Title: Data Grids Data Intensive Computing


1
Data Grids Data Intensive Computing
2
Simplistically
  • Data Grids
  • Large number of users
  • Large volume of data
  • Large computational task involved
  • Connecting resources through a network

3
Grid
  • Term Grid borrowed from electrical grid
  • Users obtains computing power through Internet by
    using Grid just like electrical power from any
    wall socket

4
Data Grid
  • By connecting to a Grid, can get
  • needed computing power
  • storage spaces and data
  • Specialized equipment
  • Each user - a single login account to access all
    resources
  • Resources - owned by diverse organizations
    Virtual Organization

5
Data Grids
  • Data
  • Measured in terabytes and soon petabytes
  • Also geographically distributed
  • Researchers
  • Access and analyze data
  • Sophisticated, computationally expensive
  • Geographically distributed
  • Queries
  • Require management of caches, data transfer over
    WANs,
  • Schedule data transfer and computation
  • Performance estimates to select replicas

6
Data Grids
  • Domains as diverse as
  • Global climate change
  • High energy physics
  • Computational genomics
  • Biomedical applications
  • http//www.gridstart.org/links.shtml

7
Data Grids
  • Data grid differs from
  • Cluster computing grid is more than homogeneous
    sites connected by LAN (grid can be multiple
    clusters)
  • Distributed system grid is more than
    distributing the load of a program across two or
    more processes
  • Parallel computing grid is more than a single
    task on multiple machines
  • Data grid is
  • heterogeneous, geographically distributed,
    independent site
  • Gridware manages the resources for Grids

8
Methods of Grid Computing
  • Distributed Supercomputing
  • Tackle problems that cannot be solved on a single
    system
  • High-Throughput Computing
  • goal of putting unused processor cycles to work
    on loosely coupled, independent tasks (SETI
    Search for Extraterrestrial Intelligence)
  • On-Demand Computing
  • short-term requirements for resources that are
    not locally accessible, real-time demands

9
Methods of Grid Computing
  • Data-Intensive Computing
  • Synthesize new information from data that is
    maintained in geographically distributed
    repositories, databases, etc.
  • Collaborative Computing
  • enabling and enhancing human-to-human
    interactions

10
An Illustrative Example
  • NASA research scientist
  • collected microbiological samples in the
    tidewaters around Wallops Island, Virginia.
  • Needs
  • high-performance microscope at National Center
    for Microscopy and Imaging Research (NCMIR),
    University of California, San Diego.

11
Example (continued)
  • Samples sent to San Diego and used NPACIs
    Telescience Grid and NASAs Information Power
    Grid (IPG) to view and control the output of the
    microscope from her desk on Wallops Island.
  • Viewed the samples, and move platform holding
    them, making adjustments to the microscope.

12
Example (continued)
  • The microscope produced a huge dataset of images
  • This dataset was stored using a storage resource
    broker on NASAs IPG
  • Scientist was able to run algorithms on this very
    dataset while watching the results in real time

13
Grid topology
Grid Topology
14
Higher level services
  • Replica selection
  • Choosing specific replica to optimize
    performance, cost, security
  • Grid info services provide info about network,
    metadata provide info about size of file
  • Determine replica with fastest access and/or
    determine of replicate will result in better
    access
  • Subsets of files

15
Scheduling and Replication in Data-Intensive
Computing
  • Ming Lei, PhD student
  • Department of Computer Science
  • University of Alabama

16
Introduction
  • Early work in data replication focused on
    decreasing access latency and network bandwidth
  • As bandwidth and computing capacity become
    cheaper, data access latency can drop
  • How to improve availability and reliability
    becomes the focus
  • Due to dynamic nature of Grid user/system,
    difficult to make replica decisions to meet
    system availability goal
  • Usually assumed unlimited storage

17
Introduction
  • Related work
  • Economical model replica decision based on
    auction protocol Carman, Zini, et al. e.g.,
    replicate if used in future, unlimited storage
  • Hotzone places replicas so client-to-replica
    latency minimized Szymaniak et al.
  • Replica strategies dynamic, shortest
    turnaround, least relative load Tang et al.
    consider only LRU
  • Multi-tiered Grid Simple Bottom Up and
    Aggregate Bottom Up Tang et al.
  • Replicate fragments of files, block mapping
    procedure for direct user access ChangChen

18
Sliding Window Replica Scheme
  • Alternative to future prediction which can
    overemphasize future accesses times when queue is
    long
  • Following example based on future access times

19
Figure 2. Without Replica File 4
Figure 3. Replica File 5
20
Sliding window replica protocol
  • Build sliding window set of times used
    immediately in the future
  • Size bound by size of local SE
  • Includes all files current job will access and
    distinct files from next arriving jobs
  • Sliding window slides forward one more file each
    time system finishes processing a file
  • Sliding window dynamic

21
Sliding window replica protocol
  • Sum of size of all files lt size of SE
  • No duplicate files in sliding window

22
(No Transcript)
23
OptorSim
  • Evaluate the performance of our replica and
    replacement strategy
  • Using OptorSim
  • OptorSim developed by the EU DataGrid Project to
    test dynamic replica schemes

24
Simulation results
  • Assume OptorSim topology
  • 10,000 jobs in Grid
  • Each job accesses 3-10 files
  • Storage available 100M-10G
  • File size 0.5-1.5 G
  • Compare replica strategies
  • LRU, LFU, EcoBio, EcoZipf, No Prediction, Sliding
    Window

25
Measurements
  • Measurements
  • Total Running time

26
Eco model
  • Compare to Economical Model in OptorSim
  • Eco
  • File replicated if maximizes profit if SE (e.g.
    what is earned over time based on predicted
    number of file requests)
  • Eco prediction functions
  • EcoBio
  • EcoZipf
  • Queue Prediction
  • No Prediction

27
Prediction Functions
  • Prediction via four kinds of prediction
    functions
  • Bio Prediction binomial distribution is used to
    predict a value based on file access history
  • Zipf Prediction Zipf distribution is used to
    predict a value based on file access history
  • Queue Prediction The current job queue is used
    to predict a value of the file
  • No Prediction No predictions of the file are
    made, the value will always be 1

28
Access Patterns
  • Consider 4 access patterns
  • Random
  • Random Walk Gaussian
  • Sequential
  • Random Walk Zipf

29
Running Time
  • First, study sliding window without RDAE
  • Measure running time

30
Figure 7. Running Time with Varying File
Accessing Pattern.
31
Sliding Window
  • Sliding window replica scheme always best
    turnaround time
  • No replication, EcoBio the worst
  • LFU second best

32
Figure 8. Impact of network bandwidth
33
Sliding Window
  • Higher the bandwidth, shorter system performance
  • Sliding window replica always the best
  • EcoZipf, EcoBio perform almost same as no
    prediction

34
Switch Time
  • Impact of switch time

35
Figure 10. Impact of varying the job switch time
36
Switch Time
  • Longer the switch time, the longer the total
    running time
  • Sliding window the best
  • LRU, LFU second best
  • Improvement provided by sliding window over LRU,
    LFU greatest for smaller switch times
  • Improvement provided by sliding window over
    EcoBio, EcoZipf greatest remains high for higher
    switch times

37
Varying Schedulers
  • Impact of varying schedulers

38
Figure 11. Running Time with Varying Schedulers
39
Conclusions and Future work
  • File bundle situation
  • Preferential treatment of smaller size files
  • Green Grids

40
Power Aware
  • Info from Pate, et al., 2002
  • Data center with 1000 racks, 25,000 square feet
    require 10 MW of power.
  • Also requires 5 MW to dissipate the heat
  • At 100/MWh, 4M per year
  • Average utilization of 20 and 80 for peak loads
  • This means 80 of resources not utilized, yet
    generating heat, consuming power

41
Power Aware
  • Green Grid group of IT professionals
  • Power Usage Effectiveness PUE
  • Total facility power/IT equipment power
  • Data Center infrastructure Efficiency metric CDiE
  • 1/PUE

42
Power Aware
  • Computer Dec. 2007 devoted to green computing
  • Servers
  • Seek high energy efficiency at peak performance
  • In sleep consume near-zero energy
  • But
  • Servers rarely completely idle, seldom operate
    near maximum utilization
  • Operate at 10 to 50 of maximum utilization

43
Power Aware
  • Mismatch between server energy efficiency and
    behavior of server class workloads
  • Need energy proportional machines to exhibit wide
    dynamic power range

44
What can be done to achieve energy proportional
behavior
  • Server power (Google) peak vs. idle
  • CPU smaller and smaller fraction of total power
    when system idle
  • Processors close to energy proportional behavior
  • Desktop and server processors can consume less
    than 1/3 of their peak power at low activity
    modes can achieve 1/10 or less
  • Dynamic power range of other components much
    narrower
  • Lower voltage processor frequency mode good
    because not much impact on overall performance
  • Networking equipment doesnt offer low power
    modes
  • Need improvements in memory and disk systems

45
Future Wwork - Power Aware
  • Ways to conserve energy
  • Power down CPU
  • Slow down CPU
  • Power down storage disks energy to power up
  • Store less data

46
Future Work
  • With Dr. John Lusth
  • Build a green grid (with lower energy mother
    boards)
  • Hardware purchased, put together
  • Implement some power saving strategies
  • Run benchmarks (e.g. computations, queries)
  • Compare to existing grid at Arkansas
  • DESIGN NEW STRATEGIES
