint() cout ltlt name ltlt ltlt
phone ltlt endl void studentprint() cout
ltlt Student ltlt endl cout ltlt ID ltlt
studentID ltlt endl cout ltlt name ltlt endl ltlt
phone ltlt endl void teacherprint() cout
ltlt Teacher ltlt endl cout ltlt Dept ltlt
deptID ltlt endl cout ltlt name ltlt endl ltlt phone
ltlt endl
12
Virtual Functions Example 3
void main() int x person array new
person3 array0 new student(Joe,
555-1234, 3976) array1 new
teacher(Daisy, 555-8909, 203) array2
new person(Mandy, 555-3782) for (x 0
x lt 3 x) arrayx-gtprint()
13
More Virtual Functions
  • Without virtual functions, only the base class
    print() function would be called
  • This is because all the pointers are of the base
    type
  • WITH virtual functions, the correct print
    function is called for each member of the array
  • array0-gtprint() calls studentprint()
  • array1-gtprint() calls teacherprint()
  • array2-gtprint() calls personprint()

14
What does this mean?
  • It means that you dont necessarily have to know
    the EXACT type of the object youre dealing with
  • You only have to know its base type
  • Base classes base class interfaces written by
    someone else long ago can work with new classes
    you write

15
Abstract Base Classes
  • Sometimes you will NEVER WANT TO instantiate an
    object of the base class.
  • E.g., doesnt make sense to make a shape object
  • Only a square object, a circle object, or some
    other derived object actually makes sense
  • Can make the class abstract so that future
    programmers cannot create a base class object
    either

16
Pure Virtual Functions
  • How do you make a base class abstract?
  • Make at least one of its member functions PURE
    VIRTUAL
  • Functions should be pure virtual if information
    is needed from the derived class for any valid
    implementation
  • a shapes area function depends on what type of
    shape it is

17
Pure Virtual Functions 2
  • Pure virtual functions are defined in the class
    declaration by
  • So for the shape area function example, wed have
    in the shape class
  • There is NO IMPLEMENTATION of pure virtual
    functions in the base class, just the declaration

virtual returnType functionName(arglist) const
0
virtual float area() const 0
18
Virtual Destructors
  • Why should destructors be virtual if a base class
    has any virtual functions?
  • Derived objects will likely be accessed by base
    pointers
  • If you delete a base pointer without a virtual
    destructor, it will only call the base
    destructor
  • If virtual, however, it will call the correct
    derived destructor, then the base destructor

19
Example
  • include ltiostream.hgt
  • class base
  • public
  • virtual void vfunc() coutltltThis is the base
    vfunc().\n
  • class derived1 public base
  • public
  • virtual void vfunc() coutltltThis is a derived
    function\n
  • class derived2 public base
  • public
  • virtual void vfunc() coutltltSo is this
    one.\n

20
Example in Action
  • int main()
  • base p
  • base b
  • derived1 d1
  • derived2 d2
  • pb
  • p-gtvfunc()
  • pd1
  • p-gtvfunc()
  • pd2
  • p-gtvfunc()

A pointer to the parent class
OUTPUT This is a base vfunc(). This is a
derived function. So is this one.
21
END
  • End of presentation

22
Other Examples of Polymorphism
  • Queue of jobs to do
  • Homework
  • Cleaning
  • Cooking
  • Linked list of classes
  • Lectures
  • Labs
  • Discussion sections

23
1. Virtual Functions
  • A virtual function is a member function that is
    declared within a base class and redefined by a
    derived class.
  • Its looks just like a normal function but has the
    keyword virtual preceding it.
  • So the virtual function defines the form of the
    interface.
  • The derived class redefines it and implements its
    operation as it relates specifically to it.

24
Why Virtual Functions are Useful
  • So you can just use virtual functions as you
    would any other function.
  • However what makes them so implortant is how they
    behave when accessed by a pointer.
  • When a base-class pointer points to a derived
    object that contains a virtual function, C
    decides which version of that function to call
    based on the type of object pointed to.
  • This is all processed at run-time.

25
Abstract Classes
  • A class that contains at least one pure virtual
    function is said to be abstract it has a
    virtual function in it that has no definition at
    all.
  • Because of this, no objects of the abstract class
    can be created.
  • It is an incomplete type a foundation for
    derived classes.
  • However you can still create a pointer to an
    abstract class.

26
Polymorphism
  • An object can take many forms.
  • Method overloading is one type of polymorphism.
  • Object polymorphism treats specialized objects as
    if they are instances of a more general type.

27
Factoring to the Base Class
  • Factor common characteristics of multiple
    classes up into a base class.
  • HWall and VWall classes have similar
    characteristics and methods.
  • Factor commonalities to a Wall class
  • Override some methods to specialize the HWall and
    VWall classes

28
Abstract Base Classes
  • The classes describe what all derived classes
    have in common.
  • Not instantiated (causes an exception)
  • Use the abstract keyword when defining abstract
    base classes and methods

29
Abstract Methods
  • Abstract methods are not implemented.
  • Derived classes must provide method
    implementation.
